Wire colors and connection points for connection wires

Never connect the power supply to the speaker wires (No.6 and No.7),
otherwise it will cause damage to the main unit.
Caution
B+ (Yellow)
1
Connect where power is constantly available, regardless of the ignition key's position.
ACC (Red)
2
Connect where the power comes on when the ignition is in the ACC position.
Illumination power supply (Orange/White)
3
Connect to where power comes on when the vehicle light switch is turned on.
Antenna power supply (Blue)
4
Connect to the automatic-antenna control terminal of the vehicle.
Control power supply (Blue/White)
5
Connect the control terminal for the external amplifier, etc.
Front speaker output wires
6
Connect to the front speakers.
Rear speaker output wires
7
Connect to the rear speakers.
No connection (Pink)
8
Ground (Black)
9
F
Genuine steering remote control terminal
Connect to the vehicle steering remote control.
※ Compatible vehicle models for installation : Vehicles with voltage detection-type steering remote control.
G
VTR input terminals
Connect the output wire of external video main unit such as a VTR.
Yellow : Video signal
White: Left + White/black:
Gray: Right + Gray/Black:
Green: Left + Green/black:
Purple: Right + Purple/Black:
Ask your dealer for details.
White : Audio (left) signal
