Installation Guide
For Model:
FRM52
E192641
net weight of fan: 18.26 lb. (8.3 kg)
READ THESE INSTRUCTIONS
AND SAVE THEM FOR FUTURE USE

Table of Contents:

Warranty. pg. 13
page 1
PRINTED IN CHINA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Forum FRM52 and is the answer not in the manual?

Questions and answers

Related Manuals for Craftmade Forum FRM52

Summary of Contents for Craftmade Forum FRM52

  • Page 1: Table Of Contents

    READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Forum Installation Guide For Model: FRM52 Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 Hanging Bracket Installation. pg. 4 Fan Assembly.

  • Page 2: Safety Tips

    (2) this remote and wall control must accept any interference received, including interference that may cause undesired operation. Distributed by: Craftmade, 650 S. Royal Lane, Coppell, TX, 75019; 1-800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.

  • Page 3: Unpacking Your Fan

    1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. Check against parts inventory that all parts have been included.

  • Page 4: Installation Preparation

    blade edge 3. Installation Preparation. 7 feet inches To prevent personal injury and damage, ensure (2.13 m) (76 cm) that the hanging location allows the blades a clearance of 7 feet (2.13m) from the floor and 30 in (76cm) from any wall or obstruction. 12 ft.

  • Page 5: Fan Assembly. Pgs

    stop pin 5. Fan Assembly. set screw Remove hanging ball from downrod provided by hanging ball loosening set screw on hanging ball. Lower hanging ball and remove stop pin and then slide hanging ball off of the downrod. [Refer to diagram 1.] diagram 1 Loosen yoke set screws and nuts at top of motor housing.

  • Page 6: Wiring. Pgs

    5. Fan Assembly. (cont.) safety cable loop wood ceiling With the hanging bracket secured to the outlet box joist and able to support the fan, you are now ready to wood screw hang your fan. Grab the fan firmly with two hands. and washer Slide downrod through opening in hanging bracket and let hanging ball rest on the hanging bracket.

  • Page 7: Canopy Assembly

    6. Wiring. (cont.) [PLEASE NOTE: Wall and/or handheld remote control must be used for fan to operate. If you do wall not wish to use the wall control, please proceed to outlet box control Section 7 to continue with fan installation.] To install wall control, remove existing wall dimmer switch.

  • Page 8: Blade Assembly

    8. Blade Assembly. WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to assemble the blades. If overtightened, blades may crack and break. motor housing Locate 15 blade attachment screws/washers in hardware pack. Hold blade arm up to blade and align holes.

  • Page 9: Switch Housing Plate Assembly

    9. Switch Housing Plate Assembly. Remove 4 screws from outer edge of fitter plate (save screws for later use). motor housing Remove 1 screw from motor plate on underside of motor assembly and partially loosen the other 2 screws. Align slotted holes in center of fitter plate with loosened screws in motor plate, allowing molex connections from motor housing to come through hole in...

  • Page 10: Handheld Remote Control Assembly

    10. Handheld Remote Control Assembly. IN ORDER TO USE THE HANDHELD REMOTE CONTROL, PLEASE CONTINUE WITH SECTION 10 for remote control remote assembly instructions. If you have already installed the wall control control but do not wish to use the handheld remote control, cover please proceed to Section 11.

  • Page 11: Automated Learning Process./Activating Code

    11. Automated Learning Process./Activating Code. CAUTION: The wall and/or handheld remote control can be programmed to multiple receivers or fans. If this is not desired, turn wall switch off to any other programmable receiver or fan. Restore electrical power and then, if using wall control, set slider switch on wall control to the ON position. Within 60 seconds of turning on the wall control, press and hold the fan OFF button on the wall control for 5 seconds or until light blinks twice.

  • Page 12: Smart Wifi Remote Control (Optional)

    To enjoy all the potential of your new device, you will need to download the Craftmade app, available on the Google Play Store and Apple App Store, or use the QR code to download the app if you have not already done so.

  • Page 13: Troubleshooting

    Service at 1-800-486-4892 to arrange for return of fan. 1. Check power to wall switch/wall control. Return fan, shipping prepaid, to Craftmade. We will repair 2. Verify that reverse switch is set completely in or ship you a replacement fan, and we will pay the return either direction.
