HOW TO USE YOUR WASHER DRYER
Time Left / Time Delay
Cold
RPM Dry Time Cotton Wash Quick
Cotton Wash Express
Cotton Dry
Delicates Dry
Cold Wash
WOOL
Power Button
Push to turn power on or off.
Wash Program Knob
Use this knob to select Wash programs. Always
turn knob clockwise. Point the knob to the desired
program number.
Each program has a pre set spin speed and a
drying time. Once the program is selected watch
the display area to view details.
Dry time button
Press to select or choose drying time
Refer to the drying chart for help
Super Wash Button-(Lights Up when pushed)
When pressed in the cotton cycles of 1, 2, 3, 4
& 5 or in the synthetic cycles of 6, 7 & 8 the
wash time is increased by 20 minutes giving your
clothes an extra wash.
Pre Wash Button
When pressed the machine does a 104º F pre wash
as an additional cycle for 10 minutes. Use in
cotton cycles of 1, 2, 3, 4, 5, 6, 7, 8 & 16 only.
Start Button
Press to begin the cycle. Once your laundry is loaded
and your selections are complete, press the start button
to commence operation. Display panel lights up and
flashes two dots to indicate starting. Once pressed
the program is irreversible. To Modify, reset or edit
turn wash program to OFF position and start again.
Making It
WASH PROGRAM
OFF
Spin Heavy COTTON
Rinse Duty Super
Regular
Color
Gentle
Gentle Regular PRESS PERMANENT Power
Regular Regular Eco
Eco DELICATES Easy For You
Time Left / Time Delay
Rinse
Cold
Wash
Dry Time Cotton Quick
RPM
Wash
Cotton Express
Cotton Dry
Delicates Dry
Cold Wash
WOOL
Antiwrinkle Button
( Lights Up when pushed)
Press to obtain an anti wrinkle effect. Use in
cotton cycles of 1 to 10 and 16, 17 & 19. At
the end of the wash program the drum
performs a special operation creating a sponge
effect that re- arranges your delicate clothes
to avoid wrinkles. When pressed, spin speed
is restricted to 800 rpm and wash time
increases by 28 minutes.
Super Rinse Button
(Lights Up when pushed)
Do not press if your load is half or less. Press
if your load is large and you need an extra rinse.
When pressed wash time is increased by 10
minutes and water consumption goes up by
3.2 gallons.
Spin Button (Does not light up)
Each wash cycle is pre set at a defined spin
speed You can choose to increase or
decrease spin speed to suit your fabric.
Refer to the wash cycle chart and decide
on the spin speed. Press to increase.
Time Delay Button
(Seen on the display panel)
Delays the starting of the wash cycle.
Choose between 1 hr to 16 hrs. Allows you
flexibility and the freedom to begin laundry
at the time of your choosing. Each press
raises the time in increments of 1hr.
WASH PROGRAM
OFF
COTTON
Spin Heavy
Duty
Super
Regular
Color
Gentle
Regular
PERMANENT
Power
PRESS
Gentle
Eco
Regular Regular
Eco
DELICATES
220 V. 60Hz
