Stand-Alone Operation; Preset Colors; Color Change Effect; Color Fade Effect - EuroLite AKKU mini IP UP-4 User Manual

Preset colors

In color mode CL the device will constantly emit one of 8 preset color combinations. Press the MENU button so
many times until CLXX is indicated in the display. Use the UP and DOWN buttons to adjust the desired color:
Display
CL01 Red
CL02 Green
CL03 Blue
CL04 White
CL05 Yellow (red and green)
CL06 Magenta (red and blue)
CL07 Turquoise (green and blue)
White (all LEDs on)
CL08
Confirm the color selection with the ENTER button.

Color change effect

In mode CC the device will automatically change the color step by step, at an adjustable speed. Press the MENU
button so many times until CCXX is indicated in the display. Use the UP and DOWN buttons to adjust the desired
running speed (00 = slow, 99 = fast). Confirm the speed selection with the ENTER button.

Color fade effect

In mode dE the device automatically fades the color at an adjustable speed. Press the MENU button so many
times until dEXX is indicated in the display. Use the UP and DOWN buttons to adjust the desired running speed
(00 = slow, 99 = fast). Confirm the speed selection with the ENTER button.

Pulsing color change effect

In mode CP the device automatically changes the pulsing color, at an adjustable speed. Press the MENU button so
many times until CPXX is indicated in the display. Use the UP and DOWN buttons to adjust the desired running
speed (00 = slow, 99 = fast). Confirm the speed selection with the ENTER button.

Sound control

In mode SUn the device will change the color to the rhythm of the music (sufficient bass provided). To select this
mode press the MENU button so many times until SUnX is indicated in the display. Use the UP and DOWN buttons
to adjust the desired color combinations. Then press the ENTER button and use the UP and DOWN buttons to
adjust the desired effect speed (0 = sensitive, 9 = insensitive). Confirm the selection with the ENTER button.

Strobe effect

Menu item F activates the strobe effect for all stand-alone operating modes. The flash frequency is adjustable.
Press the MENU button so many times until FXXX is indicated in the display. Use the UP and DOWN buttons to
adjust the flash frequency (010 = slow, 255 = fast). Confirm the speed selection with the ENTER button.

Individual color mix

Menu options r, G, b and u generate a mixed color by brightness control of the red, green, blue and white
channels. The device will constantly emit the color adjusted. Press the MENU button so many times until r for the
color red and the corresponding brightness value is indicated in the display. Then use the buttons UP and DOWN
to adjust the desired brightness. Adjust the other primary colors in the same way.

STAND-ALONE OPERATION

Color
18 • EN
