Use and Care Guide
WASHER DRYER COMBO
COMBINADA LAVADORA SECADORA
COMBINE LAVE-LINGE/SECHE-LINGE
Technical Services and Support
Call Center
For service call: 1.866.517.7827
14
15
16
17~18
19~21
Backcover
WASH PROGRAM
DRYER TIME
OFF
OFF
Max
EXTRA RINSE RINSE HOLD
NO SPIN
SPIN SPEED
POWER
110
WOOL
COTTON
Spin
17
1
Prewash
2 3
Super
30
100
16
4
5
Regular
15
40
Dry
550 RPM
90
Spin
Rinse
6
1200 RPM
14
50
80
Rinse
13
DOOR LOCK
60
70
104
86
122
Express
LIGHT
12
WASH TEMP
Gentle
11
10
7
MEDIUM
Regular
9
8
Spin
Pre-Wash
Dry
OFF
PERMANENT
PRESS
Max.
140
HOT
UL HARMONIZED
Advertisement
Table of Contents
Related Manuals for EdgeStar CW1200
Summary of Contents for EdgeStar CW1200
-
Page 1: Table Of Contents
Appliance Registration Model and Serial Numbers Safety Instructions Installation Instructions Water and Electrical Requirements Operating Guide Cycle Selection Detergent Guide Model CW1200 A 110 Volt Product 461305597 Use and Care Guide WASHER DRYER COMBO COMBINADA LAVADORA SECADORA COMBINE LAVE-LINGE/SECHE-LINGE 9~10 11~12 Care &... -
Page 2: Appliance Registration
Help us Help You... Before using your washer dryer read this book carefully. It is intended to help you properly operate and maintain your new washer dryer. Keep it handy for answers to your questions. If you don’t understand something or need technical assistance, please contact: Technical Service and Support 101 3rd Street... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read all instructions before using this appliance WARNING-- When using this appliance, always exercise basic safety precautions, including the following: Use this appliance only for its intended purpose, as you will find described in this Use and Care Guide. This washer dryer must be properly installed and located in accordance with installation instructions before it is used. -
Page 4: Installation Instructions 4~7
Installation sheet Tools needed for Installation Parts supplied for installation. Inlet Water Hose - One Washers - Two Cabinet Dimensions Width 23.62 inch Page 4 • Multi wrench • Utility Knife • Channel Lock • Nut driver • Level • Screw driver - Flat Blade Height 33.46 inch Electrical Refer to serial plate for specific... - Page 5 Installation sheet Proper installation is extremely important for your washer dryer to function correctly. When you first receive your washer dryer remove the box and packing material from the unit and inspect it carefully. If you find damage, immediately contact the delivery company and the company from which the unit was purchased.
- Page 6 Installation Sheet STEP 3 Final Installation Check List 1. Instructions and other items have been removed from the tub. 2. Shipping bolts have been removed. 3. Washer dryer is plugged in to an electric outlet and is properly grounded. 4. Water hose is connected to the faucet with inlet screens and washers. 5.
- Page 7 Installation sheet Shipping Bolts Spacers Bolts Spacers Leveling Plug and Wall Receptacle Plumbing Spacers A. Should be 36 inches maximum and 28 inches minimum. Page 7...
-
Page 8: Water And Electrical Requirements
Water and Electrical Requirements Electrical 110V, 60Hz 20/30 Amp fuse or circuit breaker We recommend a dedicated circuit meant only for the washer dryer. The washer dryer is equipped with a power cord and a three prong NEMA 5-20P plug. Never use an extension cord. -
Page 9: Operating Guide 9~10
HOW TO USE YOUR WASHER DRYER WASH PROGRAM DRYER TIME EXTRA RINSE RINSE HOLD NO SPIN SPIN SPEED POWER WOOL Prewash COTTON Spin Super Heavy Duty Rinse Color Regular Regular Express 550 RPM Spin Rinse 1200 RPM Rinse DOOR LOCK LIGHT WASH TEMP Express... - Page 10 How To Operate Your Washer Dryer Good Washing starts with hot water. To get your clothes clean and dry you need hot water. Your washer dryer automatically heats the water in the wash cycle. AUTOMATIC PROGRAM Wash Program Temperature Dryer Timer WASH ONLY Wash Program Temperature...
-
Page 11: Cycle Selection 11~12
Wash Cycle Selection What happens in each cycle? Wash Fabric Temperature Cycles Type ºF Cotton Whites Pre-wash Cotton Heavy Very Dirty Duty Whites Cotton Jeans Super Cotton Resistant Regular Colors Cotton Delicate Color Colors Rapid Cotton Wash Assorted Express Colors Synthetic 104~140 Resistant... - Page 12 Drying Options Choose your drying options from the table below to suit your personal preference. Fabric Cotton & Linen Cotton & 4.4 lbs Linen Synthetic 3.3 lbs & Delicate Synthetic 2.2 lbs & Delicate Page 12 Load 6 lbs 1000 1000 Damp Dry Minutes...
-
Page 13: Detergent Guide
Detergent Guide How to choose and use the right detergent First, use only detergent specifically made for use in front load washers. Other types will cause over sudsing. Second, use only low sudsing powder or liquid detergent. Performance of this machine will be adversely effected if high suds detergents are used. -
Page 14: Care & Cleaning
Care and Cleaning ! Unplug electric power cord before cleaning washer dryer to avoid shock. Cleaning the Exterior Use a soft damp cloth or sponge to wipe up any spills. Occasionally wipe the outside of your unit to keep it looking new. Cleaning the Interior The drum is made of stainless steel so it will no rust. -
Page 15: Vacation & Winter Storage
Vacation & Winter Storage Install and store your washer/dryer where it will not freeze. Because some water may stay in the hoses and other parts and components, freezing can damage your washer dryer. If storing or moving your washer dryer during freezing weather, winterize it. Nonuse or Vacation care If you are going away on vacation or not using your washer/dryer for an extended period of time,... -
Page 16: Safety Features
Safety Features For the protection of your family and loved ones your washer dryer is equipped with many safety features. Child Safe Door An electromechanical safety device in the door prevents it from opening during operation. Door will not open until the unit is shut down and the power button is turned off. Washer Motor A thermal safety device protects the motor from overload or underload giving the motor long life. -
Page 17: Fabric Care Symbols 17~18
Fabric Care Care Label Guide The following information is provided by U.S. Federal Trade Commission as part of Project Clean. The symbols appearing on garment labels provide care instructions from the garment manufacturer. These symbols seen on the fabric serve as minimum laundering instructions to indicate washing, bleaching, drying, ironing and dry cleaning. -
Page 18: Color
Fabric Care BLEACH Any Bleach (when needed) Only non-chlorine bleach (when needed) Warning: Do Not Bleach Normal Permanent Press/Wrinkle Resistant Gentle/Delicate Heat Setting: High Heat Setting: Medium Heat Setting: Low Special Instructions: Line Dry/Hang to Dry Special Instructions: Drip Dry Special Instructions: Dry Flat Special Instructions: Dry in Shade Warning: Do Not Dry... -
Page 19: Rinse
Questions? Use This Troubleshooting Guide PROBLEM Washer won’t fill, rinse or drum will not turn Drum does not fill, but water is flowing Washer dryer stops Washer won’t drain Washer continues to fill or drain or the cycle seems stuck Washer makes noise POSSIBLE CAUSE AND REMEDY •... -
Page 20: Troubleshooting Guide
Troubleshooting Guide PROBLEM Washer/Dryer leaks Detergent dispenser clogged Load too wet Residue or l int on load Stains after wash Load is wrinkled Page 20 POSSIBLE CAUSE AND REMEDY • Is water inlet hose tight? Are all hose washers properly seated? •... -
Page 21: Express
Troubleshooting Guide PROBLEM oad is tangled or twisted Fabric damage Washer does not dry Door does not open To receive more information call toll-free 1.866.517.7827 POSSIBLE CAUSE AND REMEDY • Did you overload drum? Loads should move freely during washing. •... - Page 22 Notes Page 22...
-
Page 23: Warranty
WARRANTY This EdgeStar product is warranted to be free from defective workmanship and materials for the first year following the date of original purchase. Replacement parts will be supplied free of charge for the first year following the date of original purchase. Labor will be performed free of charge for the first 90 days following the date of original purchase. - Page 24 DESCRIPTION OF WARRANTY SERVICE: All defective product components covered by this warranty will be repaired or replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s authorized repair facility during the first 90 days from the date of original purchase.
