PRESSURE REGULATOR
MODEL NO: IR1A, IR2A, IR1C & IR2C
PART NO: 8134060, 8134070, 8134090 & 8134100
OPERATING & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS
GC0821 REV 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the weld IR1A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clarke weld IR1A

  • Page 1 PRESSURE REGULATOR MODEL NO: IR1A, IR2A, IR1C & IR2C PART NO: 8134060, 8134070, 8134090 & 8134100 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0821 REV 1...
  • Page 2: Specifications

    Your regulator has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. SPECIFICATIONS Colour...
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS CAUTION: FAILURE TO FOLLOW THESE PRECAUTIONS COULD RESULT IN PERSONAL INJURY, AND/OR DAMAGE TO PROPERTY. • Incorrect use of the pressure reducer can cause serious damage. • Users must be trained technicians or else, under full supervision. • ALWAYS check to ensure the reducer is the correct model for the type of gas being used.
  • Page 4: Hose Connection

    ASSEMBLY Refer to parts diagram - page 7. CONNECTION OF THE PRESSURE REDUCER 1. Check to ensure the pressure reducer is correct both for the type of gas and the pressure in the cylinder to be used. 2. Turn the pressure adjuster (6) fully anticlockwise, to ensure the pressure reducer valve is closed.
  • Page 5: Shutting Down

    HOW TO REGULATE THE PRESSURE 1. To increase pressure; slowly turn the reducer pressure adjuster (6) clockwise until the reading on the gauge (if fitted) is at the pressure recommended by the tools’ manufacturer. 2. To decrease pressure; slowly turn the reducer pressure adjuster (6) anticlockwise.
  • Page 6: Maintenance

    MAINTENANCE Do not carry out maintenance or repairs other than the following. • Use only original CLARKE spare parts and accessories. (see your dealer). • DO NOT dismantle the gauge assembly. Return to your CLARKE dealer for servicing. • DO NOT clean the gauge glass with solvents - petrol etc.
  • Page 7: Parts List And Diagram

    High pressure gauge Body Low pressure gauge Gauge cover ACCESSORIES A wide range of welding accessories is available. Contact your CLARKE dealer for further information or CLARKE International Service Department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
