EdgeStar Model CW 2200 Use And Care Manual

Washer dryer combo

Hide thumbs Also See for Model CW 2200:

Reassembly manual (2 pages)

Parts list (16 pages)

Troubleshooting manual (3 pages)

Table of Contents

Quick Links

Troubleshooting

Need help?

Do you have a question about the Model CW 2200 and is the answer not in the manual?

Questions and answers

Summary of Contents for EdgeStar Model CW 2200

Page 1: Table Of Contents
Appliance Registration Model and Serial Numbers Safety Instructions Installation Instructions Water and Electrical Requirements Operating Guide Cycle Selection Detergent Guide Model CW 2200 A 220 Volt Product 461305725 Use and Care Guide WASHER DRYER COMBO COMBINADA LAVADORA SECADORA COMBINE LAVE-LINGE/SECHE-LINGE ELECTRONIC Care &...
Page 2: Appliance Registration
Help us Help You... Before using your washer dryer read this book carefully. It is intended to help you properly operate and maintain your new washer dryer. Keep it handy for answers to your questions. If you don’t understand something or need technical assistance, please contact: Technical Service and Support 101 3rd Street...
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance WARNING-- When using this appliance, always exercise basic safety precautions, including the following: Use this appliance only for its intended purpose, as you will find described in this Use and Care Guide. This washer dryer must be properly installed and located in accordance with installation instructions before it is used.
Page 4: Installation Instructions 4~7
Installation sheet Tools needed for Installation Parts supplied for installation. Inlet Water Hose - One Washers - Two Electrical Refer to serial plate for specific electrical requirements Water Washer dryer needs one standard 3/4 inch water supply faucet with a pressure between 30 to 120 pounds per square inch Cabinet Dimensions Width 23.62 inch...
Page 5 Installation sheet Proper installation is extremely important for your washer dryer to function correctly. When you first receive your washer dryer remove the box and packing material from the unit and inspect it carefully. If you find damage, immediately contact the delivery company and the company from which the unit was purchased.
Page 6 Installation Sheet STEP 3 Final Installation Check List 1. Instructions and other items have been removed from the tub. 2. Shipping bolts have been removed. 3. Washer dryer is plugged in to an electric outlet and is properly grounded. 4. Water hose is connected to the faucet with inlet screens and washers. 5.
Page 7 Installation sheet Plumbing Shipping Bolts Spacers Spacers Bolts Spacers Leveling A. Should be 36 inches maximum and 28 inches minimum. Plug and Wall Receptacle Page 7...
Page 8: Water And Electrical Requirements
Water and Electrical Requirements Electrical 220V, 60Hz 20/30 Amp fuse or circuit breaker We recommend a dedicated circuit meant only for the washer dryer. The washer dryer is equipped with a power cord and a four prong NEMA 14-30P plug. Never use an extension cord.
Page 9: Operating Guide 9~10
HOW TO USE YOUR WASHER DRYER Time Left / Time Delay WASH PROGRAM Spin Heavy COTTON Cold Rinse Duty Super Dry Time Cotton Wash Quick Regular Cotton Express Wash Color Cotton Gentle Delicates Gentle Regular PERMANENT PRESS Power Cold Wash Regular Regular WOOL...
Page 10 DISPLAY PANEL READINGS The display window / panel is divided in two parts - Upper and lower. The upper part displays the current ongoing operations. The lower part displays numbers to indicate cycle time, delay timer or spin speed. When Power button is pressed - When Wash Prog is selected When start button is pressed When drying time is selected...
Page 11: Cycle Selection 11~12
DRYING TIME GUIDE Dry time can depend on fabric type, wash cycle selected, room temperature, room moisture etc. Allow your Personal experience to guide the selection process. DRYING GROUND RULES 1. Do not tumble dry woolen clothes. 2. Avoid drying woven and loop knit materials. 3.
Page 12 Drying Options Choose your drying options from the table below to suit your personal preference. Fabric Cotton & Linen Cotton & 4.4 lbs Linen Synthetic & Delicate Synthetic & Delicate Page 12 Load 6 lbs 1200 1200 3.3 lbs 2.2 lbs Damp Dry Minutes Minutes...
Page 13: Detergent Guide
Detergent Guide How to choose and use the right detergent First, use only detergent specifically made for use in front load washers. Other types will cause over sudsing. Second, use only low sudsing powder or liquid detergent. Performance of this machine will be adversely effected if high suds detergents are used.
Page 14: Care & Cleaning
Care and Cleaning ! Unplug electric power cord before cleaning washer dryer to avoid shock. Cleaning the Exterior Use a soft damp cloth or sponge to wipe up any spills. Occasionally wipe the outside of your unit to keep it looking new. Cleaning the Interior The drum is made of stainless steel so it will no rust.
Page 15: Vacation & Winter Storage
Vacation & Winter Storage Install and store your washer/dryer where it will not freeze. Because some water may stay in the hoses and other parts and components, freezing can damage your washer dryer. If storing or moving your washer dryer during freezing weather, winterize it.
Page 16: Safety Features
Safety Features For the protection of your family and loved ones your washer dryer is equipped with many safety features. Child Safe Door An electromechanical safety device in the door prevents it from opening during operation. Door will not open until the unit is shut down and the power button is turned off. Washer Motor A thermal safety device protects the motor from overload or underload giving the motor long life.
Page 17: Fabric Care Symbols 17~18
Fabric Care Care Label Guide The following information is provided by U.S. Federal Trade Commission as part of Project Clean. The symbols appearing on garment labels provide care instructions from the garment manufacturer. These symbols seen on the fabric serve as minimum laundering instructions to indicate washing, bleaching, drying, ironing and dry cleaning.
Page 18 Fabric Care BLEACH Any Bleach (when needed) Only non-chlorine bleach (when needed) Warning: Do Not Bleach Normal Permanent Press/Wrinkle Resistant Gentle/Delicate Heat Setting: High Heat Setting: Medium Heat Setting: Low Special Instructions: Line Dry/Hang to Dry Special Instructions: Drip Dry Special Instructions: Dry Flat Special Instructions: Dry in Shade Warning: Do Not Dry...
Page 19: Troubleshooting Guide
Questions? Use This Troubleshooting Guide PROBLEM Washer won’t fill, rinse or drum will not turn Drum does not fill, but water is flowing Washer dryer stops Washer won’t drain Washer continues to fill or drain or the cycle seems stuck Washer makes noise POSSIBLE CAUSE AND REMEDY •...
Page 20: Troubleshooting Guide
• Did you press Rinse and Hold button? Is voltage correct? • Did you sort your laundry properly? • Did you overload the washer/dryer? Lint can be trapped in the load if overloaded. Wash smaller loads. • Was paper or tissue left in the pockets? •...
Page 21 Troubleshooting Guide PROBLEM Load is tangled or twisted Fabric damage Washer does not dry Door does not open To receive more information call toll-free 1.866.517.7827 POSSIBLE CAUSE AND REMEDY • Did you overload drum? Loads should move freely during washing. •...
Page 22 Notes Page 22...
Page 23: Warranty
WARRANTY This EdgeStar product is warranted to be free from defective workmanship and materials for the first year following the date of original purchase. Replacement parts will be supplied free of charge for the first year following the date of original purchase. Labor will be performed free of charge for the first 90 days following the date of original purchase.
Page 24 DESCRIPTION OF WARRANTY SERVICE: All defective product components covered by this warranty will be repaired or replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s authorized repair facility during the first 90 days from the date of original purchase.
