  • Page 1 Professional Power Amplifiers more than 60 years of amplifiers experience Mobile Audio | Concert Sound | Fixed Installation | Pro Entertainment English...

  • Page 2: Table Of Contents

    ontents Contents introduction contents one Brand fits all history 04-05 milestones 06-07 manufacturing 08-09 Bosch production system 10-11 products powerh series 12-17 remote control & iris-net rcm-26 controller modul 19-21 lx series 22-27 cl series 28-33 sl series 34-37 Dsa series - multi-channel 38-41 rcm-810 controller modul 42-43...

  • Page 3: One Brand Fits All

    The spectrum of these requirements—from live music to fixed installation—has an extremely wide bandwidth and extends from very high power output combined with minimum weight to remote supervision and network capability. DYNACORD’s extensive power amplifier portfolio offers an ideal and cost-effective solution for every field of application.

  • Page 4: History

    German Engineering Excellence for more than 60 years, DynacorD has Been one of the most innovative anD successful manufacturers of professional auDio equipment.

  • Page 5: History

    60 years of expertise in professional power amplifier technology— expertise upon which the brand DYNACORD is able to draw today. Early results included the KI cinema amplifier with its output of 25 watts. The devices of the company, which...

  • Page 6: Milestones

    ilestones Milestones the constantly expanDing proDuct range yielDeD many pro auDio milestones.

  • Page 7: Milestones

    60 years defined the brand dYnacord. • the first generations of professional mixing amplifiers [Eminent, Gigant] the first tape-echo/reverb devices [Echochord] •...
  • Page 8 osCH roduCtion ysteM...

  • Page 9: Bosch Production System

    System quality with system With the introduction of the Bosch production system (Bps) at the straubing works, the brand dYnacord is further enhancing its already legendary reputation for the highest production quality and reliability. Quality with system is assured by the BPS worldwide in...
  • Page 10 600 square metres is one of the worlD’s largest auDio measurement halls. Manufacturing since september 2006, dYnacord has belonged to the Bosch concern’s security technology department. The production facility in Straubing has been considerably expanded and the work reorganized along the lines of the Bosch Production System (BPS).
  • Page 11 One of the particular strengths of the brand DYNACORD is the fact that over the many years of its history profound know-how, covering the entire signal chain from the mixer to the loudspeakers has been acquired.
  • Page 12 recommenDeD applications concertsound, touring, club/Disco, prosound, network “All the measured data and the stability under continuous output are—as expected— of the highest order” PowerH 5000 test in `Production Partner` 10/2007...
  • Page 13 60-year pro audio tradition of dYnacord. DYNACORD has long been established worldwide as a manufacturer of professional high-performance amplifiers and by virtue of numerous innovations and the downright legendary reliability of its products has secured for itself a firm place in the elite segment.

  • Page 14: Powerh Series

    1500 W / 4 Ω. This is the approach adopted by many DYNACORD power amplifiers. The limitation of the Class H push-pull approach is the 250 V specification of typical audio power transistors and their second breakdown restrictions.
  • Page 15 of audio performance. One of the key advantages of Grounded Bridge solutions is the considerable reduction in ‚voltage stress‘ for the power transistors. This permits the design of high-powered power amplifiers with peak output voltages in excess even of 200 V. A logical step in the direction of lowering power dissipation whilst at the same time increasing the...
  • Page 16 FIR filtering and digital algorithms to protect PowerH 5000 test in `Production Partner` 10/2007 the loudspeakers. DYNACORD power amplifiers are known for their absolute reliability under the most arduous of conditions on the road.
  • Page 17 circuits at the output of the power amplifier are detected early on, even at low levels. The protective circuit is activated and a report on the fault in question appears simulta- neously on the front display. In the event of excessive high-frequency overload, there is an automatic level reduction to protect the power amplifier itself and also the loud-...

  • Page 18: Remote Control & Iris-Net

    Remote Control and IRIS-Net iris-net is the integrateD software platform for all remote- controllaBle Devices anD systems from DynacorD anD electro-voice. using iris-net, complete audio systems with a large number of devices of the same or different...
  • Page 19 RCM-26 Digital controller moDul for power h the rcM-26 is a dual-channel digital controller module for live sound, pa and fixed installation. it offers all conventional signal processing functions such as parametric equalizers, crossovers, delays, compressors and limiters. It also makes available linear phase FIR filters, zero-latency FIR filters and digital loudspeaker protection algorithms to permit the dynamic range of the amplifier to be exploited to the full.
  • Page 20 Both linear-phase FIR filters and ‚zero latency‘ FIR filters, which add no further delay to the time signals take to pass through the device, are available. Users can create their own linear phase ‚brick-wall X-over‘ and edit them in real time. For DYNACORD...
  • Page 21 For DYNACORD loudspeaker cabinets, measurements of the frequency and phase response are already provided in the IRIS-Net. This data together with the filter, crossover and delay settings conducted in the RCM-26 can be displayed and taken into account by IRIS-Net.
  • Page 22 recommenDeD applications live music, concertsound, touring | pro sound Ultra Lightweight Premium Audio Performance.
  • Page 23 lX s eries Power Amplifiers · lx 1600 · lx 2200 · lx 3000 · xa 4000...

  • Page 24: Lx Series

    lX s eries LX Series ultra light weight power amplifiers LX1600 • LX2200 • LX3000 Xa 4000 • high-efficiency Class-H design • switching power supply • extremely light and compact • 30% dynamic headroom • very high 2 ohm stability • complete package of protective circuits • dynamic audio limiter • precise raster pots on front panel • constant gain with 32dB sWitching poWer supplY technologY The combination of an analogue class-H design with a state-of- the-art switching power supply has made possible the creation...
  • Page 25 lX s eries...
  • Page 26 DouBt have the auDiophiles Drooling. from every single Discipline it’s eviDent that the people working in DynacorD’s Development Department in strauBing are perfectionists in the Best sense of the worD. front panel...

  • Page 27: Lx Series

    lX 1600 With an output rated at 2 x 1300 watts into 2 ohms and 2 x 800 watts into 4 ohms, this is the ideal power amplifier for small to medium-sized full-range cabinets and MF/HF components in active multi-way systems. lX 2200 With a stable output of 2 x 1600 watts into 2 ohms and 2 x 1100 watts into 4 ohms, this is the ideal...
  • Page 28 recommenDeD applications live music | concert sound, club/Disco, commercial Superior Audio Performance, highest reliability and operational safety.
  • Page 29 Cl s eries Power Amplifiers · cl 800 · cl 1200 · cl 1600 · cl 2000...
  • Page 30 Cl s eries...

  • Page 31: Cl Series

    CL Series thoroughBreD workhorses for the most DemanDing auDio tasks technologY Through the use of optimized power supplies with toroidal transformers (on account of their low stray fields) and the intelligent application of class H technology (CL 800: class AB), headroom way above the declared nominal power has been achieved as well as a notable reduction in weight and waste heat.
  • Page 32 Cl s eries front panel The dB-calibrated level controls are implemented as ultra-precise detent potentiometers that are recessed in the front panel to protect them from accidental contact. Power, Protect, Signal and Limit LEDs provide a quick overview of the operating status. rear panel The electronically balanced XLR IN / OUT sockets are provided for direct operation with professional...

  • Page 33: Cl Series

    Dynamic limiters are general components in all DYNACORD power amplifiers. High-speed audio processors are continuously comparing the input signal to the out- put signal, and in the event of any non-linearity, the processors send control signals to the limiters, which operate dynamically upon the input level.
  • Page 34 recommenDeD applications live music | concert sound, commercial Stable power output and a high efficiency factor on the high performance level.
  • Page 35 sl s eries Power Amplifiers · sl 900 · sl 1200 · sl 1800 · sl 2400...

  • Page 36: Sl Series

    They offer high, stable power output and a high efficiency factor on the high performance level and...

  • Page 37: Sl Series

    The switchable Low-Pass Notch (LPN) filter is a typical DYNACORD special feature. This filter circuitry corrects the frequency response and optimizes the transient behaviour of loudspeakers. The resulting dynamization cannot be achieved with any graphic or parametric equalizer or ‘bass booster’, since the...
  • Page 38 recommenDeD applications multi media, club/Disco, pro sound, commercial | network Universal installation power amplifiers with optional network capability (IRIS-Net).
  • Page 39 dsa s eries Power Amplifiers · Dsa 8405 · Dsa 8410 · Dsa 8805 · Dsa 8204 · Dsa 8206 · Dsa 8209 · Dsa 8212...

  • Page 40: Dsa Series - Multi-Channel

    500 w anD 1000 w respectively per channel or Directly Drive 70 v or 100 v louDspeaker lines. innovative dYnacord technology, exemplary flexibility, very high output with an extremely good efficiency and integration into iris-net networks: a thumbnail...
  • Page 41 It goes without saying that all protective circuits and dy- namic limiters (as is the case with in all DYNACORD power amplifiers) are available in every channel. Using the ON DELAY selector switch on the rear panel of the power...
  • Page 42 rCM-810...
  • Page 43 RCM-810 Digital controller moDule the rcM-810 remote control module is a digital controller module for pa and fixed installation and permits the integration of dsa amplifiers in a remote control network with up to 250 devices. With it, a complete PA system can be controlled and supervised from one or several PCs with the help of IRIS-Net software.
  • Page 44 dsa s eries Hannel...

  • Page 45: Dsa Serie - Dual-Channel

    DSA Series - Dual-Channel amplifiers that proviDe a multituDe of highly economic solutions to the proBlems poseD By fixeD installations. solid dYnacord technology for fixed installations at very competitive prices was the maxims for the development of the dsa power amplifier series.
  • Page 46 recommenDeD applications commercial Power amplifiers for challenging sound reinforcement.

  • Page 47: Pcl Series

    PCl s eries pcl series · pcl 1125t · pcl 1225t · pcl 1240t · pcl 1245 · pcl 1415...
  • Page 48 PCl s eries PCL Series contractor line power amplifiers With the pcl series, dYnacord is adding to its extensive power amplifier range in the fixed installation segment a number of models with fairly low to medium output levels. The power amplifiers are particularly...
  • Page 49 features • five models from 160 W to 450 W per channel; 4 ohm or 50 / 70 / 100 V • compact 2U housing • Phoenix input plugs for simple setting-up • single block plug for all output signals • bridged mode for all multi-channel models • switchable high-pass filter in each channel; 50 Hz or 300 Hz • level controller for each channel on the rear panel • front-to-rear cooling • numerous protective circuits PCl s eries...
  • Page 50 recommenDeD applications network, live safety | prosound | multi media, commercial Fixed installation power amplifiers with emergency power capability and IRIS-Net integration.

  • Page 51: Dpa Series

    dPa s eries dpa series · Dpa 4120 · Dpa 4140 · Dpa 4410 · Dpa 4411 · Dpa 4245 · Dpa 4260 · Dpa 8150 · Dpa 8225 · Dpa 8412...
  • Page 52 Thousands upon thousands of DPA 4000 series power amplifiers for example are proving their worth every day in countless installations throughout the globe—invariably leading in terms of performance,...
  • Page 53 the new models of the dpa 8000 series are based on highly efficient class d platforms and offer in addition to outstanding audio performance features such as integrated automatic break- down switchover, integrated electronics for the connection of multiple loudspeaker lines per amplifier channel, an additional audio input, etc.
  • Page 54 The spectrum of these requirements—from live music to fixed installation—has an extremely wide bandwidth and extends from very high power output combined with minimum weight to remote supervision and network capability. DYNACORD’s extensive power amplifier portfolio offers an ideal and cost-effective solution for every field of application.

  • Page 55: Technical Specifications

    PowerH Series technical specifications General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1% Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power @ 8Ω, 1 kHz THD at rated output power MBW=80kHz, 1 kHz...
  • Page 56 4000 Xa 4000 technical specifications General Load Impedance Maximum Midband Output Power, THD=1%, 80Hz SUB, 1 kHz TOP, Single Channel Rated Output Power, THD <0.1%, 20 Hz-140 Hz SUB, 140 Hz-20 kHz TOP Single Channel Maximum RMS Voltage Swing, THD=1%, 80 Hz SUB, 1 kHz TOP Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power, 1 kHz THD at rated output power, MBW=80kHz, 1 kHz Max. Input Level Input Inpedance, active balanced Damping Factor ,1kHz Slew Rate Signal to Noise Ratio, A-weighted...

  • Page 57: Lx Series

    LX Series technical specifications General 2 Ω Load Impedance 1300 W Maximum Midband Output Power, 1 kHz, THD=1% Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% 2200 W Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output 1700 W Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref.

  • Page 58: Cl Series

    Cl s eries CL Series technical specifications General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1% Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω...
  • Page 59 General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1% Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power @ 8Ω, 1 kHz THD at rated output power MBW=80kHz, 1 kHz IMD-SMPTE, 60 Hz, 7 kHz...

  • Page 60: Sl Series

    sl s eries SL Series technical specifications General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω...

  • Page 61: Sl Series

    General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power @ 8Ω, 1 kHz THD at rated output power MBW=80kHz, 1 kHz IMD-SMPTE, 60 Hz, 7 kHz...

  • Page 62: Dsa Series

    dsa s eries ulti Hannel DSA Series - Multi-Channel technical specifications General 2 Ω Load Impedance Maximum Midband Output 500 W Power, 1 kHz, THD=1%, 4 channels driven 450 W Rated Output Power, 20 Hz ... 20 kHz, THD <0.3%, 4 channels driven Maximum Bridged Output Power 1000 W 1 kHz, THD=1% Maximum RMS Voltage Swing 32 V 1 kHz, THD=1% Input Sensitivity, 0.775 V rated power, 1 kHz...
  • Page 63 General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, 4 channels driven Rated Output Power, 20 Hz ... 20 kHz, THD <0.3%, 4 channels driven Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Input Sensitivity, rated power, 1 kHz Power Bandwidth, THD=1%, ref. 1kHz, half power @ rated load Voltage Gain ref. 1 kHz THD at rated output power MBW=80kHz, 1 kHz IMD-SMPTE, 60 Hz, 7 kHz DIM 30, 3.15 kHz, 15 kHz Max.
  • Page 64 dsa s eries Hannel DSA Series - Dual-Channel technical specifications General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω...
  • Page 65 General Load Impedance Maximum Midband Output Power, 1 kHz, THD=1%, Dual Channel Rated Output Power, 20 Hz ... 20 kHz, THD <0.1% Max. Single Channel Output Power Dynamic-Headroom, IHF-A Max. Single Channel Output Power Continuous, 1kHz Maximum Bridged Output Power 1 kHz, THD=1% Maximum RMS Voltage Swing 1 kHz, THD=1% Power Bandwidth, THD=1%, ref. 1kHz, half power @ 4Ω Voltage Gain ref. 1 kHz Input Sensitivity at rated output power @ 8Ω, 1 kHz THD at rated output power MBW=80kHz, 1 kHz IMD-SMPTE, 60 Hz, 7 kHz...

  • Page 66: Pcl Series

    PCl s eries PCL Series technical specifications General Load Impedance Max. Midband Output (THD < 0.2 %, 20 Hz…20 kHz) Rated Output Power (THD < 0.2 %, 20 Hz…20 kHz) Channels Max. RMS Voltage Swing (THD = 1 %, 1 kHz) Voltage Gain (at 1 kHz) Power Handling (at 1/8 max. output power, limited pink) Input Sensitivity (at ROP or Voltage, 1 kHz) THD (MBW = 80 kHz, 1 kHz) Frequency Response (-1 dB, ref. 1 kHz) Input Impedance (20 Hz…20 kHz symmetr.) Damping Factor (at 100 Hz / 1 kHz, 4 Ω) Signal to Noise Ratio S/N (A-weighted)
  • Page 67 General Load Impedance Max. Midband Output (THD < 0.2 %, 20 Hz…20 kHz) Rated Output Power (THD < 0.2 %, 20 Hz…20 kHz) Channels Max. RMS Voltage Swing (THD = 1 %, 1 kHz) Voltage Gain (at 1 kHz) Power Handling (at 1/8 max. output power, limited pink) Input Sensitivity (at ROP or Voltage, 1 kHz) THD (MBW = 80 kHz, 1 kHz) Frequency Response (-1 dB, ref. 1 kHz) Input Impedance (20 Hz…20 kHz symmetr.) Damping Factor (at 100 Hz / 1 kHz, 4 Ω) Signal to Noise Ratio S/N (A-weighted) Power Requirements Protection Cooling...
  • Page 68 dPa 4000 s eries DPA 4000 Series technical specifications General Load Impedance Rated Output Power (Mains) Power Output Characteristics Input Characteristics Input Sensitivity Input Impedance Distortion @ 1 kHz and Nom. Outp. Power Interference Voltage (A) Frequency Response Load Impedance (monitor) Nominal Output Voltage (monitor) Output Characteristics (monitor) Output Stage Topology Power Requirements...
  • Page 69 General Load Impedance Rated Output Power Maximum Output Power Output Power in Bridged-Operation Power Output Characteristics: Input Characteristics: Input Sensitivity Input Impedance Distortion @ 1kHz and Nom. Outp. Power Frequency Response Signal to Noise Ratio Output Stage Topology Power Requirements Mains Mains Power Consumption Protection Cooling...
  • Page 70 dPa 8000 s eries DPA 8000 Series technical specifications General Load Impedance Rated Output Power, 1kHz, THD < 0.5% Rated RMS Voltage Swing, 1kHz, THD=1% Input Sensitivity, rated power @ rated load, 1kHz Voltage Gain ref. 1kHz THD at rated output power MBW=80kHz, 1kHz IMD-SMPTE, 60Hz, 7kHz DIM 30, 3,15kHz, 15kHz Max. Input Level Crosstalk, ref. 1 kHz at rated output power Frequency Response, ref. 1 kHz, rated load Input Impedance, active balanced Signal to Noise Ratio, A-weighted Output Stage Topology...
  • Page 71 General Load Impedance Rated Output Power, 1kHz, THD < 0.5% Rated RMS Voltage Swing, 1kHz, THD=1% Input Sensitivity, rated power @ rated load, 1kHz Voltage Gain ref. 1kHz THD at rated output power MBW=80kHz, 1kHz IMD-SMPTE, 60Hz, 7kHz DIM 30, 3,15kHz, 15kHz Max. Input Level Crosstalk, ref. 1 kHz at rated output power Frequency Response, ref. 1 kHz, rated load Input Impedance, active balanced Signal to Noise Ratio, A-weighted Output Stage Topology Power Requirements Power Consumption, at rated Output Power...
