RAM TRUCK

2 0 1 1

C H A S S I S C A B

O W N E R ' S M A N U A L

Table of Contents

Advertisement

Chapters

Table of Contents

Need help?

Need help?

Do you have a question about the 2011 Ram Truck Chassis Cab and is the answer not in the manual?

Questions and answers

Summary of Contents for RAM 2011 Ram Truck Chassis Cab

Page 1 RAM TRUCK 2 0 1 1 C H A S S I S C A B O W N E R ’ S M A N U A L...
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4 CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6 INTRODUCTION 5...
Page 7: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in an accident or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 8: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death. Vehicle Identification Number NOTE: It is illegal to remove or alter the VIN.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) — If Equipped ......12 Key FOB .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Open Window Feature — If Equipped ......23 Using The Panic Alarm .
Page 12 Driver And Right Front Passenger Supplemental Restraint System (SRS) – Airbag ......49 Airbag System Components .
Page 13: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Key Fob with Remote Keyless Entry (RKE) — If Equipped Your vehicle uses a keyless ignition system. This system consists of a Key Fob with Remote Keyless Entry (RKE) transmitter and a Wireless Ignition Node (WIN) with integral ignition switch.
Page 14: Key Fob
Wireless Ignition Node (WIN) 1 — OFF 2 — ACC (ACCESSORY) 3 — ON/RUN 4 — START THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. It also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob.
Page 15: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand. Emergency Key Removal NOTE: You can insert the double-sided emergency key into the lock cylinder with either side up.
Page 16: Key-In-Ignition Reminder
Information Center (EVIC) /Personal Settings (Customer- Programmable Features)” in “Understanding Your In- strument Panel” for further information. WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured.
Page 17: Sentry Key
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE SENTRY KEY The Sentry Key Immobilizer System prevents unautho- rized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation is automatic, regardless of whether the vehicle is locked or unlocked.
Page 18: Replacement Keys
All of the Key Fobs provided with your new vehicle have been programmed to the vehicle electronics. Replacement Keys NOTE: Only Key Fobs that are programmed to the vehicle electronics can be used to start and operate the vehicle. Once a Key Fob is programmed to a vehicle, it cannot be programmed to any other vehicle.
Page 19: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information The Sentry Key system complies with FCC rules Part 15 and with RSS-210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. •...
Page 20: To Disarm The System
NOTE: If the Vehicle Security Light stays on continu- ously during vehicle operation, have the system checked by an authorized dealer. To Disarm the System Use the RKE transmitter to unlock the door. If something has triggered the system in your absence, the horn will sound three times when you unlock the doors and the Vehicle Security Light will flash for 30 seconds.
Page 21: Remote Keyless Entry (Rke) - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The illuminated entry system will not operate if the dimmer control is in the extreme left position. REMOTE KEYLESS ENTRY (RKE) — IF EQUIPPED The RKE system allows you to lock or unlock the doors and activate the Panic Alarm from distances up to approximately 66 ft (20 m) using a hand-held radio transmitter with integrated key.
Page 22 Remote Key Unlock, Driver Door/All Doors First This feature lets you program the system to unlock either the driver’s door or all doors on the first press of the UNLOCK button on the RKE transmitter. To change the current setting, proceed as follows: •...
Page 23: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lamps with Remote Key Lock This feature will cause the turn signal lights to flash when the doors are locked or unlocked with the RKE transmit- ter. This feature can be turned on or turned off. To change the current setting, proceed as follows: •...
Page 24: Remote Open Window Feature
Sound Horn with Remote Key Lock This feature will cause the horn to chirp when the doors are locked with the RKE transmitter. This feature can be turned on or turned off. To change the current setting, proceed as follows: •...
Page 25: Using The Panic Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Using the Panic Alarm To turn the Panic Alarm feature ON or OFF, press and hold the PANIC button on the RKE transmitter for at least one second and release. When the Panic Alarm is on, the headlights and park lights will flash, the horn will pulse on and off, and the interior lights will turn on.
Page 26: General Information
1. With the RKE transmitter buttons facing down, use a flat blade screwdriver to pry the two halves of the RKE transmitter apart. Make sure not to damage the seal during removal. 2. Remove and replace the battery. Avoid touching the new battery with your fingers.
Page 27: Remote Starting System - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) transmitter to start the engine conve- niently from outside the vehicle while still maintaining security. The system has a range of approximately 300 ft (91 m).
Page 28 Remote Start Abort Message on Electronic Vehicle Information Center (EVIC) — If Equipped The following messages will display in the EVIC if the vehicle fails to remote start or exits remote start prema- turely: • Remote Start Aborted - Door Ajar •...
Page 29 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: To avoid unintentional shut downs, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid Remote Start request. To Exit Remote Start Mode and Drive the Vehicle Before the end of the 15-minute cycle, press and release the UNLOCK button on the RKE transmitter to unlock the doors and disarm the Vehicle Security Alarm System...
Page 30: Door Locks
DOOR LOCKS Manual Door Locks Front and rear doors may be locked by moving the lock knob down or unlocked by moving the lock knob up. Front doors may be opened with the inside door handle without lifting the lock knob. Doors locked before closing will remain locked when closed.
Page 31: Power Door Locks - If Equipped
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks — If Equipped A power door LOCK switch is on each front door trim panel. Use this switch to lock or unlock the doors. Power Door Lock Switch Location 1 - Unlock 2 - Lock If you press the power door LOCK switch while the Key...
Page 32 • For vehicles not equipped with the EVIC, perform the following procedure: 1. Enter your vehicle and close all doors. 2. Fasten your seat belt. (Fastening the seat belt will cancel any chiming that may confuse you during this programming procedure.) 3.
Page 33: Child-Protection Door Lock
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the following procedure: 1. Enter your vehicle and close all doors. 2. Fasten your seat belt. (Fastening the seat belt will cancel any chimes that may be confusing during this programming procedure.) 3.
Page 34 To use the system, open each rear door, use a flat blade screwdriver (or emergency key) and rotate the dial to engage and disengage the Child-Protection locks. When the system on a door is engaged, that door can only be opened by using the outside door handle even if the inside door lock is in the unlocked position.
Page 35: Windows
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS Power Windows – If Equipped Power Window Switches 1 – Left Front 3 – Right Rear 2 – Right Front 4 – Left Rear The control on the left front door panel has UP-DOWN switches that give you fingertip control of all power windows.
Page 36 WARNING! Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured. Don’t leave the key in the ignition. A child could operate power windows, other controls, or move the vehicle.
Page 37 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE rough road conditions may trigger the auto reverse function unexpectedly during auto closure. If this happens, pull the switch lightly to the first detent and hold to close the window manually. • If the Auto-Up function is lost, reset the Auto-Up function by running the window all the way up (by holding the switch in the first up detent) and then hold the switch in the full up position for two seconds.
Page 38: Wind Buffeting
Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down or in partially open positions. This is a normal occurrence and can be minimized.
Page 39: Lap/Shoulder Belts
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! In an accident, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.
Page 40 WARNING! (Continued) • Be sure everyone in your vehicle is in a seat and using a seat belt properly. • Wearing a seat belt incorrectly is dangerous. Seat belts are designed to go around the large bones of your body. These are the strongest parts of your body and can take the forces of an accident best.
Page 41 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. The seat belt latch plate is above the back of the front seat, next to your arm in the rear seat. Grasp the latch plate and pull out the belt. Slide the latch plate up the webbing as far as necessary to allow the belt to go around your lap.
Page 42 WARNING! • A belt buckled into the wrong buckle will not protect you properly. The lap portion could ride too high on your body, possibly causing internal inju- ries. Always buckle your belt into the buckle nearest you. • A belt that is too loose will not protect you properly.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt.
Page 44 WARNING! A frayed or torn belt could rip apart in an accident and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after an accident if they have been damaged (bent retractor, torn webbing, etc.) or if the airbag deployed.
Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 2. To reattach the seat belt to the front center seat, pull the black buckle latch plate forward from the cab back panel and insert it into the black keyed buckle until there is an audible “click”.
Page 46 In Use Position THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in an accident.
Page 47: Adjustable Upper Shoulder Belt Anchorage
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Adjustable Upper Shoulder Belt Anchorage In the front row outboard seats, the shoulder belt can be adjusted upward or downward to help position the belt away from your neck. Press the button located on the upper belt guide, and then move it up or down to the position that fits you best.
Page 48: Automatic Locking Retractor (Alr) Mode - If Equipped
WARNING! • A lap belt worn too loose or too high is dangerous. • A belt worn too loose can allow you to slip down and under the belt in a collision. • A belt that is too loose or too high will apply crash forces to the abdomen, not to the stronger hip bones.
Page 49: Enhanced Seat Belt Use Reminder System (Beltalert )
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Seat Belt Use Reminder System (BeltAlert ) If the driver’s seat belt has not been buckled within 60 seconds of starting the vehicle and if the vehicle speed is greater than 5 mph (8 km/h), the BeltAlert will alert the driver to buckle the seat belt.
Page 50: Seat Belts And Pregnant Women
Seat Belts and Pregnant Women We recommend that pregnant women use seat belts throughout their pregnancies. Keeping the mother safe is the best way to keep the baby safe. Pregnant women should wear the lap part of the belt across the thighs and as snug against the hips as possible. Keep the belt low so that it does not come across the abdomen.
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE mounted in the instrument panel, above the glove com- partment. The words SRS AIRBAG are embossed on the airbag covers. Advanced Front Airbag and Knee Bolster Locations 1 — Driver and Passenger Advanced Front Airbags (if equipped) NOTE: These airbags are certified to the new Federal regulations for Advanced Airbags.
Page 52: Airbag System Components
Airbag System Components Your vehicle may be equipped with the following airbag system components: • Occupant Restraint Controller (ORC) • Airbag Warning Light • Steering Wheel and Column • Instrument Panel • Knee Impact Bolster • Driver Advanced Front Airbag •...
Page 53 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not put anything on or around the airbag covers or attempt to open them manually. You may damage the airbags and you could be injured because the airbags may no longer be functional. The protective covers for the airbag cushions are designed to open only when the airbags are inflat- ing.
Page 54 ride properly buckled up in the rear seat. Never allow children to slide the shoulder belt behind them or under their arm. If a child from 1 to 12 years old (not in a rear facing child seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint.
Page 55: Airbag Deployment Sensors And Controls
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Deployment Sensors and Controls Occupant Restraint Controller (ORC) The ORC is part of a Federally regulated safety system required for this vehicle. The ORC determines if deployment of the front airbags in a frontal collision is required.
Page 56 The ORC contains a backup power supply system that may deploy the airbags even if the battery loses power or it becomes disconnected prior to deployment. Also, the ORC turns on the Airbag Warning Light in the instrument panel for approxi- mately four to eight seconds for a self-check when the ignition is first turned on.
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE instrument panel separate and fold out of the way as the airbags inflate to their full size. The airbags fully inflate in about 50 to 70 milliseconds. This is about half of the time it takes to blink your eyes.
Page 58 If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor.
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you.
Page 60: Event Data Recorder (Edr)
Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. The Airbag Warning Light monitors the internal circuits and interconnecting wiring associated with airbag system electrical components. While the airbag system is designed to be maintenance free, if any of the following occurs, have an authorized dealer ser- vice the airbag system immediately.
Page 61: Child Restraints
60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Whether or not the driver and passenger safety belts were buckled/fastened; • How far (if at all) the driver was depressing the accelerator and/or brake pedal; and, • How fast the vehicle was traveling. These data can help provide a better understanding of the circumstances in which crashes and injuries occur.
Page 62 WARNING! In an accident, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap can become so great that you could not hold the child, no matter how strong you are.
Page 63 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE children who weigh 20 to 40 lbs (9 to 18 kg) and who are older than one year. These child seats are also held in the vehicle by the lap/shoulder belt. • The belt-positioning booster seat is for children weigh- ing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly.
Page 64 Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. Chrysler Group LLC also recommends that you make sure that you can install the child restraint in the vehicle where you will use it before you buy it.
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Improper installation can lead to failure of an infant or child restraint. It could come loose in an accident. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.
Page 66 Because the lower anchorages are to be introduced to passenger carrying vehicles over a period of years, child restraint systems having attachments for those anchor- ages will continue to have features for installation in vehicles using the lap or lap/shoulder belt. They will also have tether straps, and you are urged to take advantage of all of the available attachments provided with your child restraint in any vehicle.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Many, but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or connector, and a means for adjusting the tension in the strap.
Page 68 then allow the belt to retract into the retractor. For additional information on ALR, refer to “Automatic Locking Mode”. To install a child restraint, first, pull enough of the seat belt webbing from the retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tether Anchorage Points at the Right and Center Front Seat (Regular Cab - All Seats) 1. Place the child restraint on the seat and adjust the tether strap so that it will reach over the seat back under the head restraint to the tether anchor directly behind the seat.
Page 70 Multiple Child Restraint Installation Sequence (Crew Cab — Rear Seats) 1. Obtain tether straps by raising the head restraints and reaching between the rear glass and rear seat. The tether strap may be retained with an elastic band. Accessibility to the tether strap is greatly improved by raising the seat cushion to the “up”...
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Multiple Child Restraint Crew Cab 1 — Inner Anchor Strap Ring(s) 2 — Snap Hook 3 — Tether Strap 4 — Passenger’s Side Rear Child Seat 5 — Rear Center Child Seat 6 —...
Page 72: Engine Break-In Recommendations
Children Too Large for Booster Seats Children who are large enough to wear the shoulder belt comfortably, and whose legs are long enough to bend over the front of the seat when their back is against the seat back should use the lap/shoulder belt in a rear seat. •...
Page 73: Safety Tips
72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. For the recommended viscosity and quality grades refer to “Maintenance Procedures”...
Page 74: Exhaust Gas
Exhaust Gas WARNING! Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO) follow these safety tips: Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area.
Page 75 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Front seat belt assemblies must be replaced after a collision. Rear seat belt assemblies must be replaced after a collision if they have been damaged (i.e., bent retractor, torn webbing, etc.). If there is any question regarding belt or retractor condition, replace the belt.
Page 76 WARNING! (Continued) • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the vehicle. • Never put floor mats or other floor coverings on top of already installed floor mats.
Page 77: Periodic Safety Checks You Should Make Outside The Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 78: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......81 Inside Day/Night Mirror ....81 Automatic Dimming Mirror —...
Page 79 78 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information ....118 Voice Command — If Equipped ... 118 Voice Command System Operation .
Page 80 Parking Lights And Panel Lights ..142 Fog Lights — If Equipped ....142 Interior Lights ..... . 143 Cargo Light .
Page 81 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cigar Lighter And Ash Receiver — If Equipped ......160 Power Inverter —...
Page 82: Mirrors
MIRRORS Inside Day/Night Mirror Headlight glare can be reduced by moving the small control lever under the mirror to the night position (lever flipped toward the rear of vehicle). Adjusting Rearview Mirror UNDERSTANDING THE FEATURES OF YOUR VEHICLE 81 The mirror should be adjusted with the lever set in the day position (lever flipped toward the windshield).
Page 83: Automatic Dimming Mirror - If Equipped
82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 84: Outside Mirrors Folding Feature
WARNING! Vehicles and other objects seen in a passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger side convex mirror.
Page 85: Power Mirrors - If Equipped
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors — If Equipped The controls for the power mirrors are located on the driver’s door trim panel. Power Mirror Controls The power mirror controls consist of mirror select but- tons and a four-way mirror control switch. Power Mirror Controls 1 —...
Page 86: Heated Mirrors - If Equipped
Power Mirror Movement Heated Mirrors — If Equipped These mirrors are heated to melt frost or ice. This feature is activated by pressing the rear window defroster button. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 85 Illuminated Vanity Mirror — If Equipped Illuminated vanity mirrors are located on each sun visor.
Page 87: Slide-On-Rod" Features Of Sun Visor - If Equipped
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Slide-On-Rod” Features of Sun Visor — If Equipped The sun visor “Slide-On-Rod” feature allows for addi- tional flexibility in positioning the visor to block out the sun. To use the “Slide-On-Rod” feature, rotate the sun visor downward and unclip it.
Page 88: Trailer Towing Mirrors - If Equipped
Trailer Towing Mirrors — If Equipped These mirrors are designed with an adjustable mirror head to provide a greater vision range when towing extra-wide loads. To change position inboard or out- board, the mirror head should be rotated (flipped in or out).
Page 89: Uconnect™ Phone - If Equipped
0.96 or higher. See the Uconnect™ website for supported phones. For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 Uconnect™ Phone allows you to transfer calls between the system and your cellular phone as you enter or exit “248-555-1212”).
Page 90 linked (or paired) cellular phone can be used with the system at a time. The system is available in English, Spanish, or French languages. WARNING! Any voice commanded system should be used only in safe driving conditions following local laws and phone use.
Page 91: Operation
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Operation Voice commands can be used to operate the Uconnect™ Phone and to navigate through the Uconnect™ Phone menu structure. Voice commands are required after most Uconnect™ Phone prompts. You will be prompted for a specific command and then guided through the available options.
Page 92 Cancel Command At any prompt, after the beep, you can say “Cancel” and you will be returned to the main menu. However, in a few instances the system will take you back to the previous menu. Pair (Link) Uconnect™ Phone to a Cellular Phone To begin using your Uconnect™...
Page 93 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE phone to use if multiple cellular phones are in the vehicle at the same time. For example, if priority three and priority five phones are present in the vehicle, the Uconnect™ Phone will use the priority three cellular phone when you make a call.
Page 94 Add Names to Your Uconnect™ Phonebook NOTE: Adding names to the Uconnect™ Phonebook is recommended when the vehicle is not in motion. • Press the button to begin. • After the “Ready” prompt and the following beep, say “Phonebook New Entry”. •...
Page 95 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To call a name from downloaded (or Uconnect™) Phonebook, follow the procedure in “Call by Saying a Name” section. • Automatic download and update, if supported, begins as soon as the Bluetooth wireless phone connection is made to the Uconnect™...
Page 96 Object Exchange Profile (OBEX). Please see your phone Owner’s Manual for specific instructions on how to send these entries from your phone. NOTE: • The phone handset must support Bluetooth OBEX transfers of phonebook entries to use this feature. • Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth , and you may see a message on the phone display that the Bluetooth link is busy.
Page 97 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in the phonebook, call the number you just edited, or return to the main menu. “Phonebook Edit”...
Page 98 Delete/Erase “All” Uconnect™ Phonebook Entries • Press the button to begin. • After the “Ready” prompt and the following beep, say “Phonebook Erase All”. • The Uconnect™ Phone will ask you to verify that you wish to delete all the entries from the phonebook. •...
Page 99: Phone Call Features
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phone Call Features The following features can be accessed through the Uconnect™ Phone if the feature(s) are available on your cellular service plan. For example, if your cellular service plan provides three-way calling, this feature can be accessed through the Uconnect™...
Page 100 in progress. To go back to the first call, refer to “Toggling Between Calls” in this section. To combine two calls, refer to “Conference Call” in this section. Place/Retrieve a Call From Hold To put a call on hold, press the a single beep.
Page 101: Uconnect™ Phone Features
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say “Redial”. • The Uconnect™ Phone will call the last number that was dialed from your cellular phone. NOTE: This may not be the last number dialed from the Uconnect™...
Page 102 • Continue to follow the system prompts to complete the language selection. After selecting one of the languages, all prompts and voice commands will be in that language. NOTE: After every Uconnect™ Phone language change operation, only the language-specific 32-name phone- book is usable.
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To use your Uconnect™ Phone System in an emer- gency, your cellular phone must be: • turned on, • paired to the Uconnect™ System, • and have network coverage. Towing Assistance If you need towing assistance: •...
Page 104 Working with Automated Systems This method is used in instances where one generally has to press numbers on the cellular phone keypad while navigating through an automated telephone system. You can use your Uconnect™ Phone to access a voice mail system or an automated service, such as a paging service or automated customer service line.
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Barge In - Overriding Prompts The “Voice Command” button can be used when you wish to skip part of a prompt and issue your voice command immediately. For example, if a prompt is asking “Would you like to pair a phone, clear a...,”...
Page 106: Advanced Phone Connectivity
NOTE: Certain brands of cellular phones do not send the dial ring to the Uconnect™ Phone to play it on the vehicle audio system, so you will not hear it. Under this situation, after successfully dialing a number the user may feel that the call did not go through even though the call is in progress.
Page 107 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE phone and the Uconnect™ Phone, follow the instructions described in your cellular phone User’s Manual. List Paired Cellular Phone Names • Press the button to begin. • After the “Ready” prompt and the following beep, say “Setup Phone Pairing”.
Page 108: Things You Should Know About Your Uconnect™ Phone
Delete Uconnect™ Phone Paired Cellular Phones • Press the button to begin. • After the “Ready” prompt and the following beep, say “Setup Phone Pairing”. • At the next prompt, say “Delete” and follow the prompts. • You can also press the button at any time while the list is being played, and then choose the phone you wish to delete.
Page 109 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE best results, the Voice Training session should be com- pleted when the vehicle is parked with the engine running, all windows closed, and the blower fan switched off. This procedure may be repeated with a new user. The system will adapt to the last trained voice only.
Page 110 • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. • When navigating through an automated system such as voice mail, or when sending a page, at the end of speaking the digit string, make sure to say “Send”.
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, • dry weather conditions, and • operation from the driver’s seat. • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the Uconnect™...
Page 112 Send Messages: You can send messages using Uconnect™ Phone. To send a new message: • Press the button. • After the “Ready” prompt and the following beep, say “SMS Send” or “Send Messages.” • You can either say the message you wish to send or say “List Messages.”...
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 16. Can this wait? 17. Bye for now 18. When can we meet 19. Send number to call 20. Start without me Turn SMS Incoming Announcement ON/OFF Turning the SMS Incoming Announcement OFF will stop the system from announcing the new incoming mes- sages.
Page 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113...
Page 115 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115...
Page 117 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 118 Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 119: Voice Command - If Equipped
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 120: Commands
NOTE: If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the Voice Command for the beep, and say your command. Pressing the Voice Command system is speaking is known as “barging in.”...
Page 121 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Changing the Volume 1. Start a dialogue by pressing the Voice Command button. 2. Say a command (e.g., “Help”). 3. Use the ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Voice Command system is speaking.
Page 122 • “Previous Station” (to select the previous station) • “Radio Menu” (to switch to the radio menu) • “Main Menu” (to switch to the main menu) Satellite Radio To switch to satellite radio mode, say “Sat” or “Satellite Radio”. In this mode, you may say the following com- mands: •...
Page 123: Voice Training
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE − “Continue” (to continue recording) − “Delete” (to delete the recording) • “Play Memos” (to play previously recorded memos) — During the playback you may press the Voice Command button to stop playing memos. You proceed by saying one of the following commands: −...
Page 124: Seats
1. Press the Voice Command Setup” and once you are in that menu then say “Voice Training.” This will train your own voice to the system and will improve recognition. 2. Repeat the words and phrases when prompted by Uconnect™ Voice. For best results, the “Voice Training” session should be completed when the vehicle is parked, engine running, all windows closed, and the blower fan switched off.
Page 125: Manual Reclining Seats - If Equipped
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE position, then release the handle to lock the seat into position. Using body pressure, move forward and rear- ward on the seat to be sure that the seat adjusters have latched. Manual Seat Adjuster WARNING! Adjusting a seat while the vehicle is moving is dangerous.
Page 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 WARNING! • Actuating the recliner handle will allow the seat- back to swing (dump) forward on manual recliner seats. Do not stand or lean in front of the seat while actuating the handle. The seatback may swing forward and hit you causing injury.
Page 127: Head Restraints
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • You can be seriously, even fatally, injured riding in a seat with the seatback reclined. Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. If you ride in this position, the shoulder harness will no longer be restraining you.
Page 128: Power Seats - If Equipped
Adjusting Head Restraint Rear Head Restraints The outboard head restraints can be adjusted. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, press the large button, located on the base of the head restraint, and push downward on the head restraint.
Page 129 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE There are two power seat switches that are used to control the movement of the seat cushion and the seat- back. Power Seat Switches 1 — Power Seat Switch 2 — Power Seatback Switch Adjusting the sear forward or rearward The seat can be adjusted both forward and rearward.
Page 130 Reclining the seatback The angle of the seatback can be adjusted forward or rearward. Push the seatback switch forward or rearward, the seat will move in the direction of the switch. Release the switch when you have reached the desired position. WARNING! •...
Page 131: Power Lumbar - If Equipped
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Lumbar — If Equipped Vehicles equipped with power driver or passenger seats may be also be equipped with power lumbar. The power lumbar switch is located on the outboard side of the power seat.
Page 132 WARNING! (Continued) • Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.
Page 133 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The heated seats switch from HIGH to LOW and from LOW to OFF automatically, based on time and tempera- ture of the seat. The heated seats can operate on HIGH heat for as little as 4 minutes and up to 30 minutes before switching to LOW heat.
Page 134: Ventilated Seats - If Equipped
NOTE: • Once a heat setting is selected, heat will be felt within two to five minutes. • The engine must be running for the heated seats to operate. The heated seats switch from HIGH to LOW and from LOW to OFF automatically, based on time and tempera- ture of the seat.
Page 135: 40-20-40 Front Bench Seat - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Vehicles Equipped with Remote Start On models equipped with remote start, the drivers ventilated seat can be programmed to come on during a remote start. Refer to “Remote Starting System — If Equipped” in “Things to Know Before Starting Your Vehicle”...
Page 136: Setting Memory Positions And Linking Rke
Keyless Entry (RKE) transmitters can also be pro- grammed to recall the same positions when the UN- LOCK button is pressed. NOTE: The power lumbar option is not programmable with driver memory seats. Your vehicle was delivered with two RKE transmitters. One or both RKE transmitters can be linked to either memory position.
Page 137: Memory Position Recall
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE performed within 10 seconds if you desire to also use a RKE transmitter to recall memory positions. 8. Turn the ignition OFF and remove the key. 9. Press and release the LOCK button on one of the RKE transmitters.
Page 138: To Disable A Rke Transmitter Linked To Memory
To Disable a RKE Transmitter Linked to Memory 1. Turn the ignition switch to the OFF position and remove the key. 2. Press and release the memory SET button located on the driver’s seat. 3. Within 10 seconds, press and release the UNLOCK button on the RKE transmitter.
Page 139: Driver Easy Exit And Easy Entry Control
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver Easy Exit and Easy Entry Control This additional feature provides automatic driver’s seat positioning which will enhance driver mobility into and out of the vehicle. The seat cushion will move rearward approximately 2.5 in (60 mm) when the key is removed from the ignition switch.
Page 140 2. Reach into the opening beneath the center of the hood and push the safety latch lever from right to left to release it, before raising the hood. Safety Latch (1500 Series Shown) UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 CAUTION! To prevent possible damage, do not slam the hood to close it.
Page 141: Lights
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS The headlight switch is located on the left side of the instrument panel, next to the steering wheel. The head- light switch controls the operation of the headlights, parking lights, instrument panel lights, cargo lights and fog lights (if equipped).
Page 142: Headlights
Headlights To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is on the parking lights, taillights, license plate light and instrument panel lights are also turned on. To turn off the headlights, rotate the headlight switch back to the O (Off) position.
Page 143: Headlight Delay
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlight Delay To aid in your exit, your vehicle is equipped with a headlight delay that will leave the headlights on for approximately 90 seconds. This delay is initiated when the ignition is turned OFF while the headlight switch is on, and then the headlight switch is cycled off.
Page 144: Interior Lights
illuminate when the fog lights are on. The fog lights will turn off when the switch is pushed a second time, when the headlight switch is rotated to the off position, or the high beam is selected. Interior Lights Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the bottom of the switch) is rotated to the far right detent position, or if equipped, when the UNLOCK...
Page 145: Cargo Light
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Cargo Light The cargo lights are turned on by pressing on the cargo button. Cargo Light Switch The cargo lights will also turn on for approximately 30 seconds when a RKE transmitter UNLOCK button is pressed, as part of the Illuminated Entry feature.
Page 146: Daytime Running Lights - If Equipped
Daytime Running Lights — If Equipped The headlights on your vehicle will illuminate when the engine is started and the transmission is in any gear except PARK. This provides a constant Lights ON condition until the ignition is turned OFF. The lights illuminate at less than 50% of normal intensity.
Page 147: Windshield Wipers And Washers
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lane Change Assist Tap the lever up or down once, without moving beyond the detent, and the turn signal (right or left) will flash three times then automatically turn off. Flash-To-Pass You can signal another vehicle with your headlights by partially pulling the multifunction lever toward the steer- ing wheel.
Page 148: Windshield Washers
Windshield Wiper/Washer Switch Intermittent Wiper System The intermittent feature of this system was designed for use when weather conditions make a single wiping cycle, with a variable pause between cycles, desirable. For maximum delay between cycles, rotate the control knob into the upper end of the delay range.
Page 149: Mist Feature
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To prevent freeze-up of your windshield washer system in cold weather, select a solution or mixture that meets or exceeds the temperature range of your climate. This rating information can be found on most washer fluid containers.
Page 150: Driver Adjustable Pedals - If Equipped
Tilt Steering Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 WARNING! Do not adjust the steering column while driving. Adjusting the steering column while driving or driv- ing with the steering column unlocked, could cause the driver to lose control of the vehicle. Be sure the steering column is locked before driving your ve- hicle.
Page 151: Adjustment
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The adjustable pedal switch is located to the left side of the steering column. Adjustable Pedals Switch Adjustment 1. Position the driver’s seat so that you are at least 10 in (25.4 cm) away from the airbag, located in the center of the steering wheel.
Page 152: Heated Steering Wheel - If Equipped
WARNING! Do not adjust the pedals while the vehicle is moving. You could lose control and have an accident. Always adjust the pedals while the vehicle is parked. HEATED STEERING WHEEL — IF EQUIPPED The steering wheel contains a heating element that helps warm your hands in cold weather.
Page 153: Electronic Speed Control - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, ex- haustion, or other physical conditions must exer- cise care when using the steering wheel heater.
Page 154: To Activate
To Activate Push the ON/OFF button (located in the end of the lever) once and the cruise indicator light (located in the mes- sage window of the cluster) will illuminate showing that the Electronic Speed Control system is on. To turn the Electronic Speed Control system off, push the ON/OFF button a second time and both the Electronic Speed Control system and indicator will turn off.
Page 155: Varying The Speed Setting
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Varying The Speed Setting When the Electronic Speed Control is set, you can in- crease speed by pushing up and holding the RESUME ACCEL lever. If the lever is continually held in the RESUME ACCEL position, the set speed will continue to increase until the lever is released, then the new set speed will be established.
Page 156: Overhead Console - If Equipped
WARNING! Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your ve- hicle could go too fast for the conditions, and you could lose control and have an accident. Do not use Electronic Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.
Page 157 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE (RKE) transmitter, if equipped. These lights are also operated individually as reading lights by pressing on the corresponding lens. Front Courtesy/Reading Lights Rear Passenger Courtesy/Reading Light NOTE: The courtesy/reading lights will remain on until the switch is pressed a second time, so be sure they have been turned off before leaving the vehicle.
Page 158: Electrical Power Outlets
ELECTRICAL POWER OUTLETS The auxiliary 12 Volt (13 Amp) power outlets can provide power for in-cab accessories designed for use with the standard “cigar lighter” plug. The 12 Volt power outlets have a cap attached to the outlet indicating “12V DC”, together with either a key symbol or a battery symbol.
Page 159 158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Inside the upper lid of the center storage compartment — if equipped. Power Outlet — Upper Lid • Rear of the center console storage compartment — Crew Cab. Power Outlet — Rear Center Console The key symbol indicates that this outlet can supply power when the key is in the ON or ACC positions.
Page 160 WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. • Close the lid when not in use and while driving the vehicle.
Page 161: Power Inverter - If Equipped
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF EQUIPPED A removable ash receiver and cigar lighter are available. For vehicles with a bench seat the cupholder tray can be used to hold the ash receiver. Ash Receiver and Cigar Lighter (Bench Seat) 1 —...
Page 162 To avoid overloading the circuit, check the power ratings on electrical devices prior to using the inverter. Power Inverter Outlet UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 The power inverter switch is located on the switch bank below the Climate Controls.
Page 163: Cupholders
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! To avoid serious injury or death: • Do not use a three-prong adapter. • Do not insert any objects into the receptacles. • Do not touch with wet hands. • Close the lid when not in use. •...
Page 164: Front Instrument Panel Cupholders - Floor Storage Bin
Front Instrument Panel Cupholders — Floor Storage Bin For vehicles equipped with bucket seats two cupholders are located in the floor storage bin. Cupholders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Rear Cupholder — Crew Cab Crew Cab vehicles are equipped with rear cupholders located in the center armrest.
Page 165: Storage
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glove Box Storage The glove box is located on the passenger side of the instrument panel and features both an upper (if equipped) and lower storage area. Glove Box 1 — Upper Glove Box (If Equipped) 2 —...
Page 166: Door Storage
To open the lower glove box, pull on the handle to release the latch and lower the door. Lower Glove Box UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Door Storage Front Door Storage — If Equipped Storage areas and bottle holders (drivers side only) are located in the door trim panels.
Page 167: Center Storage Compartment - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Door Storage — Crew Cab Storage compartments are located in both the driver and passenger door trim panels. Rear Door Storage Center Storage Compartment — If Equipped The center storage compartment is located between the driver and passenger seats.
Page 168 WARNING! • This armrest is not a seat. Anyone seated on the armrest could be seriously injured during vehicle operation, or an accident. Only use the center seating position when the armrest is fully upright. • In an accident, the latch may open if the total weight of the items stored exceeds about 10 lbs (4.5 kg).
Page 169: Seatback Storage
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE With the upper lid closed, pull on the lower handle to open the lower storage bin. Lower Storage Bin Seatback Storage Located in the back of both the driver and passenger front seats are pockets that can be used for storage. Drivers Side Seatback Storage...
Page 170: Storage (Regular Cab)
Storage (Regular Cab) The storage bin is located behind the front seats and runs the length of the cab. Storage Bin UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 Storage and Seats (Crew Cab) The Crew Cab models provide additional storage under the rear seats.
Page 171: Plastic Grocery Bag Retainers (Regular Cab Models)
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Always lift the storage compartment lids by using the handle. Failure to lift the lids by using the handle can result in damage to the lids. Plastic Grocery Bag Retainers (Regular Cab Models) Retainer hooks which will hold plastic grocery bag handles are built into the back panel of the cab, behind the seats.
Page 172: Rear Window Features
REAR WINDOW FEATURES Rear Window Defroster The rear window defroster button is located on the climate control panel. Press this button to turn on the rear window defroster and the heated outside mirrors (if equipped). An indicator in the button will illuminate when the rear window defroster is on.
Page 173: Power Sliding Rear Window - If Equipped
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sliding Rear Window — If Equipped The switch for the power sliding rear window is located on the overhead console. Press the left side of the switch to open the glass and the right side of the switch to close the glass.
Page 174: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....176 Instrument Cluster — Base ....177 Instrument Cluster —...
Page 175 174 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 730N/430/430N (RER/RBZ/ RHB) CD/DVD/HDD/NAV — If Equipped . . . 210 Operating Instructions (Voice Command System) — If Equipped ....210 Operating Instructions (Uconnect™...
Page 176 Uconnect™ Multimedia (Satellite Radio) — If Equipped (REN/RER/RES Radios Only) ..240 System Activation ....240 Electronic Serial Number/Sirius Identification Number (ESN/SID) .
Page 177: Instrument Panel Features
176 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Headlight Switch 2 — Instrument Cluster 3 — Radio 4 — Upper Switch Bank 5 — Upper Glove Compartment 6 — Lower Glove Compartment 7 — 115v Power Inverter Outlet 8 —...
Page 178: Instrument Cluster - Base
UNDERSTANDING YOUR INSTRUMENT PANEL 177 INSTRUMENT CLUSTER — BASE...
Page 179: Instrument Cluster - Premium
178 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — PREMIUM...
Page 180: Instrument Cluster Descriptions
INSTRUMENT CLUSTER DESCRIPTIONS 1. Tachometer The Tachometer indicates engine speed in revolutions per minute. CAUTION! Do not operate the engine with the tachometer pointer at high RPM for extended periods. Engine damage may occur. 2. Turn Signal Indicators The arrow will flash with the exterior turn signal when the turn signal lever is operated.
Page 181 180 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Driving with a hot engine cooling system could damage your vehicle. If temperature gauge reads “H” pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range.
Page 182 If a problem is detected, the light will come on while the engine is running. Cycle the ignition key when the vehicle has completely stopped and the shift lever is placed in the PARK position, the light should turn off. If the light remains lit with the engine running, your vehicle will usually be drivable;...
Page 183 182 UNDERSTANDING YOUR INSTRUMENT PANEL 10. TOW/HAUL The TOW HAUL button is located on the center stack switch bank. This light will illumi- nate when TOW HAUL mode is selected 11. Vehicle Security Light — If Equipped This light will flash at a fast rate for approxi- mately 15 seconds, when the vehicle security alarm is arming, and then will flash slowly until the vehicle is disarmed.
Page 184 service, so that you can be sure that it is properly reset, or that the door jamb sticker is accurate if the odometer must be reset at zero. The two trip odometers show individual trip mileage. To switch from odometer to trip odometers, press and release the TRIP ODOMETER button.
Page 185 184 UNDERSTANDING YOUR INSTRUMENT PANEL the TRIP button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). noFUSE If the vehicle diagnostic system determines that the Ignition Off Draw (IOD) fuse is improperly installed, or...
Page 186 NOTE: If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure. 15. Engine Temperature Warning Light This light warns of an overheated engine condi- tion. As temperatures rise and the gauge ap- proaches H, this indicator will illuminate and a single chime will sound after reaching a set threshold.
Page 187 186 UNDERSTANDING YOUR INSTRUMENT PANEL 17. Low Fuel Light When the fuel level reaches approximately 3.0 gal (11.0 L) this light will turn on, and remain on until fuel is added. For vehicles equipped with a premium cluster this indi- cator will display in the Electronic Vehicle Information Center (EVIC).
Page 188 21. Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the Anti-lock Brake System reservoir.
Page 189 188 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have an accident. Have the vehicle checked immediately. Vehicles equipped with the ABS, are also equipped with Electronic Brake Force Distribution (EBD).
Page 190 Center (EVIC). Refer to ”Electronic Vehicle Information Center (EVIC) — If Equipped” for further information. 23. Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic (OBDII) system which monitors the emissions and engine control sys- tem.
Page 191 190 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants or wood or cardboard, etc. This could result in death or serious injury to the driver, occu- pants or others.
Page 192 27. Transmission Temperature Warning Light This light indicates that there is excessive trans- mission fluid temperature that might occur with severe usage such as trailer towing. It may also occur when operating the vehicle in a high torque converter slip condition, such as 4-wheel-drive operation (e.g., snow plowing, off- road operation).
Page 193: Electronic Vehicle Information Center (Evic) - If Equipped
192 UNDERSTANDING YOUR INSTRUMENT PANEL belt remains unbuckled, the seat belt reminder light will flash or remain on continuously. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” for further information. 29. Charging System Light This light shows the status of the electrical charg- ing system.
Page 194 Electronic Vehicle Information Center (EVIC) NOTE: The compass on your vehicle is self-calibrating, eliminating the need to manually calibrate the compass. UNDERSTANDING YOUR INSTRUMENT PANEL 193 This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel.
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL Steering wheel EVIC control button, as it appears on the left side of the steer- ing wheel. Press and release the UP button to scroll up- ward through the main menus (DTE, mi/gal, System Info, Messages, Units, Setup) and sub menus.
Page 196: Electronic Vehicle Information Center (Evic) Displays
Electronic Vehicle Information Center (EVIC) Displays When the appropriate conditions exist, the EVIC displays the following messages: • Left front turn signal lamp out • Right front turn signal lamp out • Left rear turn signal lamp out • Right rear turn signal lamp out •...
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL • Turn Signal On • RKE Battery Low • LOW WASHER FLUID • Oil Change Due > Dealer Info • Park Assist On • Park Assist Off • Warning Object Detected • Left Front Turn Signal Light Out •...
Page 198 • Memory System Unavailable — Seatbelt Buckled • Memory 1 Profile Recall • Memory 2 Profile Recall • Adjustable Pedals Unavailable — Vehicle in Reverse • Adjustable Pedals Unavailable — Cruise Engaged • To Tow Vehicle Safely, Read Neutral Shift Procedure in Owners Manual EVIC Warning Lights •...
Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control Light This light will turn on when the electronic speed control is ON. • Electronic Throttle Control (ETC) Light This light informs you of a problem with the Electronic Throttle Control (ETC) system. The light will come on when the ignition is first turned ON and remain on briefly as a bulb check.
Page 200 shift the transmission into NEUTRAL and idle the ve- hicle. If the temperature reading does not return to normal, turn the engine off immediately and call for service. Refer to “If Your Engine Overheats” in “What To Do In Emergencies” for more information. •...
Page 201: Distance To Empty (Dte)
200 UNDERSTANDING YOUR INSTRUMENT PANEL scheduled oil change interval. The engine oil change indicator system is duty-cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the ON position.
Page 202: Evic Average Fuel Economy
significant amount of fuel to the vehicle will turn off the LOW FUEL text and a new DTE value will display. EVIC Average Fuel Economy Shows the average fuel economy since the last reset. When the fuel economy is reset, the display will read “RESET”...
Page 203: Vehicle Info
202 UNDERSTANDING YOUR INSTRUMENT PANEL To Reset The Display Reset will only occur while a resettable function is being displayed. Press and release the ODOMETER/TRIP ODOMETER button once to clear the resettable function being displayed. Vehicle Info (Customer Information Features) Press and release the UP or DOWN button until “Vehicle Info”...
Page 204: Compass / Temperature Display
Compass / Temperature Display The compass readings indicate the direction the vehicle is facing. The EVIC will display one of eight compass readings and the outside temperature. NOTE: • The system will display the last known outside tem- perature when starting the vehicle and may need to be driven several minutes before the updated tempera- ture is displayed.
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, etc. Manual Compass Calibration If the compass appears erratic and the CAL indicator does not appear in the EVIC display, you must put the compass into the Calibration Mode manually, as follows: 1.
Page 206: Customer-Programmable Features (System Setup)
Compass Variance Map 1. Turn the ignition switch ON. 2. Press the UP or DOWN button until the System Setup (Customer-Programmable Features) menu is reached, then press the SELECT button. UNDERSTANDING YOUR INSTRUMENT PANEL 205 3. Press the DOWN button until the “Compass Variance” message is displayed in the EVIC, then press the SELECT button.
Page 207 206 UNDERSTANDING YOUR INSTRUMENT PANEL Use the UP or DOWN button to display one of the following choices. Select Language When in this display you may select one of five lan- guages for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the UP or DOWN button while in this display and scroll through the language choices.
Page 208 feature showing the system has been activated, or the check-mark is removed showing the system has been deactivated. Remote Unlock Sequence When Driver Door 1st Press is selected, only the driver’s door will unlock on the first press of the RKE transmitter UNLOCK button.
Page 209 208 UNDERSTANDING YOUR INSTRUMENT PANEL Horn With Remote Lock When this feature is selected, a short horn sound will occur when the RKE transmitter LOCK button is pressed. This feature may be selected with or without the Flash Lamps with Lock feature. To make your selection, press and release the SELECT button until a check-mark ap- pears next to the feature showing the system has been activated or the check-mark is removed, showing the...
Page 210 Key-Off Power Delay When this feature is selected, the power window switches, radio, hands-free system (if equipped), DVD video system (if equipped), power sunroof (if equipped), and power outlets will remain active for up to 10 minutes after the ignition switch is turned OFF. Opening a vehicle door will cancel this feature.
Page 211: Media Center 730N/430/430N (Rer/Rbz/Rhb) Cd/Dvd/Hdd/Nav - If Equipped
210 UNDERSTANDING YOUR INSTRUMENT PANEL make your selection, press and release the SELECT button until a check-mark appears next to the feature showing the system has been activated or the check-mark is removed, showing the system has been deactivated. Remote Start Comfort Sys. When this feature is selected and the remote start is activated, the heated steering wheel and driver heated seat features will automatically turn on in cold weather.
Page 212: Media Center 130 (Sales Code Res)
MEDIA CENTER 130 (SALES CODE RES) NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 130 (RES) UNDERSTANDING YOUR INSTRUMENT PANEL 211 Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 213 212 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 214 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
Page 215: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
214 UNDERSTANDING YOUR INSTRUMENT PANEL SET 2 in both AM and FM. This allows a total of 12 AM and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice.
Page 216 If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the track number, and index time in minutes and seconds.
Page 217: Notes On Playing Mp3 Files
216 UNDERSTANDING YOUR INSTRUMENT PANEL the current selection. Pressing and holding the SEEK button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold the FF (Fast Forward) button and the CD player will begin to fast forward until FF is released, or...
Page 218 Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 219 218 UNDERSTANDING YOUR INSTRUMENT PANEL When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rate.
Page 220: Operation Instructions - Auxiliary Mode
To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option before writing to the disc. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device, such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the...
Page 221: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)
220 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 WITH SATELLITE RADIO (SALES CODE RES+RSC) NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 130 (RES/RSC) Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 222 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 223 222 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save time change.
Page 224 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
Page 225 224 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type 16-Digit Character Display Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Program Type Inform Top 40 Jazz Weather News By pressing the SEEK button when the Music Type icon...
Page 226 hours, press the TUNE/SCROLL control knob to set the minutes. The minutes will begin to blink. Adjust the minutes using the right side TUNE/SCROLL control knob. Press the TUNE/SCROLL control knob to save time change. AM/FM Button Press the button to select either AM or FM mode. SET/RND Button —...
Page 227: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
226 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions — CD MODE for CD and MP3 Audio Play NOTE: • The ignition switch must be in the ON or ACC position to operate the radio. • This radio is capable of playing compact discs (CD), recordable compact discs (CD-R), rewritable compact discs (CD-RW), compact discs with MP3 tracks and multisession compact discs with CD and MP3 tracks.
Page 228 EJECT Button - Ejecting a CD Press the EJECT button to eject the CD. If you have ejected a disc and have not removed it within 10 seconds, it will be reloaded. If the CD is not removed, the radio will reinsert the CD but will not play it. A disc can be ejected with the radio and ignition OFF.
Page 229: Notes On Playing Mp3 Files
228 UNDERSTANDING YOUR INSTRUMENT PANEL Press the SET/RND button a second time to stop Ran- dom Play. Notes On Playing MP3 Files The radio can play MP3 files; however, acceptable MP3 file recording media and formats are limited. When writing MP3 files, pay attention to the following restric- tions.
Page 230 Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal CD audio tracks and computer files (including MP3 files). Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of multisession for CD audio or MP3 playback may result in longer disc loading times.
Page 231: List Button (Cd Mode For Mp3 Play)
230 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files When a medium containing MP3 data is loaded, the radio checks all files on the medium. If the medium contains a lot of folders or files, the radio will take more time to start playing the MP3 files.
Page 232: Uconnect™ Multimedia (Satellite Radio) - If Equipped
Press and hold the INFO button again for three seconds to return to elapsed time display. Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack which allows the user to plug in a portable device such as an MP3 player or cassette player and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 233 232 UNDERSTANDING YOUR INSTRUMENT PANEL radio system in your vehicle. Sirius will supply a wel- come kit that contains general information, including how to setup your on-line listening account. For further information, call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com, or at www- .siriuscanada.ca for Canadian residents.
Page 234 Reception Quality Satellite reception may be interrupted due to one of the following reasons: • The vehicle is parked in an underground parking structure or under a physical obstacle. • Dense tree coverage may interrupt reception in the form of short audio mutes. •...
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next channel in the direction of the arrows. TUNE Control (Rotary) Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the channel.
Page 236: Universal Consumer Interface (Uci) 0.5 - If Equipped
selected within five seconds after pressing the SET but- ton, the channel will continue to play but will not be stored into pushbutton memory. You may add a second channel to each pushbutton by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window.
Page 237: Connecting The Ipod
236 UNDERSTANDING YOUR INSTRUMENT PANEL UCI supports Mini, 4G, Photo, Nano, 5G iPod iPhone devices. Some iPod software versions may not fully support the UCI features. Please visit Apple’s website for software updates. NOTE: • If the radio has a USB port, connecting an iPod to this port does not play the media.
Page 238: Controlling The Ipod Using Radio Buttons
• The iPod can be controlled using the radio buttons to Play, Browse, and List the iPod contents. • The iPod battery charges when plugged into the UCI connector (if supported by the specific iPod device) Controlling The iPod Using Radio Buttons To get into the UCI (iPod ) mode and access a connected iPod , press the “AUX”...
Page 239: List Or Browse Mode
238 UNDERSTANDING YOUR INSTRUMENT PANEL jump to the previous track in the list; pressing this button at any other time in the track, it will jump to the beginning of the track. Pressing the SEEK >> button during play mode, it will jump to the next track in the list.
Page 240 the track detail on the radio display. Once the track to be played is highlighted on the radio display, press the TUNE control knob to select and start playing the track. Turning the TUNE control knob fast will scroll through the list faster. During fast scroll, a slight delay in updating the information on the radio display may be noticed.
Page 241: Uconnect™ Multimedia (Satellite Radio) - If Equipped (Ren/Rer/Res Radios Only)
240 UNDERSTANDING YOUR INSTRUMENT PANEL • MUSIC TYPE button: The MUSIC TYPE button is another shortcut button to the genre listing on your iPod . CAUTION! • Leaving the iPod (or any supported device) any- where in the vehicle in extreme heat or cold can alter the operation or damage the device.
Page 242: Electronic Serial Number/Sirius Identification Number (Esn/Sid)
information, call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com, or at www- .siriuscanada.ca for Canadian residents. Electronic Serial Number/Sirius Identification Number (ESN/SID) Please have the following information available when calling: 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID).
Page 243: Reception Quality
242 UNDERSTANDING YOUR INSTRUMENT PANEL bikes should be placed as far rearward as possible, within the loading design of the rack. Do not place items directly on or above the antenna. Reception Quality Satellite reception may be interrupted due to one of the following reasons: •...
Page 244 INFO Button Pressing the INFO button will cycle the display informa- tion between Artist, Song Title, and Composer (if avail- able). Also, pressing and holding the INFO button for an additional three seconds will make the radio display the Song Title all of the time (press and hold again to return to normal display).
Page 245: Operating Instructions - Uconnect™ Phone (If Equipped)
244 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 246: Steering Wheel Audio Controls - If Equipped
STEERING WHEEL AUDIO CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. Remote Sound System Controls (Back View Of Steering Wheel) UNDERSTANDING YOUR INSTRUMENT PANEL 245 The right hand control is a rocker type switch with a pushbutton in the center.
Page 247: Cd Player
246 UNDERSTANDING YOUR INSTRUMENT PANEL The button located in the center of the left hand control will tune to the next pre-set station that you have programmed in the radio pre-set pushbuttons. CD Player Pressing the top of the switch once will go to the next track on the CD.
Page 248: Radio Operation And Cellular Phones
NOTE: If you experience difficulty in playing a particu- lar disc, it may be damaged (i.e., scratched, reflective coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding. Try a known good disc before considering disc player service. RADIO OPERATION AND CELLULAR PHONES Under certain conditions, the cellular phone being on in your vehicle can cause erratic or noisy performance from...
Page 249: Manual Heating And Air Conditioning System
248 UNDERSTANDING YOUR INSTRUMENT PANEL Manual Heating and Air Conditioning System The controls for the manual heating and air conditioning system in this vehicle consist of a series of outer rotary dials and inner push knobs. These comfort controls can be set to obtain desired interior conditions.
Page 250 temperatures. Rotating the knob clockwise, into the red area, indicates warmer temperatures. NOTE: If your air conditioning performance seems lower than expected, check the front of the A/C con- denser (located in front of the radiator), for an accumu- lation of dirt or insects. Clean with a gentle water spray from behind the radiator and through the condenser.
Page 251 250 UNDERSTANDING YOUR INSTRUMENT PANEL Mix Mode Air is directed through the floor, defrost and side window demist outlets. This setting works best in cold or snowy conditions that require extra heat at the windshield. This setting is good for maintaining comfort, while reducing moisture on the windshield.
Page 252 • In cold or damp weather, the use of the Recirculation mode will cause windows to fog on the inside because of moisture buildup inside the vehicle. For maximum defogging, select the Outside Air position. • The A/C can be deselected manually without disturb- ing the mode control selection by pressing the A/C button.
Page 253: Automatic Temperature Control (Atc) - If Equipped
252 UNDERSTANDING YOUR INSTRUMENT PANEL MAX A/C For maximum cooling, when MAX A/C is selected the A/C is turned on automatically and the air is recircu- lated. NOTE: A/C cannot be deselected when in MAX A/C position. The LED will blink three times if the A/C button is pushed.
Page 254 Automatic Temperature Control (ATC) Panel 1 - Blower Control 9 - DEFROST 2 - Left Temperature Up 10 - Right Temperature Down 3 - SYNC Indicator 11 - A/C 4 - Left Temperature Indicator 12 - A/C Indicator 5 - Right Temperature 13 - SYNC Temperature Button Indicator 6 - DELAY Indicator...
Page 255 254 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • It is not necessary to move the temperature settings for cold or hot vehicles. The system automatically adjusts the temperature, mode and fan speed to provide comfort as quickly as possible. • The temperature can be displayed in U.S. or Metric units by selecting the US/M customer-programmable feature.
Page 256 selected. This allows the front occupants to control the volume of air circulated in the vehicle and cancel the Auto mode. The operator can also select the direction of the airflow by selecting one of the following positions. Panel Mode Air comes from the outlets in the instrument panel.
Page 257: Summer Operation
256 UNDERSTANDING YOUR INSTRUMENT PANEL The Air Conditioning (A/C) button allows the operator to manually activate or deactivate the air conditioning system. When in A/C mode and the ATC is set to a cool temperature, dehumidified air flows through the air outlets. If Economy mode is desired, press the A/C button to turn off the A/C mode in the ATC display and deactivate the A/C system.
Page 258: Winter Operation
glycol antifreeze coolant and 50% water is recommended. Refer to “Maintenance Procedures” in “Maintaining Your Vehicle” for proper coolant selection. Winter Operation To ensure the best possible heater and defroster perfor- mance, make sure the engine cooling system is function- ing properly and the proper amount, type, and concen- tration of coolant is used.
Page 259: Operating Tips
258 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Tips...
Page 260 STARTING AND OPERATING CONTENTS Starting Procedures ....263 Normal Starting ..... 263 Automatic Transmission .
Page 261 260 STARTING AND OPERATING Electronically Shifted Transfer Case (Four-Position Switch) – If Equipped ..278 Shifting Procedure ....282 Limited-Slip Differential .
Page 262 Replacement Tires ....311 Supplemental Tire Pressure Information — If Equipped ......313 Tire Chains .
Page 263 262 STARTING AND OPERATING Towing Tips ......339 Snowplow ......340 Before Plowing .
Page 264: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belt. The starter should not be operated for more than 15- second intervals. Waiting a few seconds between such intervals will protect the starter from overheating. WARNING! Never leave children alone in a vehicle.
Page 265: If Engine Fails To Start
264 STARTING AND OPERATING If Engine Fails To Start If the engine fails to start after you have followed the “Normal Starting” procedure, it may be flooded. Push the accelerator pedal all the way to the floor and hold it there while cranking the engine.
Page 266: After Starting
If the engine has been flooded, it may start to run, but not have enough power to continue running when the key fob is released. If this occurs, continue cranking with the accelerator pedal pushed all the way to the floor. Release the accelerator pedal and the key fob once the engine is running smoothly.
Page 267: Automatic Transmission
266 STARTING AND OPERATING AUTOMATIC TRANSMISSION CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: • Shift into PARK only after the vehicle has come to a complete stop. • Shift into or out of REVERSE only after the vehicle has come to a complete stop and the engine is at idle speed.
Page 268: Starting And Operating 267
WARNING! (Continued) • Unintended movement of a vehicle could injure those in and near the vehicle. As with all vehicles, you should never exit a vehicle while the engine is running. Before exiting a vehicle, you should always shift the transmission into PARK, remove the key fob from the ignition, and apply the parking brake.
Page 269: Five-Speed Automatic Transmission (545Rfe) - 5.7L Engine Only
268 STARTING AND OPERATING 3. Firmly set the parking brake. 4. Press and maintain firm pressure on the brake pedal. 5. Using the screwdriver or other suitable tool, press and hold the override tab through the access port (ringed circle) on the bottom of the steering column. Interlock Manual Override 6.
Page 270 column shift lever down (-) or up (+) to select the desired top gear. For example, if the driver shifts the transmission into 3 (third gear), the transmission will never shift above third gear, but can shift down to 2 (second gear) or 1 (first gear), when needed.
Page 271 270 STARTING AND OPERATING the transmission and display 5 (ERS 5 is the same as normal fourth gear). Another tap down (-) will shift the transmission down to ERS 4 (direct gear). To exit ERS mode, press and hold the top of the switch/ shift lever in the (+) direction until “D”...
Page 272 WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage. • Your vehicle could move and injure you and others if it is not completely in PARK.
Page 273 272 STARTING AND OPERATING Overdrive Operation The Overdrive automatic transmission contains an elec- tronically controlled fourth and fifth gear (Overdrive). The transmission will automatically shift from DRIVE to Overdrive if the following conditions are present: • the shift lever is in DRIVE; •...
Page 274 performance and reduce the potential for transmission overheating or failure due to excessive shifting. When operating in the “TOW/HAUL” mode, fifth gear is disabled and 2-3 and 3-4 shift patterns are modified. TOW/HAUL Switch STARTING AND OPERATING 273 Shifts into Overdrive (normal fourth gear) are allowed during steady cruise (for improved fuel economy) and automatic closed-throttle downshifts to direct gear and a special underdrive gear (refer to “Electronic Range Se-...
Page 275: Four-Wheel Drive Operation - If Equipped
274 STARTING AND OPERATING the upper gears. When the vehicle speed drops or during acceleration when the transmission downshifts to second gear, the clutch automatically disengages. NOTE: • The torque converter clutch will not engage until the transmission fluid and engine coolant (antifreeze) are warm [usually after 1 to 3 miles (1.6 to 4.8 km) of driving].
Page 276 • Four-wheel drive low range (4L) This transfer case is intended to be driven in the 2H position for normal street and highway conditions such as dry, hard surfaced roads. When additional traction is required, the 4H and 4L positions can be used to lock the front and rear drive- shafts together and force the front and rear wheels to rotate at the same speed.
Page 277 276 STARTING AND OPERATING Because four-wheel drive provides improved traction, there is a tendency to exceed safe turning and stopping speeds. Do not go faster than road conditions permit. NOTE: Delayed shifts out of four-wheel drive may be experienced due to uneven tire wear, low or uneven tire pressures, excessive vehicle loading, or cold tempera- tures.
Page 278: Shifting Procedure - Manually Shifted Transfer Case
Four-Wheel Drive Low Range - This range locks the front and rear driveshafts together forcing the front and rear wheels to rotate at the same speed. Additional traction and maximum pulling power for loose, slippery road surfaces only. Do not exceed 25 mph (40 km/h). Shifting Procedure –...
Page 279: Transfer Case Position Indicator Light
278 STARTING AND OPERATING method is with the vehicle rolling 2 to 3 mph (3 to 5 km/h). Avoid attempting to engage or disengage 4L with the vehicle moving faster than 2 to 3 mph (3 to 5 km/h). • Do not attempt to shift into or from 4L while the transmission is in gear.
Page 280 • Neutral (NEUTRAL) This electronically shifted transfer case is designed to be driven in the two-wheel drive position (2WD) for normal street and highway conditions on dry, hard surfaced roads. When additional traction is required, the transfer case 4WD LOCK and 4WD LOW positions can be used to lock the front and rear driveshafts together, forcing the front and rear wheels to rotate at the same speed.
Page 281 280 STARTING AND OPERATING If One Or More Shift Conditions Are Not Met: 1. The indicator light for the current position will remain 2. The newly selected position indicator light will con- tinue to flash. 3. The transfer case will not shift. NOTE: Before retrying a selection, make certain that all the necessary requirements for selecting a new transfer case position have been met.
Page 282 Proper operation of four-wheel drive vehicles depends on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the transfer case. Because four-wheel drive provides improved traction, there is a tendency to exceed safe turning and stopping speeds.
Page 283: Shifting Procedure
282 STARTING AND OPERATING Neutral - This range disengages both the front and rear driveshafts from the powertrain. To be used for flat towing behind another vehicle. Refer to “Recreational Towing” in Starting and Operating” for further information. Shifting Procedure NOTE: •...
Page 284 NOTE: The four-wheel drive system will not allow shifts between 2WD/4WD LOCK if the front and/or rear wheels are spinning (no traction). In this situation, the selected position indicator light will flash and the origi- nal position indicator light will remain ON. At this time, reduce speed and stop spinning the wheels to complete the shift.
Page 285: Limited-Slip Differential
284 STARTING AND OPERATING NOTE: • If Steps 1 or 2 of either the Preferred or Alternate Procedure are not satisfied prior to attempting the shift, then the desired position indicator light will flash continuously while the original position indicator light is ON, until all requirements have been met.
Page 286: Driving On Slippery Surfaces
Care should be taken to avoid sudden accelerations when both rear wheels are on a slippery surface. This could cause both rear wheels to spin, and allow the vehicle to slide sideways on the crowned surface of a road or in a turn.
Page 287: Flowing/Rising Water
286 STARTING AND OPERATING Flowing/Rising Water WARNING! Do not drive on or across a road or path where water is flowing and/or rising (as in storm run-off). Flow- ing water can wear away the road or path’s surface and cause your vehicle to sink into deeper water. Furthermore, flowing and/or rising water can carry your vehicle away swiftly.
Page 288 CAUTION! (Continued) • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission, axle, etc.) for signs of contamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 289: Power Steering
288 STARTING AND OPERATING POWER STEERING The standard power steering system will give you good vehicle response and increased ease of maneuverability in tight spaces. The system will provide mechanical steering capability if power assist is lost. If for some reason the power assist is interrupted, it will still be possible to steer your vehicle.
Page 290: Power Steering Fluid Check
Power Steering Fluid Check Checking the power steering fluid level at a defined service interval is not required. The fluid should only be checked if a leak is suspected, abnormal noises are apparent, and/or the system is not functioning as antici- pated.
Page 291 290 STARTING AND OPERATING The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully. To release the parking brake, pull the parking brake release handle.
Page 292 The parking brake should always be applied whenever the driver is not in the vehicle. WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons. A child or others could be seriously or fatally injured.
Page 293: Brake System
292 STARTING AND OPERATING BRAKE SYSTEM If power assist is lost for any reason (for example, repeated brake applications with the engine off), the brakes will still function. However, you will experience a substantial increase in braking effort to stop the vehicle. If either the front or rear hydraulic system loses normal braking capability, the remaining system will still func- tion with some loss of overall braking effectiveness.
Page 294 with a separate computer to modulate hydraulic pressure to prevent wheel lockup and help avoid skidding on slippery surfaces. The system’s pump motor runs during an ABS stop to provide regulated hydraulic pressure. The pump motor makes a low humming noise during operation. This is normal.
Page 295: Tire Safety Information
294 STARTING AND OPERATING WARNING! (Continued) • The Anti-Lock Brake System (ABS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase braking or steering efficiency beyond that afforded by the condition of the vehicle brakes and tires or the traction afforded.
Page 296 NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 297 296 STARTING AND OPERATING Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
Page 298 Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 299: Tire Identification Number (Tin)
298 STARTING AND OPERATING Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire.
Page 300: Tire Terminology And Definitions
Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 301: Tire Loading And Tire Pressure
300 STARTING AND OPERATING Tire Loading and Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire Placard Location...
Page 302 This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear, and spare tires.
Page 303 302 STARTING AND OPERATING 2. Determine the combined weight of the driver and passengers that will be riding in your vehicle. 3. Subtract the combined weight of the driver and pas- sengers from XXX lbs or XXX kg. 4. The resulting figure equals the available amount of cargo and luggage load capacity.
Page 304 STARTING AND OPERATING 303...
Page 305: Tires - General Information
304 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 306: Tire Inflation Pressures
WARNING! (Continued) • Always drive with each tire inflated to the recom- mended cold tire inflation pressure. Economy Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement.
Page 307 306 STARTING AND OPERATING Inflation pressures specified on the placard are always “cold tire inflation pressure.” Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after a three hour period.
Page 308 STARTING AND OPERATING 307 4500/5500 Tire Inflation...
Page 309 308 STARTING AND OPERATING When adjusting inflation pressure to a tire and wheel assembly mounted on a vehicle, use a Remote Mount Automatic Inflation Kit or see your authorized dealer. NOTE: Never attempt to re-inflate a tire and wheel assembly which has been run flat or is extremely under- inflated without first removing the tire from the wheel assembly for inspection.
Page 310: Radial Ply Tires
Radial Ply Tires WARNING! Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle poorly. The instability could cause an accident result- ing in serious injury or death. Always use radial ply tires in sets of four (or six, in case of trucks with dual rear wheels).
Page 311: Tread Wear Indicators
310 STARTING AND OPERATING Tread Wear Indicators Tread wear indicators are in the original equipment tires to help you in determining when your tires should be replaced. 1 — Worn Tire 2 — New Tire These indicators are molded into the bottom of the tread grooves.
Page 312: Replacement Tires
WARNING! Tires and spare tire should be replaced after six years, regardless of the remaining tread. Failure to follow this warning can result in sudden tire failure. You could lose control and have an accident resulting in serious injury or death. Keep dismounted tires in a cool, dry place with as little exposure to light as possible.
Page 313 312 STARTING AND OPERATING WARNING! • Do not use a tire, wheel size or rating other than that specified for your vehicle. Some combinations of unapproved tires and wheels may change sus- pension dimensions and performance characteris- tics, resulting in changes to steering, handling, and braking of your vehicle.
Page 314: Supplemental Tire Pressure Information - If Equipped
SUPPLEMENTAL TIRE PRESSURE INFORMATION — IF EQUIPPED A light load vehicle condition is defined as two passen- gers [150 lbs (68 kg) each] plus 200 lbs (91 kg) of cargo. Cold tire inflation pressures for a lightly loaded vehicle will be found on the face of the driver’s door. TIRE CHAINS Use “Class U”...
Page 315 314 STARTING AND OPERATING CAUTION! (Continued) • Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage. Always use the lower sug- gested operating speed of the chain manufacturer if different than the speed recommended by the manufacturer.
Page 316: Snow Tires
SNOW TIRES Snow tires should be of the same size and type construc- tion as the front tires. Consult the manufacturer of the snow tire to determine any maximum vehicle speed requirement associated with the tire. These tires should always be operated at the vehicle maximum capacity inflation pressures under any load condition.
Page 317: Dual Rear Wheels
316 STARTING AND OPERATING Refer to “Maintenance Schedule” for the proper mainte- nance intervals. More frequent rotation is permissible if desired. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed. Tire Rotation NOTE: On Canadian vehicles only, if your vehicle is equipped with All-Season type tires on the front and On/Off Road type tires mounted on the rear, do not use a front to back rotation pattern.
Page 318: Fuel Requirements
To check if tires are even, lay a straight edge across all four tires. The straight edge should touch all the tires. CAUTION! 4500/5500 Dual Rear Tires have only one approved direction of rotation. This is to accommodate the asymmetrical design (tread pattern) of the On/Off road tire.
Page 319: Reformulated Gasoline
318 STARTING AND OPERATING Over 40 auto manufacturers worldwide have issued and endorsed consistent gasoline specifications (the World- wide Fuel Charter, WWFC) to define fuel properties necessary to deliver enhanced emissions, performance and durability for your vehicle. We recommend the use of gasolines that meet the WWFC specifications if they are available.
Page 320: E-85 Usage In Non-Flex Fuel Vehicles
E-85 Usage In Non-Flex Fuel Vehicles Non-FFV vehicles are compatible with gasoline contain- ing 10% ethanol (E10). Gasoline with higher ethanol content may void the vehicle’s warranty. If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, the engine will have some or all of these symptoms: •...
Page 321: Materials Added To Fuel
320 STARTING AND OPERATING allowed in the United States. MMT is prohibited in Federal and California reformulated gasoline. Materials Added To Fuel All gasolines sold in the United States are required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and would result in unnecessary cost.
Page 322: Carbon Monoxide Warnings
CAUTION! (Continued) • The use of fuel additives which are now being sold as octane enhancers is not recommended. Many of these products contain high concentra- tions of methanol. Fuel system damage or vehicle performance problems resulting from the use of such fuels or additives is not the responsibility of the manufacturer.
Page 323: Adding Fuel
322 STARTING AND OPERATING WARNING! (Continued) • Guard against carbon monoxide with proper maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly. Until repaired, drive with all side windows fully open. ADDING FUEL The fuel tank filler tube has a restricting door about 2 in (50 mm) inside the opening.
Page 324: Loose Fuel Filler Cap Message
WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank is being filled. • Never add fuel to the vehicle when the engine is running. This is in violation of most state and federal fire regulations and may cause the MIL to turn on.
Page 325: Vehicle Loading
324 STARTING AND OPERATING VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or pillar. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 326 Tire Size The tire size on the Label represents the actual tire size on your vehicle. Replacement tires must be equal to the load capacity of this tire size. Rim Size This is the rim size that is appropriate for the tire size listed.
Page 327: Trailer Towing
326 STARTING AND OPERATING Improper weight distributions can have an adverse effect on the way your vehicle steers and handles and the way the brakes operate. CAUTION! Do not load your vehicle any heavier than the GVWR or the maximum front and rear GAWR. If you do, parts on your vehicle can break, or it can change the way your vehicle handles.
Page 328 The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be supported by the scale. Gross Combination Weight Rating (GCWR) The GCWR is the total permissible weight of your vehicle and trailer when weighed in combination.
Page 329 328 STARTING AND OPERATING that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling. Weight-Carrying Hitch A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or some other connecting point of the truck.
Page 330: Trailer Hitch Classification
Fifth-Wheel Hitch The fifth-wheel hitch is a special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed. It connects a vehicle and fifth-wheel trailer with a coupling king pin. Gooseneck Hitch The gooseneck hitch employs a pivoted coupling arm which attaches to a ball mounted in the bed of a pickup truck.
Page 331: Trailer Towing Weights
• http:// www.dodge.com/bodybuilder. • http:// www.dodge.ca (Canada). Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the GTW on the tow hitch of your vehicle.
Page 332: Towing Requirements
Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer • The weight of any other type of cargo or equipment put in or on your vehicle • The weight of the driver and all passengers. NOTE: Remember that everything put into or on the trailer adds to the load on your vehicle.
Page 333 332 STARTING AND OPERATING WARNING! Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: • Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 334 WARNING! (Continued) 2. GTW 3. GAWR 4. Trailer tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements –...
Page 335 334 STARTING AND OPERATING • An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. •...
Page 336 NOTE: This module has been designed and verified for electric trailer brakes. To determine the type of brakes on your trailer, check with your trailer manufacturer or dealer. 1 — GAIN/Brake Output Power Display 2 — Manual Brake Control Lever 3 —...
Page 337 336 STARTING AND OPERATING lever is activated while the brake is also applied, the greater of the two inputs determines the power sent to the trailer brakes. The trailer and the vehicle’s brake lamps will come on when either vehicle braking or manual trailer brakes are applied.
Page 338 1. Make sure the trailer brakes are in good working condition, functioning normally, and properly adjusted. See your trailer dealer if necessary. 2. Hook up the trailer and make the electrical connec- tions according to the trailer manufacturer’s instructions. 3. When a trailer with electric brakes is plugged in, the GAIN setting will illuminate.
Page 339 338 STARTING AND OPERATING CAUTION! The ITBM module has been designed and verified for electric trailer brakes. Connecting a trailer that is not compatible with the ITBM system may result in reduced or complete loss of trailer braking. There may be a increase in stopping distance or trailer instability which could result in damage to your vehicle, trailer, or other property.
Page 340: Towing Tips
WARNING! Any work done to the vehicle’s electrical system or wiring should be performed by a qualified automo- tive technician. If done improperly it may cause damage to the electrical system wiring and could result in serious or fatal injury. Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer up in an area away from heavy...
Page 341: Snowplow
NOTE: Before installation of a snowplow it is highly recommended that the owner/installer obtain and follow the recommendations contained within the current Dodge Body Builders Guide. See your authorized dealer, installer or snowplow manufacturer for this information. There are unique electrical systems that must be con- nected to properly assure operator safety and prevent overloading vehicle systems.
Page 342: Before Plowing
• Check that snowplow lighting is connected and func- tioning properly. Snowplow Prep Package Model Availability For Information about snowplow applications visit www.dodge.com or refer to the current Dodge Body Builders Guide. 1. The maximum number of occupants in the truck should not exceed two.
Page 343: Over The Road Operation With Snowplow Attached
342 STARTING AND OPERATING The loaded vehicle weight, including the snowplow system, all aftermarket accessories, driver, passengers, options, and cargo, must not exceed either the Gross Vehicle Weight (GVWR) or Gross Axle Weight (GAWR) ratings. These weights are specified on the Safety Com- pliance Certification Label on the driver’s side door opening.
Page 344: General Maintenance
NOTE: During snowplow usage on vehicles equipped with outside temperature display, the display may show higher temperatures than the outside ambient tempera- ture. The higher displayed temperature is due to blocked or reduced airflow to the underhood ambient tempera- ture sensor caused by the snowplow. In addition, on vehicles equipped with Automatic Temperature Control (ATC), it is suggested that the interior cabin temperature be manually controlled should the system not perform as...
Page 345: Recreational Towing (Behind Motorhome, Etc.)
344 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Flat Tow Dolly Tow On Trailer Two-Wheel Drive Ground Models NONE NOT ALLOWED Front NOT ALLOWED Rear Four-Wheel Drive Models See Instructions •...
Page 346: Recreational Towing - Two-Wheel Drive Models
Recreational Towing – Two-Wheel Drive Models DO NOT flat tow this vehicle. Damage to the drivetrain will result. Recreational towing (for two-wheel drive models) is allowed ONLY if the rear wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer.
Page 347 346 STARTING AND OPERATING CAUTION! • Front or rear wheel lifts should not be used. Internal damage to the transmission or transfer case will occur if a front or rear wheel lift is used when recreational towing. • Tow only in the forward direction. Towing this vehicle backwards can cause severe damage to the transfer case.
Page 348 WARNING! You or others could be injured if you leave the vehicle unattended with the transfer case in the Neutral (N) position without first fully engaging the parking brake. The transfer case Neutral (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to move, even if the transmission is in PARK.
Page 349 348 STARTING AND OPERATING 12. Shift the transmission into PARK or place manual transmission in gear (not in Neutral). CAUTION! Damage to the transmission may occur if the trans- mission is shifted into PARK with the transfer case in Neutral (N) and the engine running. With the trans- fer case in Neutral (N) ensure that the engine is OFF prior to shifting the transmission into PARK.
Page 350 7. Shift the automatic transmission into PARK, or place manual transmission in Neutral. 8. Release the brake pedal. 9. Disconnect vehicle from the tow vehicle. 10. Start the engine. 11. Press and hold the brake pedal. 12. Release the parking brake. 13.
Page 351 350 STARTING AND OPERATING 1. Bring the vehicle to a complete stop. Shift automatic transmission into PARK. 2. Turn OFF the engine. 3. Turn the ignition switch to the ON/RUN position, but do not start the engine. 4. Press and hold the brake pedal. 5.
Page 352 CAUTION! Damage to the transmission may occur if the trans- mission is shifted into PARK with the transfer case in NEUTRAL and the engine running. With the transfer case in NEUTRAL, ensure that the engine is OFF prior to shifting the transmission into PARK. 15.
Page 353 352 STARTING AND OPERATING Shifting Out of Neutral – Electronic Shift Transfer Case (If Equipped) Use the following procedure to prepare your vehicle for normal usage: 1. Bring the vehicle to a complete stop, leaving it con- nected to the tow vehicle. 2.
Page 354 15. Shift the transmission into gear, release the brake pedal (and clutch pedal on manual transmissions), and check that the vehicle operates normally. NOTE: • Steps 1 through 5 are requirements that must be met prior to pressing the transfer case NEUTRAL button and must continue to be met until the shift has been completed.
Page 356 WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....356 Jacking And Tire Changing ....356 3500 Models —...
Page 357: Hazard Warning Flasher
356 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning flasher switch is located on the upper switch bank just below the radio. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 358: What To Do In Emergencies 357
3500 Models — If Equipped The jack and jack tools are stored under the front passenger seat. Lift the flap on the side of the seat for access. Remove the jack and tools by removing the wing bolt and sliding the assembly from under the seat. Jack Location WHAT TO DO IN EMERGENCIES 357 WARNING!
Page 359: Preparations For Jacking
358 WHAT TO DO IN EMERGENCIES Preparations For Jacking 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. WARNING! Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
Page 360 WARNING! (Continued) • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle. • Turn on the Hazard Warning flasher. • Block the wheel diagonally opposite the wheel to be raised.
Page 361 360 WHAT TO DO IN EMERGENCIES 3. When changing the front wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle as close to the tire as possible with the drive tubes extending to the front.
Page 362 Before raising the wheel off the ground, make sure that the jack will not damage surrounding truck parts and adjust the jack position as required. NOTE: If the jack will not lower by turning the dial (thumbwheel) by hand, it may be necessary to use the jack drive tube in order to lower the jack.
Page 363 362 WHAT TO DO IN EMERGENCIES 7. Install wheel center cap (if equipped) and remove wheel blocks. Do not install chrome or aluminum wheel center caps on the spare wheel. This may result in cap damage. 8. Lower the jack to its fully closed position. If the jack will not lower by turning the dial (thumbwheel) by hand, it may be necessary to use the jack drive tube in order to lower the jack.
Page 364 CAUTION! • Use a back and forth motion to remove the hub cap. Do not use a twisting motion when removing the hub cap, damage to the hub cap; finish may occur. • The rear hub caps on the dual rear wheel has two pry off notches.
Page 365 364 WHAT TO DO IN EMERGENCIES Slots in the wheels will assist in properly orienting the These dual rear wheels should be tightened as follows: inner and outer wheels. Align these slots when assem- bling the wheels for best access to the tire valve on the inner wheel.
Page 366 Tightening Pattern (10 Studs) 1. Tighten the wheel nuts in the numbered sequence to a snug fit. 2. Retighten the wheel nuts in the same sequence to the torques listed in the table. Go through the sequence a second time to verify that specific torque has been achieved.
Page 367: Hoisting
366 WHAT TO DO IN EMERGENCIES Disc Wheels Type Nut Cone Flanged To Stow The Flat Or Spare — If Equipped Refer to Upfitters Body Builders Guide for information on stowing your spare tire (if equipped). HOISTING A conventional floor jack may be used at the jacking locations.
Page 368: Preparations For Jump-Start
CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. WARNING! Do not attempt jump-starting if the battery is frozen. It could rupture or explode and cause personal injury.
Page 369: Jump-Starting Procedure
368 WHAT TO DO IN EMERGENCIES WARNING! • Take care to avoid the radiator cooling fan when- ever the hood is raised. It can start anytime the ignition switch is on. You can be injured by moving fan blades. • Remove any metal jewelry such as watch bands or bracelets that might make an inadvertent electrical contact.
Page 370 CAUTION! Failure to follow these procedures could result in damage to the charging system of the booster vehicle or the discharged vehicle. 1. Connect the positive (+) end of the jumper cable to the positive (+) post of the discharged vehicle. 2.
Page 371: Freeing A Stuck Vehicle
370 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper cable from the positive (+) post of the booster battery. 9. Disconnect the positive (+) end of the jumper cable from the positive (+) post of the discharged vehicle. If frequent jump-starting is required to start your vehicle you should have the battery and charging system in- spected at your authorized dealer.
Page 372: Emergency Tow Hooks - If Equipped
CAUTION! (Continued) • When “rocking” a stuck vehicle by moving be- tween 1st and REVERSE, do not spin the wheels faster than 15 mph (24 km/h), or drivetrain damage may result. • Revving the engine or spinning the wheels too fast may lead to transmission overheating and failure.
Page 373: Towing A Disabled Vehicle
372 WHAT TO DO IN EMERGENCIES WARNING! • Chains are not recommended for freeing a stuck vehicle. Chains may break, causing serious injury or death. • Stand clear of vehicles when pulling with tow hooks. Tow straps and chains may break, causing serious injury.
Page 374: Two-Wheel Drive Vehicles
NOTE: The transfer case must be in the NEUTRAL position, and the transmission must be in PARK (auto- matic transmission), or in gear (manual transmission) to tow a four-wheel drive vehicle, unless all its wheels are OFF the ground. The manufacturer recommends towing with all wheels OFF the ground.
Page 376 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 5.7L ... . . 377 Onboard Diagnostic System (OBD II) ..378 Loose Fuel Filler Cap Message ... 378 Emissions Inspection And Maintenance Programs .
Page 377 376 MAINTAINING YOUR VEHICLE Exhaust System ..... 390 Cooling System ..... 392 Brake System .
Page 378: Engine Compartment - 5.7L
ENGINE COMPARTMENT — 5.7L 1 — Air Cleaner Filter 2 — Automatic Transmission Dipstick 3 — Engine Oil Fill 4 — Engine Oil Dipstick 5 — Brake Fluid Reservoir 6 — Battery MAINTAINING YOUR VEHICLE 377 7 — Washer Fluid Reservoir 8 —...
Page 379: Onboard Diagnostic System (Obd Ii)
378 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM (OBD II) Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 380: Maintaining Your Vehicle 379
the SELECT button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the Malfunction Indicator Light (MIL). EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...
Page 381: Replacement Parts
380 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 382: Maintenance Procedures
your vehicle. Refer to these Service Manuals before attempting any procedure yourself. NOTE: Intentional tampering with emissions control systems may void your warranty and could result in civil penalties being assessed against you. WARNING! You can be badly injured working on or around a motor vehicle.
Page 383: Engine Oil
382 MAINTAINING YOUR VEHICLE CAUTION! (Continued) • Your vehicle has been built with improved fluids that protect the performance and durability of your vehicle and also allow extended maintenance intervals. Do not use chemical flushes in these components as the chemicals can damage your engine, transmission, power steering or air condi- tioning.
Page 384 NOTE: Under no circumstances should oil change intervals exceed 8,000 miles (13 000 km) or six months, whichever occurs first. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends engine oils that are API Certified and meet the requirements of Chrysler Material Standard MS-6395.
Page 385: Engine Oil Filter
384 MAINTAINING YOUR VEHICLE Synthetic Engine Oils You may use synthetic engine oils if the recommended oil quality requirements are met and the recommended maintenance intervals for oil and filter changes are followed. Materials Added to Engine Oil The manufacturer strongly recommends against the addi- tion of any additives (other than leak detection dyes) to the engine oil.
Page 386: Maintenance-Free Battery
WARNING! The air induction system (air cleaner, hoses, etc.) can provide a measure of protection in the case of engine backfire. Do not remove the air induction system (air cleaner, hoses, etc.) unless such removal is necessary for repair or maintenance. Make sure that no one is near the engine compartment before starting the vehicle with the air induction system (air cleaner, hoses, etc.) removed.
Page 387 386 MAINTAINING YOUR VEHICLE WARNING! (Continued) • Battery gas is flammable and explosive. Keep flame or sparks away from the battery. Do not use a booster battery or any other booster source with an output greater than 12 Volts. Do not allow cable clamps to touch each other.
Page 388: Air Conditioner Maintenance
Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time.
Page 389: Front Prop Shaft Lubrication - Four-Wheel Drive Models
388 MAINTAINING YOUR VEHICLE NOTE: Use only manufacturer approved A/C System Sealers, Stop Leak Products, Seal Conditioners, Compres- sor Oil, or Refrigerants. Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluoro- carbon (HFC) that is endorsed by the Environmental Protection Agency (EPA) and is an ozone-saving product.
Page 390: Windshield Wiper Blades
amount of a high quality lubricant such as MOPAR Lock Cylinder Lubricant or equivalent directly into the lock cylinder. Windshield Wiper Blades Clean the rubber edges of the wiper blades and the windshield periodically with a sponge or soft cloth and a mild nonabrasive cleaner.
Page 391: Exhaust System
390 MAINTAINING YOUR VEHICLE The washer fluid reservoir will hold a full gallon of fluid when the Low Washer Fluid Light illuminates. WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.
Page 392 WARNING! • Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing CO, refer to “Safety Tips/Exhaust Gas” in “Things To Know Before Starting Your Vehicle”...
Page 393: Cooling System
392 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- verter will not require maintenance. However, it is impor- tant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst damage. NOTE: Intentional tampering with emissions control systems can result in civil penalties being assessed against you.
Page 394 Engine Coolant Checks Check the engine coolant (antifreeze) protection every 12 months (before the onset of freezing weather, where applicable). If the engine coolant (antifreeze) is dirty or rusty in appearance, the system should be drained, flushed and refilled with fresh coolant. Check the front of the A/C condenser for any accumulation of bugs, leaves, etc.
Page 395 394 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified HOAT engine coolant (antifreeze), may result in engine damage and may decrease corro- sion protection. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emergency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
Page 396 • Mix a minimum solution of 50% HOAT engine coolant and distilled water. Use higher concentrations (not to exceed 70%) if temperatures below anticipated. • Use only high purity water such as distilled or deion- ized water when mixing the water/engine coolant (antifreeze) solution.
Page 397 396 MAINTAINING YOUR VEHICLE WARNING! (Continued) • Do not use a pressure cap other than the one specified for your vehicle. Personal injury or en- gine damage may result. Disposal of Used Coolant Used ethylene glycol-based engine coolant (antifreeze) is a regulated substance requiring proper disposal.
Page 398 normally a result of moisture from rain, snow, or high humidity accumulating on the radiator and being vapor- ized when the thermostat opens, allowing hot coolant to enter the radiator. If an examination of your engine compartment shows no evidence of radiator or hose leaks, the vehicle may be safely driven.
Page 399: Brake System
398 MAINTAINING YOUR VEHICLE Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Refer to “Maintenance Schedule” for the proper mainte- nance intervals. WARNING! Riding the brakes can lead to brake failure and possibly an accident.
Page 400 WARNING! • Use only manufacturer’s recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. Using the wrong type of brake fluid can severely damage your brake system and/or impair its performance. The proper type of brake fluid for your vehicle is also labeled on the origi- nal factory installed hydraulic master cylinder reservoir.
Page 401: Rear Axle And 4X4 Front Driving Axle Fluid Level
400 MAINTAINING YOUR VEHICLE WARNING! (Continued) • Do not allow petroleum based fluid to contami- nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure. This could result in an accident. Rear Axle And 4x4 Front Driving Axle Fluid Level For models with 9.25 in Front Axles and 11.5 in Rear Axles, refer to “Fluids, Lubricants, and Genuine Parts”...
Page 402: Transfer Case
Lubricant Selection Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. NOTE: The presence of water in the gear lubricant will result in corrosion and possible failure of differential components. Operation of the vehicle in water, as may be encountered in some off-highway types of service, will require draining and refilling the axle to avoid damage.
Page 403: Automatic Transmission
402 MAINTAINING YOUR VEHICLE Automatic Transmission Selection Of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor- mance. Use only the manufacturer’s recommended trans- mission fluid. Refer to “Fluids, Lubricants, and Genuine Parts”...
Page 404 transmission with an improper fluid level will greatly reduce the life of the transmission and of the fluid. Check the fluid level whenever the vehicle is serviced. Fluid Level Check – 545RFE Check the fluid level while the transmission is at normal operating temperature 82°C (180°F).
Page 405 404 MAINTAINING YOUR VEHICLE room temperature, it should be between the “HOT” (upper) reference holes when the transmission reaches 180°F (82°C). Remember it is best to check the level at the normal operating temperature. CAUTION! Be aware that if the fluid temperature is below 50°F (10°C) it may not register on the dipstick.
Page 406: Appearance Care And Protection From Corrosion
Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- graphic locations and usage. Chemicals that make roads passable in snow and ice, and those that are sprayed on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle.
Page 407 406 MAINTAINING YOUR VEHICLE • Use a high quality cleaner wax, such as MOPAR Cleaner Wax or equivalent to remove road film, stains and to protect your paint finish. Take care never to scratch the paint. • Avoid using abrasive compounds and power buffing that may diminish the gloss or thin out the paint finish.
Page 408 • If you carry special cargo such as chemicals, fertilizers, de-icer salt, etc., be sure that such materials are well packaged and sealed. • If a lot of driving is done on gravel roads, consider mud or stone shields behind each wheel. •...
Page 409 408 MAINTAINING YOUR VEHICLE • For grease stains, apply MOPAR Cleaner or equivalent to a clean, damp cloth and remove stain. Use a fresh, damp towel to remove soap residue. • Do not use any harsh solvents or any other form of protectants on Stain Repel products.
Page 410 Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed. To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth. To remove road dirt, wash with a mild soap solution fol- lowed by rinsing.
Page 411: Fuses
410 MAINTAINING YOUR VEHICLE If the belts need cleaning, use a mild soap solution or lukewarm water. Do not remove the belts from the car to wash them. Replace the belts if they appear frayed or worn or if the buckles do not work properly.
Page 412 Cavity Cartridge Mini Fuse Fuse 25 Amp Bat – Passenger Door Natural Node 40 Amp Bat – ABS Pump Green 30 Amp Bat – ABS Valve Pink 30 Amp Bat – H/Lamp Wash/ Pink MTV/CM2200/Elec Vac Pump 25 Amp Bat – Driver Door Natural Node 30 Amp...
Page 413 412 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 5 Amp 25 Amp Natural 25 Amp Natural 20 Amp Yellow 20 Amp Yellow 20 Amp Yellow 10 Amp 10 Amp Description Cavity Cartridge Ign R/ACC – Sunroof/Window Sw Illum Frt Wiper Door Locks Fuel Pump Bat –...
Page 414 Cavity Cartridge Mini Fuse Fuse 20 Amp Htd Seat/Htd Str Yellow Wheel/Rear Htd Seat 20 Amp Ign R-Rear Seat/Steer Yellow Wheel 10 Amp Horn #1 20 Amp IOD-CCN/Interior Yellow Mods 30 Amp IOD-Amp/Radio Green 25 Amp Rear Wiper Natural 15 Amp IOD-SDARS/VES Blue 2–3/DVD/HFM/...
Page 415 414 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Fuse Fuse 20 Amp Yellow 10 Amp 15 Amp Blue 20 Amp Yellow Description • When installing the totally integrated power mod- ASD #3 ule cover, it is important to ensure the cover is properly positioned and fully latched.
Page 416: Vehicle Storage
VEHICLE STORAGE If you are storing your vehicle for more than 21 days, we recommend that you take the following steps to mini- mize the drain on your vehicle’s battery: • Disconnect the Ignition-Off Draw (IOD) fuse located in the Integrated Power Module, located in the engine compartment.
Page 417: Bulb Replacement
416 MAINTAINING YOUR VEHICLE NOTE: For lighted switches, see your authorized dealer for replacement instructions. All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved. LIGHT BULBS – Exterior Center High Mounted Stop Lamp (CHMSL) ..921 Fog Lamp .
Page 418 7. Reach into the front wheel house ahead of the front wheel, remove the fastener, and lift the cover over the access hole in the front of the wheel house splash shield. Access to the rear of the lamp can be gained through this access hole.
Page 419: Fog Lamps - If Equipped
418 MAINTAINING YOUR VEHICLE 10. Disconnect electrical connectors. 11. Replace bulb(s) as necessary. CAUTION! • Do not contaminate the bulb glass by touching it with your fingers or by allowing it to contact other oily surfaces. Shortened bulb life will result. •...
Page 420: Center High-Mounted Stoplamp (Chmsl) With Cargo Lamp
Center High-Mounted Stoplamp (CHMSL) With Cargo Lamp 1. Remove the two screws holding the housing/lens to the body as shown. MAINTAINING YOUR VEHICLE 419 2. Separate the connector holding the housing and wir- ing harness to the body. 3. Turn the desired bulb socket ⁄...
Page 421: Cab Top Clearance Lamps - If Equipped
420 MAINTAINING YOUR VEHICLE 4. Pull the desired bulb straight from the socket. CAUTION! Do not contaminate the bulb glass by touching it with your fingers or by allowing it to contact other oily surfaces. Shortened bulb life will result. •...
Page 422 MAINTAINING YOUR VEHICLE 421 2. Rotate the socket ⁄ turn and pull it from the lamp 3. Pull the bulb straight from it’s socket and replace. assembly.
Page 423: Fluid Capacities
422 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Standard Rear Tank Optional Midship Tank Engine Oil with Filter 5.7L Engine (SAE 5W-20, API Certified) Cooling System 5.7L Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent. U.S. Metric 52 Gallons 197 Liters 22 Gallons 83 Liters...
Page 424: Fluids, Lubricants And Genuine Parts
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil – 5.7L Engine Engine Oil Filter – 5.7L Engine Spark Plugs – 5.7L Engine Fuel Selection – 5.7L Engine Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5–Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent.
Page 425: Chassis
424 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission (Five-Speed 545RFE) Transfer Case Front and Rear Axle Fluid (4500/5500) Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product.
Page 426: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..426 Maintenance Schedule ....426 5.7L Gas Engine ..... 426 Required Maintenance Intervals .
Page 427 426 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 428 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been 6 months since your last oil change even if the oil change indicator message is NOT illumi- nated.
Page 429 428 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
Page 430 8,000 Miles (13,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 8,000 miles (13 000 km). ❏...
Page 431: Service Schedule
430 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 24,000 miles (39 000 km). ❏...
Page 432 40,000 Miles (65,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 40,000 miles (65 000 km). ❏...
Page 433 432 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). ❏...
Page 434 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
Page 435 434 MAINTENANCE SCHEDULES 72,000 Miles (117,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 72,000 miles (117 000 km). ❏...
Page 436 88,000 Miles (147,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (147 000 km). ❏...
Page 437 436 MAINTENANCE SCHEDULES 96,000 Miles (160,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (160 000 km). ❏...
Page 438 104,000 Miles (173,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 104,000 miles (173 000 km). ❏...
Page 439 438 MAINTENANCE SCHEDULES 120,000 Miles (199,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (199 000 km). ❏...
Page 440 128,000 Miles (212,000 km) or 96 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 128,000 miles (212 000 km). ❏...
Page 441 440 MAINTENANCE SCHEDULES 144,000 Miles (238,000 km) or 108 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 144,000 miles (238 000 km). ❏...
Page 442 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 444 IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......445 Prepare For The Appointment .
Page 445 444 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....449 Department Of Transportation Uniform Tire Quality Grades ......451 Treadwear .
Page 446: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 447: 446 If You Need Consumer Assistance
446 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 448: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 449: Warranty Information
448 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 450: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 451 450 IF YOU NEED CONSUMER ASSISTANCE LLC vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts. • Diagnostic Procedure Manuals Diagnostic Procedure Manuals are filled with dia- grams, charts and detailed illustrations. These practi- cal manuals make it easy for students and technicians to find and fix problems on computer-controlled ve- hicle systems and features.
Page 452: Traction Grades
DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 453: Department Of Transportation Uniform Tire Temperature Grades
452 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 454: Index
INDEX...
Page 455 454 INDEX Adding Engine Coolant (Antifreeze) ..394 Adding Fuel ......322 Adjustable Pedals .
Page 456 Automatic Transmission Adding Fluid ......403 Fluid and Filter Changes ....404 Fluid Level Check .
Page 457 456 INDEX Carbon Monoxide Warning ....73,321 Cargo Light ......144 Cellular Phone .
Page 458 Points to Remember ....396 Pressure Cap ......395 Radiator Cap .
Page 459 458 INDEX Tow Hooks ......371 Towing ......372 Emission Control System Maintenance .
Page 460 Fluid Level Checks Automatic Transmission ....403 Brake ......398 Power Steering .
Page 461 460 INDEX Guide, Body Builders ..... . 6 GVWR ....... 324 Hands-Free Phone (Uconnect™) .
Page 462 Instrument Panel and Controls ....176 Instrument Panel Lens Cleaning ... . . 409 Integrated Power Module (Fuses) ... . 410 Integrated Trailer Brake Controls .
Page 463 462 INDEX Cargo ......144 Center Mounted Stop ....419 Check Engine (Malfunction Indicator) .
Page 464 Maintenance Free Battery ....385 Maintenance Procedures ....381 Maintenance Schedule .
Page 465 464 INDEX Identification Logo ..... 383 Materials Added to ..... 384 Pressure Gauge .
Page 466 Programming Transmitters (Remote Keyless Entry) ....20 Radial Ply Tires ......309 Radiator Cap (Coolant Pressure Cap) .
Page 467 466 INDEX Safety Information, Tire ....294 Safety Tips ......72 Satellite Radio Antenna .
Page 468 Transfer Case, Shifting out of Transfer Case Neutral (N) ..... . . 348,352 Shoulder Belt Upper Anchorage ....46 Shoulder Belts .
Page 469 468 INDEX Tip Start ......263 Tire and Loading Information Placard ..300,313 Tire Identification Number (TIN) .
Page 470 Cooling System Tips ....340 Hitches ......329 Minimum Requirements .
Page 471 470 INDEX Warning Lights (Instrument Cluster Description) ... . . 179 Warnings and Cautions ..... 6 Warranty Information .
Page 472 Chrysler Group LLC 11DD43-126-AC Second Edition Printed in U.S.A.
