INSTRUCTIONS FOR 540ESC, 540ESSC, 540ESCM6 DIE GRINDERS
Read and understand "Safety Instructions For Air Tools" and these instructions before

AIR SUPPLY

The efficiency of the tool is dependent on the proper supply of clean dry air at 90 psig (6.2 bar). The use of a line filter, pressure regulator,
and lubricator will insure maximum output and life of tools. Before connecting tool, blow out the air line to remove water and dirt which may
have accumulated.

HOSE AND HOSE CONNECTIONS

Supply hose should be not less than 3/8" (10mm) I.D. Extension hoses should be at least 1/2" (13mm) I.D. Use couplings and fittings with at
least 3/8" (10mm) I.D.

LUBRICATION

Use SIOUX No. 288 air motor oil. An airline lubricator, set to deliver 2 to 3 drops per minute, is recommended. If a lubricator is not used, add
.08 oz. (2.4 cc, 24 to 30 drops) of oil into the air inlet every 2 to 3 hours.

GENERAL OPERATION

•
When using the tool in a vise or toolpost holder, use moderate pressure.
•
Refer to "Safety Guide for Sioux Abrasive Wheel" for abrasive wheel selection and safe operation.
We, Sioux Tools Inc., 250 Snap-on Drive, P.O. Box 1596, Murphy, NC, 28906, USA, declare under our sole responsibility that the products
to which this declaration relates are in conformity with the following standard or standards or other normative document or documents:
July 1, 2003
Murphy, North Carolina, USA
Date and place of issues
operating this tool.

INSTRUCTIONS FOR DIE GRINDERS

SOUND AND VIBRATION READINGS

*Sound Pressure
Catalog No.
dBA
540ESC
77.1
540ESSC
77.1
540ESCM6
77.1
*per PN8NTC1

DECLARATION OF CONFORMITY

540ESC, 540ESSC, 540ESCM6
EN 792 (draft), EN 292 Parts 1&2, ISO 8662, Pneurop PN8NTC1
following the provisions of
89/392/EEC as amended by 91/368/EEC & 93/44/EC Directives.
Gerald E. Seebeck
Sioux Tools Inc.
Name and position of issuer
*Sound Power
dBA
88.8
Less than 3.5
88.8
Less than 3.5
88.8
Less than 3.5
*per PN8NTC1
*per ISO 8662
President
1
Form ZCE674
Date 2003July29/C
Page 1 of 8
*Vibration
m/s
2
Signature of issuer
Printed In U.S.A.
