- Page 1 Grow and Roll Glass Boards Part Number: 84426-XXXX, 84425-XXXX ASSEMBLY INSTRUCTIONS INSTRUCCIONES DE ENSEMBLAJE INSTRUCTIONS DE MONTAGE DO NOT THROW AWAY! NO LA TIRE NE PAS JETER UPDATED AS OF: 04/07/2020 1 of 7...
- Page 2 Parts Hardware P1 - Glass Board A - M6 x 12mm B - M6 x 35mm P2 - Upright C - Locking Caster P3 - Board Rest D - Non-Locking (Pre-installed in P4) Caster E - Lock Washer P4 - Bottom Crossbar P5 - Crossbar P6 - Top Panel...
- Page 3 OVERVIEW Tools Included: UPDATED AS OF: 04/07/2020 3 of 7...
- Page 4 WARNINGS AND DISCLAIMERS ADVERTENCIAS Y RENUNCIAS AVERTISSEMENTS Review full assembly instructions and Previo a comenzar el proceso de Avant de commencer l’ assamblage check that all parts are present before ensamblaje favor revisar veuillez consulter instructions beginning assembly. Heavy or large instrucciones y asegurarse que cuenta con complètes et vérifier si vous avez toutes furniture may require multiple persons in...
- Page 5 STEP 1 Repeat for both Uprights STEP 2 Screw holes should face up Remove MDF protective strips from Bottom Crossbar UPDATED AS OF: 04/07/2020 5 of 7...
- Page 6 STEP 3 Use longer screws (B) only for Bottom Crossbar to screw into Upright feet STEP 4 Insert bottom edge of board in Board Rest then rotate up Peel adhesive backing from strips on one side of frame to frame and press into adhesive Repeat step for second board on opposite side UPDATED AS OF: 04/07/2020 6 of 7...
- Page 7 STEP 5 THIS COMPLETES ASSEMBLY INSTRUCTION UPDATED AS OF: 04/07/2020 7 of 7...
