Main unit components

1 Main unit x 1
Panel
5
x 1
MAP DVD-ROM
9
x 1

GPS antenna components

GPS antenna
11
10
x 1

Wiring components

14 Wire tie
(for GPS antenna)
x 4
Tip
When installing the main unit, some vehicle models may require the use of items that need to be
obtained separately such as a power supply adaptor wire, radio antenna adaptor wire or mounting
bracket.
Check that all of the following components are present
Check that all of the following components are present
interconnecting wires
2
(Power and front speaker connector)
(10P) x 1
Hex-head bolt
6
(Red:M5x8) x 8
Waterproof cushion Ground plate
12
x 1
- 2 -
interconnecting wires
3
(Rear speaker connector)
(6P) x 1
7 Flat head screw
(Red:M5x8) x 8
Body protective sheet
13
x 1
interconnecting wires
4
(Video input and steering
remote control connector)
(8P) x 1
8 Splicing connector
x 3
x 1
