Carrier WeatherMaker 50TC Series Installation Instructions Manual

18-29 single package rooftop with cooling only horizontal airflow unit with puron (r-410a) refrigerant
Hide thumbs Also See for WeatherMaker 50TC Series:
Table of Contents

Advertisement

Quick Links

50TC units for installation in the United States contain use of Carrier's Staged Air Volume
(SAV™) 2-speed indoor fan control system. This complies with the U.S. Department of
Energy (DOE) efficiency standard of 2018.
50TC units for installation outside the United States may or may not contain use of the SAV
2-speed indoor fan control system as they are not required to comply with the U.S.
Department of Energy (DOE) efficiency standard of 2018.
For specific details on operation of the Carrier SAV 2-speed indoor fan system refer to the
Variable Frequency Drive (VFD) Factory-Installed Option 2-Speed Motor Control Installation,
Setup, and Troubleshooting manual.
CONTENTS
SAFETY CONSIDERATIONS . . . . . . . . . . . . . . . . . . . . 1
GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Rated Indoor Airflow (cfm) . . . . . . . . . . . . . . . . . . . . . 2
INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Job-Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 1 - Plan for Unit Location . . . . . . . . . . . . . . . . 16
Step 3 - Inspect Unit . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 4 - Provide Unit Support . . . . . . . . . . . . . . . . . 16
Step 5 - Rig and Place Unit . . . . . . . . . . . . . . . . . . . 21
Step 6 - Field Fabricate Ductwork . . . . . . . . . . . . . 21
Step 7 - Horizontal Duct Connection . . . . . . . . . . . 21
Option) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Electric Heaters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Catalog No. 04-53500263-01
Installation Instructions
Printed in U.S.A.
Form 50TC-18-29-H-03SI
WeatherMaker
Single Package Rooftop with Cooling Only
with Puron
Humidi-MiZer® Control Connections . . . . . . . . . . . .29
• CO2 SENSOR WIRING
Drive (Factory Option) . . . . . . . . . . . . . . . . . . . . . .44
PremierLink™ Control . . . . . . . . . . . . . . . . . . . . . . . .44
RTU Open Control System. . . . . . . . . . . . . . . . . . . . .44
Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Smoke Detectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
• ECONOMI$ER® IV OCCUPANCY SWITCH
Step 12 - Install Accessories . . . . . . . . . . . . . . . . . .57
Step 13 - Check Belt Tension . . . . . . . . . . . . . . . . .57
Pre-Start and Start-Up . . . . . . . . . . . . . . . . . . . . . . . .58
START-UP CHECKLIST . . . . . . . . . . . . . . . . . . . . .CL-1

SAFETY CONSIDERATIONS

Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components. Only
trained and qualified service personnel should install, repair, or
service air-conditioning equipment.
Pg 1
®
50TC 18-29
Horizontal Airflow Unit
®
(R-410A) Refrigerant
9-19
Replaces: 50TC-18-29-H-02SI
