User assigned EDID Mode — Using SIS commands, an EDID file can be selected from a
table of 19 EDID files. One additional EDID file location is reserved for user-loaded EDID files
for the VGA and DVI groups. Once a user assigned EDID is chosen, the switcher stores it at
the inputs and no longer polls for the EDID of a connected display. the chart below lists the
native resolution of each factory EDID file and timing characteristics associated with each.
If the display connected to the VGA output of the switcher does not support DDC, or the
switcher does not obtain EDID from the output, the default resolution (2) is used.

HDCP

the DVI and HDMI groups are HDCP compliant. When EDID Minder is enabled, (default),
HDCP is not supported on the DVI inputs.
HDCP communication occurs between the selected input source and the output device
directly (pass-though).
EDID Resolution Table
EDID Native Resolution
0 Automatic Mode
1 800 x 600
2 1024 x 768
3 1280 x 768
4 1280 x 800
5 1280 x 1024
6 1360 x 768
7 1440 x 900
8 1400 x 1050
9 1680 x 1050
10 1600 x 1200
11 1920 x 1200
12 720p, basic audio
13 720p, basic audio
14 720p, full audio
15 720p, full audio
16 1080p, basic audio
17 1080p, basic audio
18 1080p, full audio
19 1080p, full audio
20 User loaded
NOTE: Basic Audio supports: 2-Ch PCM audio
Full Audio supports: 2-Ch PCM, 8-Ch PCM, 8-Ch AC-3, 8-Ch DtS,
8-Ch DD+, 8-Ch DtS-HD, & 8-Ch Dolby trueHD
NOTE: Basic audio = 2-channel PCM audio
Full audio = support for various digital encoding formats and
up to 8-channel audio
Refresh Pixel Clock
60 Hz 40 MHz
60 Hz 65 MHz
60 Hz 79.5 MHz
60 Hz 83.5 MHz
60 Hz 108 MHz
60 Hz 85.5 MHz
60 Hz 106.5 MHz
60 Hz 121.75 MHz
60 Hz 119 MHz
60 Hz 162 MHz
60 Hz 154 MHz
50 Hz 74.25 MHz
60 Hz 74.25 MHz
50 Hz 74.25 MHz
60 Hz 74.25 MHz
50 Hz 148.5 MHz
60 Hz 148.5 MHz
50 Hz 148.5 MHz
60 Hz 148.5 MHz
MPS 409 • Operation 19
