T A B L E O F C O N T E N T S INTRODUCTION/WELCOME Uconnect 8.4AN ... . . 126 ® STEERING WHEEL AUDIO WELCOME FROM CHRYSLER CONTROLS ....147 GROUP LLC .
Page 4
T A B L E O F C O N T E N T S WHAT TO DO IN EMERGENCIES MAINTENANCE PROCEDURES ..252 MAINTENANCE SCHEDULE — ROADSIDE ASSISTANCE ..201 GASOLINE ENGINE .
I N T R O D U C T I O N / W E L C O M E WELCOME FROM CHRYSLER GROUP LLC Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles.
Page 6
I N T R O D U C T I O N / W E L C O M E VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution (excluding legal lines).
C O N T R O L S A T A G L A N C E DRIVER COCKPIT 1. Headlight Switch pg. 38 2. Electronic Vehicle Information Center (EVIC) Controls Or Driver Information Display (DID) Controls pg. 148 3. Turn Signal/Wiper/Washer/High Beams Lever pg. 37 4.
Page 9
C O N T R O L S A T A G L A N C E 11. Switch Panel 12. Power Inverter Outlet pg. 155 13. Glove Compartment 14. Power Outlet 15. Shifter 16. Hood Release (below steering wheel at base of instrument panel) pg. 231 17.
C O N T R O L S A T A G L A N C E INSTRUMENT CLUSTER 1. Temperature Gauge 2. Tachometer 3. Voltmeter (See page 201 for Instrument Cluster Warning Lights.)
Page 11
C O N T R O L S A T A G L A N C E 4. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) 5. Oil Pressure Gauge 6. Speedometer 7. Fuel Gauge (See page 207 for Instrument Cluster Indicator Lights.)
G E T T I N G S T A R T E D KEY FOB This feature allows the driver to operate the ignition switch with the push of a button, as long as the Remote Keyless Entry (RKE) transmitter is in the passen- ger compartment.
G E T T I N G S T A R T E D NOTE: In case the ignition switch does not change with the push of a button, the RKE transmitter (Key Fob) may have a low or dead battery. In this situation a back up method can be used to operate the ignition switch.
Page 14
G E T T I N G S T A R T E D RKE Air Suspension (Remote Lowering Of Vehicle) — If Equipped • This vehicle is equipped with a feature that can lower the vehicle to a height which will improve ease of passenger entry/exit and cargo loading/unloading.
G E T T I N G S T A R T E D KEYLESS ENTER-N-GO™ The Keyless Enter-N-Go™ system is an enhancement to the vehicle's Key Fob. This feature allows you to lock and unlock the vehicle's door(s) without having to push Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the push of a button.
Page 16
G E T T I N G S T A R T E D NOTE: • After pushing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle without the vehicle reacting and unlocking.
G E T T I N G S T A R T E D REMOTE START • Push REMOTE START button on the Key Fob twice within five seconds. Pushing the REMOTE START button a third time shuts the engine off. •...
G E T T I N G S T A R T E D To Disarm The System: • Push the Key Fob UNLOCK button or cycle the ignition to the ON/RUN position. The Vehicle Security Alarm is designed to protect your vehicle; however, you can create conditions where the Vehicle Security Alarm will give you a false alarm.
G E T T I N G S T A R T E D Seat Belt Pretensioner • The front seat belt system is equipped with pretensioning devices that are designed to remove slack from the seat belt in the event of a collision. •...
Page 20
G E T T I N G S T A R T E D Advanced Front Air Bags • This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision.
Page 21
G E T T I N G S T A R T E D • If it is necessary to modify the air bag system for persons with disabilities, contact your authorized dealer. • Refer to the Owner's Manual on the DVD for further details regarding the Supplemental Restraint System (SRS).
G E T T I N G S T A R T E D CHILD RESTRAINTS Children 12 years or younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front.
Page 23
G E T T I N G S T A R T E D Locating The LATCH Lower Anchorages The lower anchorages are round bars that are found at the rear of the seat cushion where it meets the seatback. They are just visible when you lean into the rear seat to install the child restraint.
Page 24
G E T T I N G S T A R T E D Installing The Child Restraint Using The LATCH Lower Anchors NOTE: Never “share” a LATCH anchorage with two or more child restraints. 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 25
G E T T I N G S T A R T E D 4. To lock the seat belt, pull down on the shoulder part of the belt until you have pulled all the seat belt webbing out of the retractor. Then, allow the webbing to retract back into the retractor.
Page 26
G E T T I N G S T A R T E D Tether Anchorage Installation Regular and Mega Cab Trucks: In the regular cab truck, the top tether anchorages are located behind the center and right passenger seats. In the mega cab truck, the top tether anchorages are located behind each rear seating position.
Page 27
G E T T I N G S T A R T E D 3. Pass the tether strap hook under the head restraint behind the child seat, though the tether strap loop behind the seat and over to the center tether strap loop. Tether Strap Through Outboard Tether Strap Loop 4.
Page 28
G E T T I N G S T A R T E D Center Seat: 1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop. 2. Place a child restraint on the seat and adjust the tether strap so that it will reach over the seat back, under the head restraint, through the tether...
Page 29
G E T T I N G S T A R T E D Installing Three Child Restraints: 1. Place a child restraint on each out- board rear seat. Route the tether straps following the directions for right and left seating positions, above. 2.
G E T T I N G S T A R T E D HEAD RESTRAINTS Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact. Head restraints should be adjusted so that the top of the head restraint is located above the top of your ear.
G E T T I N G S T A R T E D Rear Head Restraints The rear seats are equipped with adjustable head restraints. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, press the adjustment button, located on the base of the head restraint, and push downward on the head restraint.
G E T T I N G S T A R T E D Memory Seat The memory seat feature allows you to save the driver's seat position (excluding lumbar position), driver's outside mirror position, adjustable brake and accelerator pedals, Automatic Temperature Control (ATC) temperature setting and radio station preset settings.
G E T T I N G S T A R T E D CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.
G E T T I N G S T A R T E D Vehicle Equipped With Remote Start On models that are equipped with remote start, this feature can be programmed to come on during a remote start. If your vehicle is equipped with a touchscreen, this feature can be programmed through the Uconnect system.
G E T T I N G S T A R T E D REAR HEATED SEATS The rear heated seat switches are located on the rear of the center console. • Press the heated seat button once to turn the High setting On. •...
G E T T I N G S T A R T E D Vehicle Equipped With Remote Start On models that are equipped with remote start, this feature can be programmed to come on during a remote start. If your vehicle is equipped with a touchscreen, this feature can be programmed through the Uconnect system.
Page 37
G E T T I N G S T A R T E D ADJUSTABLE PEDALS Press the switch located on the left side of the steering column forward to move the brake and accelerator pedals away from the driver and press the switch rearward to move the pedals closer to the driver.
O P E R A T I N G Y O U R V E H I C L E ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km).
O P E R A T I N G Y O U R V E H I C L E TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER Turn Signal/Wiper/Washer/High Beam Lever Turn Signals/Lane Change Assist Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.
O P E R A T I N G Y O U R V E H I C L E HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights • Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent for parking lights and to the second detent for headlights...
O P E R A T I N G Y O U R V E H I C L E Cargo Light The cargo light is strategically placed lighting that helps illuminate the bed area of the truck. A cargo light symbol will illuminate in the cluster to indicate the light is on. •...
Page 42
O P E R A T I N G Y O U R V E H I C L E Accel/Decel To Increase Speed • When the Electronic Speed Control is set, you can increase speed by pushing the RES + button. The drivers preferred units can be selected through the instrument panel settings if equipped.
O P E R A T I N G Y O U R V E H I C L E Resume • To resume a previously selected set speed in memory, push the RESUME/ACCEL switch and release. Cancel • Push the CANCEL switch or apply the brakes to cancel the set speed and maintain the set speed memory.
O P E R A T I N G Y O U R V E H I C L E ELECTRONIC RANGE SELECT (ERS) OPERATION • Electronic Range Select (ERS) allows you to limit the highest available trans- mission gear, and can be activated during any driving condition.
Page 45
O P E R A T I N G Y O U R V E H I C L E ELECTRONIC RANGE SELECT (ERS) OPERATION — EIGHT-SPEED TRANSMISSION • The Electronic Range Select (ERS) shift control allows the driver to limit the highest available gear when the transmission shifter switch is in the DRIVE position...
O P E R A T I N G Y O U R V E H I C L E 1500 AIR SUSPENSION SYSTEM The air suspension system provides full time load leveling capability along with the benefit of being able to adjust vehicle height by the push of a button. Automatic height changes will occur based on vehicle speed and the current vehicle height.
O P E R A T I N G Y O U R V E H I C L E Aero Mode (Lowers the vehicle approximately .6 in (15 mm) – 1500 Models Only - This position provides improved aerodynamics by lowering the vehicle. The vehicle will automatically enter Aero Mode when the vehicle speed remains between 62 mph (100 km/h) and 66 mph (106 km/h) for greater than 20 seconds or if the vehicle speed exceeds 66 mph (106 km/h).
Page 48
O P E R A T I N G Y O U R V E H I C L E Transport Mode To assist with flat bed towing, the air suspension system has a feature which will put the vehicle into Entry/Exit height and disable the automatic load leveling system. Refer to “Electronic Vehicle Information Center (EVIC)/Driver Information Display (DID)”...
O P E R A T I N G Y O U R V E H I C L E 2500-3500 AIR SUSPENSION SYSTEM The air suspension system provides full time rear load leveling capability for all loading conditions including towing. Description Normal Ride Height (NRH) - This is the standard position of the suspension and...
Page 50
O P E R A T I N G Y O U R V E H I C L E Air Suspension Modes The Air Suspension system has multiple modes to protect the system in unique situations: Tire Jack Mode To assist with changing a spare tire, the air suspension system has a feature which allows the automatic leveling to be disabled.
O P E R A T I N G Y O U R V E H I C L E MANUAL CLIMATE CONTROLS WITHOUT TOUCHSCREEN Manual Climate Controls 1 — Rotate Blower Control 4 — Push A/C Button 2 — Push Air Recirculation Button 5 —...
O P E R A T I N G Y O U R V E H I C L E MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Uconnect® 8.4 Manual Climate Controls 1 — Max A/C Indicator 6 — Blower Speed Up Button 2 —...
O P E R A T I N G Y O U R V E H I C L E Climate Control Knobs 1 — A/C Button 5 — Rotate Blower Control 2 — Temperature Control Buttons 6 — OFF Button 3 —...
O P E R A T I N G Y O U R V E H I C L E AUTOMATIC CLIMATE CONTROLS WITH TOUCHSCREEN Touchscreen Automatic Climate Controls 1 — MAX A/C Button 8 — Passenger Temperature Down 2 — A/C Button 9 —...
Page 55
O P E R A T I N G Y O U R V E H I C L E Climate Control Knobs 1 — A/C Button 7 — Rear Defroster Button 2 — Driver Temperature Up 8 — Passenger Temperature Down 3 —...
O P E R A T I N G Y O U R V E H I C L E Air Recirculation • Use Recirculation for maximum A/C operation. • For window defogging, turn the Recirculation button off. • If the Recirculation button is pushed while in the AUTO mode, the indicator light may flash three times to indicate the cabin air is being controlled automatically.
O P E R A T I N G Y O U R V E H I C L E PARKVIEW® REAR BACK-UP CAMERA • You can see an on-screen image of the rear surroundings of your vehicle whenever the shift lever is put into REVERSE. The ParkView Rear Back-Up Camera image ®...
O P E R A T I N G Y O U R V E H I C L E POWER SUNROOF • The power sunroof switch is located on the overhead console. Opening Sunroof Express Open Press the switch rearward and release it within one-half second.
O P E R A T I N G Y O U R V E H I C L E Pinch Protection Feature This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract.
E L E C T R O N I C S YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect Voice Command Button pg. 111 ® 2. Uconnect Phone Button pg. 139 ® 3. Steering Wheel Audio Controls (Left) pg. 147 4. Steering Wheel Audio Controls (Right) pg. 147 5.
Page 61
E L E C T R O N I C S 7. 9-1-1 Button pg. 69 8. Uconnect 8.4 Radio pg. 95 ® 9. Screen Off Button 10. Back Button 11. Tune/Scroll Knob/Browse/Enter Button 12. Media Hub: Audio Jack, USB Port, and SD Card Slot (located center console) pg.
E L E C T R O N I C S IDENTIFYING YOUR RADIO Uconnect® 3.0 • Two buttons on the faceplate on either side of the display Uconnect® 3.0 Uconnect® 5.0 • 5” Touchscreen • Three buttons on the faceplate on ei- ther side of the display Uconnect®...
E L E C T R O N I C S Uconnect® 8.4AN • 8.4” Touchscreen • Climate button on the touchscreen in lower menu bar • HD Button will be visible on right side of screen when viewing AM or FM •...
Page 64
E L E C T R O N I C S • Listen to your text messages or send free-form text messages with your voice while keeping your hands on the wheel, using the Voice Texting feature. Requires a cell phone that supports Bluetooth Message Access Profile (MAP).
E L E C T R O N I C S Uconnect® Access Registration (Uconnect® 8.4A/8.4AN, U.S. 48 Contiguous States, Alaska And Hawaii) To unlock the full potential of Uconnect Access in your vehicle, you first need to ® register with Uconnect Access.
Page 66
E L E C T R O N I C S 8. Once you are logged in to your Mopar Owner Connect account, you will create a personal Uconnect Security PIN. The Uconnect Security PIN will be required ® ® to authenticate you when accessing your account via Uconnect Care or perform- ®...
Page 67
E L E C T R O N I C S Pandora® (www.pandora.com) • Enter your Pandora username/email address and password, then click “Save.” ® • Create a new Pandora account. ® Slacker Radio (www.slacker.com) • Enter your Slacker username/email address and password, then click “Save.” •...
Page 68
E L E C T R O N I C S Purchasing WiFi Hotspot While In Your Vehicle You must set up a Uconnect Access Payment Account online (log in to ® moparownerconnect.com, go to Edit Profile, then Uconnect Payment Account, to ®...
Page 69
E L E C T R O N I C S Get started with your Uconnect Access apps by pressing the Uconnect “Apps” ® ® button on the menu bar at the bottom right corner of the radio touchscreen. Available apps and features are organized by the tabs on the left of the screen: Favorite Apps —...
Page 70
E L E C T R O N I C S Maintaining Your Uconnect® Access Account Reinstalling An App (Uconnect® 8.4A/8.4AN) You can easily correct many Application related issues you may be experiencing by resetting the App back to the factory setting. From the vehicle’s radio touchscreen, complete the following steps: 1.
Page 71
E L E C T R O N I C S Built-In Features (Uconnect® 8.4AN Only) CAUTION! • Ignoring the rearview mirror light could mean you may not have 9-1-1 Call service if needed. If the rearview mirror light is illuminated, have an authorized dealer service the 9-1-1 Call system immediately.
Page 72
E L E C T R O N I C S 2. Emergency 9-1-1 Call (If Equipped) — The rearview mirror contains a 9-1-1 button that, when pressed, may place a call from your vehicle to a local 9-1-1 operator to request help from local police, fire or ambulance personnel.
Page 73
E L E C T R O N I C S 6. Stolen Vehicle Assistance — If your vehicle is stolen, contact local law enforce- ment immediately to file a stolen vehicle report. Once this report has been filed, Uconnect care can help locate your vehicle.
Page 74
E L E C T R O N I C S NOTE: Your four digit Uconnect Security PIN is required to confirm the request. ® • You can set-up notifications for your account to receive an email or text (SMS) message every time a command is sent.
Page 75
E L E C T R O N I C S Voice Texting — Want to dictate a personal message? Register with Uconnect ® Access to take advantage of a new, cloudbased Voice Texting service, an enhance- ment to Voice Text Reply. Voice Texting allows you to compose a new text or reply to an incoming text message.
Page 76
E L E C T R O N I C S Sample Commands For Voice Text Reply And Voice Texting Example Command Action Send a message to specific contact in “Text John Smith” address book Send 123 - 456 - 7890 a message from “Text 123 - 456 - 7890”...
Page 77
E L E C T R O N I C S Launch the Uconnect Access App on your smartphone, and login with your ® username and password that was set up during registration, (this is your moparownerconnect.com login). Accept the Terms and Conditions. •...
Page 78
E L E C T R O N I C S Each time you want to use a Via Mobile app in your vehicle, the Uconnect Access ® App must be running on your smartphone and the smartphone must be paired via Bluetooth ®...
Page 79
E L E C T R O N I C S If equipped, the Via Mobile apps can be found by selecting the “Apps” button on the touchscreen in the lower right corner of the radio touchscreen. Via Mobile apps are listed under the “All Apps”...
Page 80
E L E C T R O N I C S Via Mobile apps can also be launched through Voice Recognition by pressing the VR button on the steering wheel and stating “launch” and then the name of the app. For example, you can say “launch Aha Via Mobile.”...
E L E C T R O N I C S Uconnect® 3.0 Uconnect® 3.0 Radio 1 — RADIO Button 8 — SEEK Up Button 2 — INFO Button 9 — ON/OFF Button/Volume Knob 3 — MEDIA Button 10 — BROWSE/ENTER Button/ 4 —...
E L E C T R O N I C S Audio • Push the AUDIO button on the radio faceplate. • The Audio Menu shows the following options for you to customize your audio settings. Treble, Mid, Bass, Fade, Balance, Speed Adjusted Volume, Loudness and Auto Volume Offset •...
Page 83
E L E C T R O N I C S USB/Audio Jack (AUX) Operation USB/iPod® • USB/iPod Mode is entered by either inserting a USB Jump Drive or iPod cable ® ® into the USB port or by pressing the MEDIA button located left of the display. Once in Media Mode, select “USB/iPod”...
E L E C T R O N I C S Uconnect® 5.0 Uconnect® 5.0 1 — Radio Mode 7 — Rotate Volume Control 2 — Compass Information 8 — Rotate Tune/Scroll Knob 3 — Media Mode 9 — Mute Button 4 —...
E L E C T R O N I C S Clock Setting To start the clock setting procedure, perform the following: 1. Push the SETTINGS button on the faceplate on the right side of the display, then press the “Clock & Date” button on the touchscreen. 2.
Page 86
E L E C T R O N I C S Radio Operation Seek Up/Down Buttons • Press to seek through radio stations in AM, FM or SXM bands. • Hold either button to bypass stations without stopping. Store Radio Presets •...
Page 87
E L E C T R O N I C S Disc Operation (If Equipped) Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin. • CD/Disc Mode is entered by either inserting a CD/Disc or by pressing the MEDIA button located on the side of the display.
Page 88
E L E C T R O N I C S Bluetooth® If using a Bluetooth - equipped device, you may also be able to stream music to your ® vehicle's sound system. • Press the MEDIA button on the faceplate, then press the “source” button on the touchscreen.
Page 89
E L E C T R O N I C S PRE-DEFINED VOICE TEXT REPLY RESPONSES Yes. Stuck in Traffic. See you later. Start without me. I’ll be Late. Okay. Where are you? I will be <number> minutes late. Call me. Are you there yet? I’ll call you later.
Page 90
E L E C T R O N I C S Uconnect® 5.0 VOICE RECOGNITION QUICK TIPS Introducing Uconnect® Start using Uconnect Voice Recognition with these helpful quick tips. It provides ® the key Voice Commands and tips you need to know to control your Uconnect ®...
Page 91
E L E C T R O N I C S Get Started 1. U.S. residents can visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition.
Page 92
E L E C T R O N I C S Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. ® Push the VR button . After the beep, say: •...
Page 93
E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM™ Satellite Radio stations ® you would like to hear. (Subscription or included SiriusXM™ Satellite Radio trial required.) Push the VR button .
Page 94
E L E C T R O N I C S Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If ® ® Equipped). Voice operation is only available for connected USB and iPod devices. ® (Remote CD player optional and not available on all vehicles.) Push the VR button .
Page 95
E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect . When the ® Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions.
Page 96
E L E C T R O N I C S Voice Text Reply Uconnect will announce incoming text messages. Push the Phone button ® say Listen. (Must have compatible mobile phone paired to Uconnect system.) ® 1. Once an incoming text message is read to you, push the Phone button .
E L E C T R O N I C S Uconnect® 8.4A Uconnect® 8.4A AT A GLANCE Uconnect® 8.4A Radio Screen 1 — Status Bar 5 — Climate Button 2 — Menu Bar 6 — Controls Button 3 — Uconnect Apps Button 7 —...
Page 98
E L E C T R O N I C S Setting The Time • Turn the unit on, then press the time display at the top of the screen. Press “Yes.” • If the time is not displayed at the top of the screen, press the “Controls” button on the touchscreen, or the “Apps”...
Page 99
E L E C T R O N I C S RADIO Uconnect® 8.4A Radio Screen 1 — Radio Station Presets 5 — Seek Down 2 — Toggle Between Presets 6 — Direct Tune To A Radio Station 3 — Choose Radio Band 7 —...
Page 100
E L E C T R O N I C S Store Radio Presets Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They are shown at the top of your radio screen. To see the 12 preset stations per band, press the arrow button on the touchscreen at the top right of the screen to toggle between the two sets of six presets.
Page 101
E L E C T R O N I C S SiriusXM Parental Controls • You can skip or hide certain channels from view if you do not want access to them. Press the “Apps” button on the touchscreen, then the “Settings” button on the touchscreen, next press the “Sirius Setup”...
Page 102
E L E C T R O N I C S Replay Option Description Option Replay Time Displays the amount of time in the upper center of the screen by which your content lags the Live channel. Live Resumes playback of Live content at any time while replaying rewound content.
Page 103
E L E C T R O N I C S MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES There are many ways to play music from iPod /MP3 players or USB devices through ® your vehicle's sound system. Press your “Media” button on the touchscreen to begin. Uconnect®...
Page 104
E L E C T R O N I C S USB Port Connect your iPod or compatible device using a USB cable into the USB Port. USB ® Memory sticks with audio files can also be used. Audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.
Page 105
E L E C T R O N I C S Uconnect® 8.4A & 8.4AN Available Media Hubs Uconnect Media Hub Media Hub Remote USB Remote USB Dual ® 8.4A & (USB, AUX (SD, USB, Port (Fully Port (Charg- Charging 8.4AN Ports) AUX Ports)
Page 106
E L E C T R O N I C S NAVIGATION (DEALER-ACTIVATED OPTION) • Your Uconnect 8.4A is “Navigation-Ready,” and can be equipped with Naviga- ® tion at an extra cost. Please see your dealer for details. • The information in the section below is only applicable if the Navigation has been activated.
Page 107
E L E C T R O N I C S Finding Points Of Interest (POI) • From the main Navigation menu, press the “Where To?” button on the touch- screen, then press the “Points of Interest” button on the touchscreen. •...
Page 108
E L E C T R O N I C S Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen.
E L E C T R O N I C S Taking A Detour • To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device might not calculate a detour.
E L E C T R O N I C S Complete The Pairing Procedure • When prompted on the phone, verify with the radio password shown on the Uconnect Screen. ® • If your phone asks you to accept a connection request from Uconnect , select ®...
Page 111
E L E C T R O N I C S Common Phone Commands (Examples) • “Call John Smith” • “Call John Smith mobile” • “Dial 1 248 555 1212” • “Call Emergency” • “Call Towing Assistance” • “Redial” Phonebook •...
Page 112
E L E C T R O N I C S Voice Text Reply (Not Compatible With iPhone®) Once your Uconnect system is paired with a compatible mobile device, the system ® can announce a new incoming text message, and read it to your over the vehicle audio system.
Page 113
E L E C T R O N I C S Uconnect® 8.4A/8.4AN VOICE RECOGNITION QUICK TIPS Introducing Uconnect® Start using Uconnect Voice Recognition with these helpful quick tips. It provides ® the key Voice Commands and tips you need to know to control your Uconnect 8.4AN ®...
Page 114
E L E C T R O N I C S Get Started 1. U.S. residents can visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition.
Page 115
E L E C T R O N I C S Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect system. ® Push the VR button . After the beep, say: •...
Page 116
E L E C T R O N I C S Radio Use your voice to quickly get to the AM, FM or SiriusXM™ Satellite Radio stations ® you would like to hear. (Subscription or included SiriusXM™ Satellite Radio trial required.) Push the VR button .
Page 117
E L E C T R O N I C S Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If ® ® Equipped). Voice operation is only available for connected USB and iPod devices. ® (Remote CD player optional and not available on all vehicles.) Push the VR button .
Page 118
E L E C T R O N I C S Phone Making and answering hands-free phone calls is easy with Uconnect . When the ® Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit: •...
Page 119
E L E C T R O N I C S Voice Text Reply will announce incoming text messages. Push the Phone button Uconnect ® say Listen. (Must have compatible mobile phone paired to Uconnect system.) ® 1. Once an incoming text message is read to you, push the Phone button .
Page 120
E L E C T R O N I C S Climate (8.4A/8.4AN) Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button .
Page 121
E L E C T R O N I C S Navigation (8.4A/8.4AN) The Uconnect navigation feature helps you save time and become more productive ® when you know exactly how to get to where you want to go. (Navigation is optional on the Uconnect 8.4A system.
Page 122
E L E C T R O N I C S Uconnect® Access — If Equipped (8.4A/8.4AN) An included trial and/or subscription is required to take advantage of the Uconnect ® Access services in the next section of this guide. To register with Uconnect Access, ®...
Page 123
E L E C T R O N I C S Register (8.4A/8.4AN) 1. Press the “Apps” button on the bottom of the 8.4-inch touchscreen. 2. If a pop-up message appears, press “Register” or go to the “Favorite Apps” or “All Apps”...
Page 124
E L E C T R O N I C S Mobile App (8.4A/8.4AN) Securely link your mobile device to your vehicle with the Uconnect Access App. ® Once you have downloaded the App, you may start your vehicle or lock it from virtually any distance.
Page 125
E L E C T R O N I C S 2. Listen to the prompt. After the beep, dictate the message you would like to send. Wait for Uconnect to process your message. ® 3. The Uconnect system will repeat your message and provide a variety of options ®...
Page 126
E L E C T R O N I C S SiriusXM Travel Link™ (8.4A/8.4AN — US Market Only) Need to find a gas station, view local movie listings, check a sports score or the 5 - day weather forecast? SiriusXM Travel Link™ is a suite of services that brings a wealth of information right to your Uconnect 8.4AN system.
E L E C T R O N I C S Uconnect® 8.4AN Uconnect® 8.4AN AT A GLANCE Uconnect® 8.4AN Radio Screen 1 — Status Bar 6 — Uconnect Navigation Button ® 2 — View Small Navigation Map 7 — Climate Button 3 —...
Page 129
E L E C T R O N I C S Setting The Time • Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A.
Page 130
E L E C T R O N I C S RADIO Uconnect® 8.4AN Radio 1 — Radio Station Presets 6 — Seek Down 2 — Toggle Between Presets 7 — Direct Tune To A Radio Station 3 — Choose Radio Band 8 —...
Page 131
E L E C T R O N I C S Direct Tune • Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number. Store Radio Presets • Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM).
Page 132
E L E C T R O N I C S Jump • Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. Press “Jump” to activate the feature.
Page 133
E L E C T R O N I C S Replay Lets you replay up to 44 minutes of the content of the current SiriusXM channel. Replay Option Description Option Play/Pause Press to Pause content playback. Press Pause/Play again to resume playback.
Page 134
E L E C T R O N I C S MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES Uconnect® 8.4AN Media Hub 1 — USB Charge Only Port 3 — USB Port 2 — SD Card Port 4 — Audio/AUX Jack There are many ways to play music from iPod /MP3 players or USB devices through ®...
Page 135
E L E C T R O N I C S USB Port • Connect your iPod or compatible device using a USB cable into the USB Port. ® USB Memory sticks with audio files can also be used. Audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.
Page 136
E L E C T R O N I C S Uconnect® 8.4A & 8.4AN Available Media Hubs Uconnect Media Hub Media Hub Remote USB Remote USB Dual ® 8.4A & (USB, AUX (SD, USB, Port (Fully Port (Charg- Charging 8.4AN Ports) AUX Ports)
Page 137
E L E C T R O N I C S NAVIGATION • Press the “Nav” button on the touchscreen in the menu bar to access the Navigation system. Changing The Navigation Voice Prompt Volume 1. Press the “View Map” button on the touchscreen from the Nav Main Menu. 2.
Page 138
E L E C T R O N I C S Finding Points Of Interest • From the main Navigation menu, press the “Where To?” button on the touch- screen, then press the “Points of Interest” button on the touchscreen. •...
Page 139
E L E C T R O N I C S Go Home • A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen.
Page 140
E L E C T R O N I C S Taking A Detour • To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device may not calculate a detour.
Page 141
E L E C T R O N I C S To access SiriusXM Travel Link, press “Apps” button on the touchscreen, then press the “SiriusXM Travel Link” button on the touchscreen. NOTE: SiriusXM Travel Link requires a subscription, sold separately after the five (5) year trial subscription included with your vehicle purchase.
Page 142
E L E C T R O N I C S Start Pairing Procedure On Mobile Phone • Search for available devices on your Bluetooth enabled mobile phone. This is ® usually within Settings or Options under “Bluetooth.” See your mobile phone’s manual for details.
Page 143
E L E C T R O N I C S Transfer Ongoing Call Between Handset And Vehicle During an on-going call, press the “Transfer” button on the touchscreen to transfer an on-going call between handset and vehicle. Common Phone Commands (Examples) •...
Page 144
E L E C T R O N I C S Voice Text Reply (Not Compatible With iPhone®) Once your Uconnect system is paired with a compatible mobile device, the system ® can announce a new incoming text message, and read it to your over the vehicle audio system.
Page 145
E L E C T R O N I C S VOICE COMMAND QUICK REFERENCE Uconnect® 8.4AN Voice Command Quick Reference If the Uconnect Voice Command button exists on your steering wheel, you ® have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel and your eyes on the road.
Page 146
E L E C T R O N I C S Available Radio Button On The Touchscreen Voice Commands Steering Wheel (1) Radio (2) Media (4) Navi- (5) Phone Climate Buttons to Mode Mode gation Mode APPS Controls Push: Uconnect ®...
Page 147
E L E C T R O N I C S Voice Command Examples – Uconnect® 8.4AN While In: Voice Command Example: GENERAL “Go to Radio” (Media, Climate, Navigation, Phone, Apps) – Settings, and Controls are not Voice Command accessible “Cancel”...
Page 148
E L E C T R O N I C S While In: Voice Command Example: PHONE “Dial 123-456-7890” (phone number) “Call John Smith mobile” (home, office, Call Initiation (Requires that phone has other) been Bluetooth paired with radio) ® “Redial”...
E L E C T R O N I C S While In: Voice Command Example: APPS “Show Fuel prices” “Show Current Weather” – provides access to Forecast as well SiriusXM Travel Link (Traffic function is “Show Weather map” – multiple map not voice command accessible within formats available SiriusXM Travel Link)
E L E C T R O N I C S ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) OR DRIVER INFORMATION DISPLAY (DID) The EVIC/DID features an interactive display that is located in the instrument cluster. Pushing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings.
E L E C T R O N I C S PROGRAMMABLE FEATURES Programmable Features The EVIC/DID can be used to view or change the following settings. Push the UP or DOWN button until System Setup displays, then push RIGHT button.
Page 152
E L E C T R O N I C S Uconnect® Customer Programmable Features The Uconnect system allows you to access Customer Programmable feature ® settings such as Display, Voice, Clock, Safety & Driving Assistance, Lights, Doors & Locks, Auto-On Comfort, Engine Off Options, Compass Settings (Uconnect 5.0,) ®...
Page 153
E L E C T R O N I C S Vehicle Info (Customer Information Features) • Push the UP or DOWN button until the Vehicle Info icon is highlighted in the EVIC/DID Display. Push the RIGHT or LEFT to scroll through the following Vehicle Info submenus: •...
E L E C T R O N I C S Trailer Tow • Push the UP or DOWN arrow button until the Trailer Tow icon is highlighted. The screen will display the following information: • Trailer Trip Distance Audio •...
Page 155
E L E C T R O N I C S NOTE: Erasing all channels should only be performed when programming HomeLink ® the first time. Do not erase channels when programming additional buttons. If you have any problems, or require assistance, please call toll-free 1-800-355-3515 or, on the Internet at HomeLink.com for information or assistance.
E L E C T R O N I C S Programming A Non-Rolling Code NOTE: For programming Garage Door Openers manufactured before 1995. 1. Turn the ignition switch to the ON/RUN position. 2. Place the hand-held transmitter 1 to 3 in (3 to 8 cm) away from the HomeLink ®...
E L E C T R O N I C S POWER INVERTER A 115 Volt, 150 Watt power inverter outlet is located on the lower instrument panel next to the climate control knob. This out- let can power cellular phones, electronics and other low power devices requiring power up to 150 Watts.
Page 158
E L E C T R O N I C S The auxiliary power outlets can be found in the following locations: • Lower left and lower right in the center of the instrument panel – if equipped with a column or a eight-speed electronic shifter. •...
Page 159
E L E C T R O N I C S NOTE: • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded, the fuse protecting the system will need to be replaced.
O F F - R O A D C A P A B I L I T I E S ELECTRONICALLY SHIFTED FOUR WHEEL DRIVE OPERATION The four position electronically shifted transfer case provides four mode posi- tions: • Two-wheel drive high range (2WD) •...
Page 161
O F F - R O A D C A P A B I L I T I E S These five position electronically shifted transfer cases provide five mode posi- tions: • Two-wheel drive high range (2WD) • Four-wheel drive automatic range (4WD AUTO) •...
Page 162
O F F - R O A D C A P A B I L I T I E S Shifting Procedure Shifting between 2WD and 4WD AUTO or 4WD LOCK can be made with the vehicle stopped or in motion at speeds up to 55 mph (88 km/h). Shifting between 2WD, 4WD AUTO and 4WD LOCK into 4WD LOW must be made with the transmission in NEUTRAL and the vehicle stopped or rolling at 2 to 3 mph (3 to 5 km/h).
U T I L I T Y TONNEAU COVER The Tonneau Cover can be removed and reinstalled by using the locking clamps located underneath the Tonneau Cover. NOTE: Be sure that the Tonneau Cover is secured before driving. EASY-OFF TAILGATE To simplify mounting of a camper unit with an overhang, the tailgate can be removed.
U T I L I T Y PICKUP BOX You can carry wide building materials (sheets of plywood, etc.) by building a raised load floor. Place lumber across the box in the indentations provided above the wheel housings and in the bulkhead dividers to form the floor. There are stampings in the sheet metal on the inner side bulkheads of the box in front of and behind both wheel housings.
Page 165
U T I L I T Y Turning Cargo Camera On Or Off — With Uconnect® 8.4A/8.4AN 1. Press the “Controls” button located on the bottom of the Uconnect display. ® 2. Press the “Cargo Camera” button to turn the Cargo Camera system ON. NOTE: The Cargo Camera image may be deactivated by touching the Uconnect display.
U T I L I T Y RAMBOX® RamBox® Features 1 — Bed Extender 2 — Bed Rail Tie-Down System Adjustable Cleats 3 — Storage Bin 4 — Press The Button To Open The RamBox system is an integrated pickup box storage and cargo management ®...
U T I L I T Y The RamBox storage bins can be locked and unlocked using the vehicle key or the ® remote keyless entry transmitter. NOTE: Provisions are provided in the bins for cargo dividers and shelf supports. These accessories (in addition to other RamBox accessories) are available from MOPAR ®...
Page 168
U T I L I T Y Divider Position There are 11 divider slots along the bed inner panels which allow for various positions to assist in managing your cargo. To install the bed extender into a divider position perform the following: 1.
Page 169
U T I L I T Y CAUTION! Failure to follow the following items could cause damage to the vehicle: • Assure that all cargo inside the storage bins is properly secured. • Do not exceed cargo weight rating of 150 lb (68 kg) per bin. •...
U T I L I T Y TOWING & PAYLOAD NOTE: For additional trailer towing information (maximum trailer weight ratings) refer to the following website addresses: • ramtrucks.com/en/towing_guide/ • ramtruck.ca (Canada) • rambodybuilder.com TOW/HAUL MODE When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting occurs, press the TOW/HAUL switch to select TOW/HAUL mode.
U T I L I T Y INTEGRATED TRAILER BRAKE MODULE The Integrated Trailer Brake Controller allows you to automatically or manually activate the Electric Trailer Brakes and Electric Over Hydraulic Trailer Brakes for a better braking performance when towing a trailer. NOTE: The Integrated Trailer Brake Controller is located in the center stack below the climate controls.
U T I L I T Y GAIN Adjustment Buttons (+/-) • Pressing the +/- buttons, located on the left side of the module, will increase/decrease the brake control power output to the trailer brakes in 0.5 increments. The GAIN setting can be increased to a maximum of 10 or decreased to a minimum of 0 (no trailer braking).
Page 173
U T I L I T Y NOTE: • When recreationally towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details. • Vehicles equipped with air suspension must be placed in Transport mode before tying them down (from the body) on a trailer or flatbed truck.
Page 174
U T I L I T Y Recreational Towing — Four-Wheel Drive Models NOTE: Both the manual shift and electronic shift transfer cases must be shifted into NEUTRAL (N) for recreational towing. Automatic transmissions must be shifted into PARK for recreational towing. Manual transmissions must be placed in gear (NOT in NEUTRAL) for recreational towing.
Page 175
U T I L I T Y Shifting Into NEUTRAL (N) Use the following procedure to prepare your vehicle for recreational towing. WARNING! You or others could be injured or killed if you leave the vehicle unattended with the transfer case in the NEUTRAL (N) position without first fully engaging the parking brake.
Page 176
U T I L I T Y 9. Shift the transmission to NEUTRAL. Firmly apply the parking brake. Turn OFF the engine. For vehicles with Keyless Enter-N-Go™, press and hold the ENGINE START/STOP button until the engine shuts off. 10. Shift the transmission into PARK or place manual transmission in gear (NOT in Neutral).
Page 177
U T I L I T Y • With electronic shift transfer case with rotary selector switch, press and hold the transfer case NEUTRAL (N) button until the NEUTRAL (N) indicator light turns off. After the NEUTRAL (N) indicator light turns off, release the NEUTRAL (N) button.
1 5 0 0 3 . 0 L D I E S E L DIESEL ENGINE BREAK-IN RECOMMENDATIONS • The 3.0 turbocharged diesel engine does not require a break-in period due to its construction. Normal operation is allowed, providing the following recommenda- tions are followed: •...
1 5 0 0 3 . 0 L D I E S E L CAUTION! If the “Water in Fuel Indicator Light” remains on, DO NOT START the engine before you drain the water from the fuel filters to avoid engine damage. Refer to “Maintenance Procedures/Draining Fuel/Water Separator Filter”...
1 5 0 0 3 . 0 L D I E S E L DIESEL FUEL FILTER/WATER SEPARATOR Draining Fuel/Water Separator If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the separator. The drain plug is located on the bottom of the Fuel Filter and Water Separator assembly which is located above the rear axle next to the fuel tank.
1 5 0 0 3 . 0 L D I E S E L EXHAUST REGENERATION This engine meets all required EPA diesel engine emissions standards. To achieve these emissions standards, your vehicle is equipped with a state-of-the-art engine and exhaust system. These systems are seamlessly integrated into your vehicle and managed by the Powertrain Control Module (PCM).
1 5 0 0 3 . 0 L D I E S E L Exhaust Filter Full — Power Reduced See Dealer The PCM derates the engine in order to limit the likelihood of permanent damage to the after-treatment system. If this condition is not corrected and a dealer service is not performed, extensive exhaust after-treatment damage can occur.
1 5 0 0 3 . 0 L D I E S E L ADDING FUEL — DIESEL ENGINE ONLY Your vehicle is equipped with a cap-less fuel system. Most fuel cans will not open the flapper door. A funnel is provided to open the flapper door to allow emergency refueling with a fuel can.
1 5 0 0 3 . 0 L D I E S E L DIESEL EXHAUST FLUID Diesel Exhaust Fluid (DEF) sometimes known simply by the name of its active component, UREA – is a key component of selective catalytic reduction (SCR) systems, which help diesel vehicles meet stringent emission regulations.
1 5 0 0 3 . 0 L D I E S E L Adding Diesel Exhaust Fluid The DEF gauge (located in the instrument panel) will display the level of DEF remaining in the tank. Completely fill the DEF tank through the diesel exhaust fluid fill location (located behind the fuel door) at every maintenance interval or before if prompted by the Electronic Vehicle Information Center (EVIC)/Driver Information Display (DID).
Page 186
1 5 0 0 3 . 0 L D I E S E L 3. Reinstall cap onto DEF tank. Refer to your Diesel Supplement on the DVD for further details. CAUTION! • To avoid DEF spillage and overfilling, do not “top off” the DEF tank after filling. •...
Page 187
1 5 0 0 3 . 0 L D I E S E L Diesel Exhaust Fluid (DEF) Fault Warning Messages There are different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected.
6 . 7 L C U M M I N S ® D I E S E L DIESEL ENGINE BREAK-IN RECOMMENDATIONS The Cummins turbocharged diesel engine does not require a break-in period due to ® its construction. Normal operation is allowed, providing the following recommenda- tions are followed: •...
6 . 7 L C U M M I N S ® D I E S E L Water In Fuel Message If a Water In Fuel message or indicator appears in the cluster and a chime sounds five times, the fuel/water separator will need to be drained immediately to prevent engine damage.
6 . 7 L C U M M I N S ® D I E S E L DIESEL EXHAUST BRAKE (ENGINE BRAKING) The Exhaust Brake switch is located on the switch bank below the audio system. This switch is used to enable exhaust brake modes. Pressing the exhaust brake switch once will enable full strength exhaust brake mode, indicated by a yellow icon in the EVIC/DID.
6 . 7 L C U M M I N S ® D I E S E L IDLE-UP FEATURE (AUTOMATIC TRANSMISSION ONLY) Speed Control Switches 1 — Push CANCEL 2 — Push ON/OFF 3 — Push Resume/Accel 4 — Push Set/Decel The Idle-Up Feature uses the speed control switches to increase engine idle speed and quickly warm the vehicle’s interior.
6 . 7 L C U M M I N S ® D I E S E L ENGINE MOUNTED FUEL FILTER/WATER SEPARATOR Draining Fuel/Water Separator If the “Water in Fuel” indicator light is illuminated and an audible chime is heard five times, you should stop the engine and drain the water from the separator.
6 . 7 L C U M M I N S ® D I E S E L CAUTION! • Diesel fuel will damage blacktop paving surfaces. Drain the filter into an appropriate container. • Do not prefill the fuel filter when installing a new fuel filter. There is a possibility debris could be introduced into the fuel filter during this action.
6 . 7 L C U M M I N S ® D I E S E L The underbody mounted filter housing will cause the engine not to run if: • No filter is installed. NOTE: • Using a fuel filter that does not meet the manufacturer's filtration and water separating requirements can severely impact fuel system life and reliability.
Page 195
6 . 7 L C U M M I N S ® D I E S E L Exhaust System — Regeneration Required Now “Exhaust System—Regeneration Required Now” will be displayed on the EVIC/DID if the exhaust particulate filter reaches 80% of its maximum storage capacity. Exhaust Filter XX% Full Indicates that the Diesel Particulate Filter (DPF) is approaching full.
6 . 7 L C U M M I N S ® D I E S E L COOL-DOWN IDLE CHART TURBO "COOL DOWN" CHART Idle Time Driving Conditions Load Turbo Temp (in minutes) Before Shut Down Stop and Go Empty Cool Less than 1...
6 . 7 L C U M M I N S ® D I E S E L Emergency Fuel Can Refueling 1. Retrieve funnel from the jack storage area under the passenger seat. 2. Insert the funnel into same filler pipe opening as the fuel nozzle. 3.
6 . 7 L C U M M I N S ® D I E S E L The purpose of the SCR system is to reduce levels of NOx (oxides of nitrogen emitted from engines) that are harmful to our health and the environment to an almost near-zero level.
6 . 7 L C U M M I N S ® D I E S E L Diesel Exhaust Fluid Storage Diesel Exhaust Fluid (DEF) is considered a very stable product with a long shelf life. If DEF is kept in temperatures between 10° to 90°F (-12° to 32°C), it will last a minimum of one year.
Page 200
6 . 7 L C U M M I N S ® D I E S E L DEF Fill Procedure 1. Remove cap from DEF tank (located behind the fuel door on drivers side of the vehicle). 2. Insert DEF container or fill nozzle into DEF fill location and fill DEF tank.
Page 201
6 . 7 L C U M M I N S ® D I E S E L Diesel Exhaust Fluid (DEF) Warning Messages Your vehicle will begin displaying warning messages when the DEF level reaches a driving range of approximately 350 miles (563 km). If the following warning message sequence is ignored, your vehicle may be limited to a maximum speed of 5 MPH (8 km/H) unless DEF is added.
Page 202
6 . 7 L C U M M I N S ® D I E S E L Diesel Exhaust Fluid (DEF) Fault Warning Messages There are four different messages which are displayed if the vehicle detects that the DEF system has been filled with a fluid other than DEF, has experienced component failures, or when tampering has been detected.
W H A T T O D O I N E M E R G E N C I E S ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling.
Page 204
W H A T T O D O I N E M E R G E N C I E S When the malfunction indicator is illuminated, the system may not be able to detect or signal low tire pressure as intended. TPMS malfunctions may occur for a variety of reasons, including the installation of replacement or alternate tires or wheels on the vehicle that prevent the TPMS from functioning properly.
W H A T T O D O I N E M E R G E N C I E S - Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
W H A T T O D O I N E M E R G E N C I E S - Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the key is in the ON/RUN position before engine start.
W H A T T O D O I N E M E R G E N C I E S - Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON/RUN position and may stay on for as long as four seconds.
Page 208
W H A T T O D O I N E M E R G E N C I E S - Transmission Temperature Warning Light This light indicates that there is excessive transmission fluid temperature that might occur with severe usage such as trailer towing. If this light turns on, stop the vehicle and run the engine at idle, with the transmission in NEUTRAL, until the light turns off.
W H A T T O D O I N E M E R G E N C I E S INSTRUMENT CLUSTER INDICATOR LIGHTS - Turn Signal Indicator The arrows will flash with the exterior turn signals when the turn signal lever is operated.
W H A T T O D O I N E M E R G E N C I E S — Electronic Speed Control Set Indicates that the Electronic Speed Control has been set. - Fuel Cap/Loose Gas Cap Message If a “gas cap”...
W H A T T O D O I N E M E R G E N C I E S JACKING AND TIRE CHANGING Jack Location The jack and jack tools are stored under the front passenger seat. Removal Of Jack And Tools •...
W H A T T O D O I N E M E R G E N C I E S 2500/3500 Series Trucks • Remove the jack and tool bracket assembly by removing the wing bolt and sliding the jack and tool bracket assembly from under the seat. Jack And Tool Bracket Assembly Removing The Spare Tire •...
Page 213
W H A T T O D O I N E M E R G E N C I E S Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas. 2. Turn on the Hazard Warning flasher. 3.
Page 214
W H A T T O D O I N E M E R G E N C I E S 3. Placement of the jack: 1500 Series Trucks • When changing a front wheel, place the scissors jack under the rear portion of the lower control arm as shown below.
Page 215
W H A T T O D O I N E M E R G E N C I E S • Operate the jack using the jack drive tube and the wheel wrench. The tube extension may be used but is not required. •...
Page 216
W H A T T O D O I N E M E R G E N C I E S 2500/3500 Series Trucks • For 2500/3500 4x2 series trucks, when changing a front wheel, place the bottle jack under the frame rail behind the wheel. Locate the jack as far forward as possible on the straight part of the frame.
Page 217
W H A T T O D O I N E M E R G E N C I E S • For 2500/3500 4x4 series trucks, when changing the front wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle as close to the tire as possible with the drive tubes extending to the front.
Page 218
W H A T T O D O I N E M E R G E N C I E S • Using the lug wrench, finish tightening the wheel nuts using a crisscross pattern. The correct wheel nut tightness is 130 ft lbs (176 N·m) torque (1500 Series), 135 ft lbs (183 N·m) torque for 2500/3500 single-rear wheel (SRW) models, and 140 ft lbs (190 N·m) for 3500 dual rear-wheel models.
Page 219
W H A T T O D O I N E M E R G E N C I E S 4. Place the jack and tools in the storage position holding the jack by the jack turn-screw, slip the jack and tools under the seat so that the bottom slot engages into the fastener on the floor.
Page 220
W H A T T O D O I N E M E R G E N C I E S 2500/3500 Series Trucks 1. Tighten the jack all the way down by turning the jack turn-screw clockwise until the jack is snug. 2.
W H A T T O D O I N E M E R G E N C I E S Wheel Nuts All wheel nuts should be tightened occasionally to eliminate the possibility of wheel studs being sheared or the bolt holes in the wheels becoming elongated. This is especially important during the first few hundred miles/kilometers of operation to allow the wheel nuts to become properly set.
Page 222
To Stow The Flat Or Spare NOTE: RAM 1500 vehicles equipped with aluminum wheels cannot be stored under the vehicle because the wheel retainer will not fit through the wheel pilot hole. Secure the flat tire in the bed of the truck. Have the flat tire repaired or replaced immediately.
Page 223
W H A T T O D O I N E M E R G E N C I E S WARNING! • Do not attempt to change a tire on the side of the vehicle close to moving traffic. Pull far enough off the road to avoid the danger of being hit when operating the jack or changing the wheel.
W H A T T O D O I N E M E R G E N C I E S JUMP-STARTING PROCEDURES If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. Jump-starting can be dangerous if done improperly so please follow the procedures in this section carefully.
W H A T T O D O I N E M E R G E N C I E S WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be injured by moving fan blades.
Page 226
W H A T T O D O I N E M E R G E N C I E S 4. Connect the opposite end of the negative (-) jumper cable to a good engine ground (exposed metal part of the discharged vehicle’s engine) away from the battery and the fuel injection system.
W H A T T O D O I N E M E R G E N C I E S EMERGENCY TOW HOOKS • If your vehicle is equipped with tow hooks, they are mounted in the front. • For off-road recovery, it is recommended to use both of the front tow hooks to minimize the risk of damage to the vehicle.
W H A T T O D O I N E M E R G E N C I E S Center Console Shifter • Firmly set the parking brake. • Turn the Key Fob to the ACC or ON/RUN position without starting the engine.
Page 229
W H A T T O D O I N E M E R G E N C I E S • Using the screwdriver or similar tool, push the Manual Park Release lever locking tab (just below the middle of the lever) to the right. Manual Park Release Lever Locking Tab •...
W H A T T O D O I N E M E R G E N C I E S To Reset The Manual Park Release: • Push the locking tab to the right, to unlock the lever. • Rotate the Manual Park Release lever forward to its original position, until the locking tab snaps into place to secure the lever.
W H A T T O D O I N E M E R G E N C I E S FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved using a rocking motion.
W H A T T O D O I N E M E R G E N C I E S EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
M A I N T A I N I N G Y O U R V E H I C L E OPENING THE HOOD 1. Pull the hood release lever located below the steering wheel at the base of the instrument panel. 2.
M A I N T A I N I N G Y O U R V E H I C L E ENGINE COMPARTMENT 3.6L Engine 1. Air Cleaner Filter 2. Engine Oil Fill (Under Cover) 3. Brake Fluid Reservoir 4.
Page 235
M A I N T A I N I N G Y O U R V E H I C L E 6. Washer Fluid Reservoir 7. Engine Coolant Reservoir 8. Engine Coolant Pressure Cap 9. Engine Oil Dipstick...
Page 236
M A I N T A I N I N G Y O U R V E H I C L E 5.7L Engine 1. Air Cleaner Filter 2. Transmission Fluid Dipstick 3. Engine Oil Fill 4. Brake Fluid Reservoir 5.
Page 237
M A I N T A I N I N G Y O U R V E H I C L E 6. Engine Oil Dipstick 7. Power Distribution Center (Fuses) 8. Washer Fluid Reservoir 9. Engine Coolant Reservoir 10. Engine Coolant Pressure Cap...
Page 238
M A I N T A I N I N G Y O U R V E H I C L E 6.4L Engine 1. Engine Coolant Reservoir 2. Transmission Fluid Dipstick 3. Engine Oil Fill 4. Brake Fluid Reservoir 5.
Page 239
M A I N T A I N I N G Y O U R V E H I C L E 7. Power Distribution Center (Fuses) 8. Washer Fluid Reservoir 9. Power Steering Reservoir 10. Engine Oil Dipstick 11. Air Cleaner Filter...
Page 240
M A I N T A I N I N G Y O U R V E H I C L E 3.0L Diesel Engine 1. Air Cleaner Filter 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Aux Power Distribution Center (Fuses) 5.
Page 241
M A I N T A I N I N G Y O U R V E H I C L E 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Coolant Reservoir 9. Engine Oil Dipstick...
Page 242
M A I N T A I N I N G Y O U R V E H I C L E 6.7L Diesel Engine With 68RFE Transmission — If Equipped 1. Batteries 2. Engine Coolant Reservoir 3. Transmission Fluid Dipstick 4.
Page 243
M A I N T A I N I N G Y O U R V E H I C L E 7. Power Steering Fluid Reservoir 8. Power Distribution Center (Fuses) 9. Engine Oil Dipstick 10. Engine Oil Fill 11.
Page 244
M A I N T A I N I N G Y O U R V E H I C L E 6.7L Diesel Engine With AS69RC Transmission — If Equipped 1. Batteries 2. Engine Coolant Reservoir 3. Transmission Fluid Dipstick 4.
Page 245
M A I N T A I N I N G Y O U R V E H I C L E 7. Washer Fluid Reservoir 8. Power Steering Fluid Reservoir 9. Engine Oil Dipstick 10. Engine Oil Fill 11. Air Cleaner Filter...
M A I N T A I N I N G Y O U R V E H I C L E GAS FLUID CAPACITIES U.S. Metric Fuel (Approximate) 1500 Regular Cab Shortbed/Crew Quad Cab Models 26 Gallons 98 Liters 1500 Regular Cab Longbed/Crew Quad Cab 32 Gallons 121 Liters...
M A I N T A I N I N G Y O U R V E H I C L E GAS FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use MOPAR Antifreeze/ ®...
Page 248
M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.
M A I N T A I N I N G Y O U R V E H I C L E Component Fluid, Lubricant, or Genuine Part Rear Axle – 1500 Models We recommend you use MOPAR Syn- ® thetic Gear Lubricant SAE 75W-140 (MS-8985).
Page 250
M A I N T A I N I N G Y O U R V E H I C L E Component Fluid, Lubricant, or Genuine Part We recommend you use MOPAR Fuel Filter. Must meet 3 micron ® rating.
M A I N T A I N I N G Y O U R V E H I C L E Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Only use Mopar ZF 8&9 Speed ATF™ Automatic Trans- ®...
API Certified to the ISO 22241 standard. Use of fluids not Diesel Exhaust API Certified to ISO 22241 may result in system damage. You can Fluid receive assistance in locating DEF in the United States by calling 866-RAM-INFO (866-726-4636). In Canada call 1–800–465–2001 (English) or 1–800–387–9983 (French).
Page 253
M A I N T A I N I N G Y O U R V E H I C L E CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection.
M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Maintenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or applicable supplement on the DVD for further details.
Page 255
M A I N T A I N I N G Y O U R V E H I C L E Severe Duty All Models • Change Engine Oil at 4000 miles (6,500 km) if the vehicle is operated in a dusty and off road environment.
Page 256
M A I N T A I N I N G Y O U R V E H I C L E...
Page 257
M A I N T A I N I N G Y O U R V E H I C L E...
Page 258
M A I N T A I N I N G Y O U R V E H I C L E...
M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE SCHEDULE — 1500 3.0L DIESEL ENGINE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
Page 260
M A I N T A I N I N G Y O U R V E H I C L E...
Page 261
M A I N T A I N I N G Y O U R V E H I C L E...
Page 262
M A I N T A I N I N G Y O U R V E H I C L E...
Page 263
M A I N T A I N I N G Y O U R V E H I C L E...
M A I N T A I N I N G Y O U R V E H I C L E MAINTENANCE SCHEDULE — 6.7L CUMMINS® DIESEL ENGINE CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
Page 265
M A I N T A I N I N G Y O U R V E H I C L E Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to the steps described under “Instrument Cluster Warning Lights”...
Page 266
M A I N T A I N I N G Y O U R V E H I C L E...
Page 267
M A I N T A I N I N G Y O U R V E H I C L E...
Page 268
M A I N T A I N I N G Y O U R V E H I C L E...
M A I N T A I N I N G Y O U R V E H I C L E FUSES Power Distribution Center The Power Distribution Center is located in the engine compartment near the battery. This center contains cartridge fuses, micro fuses, relays, and circuit breakers. A description of each fuse and component may be stamped on the inside cover, otherwise the cavity number of each fuse is stamped on the inside cover that corresponds to the following chart.
Page 270
M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Micro Fuse Description 30 Amp Pink Electric Park Brake Right Side – If Equipped 30 Amp Pink Smart Bar –...
Page 271
M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Micro Fuse Description 20 Amp Yellow Air Suspension Control Module – If Equipped 10 Amp Red Ignition Node Module / Keyless Ignition 5 Amp Tan...
Page 272
M A I N T A I N I N G Y O U R V E H I C L E Cavity Cartridge Fuse Micro Fuse Description 10 Amp Red Drivetrain Control Module/Front Axle Disconnect Module 10 Amp Red Engine Control Module / Electric Power Steering 15 Amp Blue...
M A I N T A I N I N G Y O U R V E H I C L E TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
Page 274
M A I N T A I N I N G Y O U R V E H I C L E Spare Tire Matching Original Equipped Tire And Wheel — If Equipped Your vehicle may be equipped with a spare tire and wheel equivalent in look and function to the original equipment tire and wheel found on the front or rear axle of your vehicle.
M A I N T A I N I N G Y O U R V E H I C L E Limited-Use Spare — If Equipped The limited-use spare tire is for temporary emergency use only. This tire is identified by a label located on the limited-use spare wheel.
M A I N T A I N I N G Y O U R V E H I C L E REPLACEMENT BULBS All of the inside bulbs are brass or glass-wedge base. Aluminum base bulbs are not approved. Interior Bulbs Bulb Number Overhead Console Lamps...
Manuals or Warranty ® Booklet. United States customers may visit the Ram Truck Contact Us page at www.ramtrucks.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Box Material” from the left menu.
• A street address is required when ordering manuals (no P.O. Boxes). • The Owner's Manual and User Guide electronic files are also available on the Chrysler, Jeep, Ram Truck, Dodge and SRT websites. • Click on the “For Owners” tab, select “Owner/Service Manuals”, then select your desired model year and vehicle from the drop down lists.
• The following highlights just some of the many Authentic Ram Accessories by Mopar featuring a fit, finish, and functionality specifically for your Ram.
F A Q ’ s FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 22 How do I program my Front Seat Memory? pg. 30 OPERATING YOUR VEHICLE How does the Electronic Range Select (ERS) operate? pg. 42 ELECTRONICS Which radio is in my vehicle? •...
Page 281
How do I shift into different four-wheel drive selections? pg. 158 UTILITY How do I know how much I can tow with my Ram Truck? pg. 168 How do I adjust the gain on the Integrated Trailer Brake Module? pg. 169 WHAT TO DO IN EMERGENCIES How do I change a flat tire? pg.
This guide has been prepared to help you get quickly acquainted with your new RAM and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect...
Page 292
Download a FREE electronic copy of the Owner’s Manual and Warranty Booklet by visiting: WWW.RAMTRUCKS.COM/EN/OWNERS/MANUALS OR WWW.RAMTRUCKS.COM/EN/WARRANTY (U.S.); WWW.OWNERS.MOPAR.CA/EN (CANADA). 15D241-926-AA RAM TRUCKS 1500/2500/3500 SECOND REV 1 EDITION USER GUIDE...
Need help?
Do you have a question about the 2015 1500 and is the answer not in the manual?
Questions and answers
