Page 1 Nitro 2 0 1 1 O W N E R ’ S M A N U A L...
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ............3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 4 CONTENTS Introduction ......4 Rollover Warning ..... . . 4 How To Use This Manual .
Page 5: Introduction
4 INTRODUCTION INTRODUCTION Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles. This Owner’s Manual has been prepared with the assis- tance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 6: How To Use This Manual
Rollover Warning Label Failure to use the driver and passenger seat belts provided is a major cause of severe or fatal injury. In fact, the U.S. government notes that the universal use of existing seat belts could cut the highway death toll by 10,000 or more each year and could reduce disabling injuries by two million annually.
Page 7 6 INTRODUCTION...
Page 8: Warnings And Cautions
INTRODUCTION 7 WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
8 INTRODUCTION VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a collision resulting in serious injury or death.
Page 10: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Ignition Key Removal ....12 Key-In-Ignition Reminder .
Page 11 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Battery Replacement ....24 General Information ....25 Remote Starting System —...
Page 12 Enhanced Seat Belt Use Reminder System (BeltAlert ) — If Equipped ....52 Seat Belt Lock Out ....54 Seat Belts And Pregnant Women .
Page 13: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The keys for your vehicle are double-sided. You can insert the keys into the locks with either side up. Vehicle Key The keys for your new vehicle are enclosed in a plastic bag with the key code number on it.
Page 14 Ignition Switch Positions 1 — Lock 3 — On 2 — Acc 4 — Start THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 15: Key-In-Ignition Reminder
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key-In-Ignition Reminder If you open the driver’s door and the key is in the ignition, a chime will sound to remind you to remove the key. NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position.
Page 16: Replacement Keys
If the Vehicle Security Light turns on during normal vehicle operation (vehicle running for longer than 10 sec- onds), it indicates that there is a fault in the electronics. Should this occur, have the vehicle serviced as soon as possible by an authorized dealer. CAUTION! The Sentry Key Immobilizer system is not compat- ible with some after-market remote starting systems.
Page 17: Customer Key Programming
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE procedure. This procedure consists of programming a blank key to the vehicle electronics. A blank key is one that has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle keys with you to an authorized dealer.
Page 18: General Information
Repeat this procedure to program up to eight keys. If you do not have a programmed Sentry Key , contact your authorized dealer for details. NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory.
Page 19: To Arm The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Arm the System Remove the keys from the ignition switch and exit the vehicle. Lock the doors and liftgate by pressing the power door LOCK switch or the LOCK button on the Remote Keyless Entry (RKE) transmitter.
Page 20: Illuminated Entry
Tamper Alert If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times when you unlock the doors. Check the vehicle for tampering. ILLUMINATED ENTRY The interior lights come on when you open any door or use the Remote Keyless Entry (RKE) transmitter to un- lock any door.
Page 21: To Unlock The Doors And Liftgate
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • For the remote starting feature (if equipped), refer to “Remote Starting System” for further information. • Your vehicle’s RKE transmitter may have three or four buttons depending on the optional features purchased with your vehicle.
Page 22: To Lock The Doors And Liftgate
3. Test the feature from outside the vehicle by pressing the LOCK and UNLOCK buttons on the RKE transmitter. 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the LOCK button on the RKE transmit- ter while you are inside the vehicle will activate the Vehicle Security Alarm.
Page 23 22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Test the feature from outside the vehicle by pressing the LOCK button on the RKE transmitter. 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the LOCK button on the RKE transmit- ter while you are inside the vehicle will activate the Vehicle Security Alarm.
Page 24: Remote Open Window Feature - If Equipped
3. Test the feature from outside the vehicle by pressing the LOCK and UNLOCK buttons on the RKE transmitter. 4. Repeat these steps if you want to return this feature to its previous setting. NOTE: Pressing the LOCK button on the RKE transmit- ter while you are inside the vehicle will activate the Vehicle Security Alarm.
Page 25: Programming Additional Transmitters
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE During the PANIC mode, the door locks and RKE systems will function normally. PANIC mode will not disarm the Vehicle Security Alarm system on vehicles so equipped. Programming Additional Transmitters Refer to Sentry Key “Customer Key Programming.” If you do not have a programmed RKE transmitter, contact your authorized dealer for details.
Page 26: General Information
3. Remove and replace the battery. Avoid touching the new battery with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 4. To reassemble the RKE transmitter case, snap the two halves together.
Page 27: How To Use Remote Start
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How to Use Remote Start All of the following conditions must be met before the engine will remote start: • Shift lever in PARK • Doors closed • Hood closed • Hazard switch off •...
Page 28 NOTE: • The park lamps will turn on and remain on during Remote Start mode. • For security, power window and power sunroof op- eration (if equipped) are disabled when the vehicle is in the Remote Start mode. • The engine can be started two consecutive times (two 15-minute cycles) with the RKE transmitter.
Page 29: Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE DOOR LOCKS Manual Door Locks Use the manual door lock knob to lock the doors from inside the vehicle. If the lock knob is down when the door is closed, the door will lock. Make sure the keys are not inside the vehicle before closing the door.
Page 30: Automatic Door Locks
Power Door Lock Switch 1 - Unlock 2 - Lock If you press the power door LOCK switch while the key is in the ignition and either of the front doors is open, the power locks will not operate. This prevents you from accidentally locking your keys in the vehicle.
Page 31: Automatic Unlock Doors On Exit
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Door Locks Programming The automatic door locks feature can be enabled or disabled as follows: For vehicles equipped with an Electronic Vehicle Infor- mation Center (EVIC), refer to “Electronic Vehicle Infor- mation Center (EVIC)/Personal Settings (Customer- Programmable Features)”...
Page 32: Child-Protection Door Lock System - Rear Doors
6. The vehicle speed is 0 mph (0 km/h). Automatic Unlock Doors on Exit Programming The automatic unlock doors on exit feature can be enabled or disabled as follows: For vehicles equipped with an Electronic Vehicle Infor- mation Center (EVIC), refer to “Electronic Vehicle Infor- mation Center (EVIC)/Personal Settings (Customer- Programmable Features)”...
Page 33 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE system on a door is engaged, that door can only be opened by using the outside door handle even if the inside door lock is in the unlocked position. Child-Protection Door Lock NOTE: •...
Page 34: Windows
WARNING! Avoid trapping anyone in a vehicle in a collision. Remember that the rear doors can only be opened from the outside when the Child-Protection locks are engaged. WINDOWS Power Windows The power window controls are located on the driver’s door trim panel.
Page 35 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further in- formation. WARNING! Never leave children in a vehicle with the keys in the ignition switch. Occupants, particularly unattended children, can become entrapped by the windows while operating the power window switches.
Page 36 Auto Up Feature with Anti-Pinch Protection — If Equipped On some models, the driver’s and front passenger’s (if equipped for passenger side) power window switches have an “Auto Up” feature. Pull the window switch up to the second detent, release, and the window will go up automatically.
Page 37 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! There is no anti-pinch protection when the window is almost closed. Be sure to clear all objects from the window before closing. Reset At some point in time, it may be necessary to reactivate the auto-up feature.
Page 38: Wind Buffeting
Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears. Your vehicle may exhibit wind buffeting with the windows down, or the sunroof (if equipped) in certain open or partially open positions. This is a normal occur- rence and can be minimized.
Page 39: Occupant Restraints
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems: • Three-point lap and shoulder belts for all seating positions • Advanced Front Airbags for driver and front passen- •...
Page 40 NOTE: The Advanced Front Airbags have a multistage inflator design. This allows the airbag to have different rates of inflation based on the severity and type of collision. Please pay close attention to the information in this section. It tells you how to use your restraint system properly, to keep you and your passengers as safe as possible.
Page 41: Lap/Shoulder Belts
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belts All seating positions in your vehicle are equipped with lap/shoulder belts. The belt webbing retractor is de- signed to lock during very sudden stops or accidents. This feature allows the shoulder part of the belt to move freely with you under normal conditions.
Page 42: Lap/Shoulder Belt Operating Instructions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the seat. 2. The seat belt latch plate is located on the B-Pillar along the outboard side and rear of the seat cushion. The rear seat belt latch plates are located on the C-Pillar for the outboard rear seating positions and next to your arm in the center rear seating position.
Page 43 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Latch Plate To Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 44 WARNING! (Continued) • A belt that is worn under your arm is dangerous. Your body could strike the inside surfaces of the vehicle in an accident, increasing head and neck injury. A belt worn under the arm can cause internal injuries. Ribs aren’t as strong as shoulder bones.
Page 45 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 5. Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt. Removing Slack From Belt 6.
Page 46: Lap/Shoulder Belt Untwisting Procedure
Lap/Shoulder Belt Untwisting Procedure Use the following procedure to untwist a twisted lap/ shoulder belt. 1. Position the latch plate as close as possible to the anchor point. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, grasp and twist the belt webbing 180 degrees to create a fold that begins immediately above the latch plate.
Page 47: Seat Belts In Passenger Seating Positions
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: The adjustable upper shoulder belt anchorage is equipped with an Easy Up feature. This feature allows the shoulder belt anchorage to be adjusted in the upward position without pressing the release button. To verify the shoulder belt anchorage is latched, pull downward on the shoulder belt anchorage until it is locked into position.
Page 48: Automatic Locking Retractors (Alr) Mode - If Equipped
• ALR — Automatic Locking Retractor If the passenger seating position is equipped with an ALR and is being used for normal usage: Only pull the belt webbing out far enough to comfortably wrap around the occupants mid-section so as to not activate the ALR.
Page 49: Supplemental Active Head Restraints (Ahr)
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Active Head Restraints (AHR) These head restraints are passive, deployable compo- nents, and vehicles with this equipment cannot be readily identified by any markings, only through visual inspec- tion of the head restraint. The head restraint will be split in two halves, with the front half being soft foam and trim, the back half being decorative plastic.
Page 50 Active Head Restraint (AHR) Components 1 — Head Restraint Front 3 — Head Restraint Back Half Half (Soft Foam and Trim) (Decorative Plastic Rear Cover) 2 — Seatback 4 — Head Restraint Guide Tubes THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 CAUTION! All occupants, including the driver, should not oper- ate a vehicle or sit in a vehicle’s seat until the head...
Page 51 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. Grasp the deployed AHR from the rear seat. Hand Positioning Points On AHR 2. Position the hands on the top of the deployed AHR at a comfortable position. 3. Pull down then rearward towards the rear of the vehicle then down to engage the locking mechanism.
Page 52 3 — Final Downward Movement To Engage Locking Mecha- nism 4. The AHR front soft foam and trim half should lock into the back decorative plastic half. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 AHR In Reset Position NOTE: •...
Page 53: Energy Management Feature
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Energy Management Feature This vehicle has a safety belt system with an energy management feature in the front seating positions to help further reduce the risk of injury in the event of a head-on accident.
Page 54 The front passenger seat BeltAlert is not active when the front passenger seat is unoccupied. BeltAlert may be triggered when an animal or heavy object is on the front passenger seat or when the seat is folded flat (if equipped). It is recommended that pets be restrained in the rear seat in pet harnesses or pet carriers that are secured by seat belts, and cargo is properly stowed.
Page 55: Seat Belt Lock Out
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Lock Out The center rear seat belt system has a lock out feature that will not allow you to extract the center webbing unless the rear seat upper latch is engaged. Seat Belts and Pregnant Women We recommend that pregnant women use the seat belts throughout their pregnancy.
Page 56 panel, above the glove compartment. The words SRS/ AIRBAG are embossed on the airbag covers. NOTE: These airbags are certified to the new Federal regulations for Advanced Airbags. Advanced Front Airbag and Knee Bolster Locations 1 — Driver and Passenger Advanced Front Airbags 2 —...
Page 57 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE This vehicle is equipped with Supplemental Side Airbag Inflatable Curtains (SABIC) that run the entire length of the headliner to protect the driver, front, and rear pas- sengers sitting next to a window. Supplemental Side Airbag Inflatable Curtains (SABIC) Label Location NOTE:...
Page 58 • Supplemental Side Airbag Inflatable Curtains (SABIC) • Front and Side Impact Sensors • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, and Seat Track Position Sensors • Supplemental Active Head Restraint for Driver and Front Passenger • Occupant Classification System (OCS) •...
Page 59 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • No objects should be placed over or near the airbag on the instrument panel, because any such objects could cause harm if the vehicle is in a collision severe enough to cause the airbag to inflate.
Page 60 Supplemental Side Airbag Inflatable Curtain (SABIC) SABIC airbags may offer side-impact and vehicle rollover protection to front and rear seat outboard occupants in addition to that provided by the body structure. Each airbag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side-impact head injuries.
Page 61 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • If your vehicle is equipped with SABIC airbags, do not have any accessory items installed which will alter the roof, including adding a sunroof to your vehicle. Do not add roof racks that require permanent attachments (bolts or screws) for instal- lation on the vehicle roof.
Page 62 If a child from 1 to 12 years old (not in a rear facing child seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint. (Refer to “Child Restraints”) You should read the instructions provided with your child restraint to make sure that you are using it properly.
Page 63: Airbag Deployment Sensors And Controls
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Being too close to the steering wheel or instrument panel during Advanced Front Airbag deployment could cause serious injury, including death. Air- bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel.
Page 64 The SABIC will not deploy in all side collisions. SABIC deployment will depend on the severity and type of collision. Because airbag sensors measure vehicle deceleration over time, vehicle speed and damage by themselves are not good indicators of whether or not an airbag should have deployed.
Page 65 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Ignoring the “Airbag Warning Light” in your instru- ment panel could mean you won’t have the airbags to protect you in a collision. If the light does not come on, stays on after you start the vehicle, or if it comes on as you drive, have an authorized dealer service the airbag system immediately.
Page 66 “PASS AIR BAG OFF” to show that the passenger Advanced Front Airbag will not inflate during a collision requiring airbag deployment. When the right front pas- senger seat is empty or when very light objects are placed on the seat, the passenger airbag will not inflate even though the PAD indicator light is not illuminated.
Page 67 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Never place a rear facing infant seat in front of an airbag. A deploying passenger Advanced Front Air- bag can cause death or serious injury to a child in a rear-facing infant seat. Passenger Airbag Disable (PAD) System Front Passenger Indicator Light...
Page 68 If there is a fault present in the airbag system, the Airbag Warning Light (a red light located in the center of the instrument cluster directly in front of the driver) will be turned on. This indicates that you should have an autho- rized dealer service the system immediately.
Page 69 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Along with seat belts and pretensioners, Advanced Front Airbags work with the knee bolsters to provide improved protection for the driver and front passenger. Side airbags also work with seat belts to improve occupant protection. Supplemental Side Airbag Inflatable Curtains (SABIC) The Supplemental Side Airbag Inflatable Curtains...
Page 70 WARNING! If your vehicle is equipped with left and right Supplemental Side Airbag Inflatable Curtains (SABIC), do not stack luggage or other cargo up high enough to block the location of the SABIC. The area where the SABIC is located should remain free from any obstructions.
Page 71 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! Unapproved modifications or service procedures to the front passenger seat assembly, its related compo- nents or seat cover may inadvertently change the airbag deployment in case of a frontal crash. This could result in death or serious injury to the front seat passenger if the vehicle is involved in a collision.
Page 72 If you do have a collision which deploys the airbags, any or all of the following may occur: • The nylon airbag material may sometimes cause abra- sions and/or skin reddening to the driver and front passenger as the airbags deploy and unfold. The abrasions are similar to friction rope burns or those you might get sliding along a carpet or gymnasium floor.
Page 73 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured if the airbag system is not there to protect you.
Page 74: Event Data Recorder (Edr)
Airbag Warning Light You will want to have the airbags ready to inflate for your protection in a collision. The airbag system is designed to be maintenance free, if any of the following occurs, have an authorized dealer service the airbag system immediately. •...
Page 75: Child Restraints
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the EDR under normal driving conditions and no per- sonal data (e.g. name, gender, age, and crash location) are recorded. However, other parties, such as law enforce- ment, could combine the EDR data with the type of personally identifying data routinely acquired during a crash investigation.
Page 76 Infants and Child Restraints • Safety experts recommend that children ride rearward- facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used: rearward-facing infant carriers and “convertible”...
Page 77 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some tips for getting the most out of your child restraint: • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable safety standards.
Page 78 buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist the short buckle-end belt several times to shorten it. Insert the latch plate into the buckle with the release button facing out. •...
Page 79 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seatback, they should use a belt-positioning booster seat.
Page 80 belts. Child restraints having tether straps and hooks for connection to the top tether anchorages, have been available for some time. For some older child restraints, many child restraint manufacturers offer add-on tether strap kits or retro-fit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle.
Page 81 80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE and are just visible when you lean into the rear seat to install the child restraint. You will easily feel them if you run your finger along the intersection of the seatback and seat cushion surfaces.
Page 82 hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap. You will first loosen the adjusters on the lower straps and on the tether strap so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 83 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Pull the belt from the retractor until there is enough to allow it to pass through the child restraint and slide the latch plate into the buckle. Then, pull the belt until it is completely extracted from the retractor.
Page 84: Engine Break-In Recommendations
WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap. Transporting Pets Airbags deploying in the front seat could harm your pet. An unrestrained pet will be thrown about and possibly injured, or injure a passenger during panic braking or in an accident.
Page 85: Safety Tips
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not inter- preted as an indication of difficulty. SAFETY TIPS Transporting Passengers NEVER TRANSPORT PASSENGERS IN THE CARGO...
Page 86: Safety Checks You Should Make Inside The Vehicle
Do not run the engine in a closed garage or in confined areas any longer than needed to move your vehicle in or out of the area. If it is necessary to sit in a parked vehicle with the engine running, adjust your heating or cooling controls to force outside air into the vehicle.
Page 87 86 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light The light should come on and remain on for four to eight seconds as a bulb check when the ignition switch is first turned ON. If the light is not lit during starting, see your authorized dealer.
Page 88 WARNING! (Continued) • Never place or install floor mats or other floor coverings in the vehicle that cannot be properly secured to prevent them from moving and inter- fering with the pedals or the ability to control the vehicle. • Never put floor mats or other floor coverings on top of already installed floor mats.
Page 89: Periodic Safety Checks You Should Make Outside The Vehicle
88 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside the Vehicle Tires Examine tires for excessive tread wear and uneven wear patterns. Check for stones, nails, glass, or other objects lodged in the tread. Inspect the tread and sidewall for cuts and cracks.
Page 90: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......93 Inside Day/Night Mirror ....93 Automatic Dimming Mirror —...
Page 91 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training ..... . 132 Seats ......132 Driver’s Power Seat —...
Page 92 Mist Feature ......156 Tilt Steering Column ....156 Electronic Speed Control —...
Page 93 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Closing Sunroof — Express ... . . 173 Closing Sunroof — Manual Mode ..173 Pinch Protect Feature ....173 Pinch Protect Override .
Page 94: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 MIRRORS Inside Day/Night Mirror A two-point pivot system allows for horizontal and vertical adjustment of the mirror. The mirror should be adjusted to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).
Page 95: Automatic Dimming Mirror - If Equipped
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light to the left of the button will illuminate to indicate when the dimming feature is activated.
Page 96: Power Mirrors
WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side mirror could cause you to collide with another vehicle or other object. Use your inside mirror when judging the size or distance of a vehicle seen in the passenger side mirror.
Page 97: Illuminated Vanity Mirrors - If Equipped
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors — If Equipped An illuminated vanity mirror is on each sun visor. To use the mirror, rotate the sun visor down and swing the mirror cover upward. The lights will turn on automati- cally.
Page 98 0.96 or higher. See the Uconnect™ website for supported phones. For Uconnect™ customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 Uconnect™ Phone allows you to transfer calls between the system and your mobile phone as you enter or exit your vehicle and enables you to mute the system’s...
Page 99: Operation
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone Button The radio or steering wheel controls (if equipped) will contain the two control buttons (Uconnect™ Phone Command button) that will enable you to access the system. When you press the button you will hear the word Uconnect™...
Page 100 • For certain operations, compound commands can be used. For example, instead of saying “Setup” and then “Phone Pairing”, the following compound command can be said: “Setup Phone Pairing.” • For each feature explanation in this section, only the compound form of the voice command is given. You can also break the commands into parts and say each part of the command when you are asked for it.
Page 101 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To complete the pairing process, you will need to reference your mobile phone Owner’s Manual. The Uconnect™ website may also provide detailed instructions for pairing. The following are general phone to Uconnect™ Phone pairing instructions: •...
Page 102 Dial by Saying a Number • Press the button to begin. • After the “Ready” prompt and the following beep, say “Dial”. • The system will prompt you to say the number you want to call. • For example, you can say “234-567-8901”. •...
Page 103 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say “Phonebook New Entry”. • When prompted, say the name of the new entry. Use of long names helps the Voice Command and it is recom- mended.
Page 104 • Automatic download and update, if supported, begins as soon as the Bluetooth wireless phone connection is made to the Uconnect™ Phone, for example, after you start the vehicle. • A maximum of 1000 entries per phone will be down- loaded and updated every time a phone is connected to the Uconnect™...
Page 105 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • The phone handset must support Bluetooth OBEX transfers of phonebook entries to use this feature. • Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth , and you may see a message on the phone display that the Bluetooth link is busy.
Page 106 After you are finished editing an entry in the phonebook, you will be given the opportunity to edit another entry in the phonebook, call the number you just edited, or return to the main menu. “Phonebook Edit” can be used to add another phone number to a name entry that already exists in the phonebook.
Page 107: Phone Call Features
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Delete/Erase “All” Uconnect™ Phonebook Entries • Press the button to begin. • After the “Ready” prompt and the following beep, say “Phonebook Erase All”. • The Uconnect™ Phone will ask you to verify that you wish to delete all the entries from the phonebook.
Page 108 mobile service plan. For example, if your mobile service plan provides three-way calling, this feature can be accessed through the Uconnect™ Phone. Check with your mobile service provider for the features that you have. Answer or Reject an Incoming Call - No Call Currently in Progress When you receive a call on your mobile phone, the Uconnect™...
Page 109 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Place/Retrieve a Call From Hold To put a call on hold, press the a single beep. This indicates that the call is on hold. To bring the call back from hold, press and hold the button until you hear a single beep.
Page 110: Uconnect™ Phone Features
Redial • Press the button to begin. • After the “Ready” prompt and the following beep, say “Redial”. • The Uconnect™ Phone will call the last number that was dialed from your mobile phone. NOTE: This may not be the last number dialed from the Uconnect™...
Page 111 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the “Ready” prompt and the following beep, say the name of the language you wish to switch to English, Espanol, or Francais. • Continue to follow the system prompts to complete the language selection.
Page 112 • If supported, this number may be programmable on some systems. To do this, press the say “Setup”, followed by “Emergency”. • The Uconnect™ Phone does slightly lower your chances of successfully making a phone call as to that for the mobile phone directly. WARNING! To use your Uconnect™...
Page 113 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Paging To learn how to page, refer to “Working with Automated Systems”. Paging works properly except for pagers of certain companies, which time out a little too soon to work properly with the Uconnect™ Phone. Voice Mail Calling To learn how to access your voice mail, refer to “Working with Automated Systems”.
Page 114 The Uconnect™ Phone will then send the corresponding phone number associated with the phonebook entry, as tones over the phone. NOTE: • You may not hear all of the tones due to mobile phone network configurations. This is normal. • Some paging and voice mail systems have system time out settings that are too short and may not allow the use of this feature.
Page 115: Advanced Phone Connectivity
114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using the Mobile Phone Keypad You can dial a phone number with your mobile phone keypad and still use the Uconnect™ Phone (while dialing via the mobile phone keypad, the user must exercise caution and take precautionary safety measures).
Page 116 from your Uconnect™ Phone paired mobile phone to the Uconnect™ Phone or vice versa, press the and say “Transfer Call”. Connect or Disconnect Link Between the Uconnect™ Phone and Mobile Phone Your mobile phone can be paired with many different electronic devices, but can only be actively “connected”...
Page 117: Things You Should Know About Your Uconnect™ Phone
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The selected phone will be used for the next phone call. If the selected phone is not available, the Uconnect™ Phone will return to using the highest priority phone present in or near (approximately within 30 ft (9 m)) the vehicle.
Page 118 You can either press the Uconnect™ Phone button to restore the factory setting or repeat the words and phrases when prompted by the Uconnect™ Phone. For best results, the Voice Training session should be com- pleted when the vehicle is parked with the engine running, all windows closed, and the blower fan switched off.
Page 119 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some. •...
Page 120 • fully closed windows, • dry weather conditions, and • operation from the driver’s seat. • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the Uconnect™ Phone. • Echo at the phone far end can sometimes be reduced by lowering the in-vehicle audio volume.
Page 121 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages: You can send messages using Uconnect™ Phone. To send a new message: • Press the button. • After the “Ready” prompt and the following beep, say “SMS Send” or “Send Messages.” •...
Page 122 16. Can this wait? 17. Bye for now 18. When can we meet 19. Send number to call 20. Start without me Turn SMS Incoming Announcement ON/OFF Turning the SMS Incoming Announcement OFF will stop the system from announcing the new incoming mes- sages.
Page 123 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123...
Page 125 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 126 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 127 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 128: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
Page 129: Commands
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If you do not say a command within a few seconds, the system will present you with a list of options. If you ever wish to interrupt the system while it lists options, press the Voice Command for the beep, and say your command.
Page 130 Changing the Volume 1. Start a dialogue by pressing the Voice Command button. 2. Say a command (e.g., “Help”). 3. Use the ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Voice Command system is speaking. Please note the volume setting for Voice Command is different than the audio system.
Page 131 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Radio FM To switch to the FM band, say “FM” or “Radio FM”. In this mode, you may say the following commands: • “Frequency” (to change the frequency) • “Next Station” (to select the next station) •...
Page 132 Memo To switch to the voice recorder mode, say “Memo”. In this mode, you may say the following commands: • “New Memo” (to record a new memo) — During the recording, you may press the Voice Command button to stop recording. You proceed by saying one of the following commands: −...
Page 133: Seats
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training For users experiencing difficulty with the system recog- nizing their voice commands or numbers the Uconnect™ Voice “Voice Training” feature may be used. 1. Press the Voice Command Setup” and once you are in that menu then say “Voice Training.”...
Page 134: Driver's Power Seat - If Equipped
Driver’s Power Seat — If Equipped Some models may be equipped with a six-way power driver seat. The power seat switch is located on the outboard side of the front seat cushion. Use this switch to move the seat up or down, forward or rearward or to tilt the seat.
Page 135: Heated Seats - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seatbelts and while the vehicle is parked.
Page 136 You can choose from HIGH, LOW or OFF heat settings. Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for HIGH, one for LOW and none for OFF. Press the switch once to select HIGH-level heating.
Page 137: Front Manual Seat Adjustment
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Repeated overheating of the seat could damage the heating element and/or degrade the material of the seat. Front Manual Seat Adjustment For models equipped with manual seats, the driver and passenger seats can be adjusted forward or rearward by using a bar by the front of the seat cushion, near the floor.
Page 138: Front Seat - Manual Recline
WARNING! • Adjusting a seat while driving may be dangerous. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death. • Seats should be adjusted before fastening the seatbelts and while the vehicle is parked. Serious injury or death could result from a poorly adjusted seatbelt.
Page 139: Fold-Flat Front Passenger Seat
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fold-Flat Front Passenger Seat The front passenger seatback can be folded flat to allow for extended cargo space. Pull up on the lever to fold down the seatback. Fold Flat Passenger Seat Head Restraints Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear impact.
Page 140 Active Head Restraints — Front Seats Active Head Restraints are passive, deployable compo- nents, and vehicles with this equipment cannot be readily identified by any markings, only through visual inspec- tion of the head restraint. The head restraint will be split in two halves, with the front half being soft foam and trim, the back half being decorative plastic.
Page 141 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE For comfort the Active Head Restraints can be tilted forward and backward. To tilt the head restraint closer to the back of your head, pull forward on the bottom of the head restraint. Push rearward on the bottom of the head restraint to move the head restraint away from your head.
Page 142 • In the event of deployment of an Active Head Re- straint, refer to “Occupant Restraints/Resetting Active Head Restraints (AHR)” in “Things to Know Before Starting Your Vehicle” for further information. WARNING! • Do not place items over the top of the Active Head Restraint, such as coats, seat covers or portable DVD players.
Page 143 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Static Head Restraints — Rear Seats The two outboard seat are equipped with adjustable head restraints. To raise the head restraint, pull upward on the head restraint. To lower the head restraint, press the adjustment button, located on the base of the head restraint, and push downward on the head restraint.
Page 144: 60/40 Split Folding Rear Seat With Fold-Flat Feature
60/40 Split Folding Rear Seat with Fold-Flat Feature To provide additional storage area, each rear seat can be folded flat to allow for extended cargo space and still maintain some rear seating room. Rear Seat Release Strap UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest.
Page 145 144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seri- ously injured or killed. •...
Page 146 To Raise Rear Seat If locked in the folded position, pull the release strap (toward the front of the vehicle). Raise the seatback and lock it into place. If interference from the cargo area prevents the seatback from fully locking, you will have difficulty returning the seat to its proper position.
Page 147: To Open And Close The Hood
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. TO OPEN AND CLOSE THE HOOD To open the hood, there are two latches that must be released.
Page 148 Safety Latch CAUTION! To prevent possible damage: • Do not slam the hood to close it. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 CAUTION! (Continued) • Lower the hood to approximately 6 in (15.2 cm) above the closed position and drop the hood to latch it.
Page 149: Lights
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Multifunction Lever The multifunction lever controls the operation of the parking lights, headlights, headlight beam selection, passing light, fog lights, instrument panel light dimming and turn signals. The multifunction lever is located on the left side of the steering column.
Page 150: Daytime Running Lights - If Equipped
To change the brightness of the instrument panel lights, rotate the center portion of the multifunction lever up or down. NOTE: If the driver’s door is left open, and the head- lights or parking lights are left on, a chime will sound. Daytime Running Lights —...
Page 151: Front Fog Lights - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Fog Lights — If Equipped The front fog light switch is in the multifunction lever. To activate the front fog lights, turn on the parking or low beam headlights and pull out the end of the lever.
Page 152: Instrument Panel Dimmer
NOTE: • If either light remains on and does not flash, or there is a very fast flash rate, check for a defective outside light bulb. If an indicator fails to light when the lever is moved, it would suggest that the indicator bulb is defective.
Page 153: Interior Lights
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the center portion of the lever upward to the last detent to turn on the interior lighting. Dimmer Control Interior Lights The overhead light comes on when a door is opened. It may also be turned on by rotating the control for the dimmer switch on the multifunction lever fully upward.
Page 154: Windshield Wiper Operation
washer, refer to “Rear Window Features” in “Under- standing the Features of Your Vehicle”. Wiper/Washer Lever Windshield Wiper Operation Rotate the end of the lever upward to the second detent past the intermittent settings for low-speed wiper opera- tion. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 Rotate the end of the lever upward to the third detent past the intermittent settings for high-speed wiper opera- tion.
Page 155: Intermittent Wiper System
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The wipers will automatically return to the “park” position if you turn OFF the ignition switch while they are operating. The wipers will resume operation when you turn the ignition switch back to the ON position.
Page 156: Windshield Washers
Front Wiper Control There are five delay settings, which allow you to regulate the wipe interval from a minimum of one cycle every second to a maximum of approximately 36 seconds between cycles or from a minimum of one cycle every second to a maximum of approximately 18 seconds between cycles at vehicle speeds greater than 10 mph (16 km/h).
Page 157: Mist Feature
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Sudden loss of visibility through the windshield could lead to a collision. You might not see other vehicles or other obstacles. To avoid sudden icing of the windshield during freezing weather, warm the windshield with defroster before and during wind- shield washer use.
Page 158: Electronic Speed Control - If Equipped
Push the lever down to unlock the steering column. With one hand firmly on the steering wheel, move the steering column up or down, as desired. Pull the lever up to lock the column firmly in place. Tilt Steering Control Handle UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 WARNING! Do not adjust the steering column while driving.
Page 159: To Activate
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Electronic Speed Control lever is located on the right side of the steering wheel. Electronic Speed Control Lever NOTE: In order to ensure proper operation, the Elec- tronic Speed Control System has been designed to shut down if multiple Speed Control functions are operated at the same time.
Page 160: To Set A Desired Speed
To Set a Desired Speed Turn the Electronic Speed Control ON. When the vehicle has reached the desired speed, press down on the lever and release. Release the accelerator and the vehicle will operate at the selected speed. NOTE: The vehicle should be traveling at a steady speed and on level ground before pressing the SET lever.
Page 161: To Accelerate For Passing
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Tapping the SET DECEL lever once will result in a 1 mph (2 km/h) decrease in set speed. Each subsequent tap of the lever results in a decrease of 1 mph (2 km/h). To Accelerate for Passing Press the accelerator as you would normally.
Page 162 • Jackhammers, large trucks, and other vibrations could affect the performance of ParkSense . • When you turn ParkSense off, the instrument cluster will display “PARK ASSIST DISABLED.” Further- more, once you turn ParkSense off, it remains off until you turn it on again, even if you cycle the ignition key.
Page 163: Enabling And Disabling Parksense
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Clean the ParkSense sensors with water, car wash soap, and a soft cloth. Do not use rough or hard cloths. Do not scratch or poke the sensors. Other- wise, you could damage the sensors. WARNING! •...
Page 164: Parksense Operation
Vehicles Equipped With the Electronic Vehicle Information Center (EVIC) You can turn ParkSense on or off through the EVIC. Refer to “Electronic Vehicle Information Center (EVIC)/ Personal Settings (Customer-Programmable Features)” in “Understanding Your Instrument Panel” for further information. Vehicles Equipped with ParkSense Rear Park Assist Switch You can turn ParkSense on or off by pressing the ParkSense Rear Park Assist switch located...
Page 165 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the ignition is turned to the ON position, and the system is enabled, the warning display will turn on all of its LEDs for approximately one second. Then, the system dimly illuminates the two inner most LEDs when it is detecting no obstacles.
Page 166: Service Parksense Rear Park Assist
Service ParkSense Rear Park Assist When the ParkSense Rear Park Assist System is defec- tive, the instrument cluster will actuate a single chime, once per ignition cycle, and it will display the “SERVICE PARK ASSIST SYSTEM” message. Refer to “Electronic Vehicle Information Center (EVIC)”...
Page 167 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The HomeLink buttons that are located in the headliner or sun visor designate the three different HomeLink channels. HomeLink Buttons NOTE: HomeLink is disabled when the Vehicle Secu- rity Alarm is active. WARNING! •...
Page 168: Programming Homelink
Programming HomeLink Before You Begin If you have not trained any of the HomeLink buttons, erase all channels before you begin training. To do this, press and hold the two outside buttons for 20 seconds until the red indicator flashes. It is recommended that a new battery be placed in the handheld transmitter of the device that is being copied to HomeLink...
Page 169 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After training a HomeLink channel, if the garage door does not operate with HomeLink and the ga- rage door opener was manufactured after 1995, the garage door opener may have a rolling code. If so, proceed to the heading “Programming A Rolling Code System.”...
Page 170: Gate Operator/Canadian Programming
1. Firmly press and release the LEARN or TRAINING button. The name and color of the button may vary by manufacturer. NOTE: You have 30 seconds in which to initiate the next step after the LEARN button has been pressed. 2.
Page 171: Using Homelink
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you unplugged the device for training, plug it back in at this time. Then proceed with Step 4 under “Programming HomeLink ” earlier in this section. Using HomeLink To operate, press and release the programmed HomeLink button.
Page 172: Troubleshooting Tips
Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the LEARN button on the Garage Door Opener to complete the training for a Rolling Code. •...
Page 173: Power Sunroof - If Equipped
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED The power sunroof switch is located between the sun visors on the overhead console. Power Sunroof Switch WARNING! • Never leave unattended children in a vehicle with the key in the ignition switch. Occupants, particu- larly unattended children, can become entrapped by the power sunroof while operating the power sunroof switch.
Page 174: Opening Sunroof - Express
Opening Sunroof — Express Press the switch rearward and release it within one-half second and the sunroof will open automatically from any position. The sunroof will open fully and stop automati- cally. This is called “Express Open”. During Express Open operation, any movement of the sunroof switch will stop the sunroof.
Page 175: Pinch Protect Override
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pinch Protect Override If a known obstruction (ice, debris, etc.) prevents closing and moves the sunroof in the opposite direction, press the switch forward and hold. This allows the sunroof to move towards the closed position. NOTE: Pinch protection is disabled while the switch is pressed.
Page 176: Ignition Off Operation
Ignition Off Operation For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power sunroof switch will remain active for 45 seconds after the ignition switch is turned to the LOCK position. Opening either front door will cancel this feature. For vehicles equipped with the EVIC, the power sunroof switch will remain active for up to approximately ten minutes after the ignition switch is turned to the LOCK...
Page 177 176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced. Front Power Outlet WARNING! To avoid serious injury or death:...
Page 178: Cupholders
CAUTION! • Many accessories that can be plugged in draw power from the vehicle’s battery, even when not in use (i.e., cellular phones, etc.). Eventually, if plugged in long enough, the vehicle’s battery will discharge sufficiently to degrade battery life and/or prevent the engine from starting.
Page 179: Storage
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The rear passengers have cupholders at the rear of the center console. Rear Cupholders STORAGE Glove Box Storage Compartment The glove box storage compartment is located on the right side of the instrument panel. Pull outward on the latch to open the storage compartment.
Page 180: Front Storage Compartment
Front Storage Compartment The front storage compartment (located on the left side of the instrument panel) can hold cell phones, PDAs, and other small items. Front Storage Compartment UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 Console Storage Compartment To open, press the latch and lift the cover. Center Console...
Page 181: Cargo Area Features
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console has a removable storage tray which can hold cell phones, PDAs, and other small items. Removable Storage Tray CARGO AREA FEATURES Cargo Light The cargo area light is activated by opening the liftgate, opening any door, or by rotating the dimmer control on the multifunction lever to the extreme top position.
Page 182 Cargo Tie-Downs UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 WARNING! Cargo tie-down hooks are not safe anchors for a child seat tether strap. In a sudden stop or accident a hook could pull loose and allow the child seat to come loose.
Page 183: Cargo Load Floor - If Equipped
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! (Continued) • Always place cargo evenly on the cargo floor. Put heavier objects as low and as far forward as possible. • Place as much cargo as possible in front of the rear axle.
Page 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 3. Flip the cover over, and lock panel back into position. Floor Panel 2. Lift the cover. Load Floor...
Page 185: Rear Window Features
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE REAR WINDOW FEATURES Rear Window Wiper/Washer The rear wiper/washer is controlled by a rotary switch located on the control lever. The control lever is located on the right side of the steering column. Rear Wiper/Washer Control Rotate the switch upward to the first detent posi- tion for rear wiper operation.
Page 186: Roof Trim Applique - Non Functional
mirrors. An indicator in the button will illuminate when the rear window defroster is on. The rear window defroster automatically turns off after approximately 10 minutes. For an additional five minutes of operation, press the button a second time. NOTE: To prevent excessive battery drain, use the rear window defroster only when the engine is operating.
Page 187 186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: Metal rails/crossbars are offered by MOPAR accessories. See your authorized dealer. External racks do not increase the total load carrying capacity of the vehicle. Be sure that the total occupant and luggage load inside the vehicle, plus the load on the luggage rack, do not exceed the maximum vehicle load capacity.
Page 188: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....190 Instrument Cluster ....191 Instrument Cluster Descriptions .
Page 189 188 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 230 (REQ) — AM/FM Stereo Radio And 6–Disc CD/DVD Changer (MP3/WMA AUX Jack) ....222 Operating Instructions - Radio Mode ..222 Operation Instructions - (Disc Mode For CD And MP3/WMA Audio Play, DVD-Video) .
Page 190 Operation Instructions — CD Mode For CD And MP3 Audio Play ....256 Notes On Playing MP3 Files ... . 258 List Button (CD Mode For MP3 Play) .
Page 191: Instrument Panel Features
190 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlet 6 — Glove Compartment 2 — Instrument Cluster 7 — Climate Control 3 — Storage Tray 8 — Heated Seat Switch * 4 — Center Air Outlet 9 — Rear Park Assist Switch * 5 —...
Page 192: Instrument Cluster
UNDERSTANDING YOUR INSTRUMENT PANEL 191 INSTRUMENT CLUSTER...
Page 193: Instrument Cluster Descriptions
192 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 1. Fuel Gauge The fuel gauge shows level of fuel in tank when ignition switch is in the ON/RUN position. 2. Fuel Door Reminder This symbol indicates the side of the vehicle where the fuel cap is located.
Page 194 WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call an authorized dealer- ship for service if your vehicle overheats. If you decide to look under the hood yourself, see “Main- taining Your Vehicle”.
Page 195 194 UNDERSTANDING YOUR INSTRUMENT PANEL normal, turn the engine off immediately and call for service. Refer to “If Your Engine Overheats” in “What To Do In Emergencies” for further information. 7. Speedometer Shows the vehicles speed. 8. High Beam Indicator This indicator shows that the high beam head- lights are on.
Page 196 • Each time the ignition is turned to ON/RUN, the ESC system will be ON even if it was turned off previously. • The ESC system will make buzzing or clicking sounds when it is active. This is normal; the sounds will stop when ESC becomes inactive following the maneuver that caused the ESC activation.
Page 197 196 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! Continued operation with the Transmission Tem- perature Warning Light illuminated could cause the fluid to boil over, come in contact with hot engine or exhaust components causing a fire that may result in personal injury. 14.
Page 198 If brake failure is indicated, immediate repair is neces- sary. WARNING! Driving a vehicle with the red brake light on is dangerous. Part of the brake system may have failed. It will take longer to stop the vehicle. You could have a collision.
Page 199 198 UNDERSTANDING YOUR INSTRUMENT PANEL the light is flashing when the engine is running, imme- diate service is required and you may experience reduced performance, an elevated/rough idle or engine stall and your vehicle may require towing. The light will come on when the ignition is first turned to ON/RUN and remain on briefly as a bulb check.
Page 200 19. Anti-Lock Brake (ABS) Light This light monitors the Anti-Lock Brake System (ABS). The light will turn on when the ignition switch is turned to the ON/RUN position and may stay on for as long as four seconds. If the ABS light remains on or turns on while driving, it indicates that the Anti-Lock portion of the brake system is not functioning and that service is required.
Page 201 200 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Tachometer This gauge measures engine revolutions-per-minute (RPM x 1000). When the engine RPM are kept within the green area, you are driving the vehicle in a fuel efficient manner. Before the pointer reaches the red area, ease up on the accelerator to prevent engine damage.
Page 202 maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale. Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly.
Page 203 202 UNDERSTANDING YOUR INSTRUMENT PANEL 26. Odometer / Trip Odometer Display Area The odometer shows the total distance the vehicle has been driven. The trip odometer shows individual trip mileage. Refer to “Trip Odometer Button” for additional information. NOTE: U.S. Federal regulations require that upon trans- fer of vehicle ownership, the seller certify to the pur- chaser the correct mileage that the vehicle has been driven.
Page 204 ECO / ECO-ON (Fuel Saver Indicator) — If Equipped The ECO-ON indicator will illuminate when you are driving in a fuel efficient manner and can be used to modify driving habits in order to increase fuel economy. The ECO display will toggle between ECO and ECO-ON depending on driving habits and vehicle usage.
Page 205 204 UNDERSTANDING YOUR INSTRUMENT PANEL ODOMETER button on the instrument cluster. To reset the oil change indicator system (after performing the scheduled maintenance), refer to the following proce- dure: 1. Turn the ignition switch to the ON/RUN position. Do not start the engine. 2.
Page 206 WARNING! A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants or wood or cardboard, etc. This could result in death or serious injury to the driver, occu- pants or others.
Page 207: Compass And Trip Computer - If Equipped
206 UNDERSTANDING YOUR INSTRUMENT PANEL Resetting the Trip Odometer Display the trip mileage that you want to reset, “Trip A” or “Trip B.” Then push and hold the button (approxi- mately two seconds) until the display resets to 0. The odometer must be in Trip Mode to reset the trip odom- eter.
Page 208: Control Buttons
Compass/Trip Computer Display Control Buttons Press and release the odometer/trip odometer reset but- ton (right side of the instrument cluster) to access the compass/trip computer displays. UNDERSTANDING YOUR INSTRUMENT PANEL 207 NOTE: The system will display the last known outside temperature when starting the vehicle and may need to be driven several minutes before the updated tempera- ture is displayed.
Page 209: Trip Conditions
208 UNDERSTANDING YOUR INSTRUMENT PANEL The compass/trip computer, when the appropriate con- ditions exist, will show the following messages in the odometer display: • Door Ajar (door) • Lift Gate Ajar (gATE) • Loose Fuel Cap (gASCAP) These messages can be manually turned off by pressing the right button (on the instrument cluster).
Page 210: Compass/Temperature Display
Compass/Temperature Display Compass Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences, the variance should be set for the zone where the vehicle is driven, per the zone map. Once properly set, the compass will automatically compensate for the differences and provide the most accurate compass head- ing.
Page 211: Electronic Vehicle Information Center (Evic) - If Equipped
210 UNDERSTANDING YOUR INSTRUMENT PANEL zone, press and release the CMTC reset button to increase the variance one step. Repeat as necessary until the desired variance is achieved. NOTE: The factory default zone is 8. During program- ming, the zone value will wrap around from zone 15 to zone 1.
Page 212 Electronic Vehicle Information Center (EVIC) This system conveniently allows the driver to select a variety of useful information by pressing the switches mounted on the steering wheel. The EVIC consists of the following: • System Status • Vehicle information warning message displays UNDERSTANDING YOUR INSTRUMENT PANEL 211 •...
Page 213: Electronic Vehicle Information Center (Evic) Displays
212 UNDERSTANDING YOUR INSTRUMENT PANEL Press the FUNCTION SELECT button to accept a selection. Also, the FUNCTION SELECT but- ton changes the current CD track being played (if equipped) when the EVIC is in the Compass/Temp/Audio screen. Press the SCROLL button to scroll through Navigation (if equipped), System Status Mes- sages, and Personal Settings (Customer- Programmable Features).
Page 214: Oil Change Required
• Door(s) ajar (with a single chime if vehicle is in motion) • Liftgate ajar (with a single chime) • Left front low pressure (with a single chime). Refer to “Tire Pressure Monitoring System” in “Starting And Operating”. • Left rear low pressure (with a single chime). Refer to “Tire Pressure Monitoring System”...
Page 215: Trip Functions
214 UNDERSTANDING YOUR INSTRUMENT PANEL engine oil change interval may fluctuate dependent upon your personal driving style. Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the MENU button.
Page 216 history information will be erased, and the averaging will continue from the last fuel average reading before the reset. • Distance To Empty (DTE) Shows the estimated distance that can be traveled with the fuel remaining in the tank. This estimated distance is determined by a weighted average of the instantaneous and average fuel economy, according to the current fuel tank level.
Page 217: Compass Display / Eco (Fuel Saver Mode) - If Equipped
216 UNDERSTANDING YOUR INSTRUMENT PANEL the FUNCTION SELECT button a second time within three seconds of resetting the currently displayed func- tion. (Reset ALL will display during this three-second window). Compass Display / ECO (Fuel Saver Mode) — If Equipped The compass readings indicate the direction the vehicle is facing.
Page 218 NOTE: A good calibration requires a level surface and an environment free from large metallic objects such as buildings, bridges, underground cables, railroad tracks, etc. Manual Compass Calibration If the compass appears erratic and the CAL indicator does not appear in the EVIC display, you must put the compass into the calibration mode manually as follows: 1.
Page 219: Personal Settings (Customer-Programmable Features)
218 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Magnetic materials should be kept away from the top of the right rear quarter window. This is where the compass sensor is located. Compass Variance Map 1. Turn the ignition switch ON. 2. Press and hold the COMPASS button for approxi- mately two seconds.
Page 220 Use the SCROLL button to display one of the following choices: Language When in this display you may select one of five lan- guages for all display nomenclature, including the trip functions and the navigation system (if equipped). Press the FUNCTION SELECT button while in this display to select English, Espanol, or Francais.
Page 221 220 UNDERSTANDING YOUR INSTRUMENT PANEL Remote Key Lock feature. To make your selection, press and release the FUNCTION SELECT button until ON or OFF appears. Flash Lights with Remote Key Lock When ON is selected, the front and rear turn signals will flash when the doors are locked or unlocked with the RKE transmitter.
Page 222 Enable/Disable the Rear Park Assist System The Rear Park Assist system will scan for objects behind the vehicle when the transmission is in the REVERSE and the vehicle speed is less than 11 mph (18 km/h). The system can be enabled with turned ON or turned OFF through the EVIC, to make your selection, press and release the FUNCTION SELECT button.
Page 223: Operating Instructions - Radio Mode
222 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 230 (REQ) — AM/FM STEREO RADIO AND 6–DISC CD/DVD CHANGER (MP3/WMA AUX JACK) NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 230 (REQ) Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 224 to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. SCAN Button Pressing the SCAN button causes the tuner to search for the next listenable station in AM, FM or Satellite (if equipped) frequencies, pausing for five seconds at each listenable station before continuing to the next.
Page 225 224 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure 1. Press and hold the TIME button until the hours blink. 2. Adjust the hours by turning the right side TUNE/ SCROLL control knob. 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes.
Page 226 Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones.
Page 227 226 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type 16-Digit Character Display Information Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk Program Type Inform Top 40 Jazz Weather News By pressing the SEEK button when the Music Type icon...
Page 228 • DVD Enter - When the disc is in DVD Menu mode, selecting DVD Enter will allow you to play the current highlighted selection. Use the remote control to scroll up and down the menu (if equipped). • DISC Play/Pause - You can toggle between playing the DVD and pausing the DVD by pushing the SELECT button (if equipped).
Page 229 228 UNDERSTANDING YOUR INSTRUMENT PANEL • Set Home Clock - Pressing the SELECT button allows you to set the clock. Turn the TUNE/SCROLL control knob to adjust the hours and then press and turn the TUNE/SCROLL control knob to adjust the minutes. Press the TUNE/SCROLL control knob again to save changes.
Page 230 Audio DRC — If Equipped Selecting this item allows you to limit maximum audio dynamic range. The default is set to High, and under this setting, dialogues will play at 11 db higher than if the setting is Normal. Aspect Ratio — If Equipped Selecting this item allows you to choose between wide screen, pan scan, and letter box.
Page 231: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
230 UNDERSTANDING YOUR INSTRUMENT PANEL both AM and FM. This allows a total of 12 AM, 12 FM, and 12 Satellite (if equipped) stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice.
Page 232 NOTE: The ignition switch must be in the ON or ACC position to operate the radio. LOAD Button — Loading Compact Disc(s) Press the LOAD button and the pushbutton with the corresponding number (1-6) where the CD is being loaded. The radio will display PLEASE WAIT and prompt when to INSERT DISC.
Page 233: Notes On Playing Mp3/Wma Files
232 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (CD MODE) Press the SCAN button to scan through each track on the CD currently playing. TIME Button (CD MODE) Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF (CD MODE) Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released, or RW or...
Page 234 The radio uses the following limits for file systems: • Maximum number of directory levels: 8 • Maximum number of files: 255 • Maximum number of folders: 100 • Maximum number of characters in file/folder names: • Level 1: 12 (including a separator . and a three- character extension) •...
Page 235 234 UNDERSTANDING YOUR INSTRUMENT PANEL MPEG Sampling Fre- Specification quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 Sampling Fre- Specification quency (kHz) 44.1 and 48 ID3 Tag information for artist, song title, and album title are supported for ID3 version 1 tags.
Page 236: List Button (Disc Mode For Mp3/Wma Play)
LIST Button (DISC Mode for MP3/WMA Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 237 236 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (Auxiliary Mode) No function. EJECT Button (Auxiliary Mode) No function. TIME Button (Auxiliary Mode) Press the TIME button to change the display from elapsed playing time to time of day. The time of day will display for five seconds.
Page 238: Uconnect™ Multimedia (Satellite Radio) - If Equipped
Macrovision This product incorporates copyright protection technol- ogy that is protected by U.S. patents and other intellec- tual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision.
Page 239 238 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Your Vehicle Identification Number. To access the ESN/SID, refer to the following steps: ESN/SID Access With the ignition switch in the ON/RUN or ACC posi- tion and the radio on, press the SETUP button and scroll using the TUNE/SCROLL control knob until Sirius ID is selected.
Page 240 Operating Instructions - Uconnect™ Multimedia (Satellite) Mode NOTE: The ignition switch must be in the ON/RUN or ACC position to operate the radio. SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode. Press the right switch to seek up and the left switch to seek down.
Page 241 240 UNDERSTANDING YOUR INSTRUMENT PANEL MUSIC TYPE Button Pressing this button once will turn on the Music Type mode for five seconds. Pressing the MUSIC TYPE button or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected.
Page 242: Media Center 730N/430/430N (Rer/Rbz/Rhb) Cd/Dvd/Hdd/Nav - If Equipped
You may add a second channel to each pushbutton by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2. This allows a total of 12 Satellite channels to be stored into pushbutton memory.
Page 243: Media Center 130 (Sales Code Res)
242 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (SALES CODE RES) NOTE: The radio sales code is located on the lower right side of the radio faceplate. Media Center 130 (RES) Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 244 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 245 244 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second time and MID will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the mid-range tones. Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display.
Page 246: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET/RND button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 247 246 UNDERSTANDING YOUR INSTRUMENT PANEL If you insert a disc with the ignition ON and the radio ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will show the track number, and index time in minutes and seconds.
Page 248: Notes On Playing Mp3 Files
the current selection. Pressing and holding the SEEK button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press and hold the FF (Fast Forward) button and the CD player will begin to fast forward until FF is released, or...
Page 249 248 UNDERSTANDING YOUR INSTRUMENT PANEL Supported Medium Formats (File Systems) The medium formats supported by the radio are ISO 9660 Level 1 and Level 2 and includes the Joliet extension. When reading discs recorded using formats other than ISO 9660 Level 1 and Level 2, the radio may fail to read files properly and may be unable to play the file nor- mally.
Page 250 When using the MP3 encoder to compress audio data to an MP3 file, the bit rate and sampling frequencies in the following table are supported. In addition, variable bit rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rate.
Page 251: Operation Instructions - Auxiliary Mode
250 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode The auxiliary (AUX) jack is an audio input jack, which allows the user to plug in a portable device, such as an MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers.
Page 252: Operating Instructions - Radio Mode
Operating Instructions — Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio. Power Switch/Volume Control (Rotary) Push the ON/VOLUME control knob to turn on the radio. Push the ON/VOLUME control knob a second time to turn off the radio.
Page 253 252 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button Uconnect™ Phone — If Equipped Press this button to operate the Uconnect™ Phone feature (if equipped). Refer to “Uconnect™ Phone” in “Under- standing The Features If Your Vehicle”. If your vehicle is not equipped with or this feature is not available on your vehicle, a “Not Equipped With Uconnect”...
Page 254 RW/FF Pressing the RW (Rewind) or FF (Fast Forward) buttons causes the tuner to search for the next frequency in the direction of the arrows. This feature operates in either AM or FM frequencies. TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency.
Page 255 254 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five seconds will allow the program format type to be se- lected. Many radio stations do not currently broadcast Music Type information. Toggle the MUSIC TYPE button to select the following format types: Program Type 16-Digit Character Display...
Page 256 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 257: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
256 UNDERSTANDING YOUR INSTRUMENT PANEL and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by pressing the pushbutton twice. Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM...
Page 258 CAUTION! • This CD player will accept 4–3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism. •...
Page 259: Notes On Playing Mp3 Files
258 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released or RW or another CD button is pressed. The RW (Reverse) button works in a similar manner. AM/FM Button Press the button to select either AM or FM mode.
Page 260 • Maximum number of files: 255 • Maximum number of folders. (The radio display of file names and folder names is limited. For large numbers of files and/or folders, the radio may be unable to display the file name and folder name and will assign a number instead.
Page 261 260 UNDERSTANDING YOUR INSTRUMENT PANEL MPEG Sampling Fre- Specification quency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 ID3 Tag information for artist, song title, and album title are supported for version 1 ID3 tags. ID3 version 2 is not supported by the radios.
Page 262: List Button (Cd Mode For Mp3 Play)
LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 263: Uconnect™ Multimedia (Satellite Radio) - If Equipped
262 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when the ignition is OFF). Uconnect™ Multimedia (Satellite Radio) — If Equipped Satellite radio uses direct satellite-to-receiver broadcast- ing technology to provide clear digital sound, coast to coast.
Page 264 using the TUNE/SCROLL control knob until Sirius ID is selected. Press the TUNE/SCROLL control knob and the Sirius ID number will display. The Sirius ID number display will time out in two minutes. Press any button on the radio to exit this screen. Selecting Uconnect™...
Page 265 264 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons Press and release the SEEK buttons to search for the next channel in Satellite mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new channel until you make another selection.
Page 266 If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset channel. SETUP Button Pressing the SETUP button allows you to select the following items: •...
Page 267: Steering Wheel Audio Controls - If Equipped
266 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. Remote Sound System Controls (Back View Of Steering Wheel) The right-hand control is a rocker type switch with a pushbutton in the center.
Page 268: Cd Player
CD Player Press the top of the switch once to go to the next track on the CD. Press the bottom of the switch once to go to the beginning of the current track or to the beginning of the previous track, if it is within one second after the current track begins to play.
Page 269: Radio Operation And Mobile Phones
268 UNDERSTANDING YOUR INSTRUMENT PANEL RADIO OPERATION AND MOBILE PHONES Under certain conditions, the mobile phone being on in your vehicle can cause erratic or noisy performance from your radio. This condition may be lessened or eliminated by relocating the mobile phone antenna. This condition is not harmful to the radio.
Page 270 Blower Control Rotate this control to regulate the amount of air forced through the ven- tilation system in any mode. The blower speed increases as you move the control to the right from the “O” (OFF) position. There are seven blower speeds.
Page 271 270 UNDERSTANDING YOUR INSTRUMENT PANEL Panel Air is directed through the outlets in the instrument panel. These outlets can be adjusted to direct airflow. NOTE: The center instrument panel outlets can be aimed so that they are directed toward the rear seat passengers for maximum airflow to the rear.
Page 272 NOTE: • The air conditioning compressor operates in Mix, Defrost, or a blend of these modes, even if the Air Conditioning (A/C) button is not pressed. This dehu- midifies the air to help dry the windshield. To improve fuel economy, use these modes only when necessary. •...
Page 273: Automatic Temperature Control (Atc) - If Equipped
272 UNDERSTANDING YOUR INSTRUMENT PANEL Air Conditioning Control Press this button to engage the Air Con- ditioning. A light will illuminate when the Air Conditioning System is engaged. Rotating the dial left into the blue area of the scale indicates cooler tempera- tures while rotating right into the red area indicates warmer temperatures.
Page 274 Operation of the system is quite simple. 1. Turn the Mode Control knob (on the right) and the Blower Control knob (on the left) to AUTO. NOTE: The AUTO position performs best for front seat occupants only. 2. Dial in the temperature you would like the system to maintain by rotating the Temperature Control knob.
Page 275 274 UNDERSTANDING YOUR INSTRUMENT PANEL • If your air conditioning performance seems lower than expected, check the front of the A/C condenser located in front of the radiator for an accumulation of dirt or insects. Clean with a gentle water spray from behind the radiator and through the condenser.
Page 276 UNDERSTANDING YOUR INSTRUMENT PANEL 275...
Page 277 276 UNDERSTANDING YOUR INSTRUMENT PANEL The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Panel Air is directed through the outlets in the instrument panel.
Page 278 • Air Conditioner Control Press this button to turn on the air conditioning during manual operation only. When the air conditioning is turned on, cool dehumidified air will flow through the outlets selected with the Mode control dial. Press this but- ton a second time to turn OFF the air conditioning.
Page 279: Operating Tips
278 UNDERSTANDING YOUR INSTRUMENT PANEL • Most of the time, when in Automatic Operation, you can temporarily put the system into Recirculation Mode by pressing the Recirculation button. However, under certain conditions, while in Automatic Mode, the system is blowing air out the defrost vents. When these conditions are present, and the Recirculation button is pressed, the indicator will flash and then turn off.
Page 280 Window Fogging Interior fogging on the windshield can be quickly re- moved by turning the mode selector to Defrost. The Defrost/Floor mode can be used to maintain a clear windshield and provide sufficient heating. If side win- dow fogging becomes a problem, increase blower speed. Vehicle windows tend to fog on the inside in mild but rainy or humid weather.
Page 281 280 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...
Page 282: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ....285 Normal Starting ..... 285 Extreme Cold Weather (Below –20°F Or –29°C) .
Page 283 282 STARTING AND OPERATING Four-Wheel Drive Operation — If Equipped . . 300 MP 143 Single-Speed Part-Time Transfer Case ..... . . 300 Shifting Procedure –...
Page 284 Radial Ply Tires ..... 328 Compact Spare Tire – If Equipped ..328 Limited-Use Spare –...
Page 285 284 STARTING AND OPERATING Vehicle Loading ..... . 353 Certification Label ....353 Trailer Towing .
Page 286: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust both inside and outside mirrors, and fasten your seat belts. WARNING! Never leave children alone in a vehicle. Leaving children in a vehicle unattended is dangerous for a number of reasons. A child or others could be seri- ously or fatally injured.
Page 287: Extreme Cold Weather (Below -20°F Or -29°C)
286 STARTING AND OPERATING Extreme Cold Weather (below –20°F or –29°C) To ensure reliable starting at these temperatures, the use of an externally powered electric engine block heater (available from your authorized dealer) is recommended. If Engine Fails to Start WARNING! •...
Page 288: After Starting
CAUTION! To prevent damage to the starter, do not crank the engine for more than 15 seconds at a time. Wait 10 to 15 seconds before trying again. If the engine has been flooded, it may start to run, but not have enough power to continue running when the key is released.
Page 289: Engine Block Heater - If Equipped
288 STARTING AND OPERATING ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms the engine, and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded three-wire extension cord. The engine block heater cord is found under the hood clipped to the heater line on the left side of the engine.
Page 290: Key Ignition Park Interlock
WARNING! • It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in REVERSE.
Page 291: Brake/Transmission Interlock Manual Override
290 STARTING AND OPERATING Brake/Transmission Interlock Manual Override Your vehicle may be equipped with a shift lock manual override. The manual override may be used in the event that the shift lever should fail to move from PARK with the key in the ON position and the brake pedal pressed. To operate the shift lock manual override, perform the following steps: 1.
Page 292: Four-Speed Automatic Transmission - 3.7L Engine
Four–Speed Automatic Transmission – 3.7L Engine NOTE: Under extreme cold temperatures (-10°F (-23°C) and when in DRIVE, transmission operation may be briefly limited to only second gear operation. Normal operation will resume once the transmission temperature has risen to a suitable level. Shifting from DRIVE to PARK or REVERSE should be done only after the accelerator pedal is released and the vehicle is stopped.
Page 293 292 STARTING AND OPERATING Never use PARK while the vehicle is in motion. Apply the parking brake when leaving the vehicle in this range. Always apply the parking brake first, then place the shift lever in the PARK position. WARNING! •...
Page 294 2 (Second) This range is used for moderate grades and to assist braking on dry pavement or in mud and snow. Begins at a stop in low gear with automatic upshift to second gear. Will not shift into third gear. 1 (First) This range is used for hard pulling at low speeds in mud, sand, snow, or on steep grades.
Page 295 294 STARTING AND OPERATING NOTE: The TOW/HAUL mode locks out Overdrive. Tow/Haul Button The “TOW/HAUL Indicator Light” will illuminate in the instrument cluster to indicate when the switch has been activated. Pressing the switch a second time restores normal operation. If the TOW/HAUL mode is desired, the switch must be pressed each time the engine is started.
Page 296: Five-Speed Automatic Transmission - 4.0L Engine
5. Move the shift lever to the desired gear range. If the problem is no longer detected, the transmission will return to normal operation. If the problem persists, PARK, REVERSE, and NEUTRAL will continue to oper- ate. Only second gear range will operate in the DRIVE position.
Page 297: Gear Ranges
296 STARTING AND OPERATING Gear Ranges NOTE: After selecting any gear range, wait a moment to allow the selected gear to engage before accelerating. This is especially important when the engine is cold. If there is a need to restart the engine, be sure to cycle the key to the LOCK position before restarting.
Page 298 NEUTRAL This range is used when vehicle is standing for pro- longed periods with engine running. Engine may be started in this range. Set the parking brake if you must leave the vehicle. NOTE: Towing the vehicle, coasting, or driving for any other reason with the shift lever in NEUTRAL can result in severe transmission damage.
Page 299 298 STARTING AND OPERATING Overdrive Operation The overdrive automatic transmission contains an elec- tronically controlled fifth gear (OVERDRIVE). The trans- mission will automatically shift from fourth gear to OVERDRIVE if the following conditions are present: • the shift lever is in DRIVE •...
Page 300 To reset the transmission, use the following procedure: 1. Stop the vehicle. 2. Move the shift lever to the PARK position. 3. Turn the engine off and turn the key to the LOCK position. 4. Wait approximately 10 seconds, then restart the en- gine.
Page 301: Mp 143 Single-Speed Part-Time Transfer Case
300 STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF EQUIPPED MP 143 Single-Speed Part-Time Transfer Case Operating Information/Precautions The transfer case is operated by the transfer case switch (located on the center console). Transfer Case Switch The electronically shifted transfer case provides two mode positions: •...
Page 302: Shifting Procedure - Electronically Shifted
CAUTION! • Driving in the 4WD LOCK position on dry hard surfaced roads may cause increased tire wear and damage to the driveline components. • Do not attempt to make a shift while only the front or rear wheels are spinning. Shifting while only the front or rear wheels are spinning can cause damage to the transfer case.
Page 303: On-Road Driving Tips
302 STARTING AND OPERATING must be in the ON position with the engine either RUNNING or OFF. This shift cannot be completed if the key is in the ACC position. NOTE: • The four-wheel drive system will not allow shifts between 2WD/4WD LOCK if the front and/or rear wheels are spinning (no traction).
Page 304: Power Steering Fluid Check
If for some reason the power assist is interrupted, it will still be possible to steer your vehicle. Under these condi- tions, you will observe a substantial increase in steering effort, especially at very low vehicle speeds and during parking maneuvers. NOTE: •...
Page 305: Parking Brake
304 STARTING AND OPERATING apparent, and/or the system is not functioning as antici- pated. Coordinate inspection efforts through an autho- rized dealer. CAUTION! Do not use chemical flushes in your power steering system as the chemicals can damage your power steering components.
Page 306 Parking Brake When the parking brake is applied with the ignition switch ON, the “Brake Warning Light” in the instrument cluster will illuminate. STARTING AND OPERATING 305 NOTE: • When the parking brake is applied and the transmis- sion is placed in gear, the “Brake Warning Light” will flash.
Page 307: Anti-Lock Brake System
306 STARTING AND OPERATING WARNING! • Never use the PARK position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage. • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 308 computer to modulate hydraulic pressure, to prevent wheel lock-up and help avoid skidding on slippery surfaces. All vehicle wheels and tires must be the same size and type, and tires must be properly inflated, to produce accurate signals for the computer. WARNING! Significant over or under-inflation of tires or mixing sizes of tires or wheels on the vehicle can lead to loss...
Page 309 308 STARTING AND OPERATING WARNING! (Continued) • The ABS cannot prevent collisions, including those resulting from excessive speed in turns, following another vehicle too closely, or hydro- planing. • The capabilities of an ABS equipped vehicle must never be exploited in a reckless or dangerous manner, which could jeopardize the user’s safety or the safety of others.
Page 310: Electronic Brake Control System
build up between the tire tread and the road. This hydroplaning action can cause loss of traction, braking ability, and control. • After going through deep water or a car wash, brakes may become wet, resulting in decreased performance and unpredictable braking action. Dry the brakes by gentle, intermittent pedal action while driving at very slow speeds.
Page 311: Traction Control System (Tcs)
310 STARTING AND OPERATING Traction Control System (TCS) This system monitors the amount of wheel spin of each of the driven wheels. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability.
Page 312: Electronic Roll Mitigation (Erm)
WARNING! The Brake Assist System (BAS) cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. BAS cannot prevent collisions, in- cluding those resulting from excessive speed in turns, driving on very slippery surfaces, or hydro- planing.
Page 313: Electronic Stability Control (Esc)
312 STARTING AND OPERATING Electronic Stability Control (ESC) This system enhances directional control and stability of the vehicle under various driving conditions. ESC cor- rects for oversteering or understeering of the vehicle by applying the brake of the appropriate wheel to assist in counteracting the oversteer or understeer condition.
Page 314 WARNING! The Electronic Stability Control (ESC) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. ESC cannot prevent col- lisions, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 315: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
314 STARTING AND OPERATING traction. To turn ESC on again, momentarily press the “ESC Off” switch. This will restore the normal “ESC On” mode of operation. NOTE: To improve the vehicle’s traction when driving with snow chains, or starting off in deep snow, sand or gravel, it may be desirable to switch to the “Partial Off”...
Page 316: Tire Safety Information
NOTE: • The “ESC Activation/Malfunction Indicator Light” and the “ESC OFF Indicator Light” come on momen- tarily each time the ignition switch is turned ON. • Each time the ignition is turned ON, the ESC system will be ON even if it was turned off previously. •...
Page 317 316 STARTING AND OPERATING NOTE: • P (Passenger) - Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. • European-Metric tire sizing is based on European design standards.
Page 318 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%)
Page 319 318 STARTING AND OPERATING Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 320: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. DOT = Department of Transportation —...
Page 321: Tire Terminology And Definitions
320 STARTING AND OPERATING Tire Terminology and Definitions Term B-Pillar Cold Tire Pressure Maximum Inflation Pressure Recommended Inflation Pressure Tire Placard Definition The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof.
Page 322: Tire Loading And Tire Pressure
STARTING AND OPERATING 321 Tire Loading and Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard Tire Placard Location...
Page 323 322 STARTING AND OPERATING This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle 4) cold tire inflation pressures for the front, rear, and spare tires.
Page 324 3. Subtract the combined weight of the driver and pas- sengers from XXX lbs or XXX kg. 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) (since 5 x 150 = 750, and 1400 –...
Page 325 324 STARTING AND OPERATING...
Page 326: Tires - General Information
WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 327: Tire Inflation Pressures
326 STARTING AND OPERATING WARNING! (Continued) • Unequal tire pressures from one side of the ve- hicle to the other can cause the vehicle to drift to the right or left. • Always drive with each tire inflated to the recom- mended cold tire inflation pressure.
Page 328: Tire Pressures For High Speed Operation
Inflation pressures specified on the placard are always “cold tire inflation pressure.” Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after a three hour period. The cold tire inflation pressure must not exceed the maximum infla- tion pressure molded into the tire sidewall.
Page 329: Radial Ply Tires
328 STARTING AND OPERATING WARNING! High speed driving with your vehicle under maxi- mum load is dangerous. The added strain on your tires could cause them to fail. You could have a serious collision. Do not drive a vehicle loaded to the maximum capacity at continuous speeds above 75 mph (120 km/h).
Page 330: Limited-Use Spare - If Equipped
WARNING! Temporary use spare tires are for emergency use only. With these tires, do not drive more than 50 mph (80 km/h). Temporary use spare tires have limited tread life. When the tread is worn to the tread wear indicators, the temporary use spare tire needs to be replaced.
Page 331: Tire Spinning
330 STARTING AND OPERATING WARNING! The limited-use spare tires are for emergency use only. Installation of this limited-use spare tire affects vehicle handling. With this tire, do not drive more than 50 mph (80 km/h). Keep inflated to the cold tire inflation pressure listed on either your tire placard or limited-use spare tire and wheel assembly.
Page 332: Life Of Tire
1 — Worn Tire 2 — New Tire These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the tread wear indicators, the tire should be replaced.
Page 333: Replacement Tires
332 STARTING AND OPERATING Replacement Tires The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance when replacement is needed.
Page 334: Tire Chains
WARNING! (Continued) • Failure to equip your vehicle with tires having adequate speed capability can result in sudden tire failure and loss of vehicle control. CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer read- ings.
Page 335: Tire Rotation Recommendations
334 STARTING AND OPERATING CAUTION! (Continued) • Observe the tire chain manufacturer’s instructions on method of installation, operating speed, and conditions for usage. Always use the lower sug- gested operating speed of the chain manufacturer if different than the speed recommended by the manufacturer.
Page 336 CAUTION! Proper operation of four-wheel drive vehicles de- pends on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the transfer case. Tire rotation schedule should be followed to balance tire wear. Refer to the “Maintenance Schedule”...
Page 337: Tire Pressure Monitor System (Tpms)
336 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- mended cold placard pressure. The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C).
Page 338 For example, your vehicle may have a recommended cold (parked for more than three hours) placard pressure of 33 psi (227 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 28 psi (193 kPa), a temperature drop to 20°F (-7°C) will decrease the tire pressure to approximately 24 psi (165 kPa).
Page 339: Base System
338 STARTING AND OPERATING NOTE: • The TPMS is not intended to replace normal tire care and maintenance, or to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure.
Page 340 The matching full-size spare wheel and tire assembly (if equipped) has a tire pressure monitoring sensor. The matching full-size spare can be used in place of any of the four road tires. The TPMS will only monitor the pressure in the full-size spare when it is used in place of a road tire.
Page 341 340 STARTING AND OPERATING 3. Lots of snow or ice around the wheels or wheel housings. 4. Using tire chains on the vehicle. 5. Using wheels/tires not equipped with TPMS sensors. Vehicles with Full-Size Spare 1. The matching full-size spare wheel and tire assembly has a tire pressure monitoring sensor that can be moni- tored by the TPMS.
Page 342: Premium System - If Equipped
Telltale Light” will turn off, as long as no tire pressure is below the low-pressure warning limit in any of the four active road tires. The vehicle may need to be driven for up to 20 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information.
Page 343 342 STARTING AND OPERATING Tire Pressure Monitoring Low Pressure Warnings The “Tire Pressure Monitoring Telltale Light” will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the Electronic Vehicle Information Center (EVIC) will display a graphic showing the pressure values of each tire with the low tire pressure values flashing.
Page 344 STARTING AND OPERATING 343 If the ignition key is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the “Tire Pressure Monitoring Telltale Light” will no longer flash, and the CHECK TPM SYSTEM message will no longer display, and a pressure value will display in place of the dashes.
Page 345 344 STARTING AND OPERATING Vehicles with Full-Size Spare 1. The matching full size spare wheel and tire assembly has a tire pressure monitoring sensor that can be moni- tored by the TPMS. 2. If you install the full size spare in place of a road tire that has a pressure below the low-pressure warning limit, a chime will sound and the “TPMS Telltale Light”...
Page 346: General Information
4. For each subsequent ignition key cycle, a chime will sound, the “TPMS Telltale Light” will flash on and off for 75 seconds and then remain on solid, and the EVIC will display a CHECK TPM SYSTEM message for three seconds and then display dashes (- -) in place of the pressure value.
Page 347: Fuel Requirements
346 STARTING AND OPERATING FUEL REQUIREMENTS 3.7L Engine All engines are designed to meet all emis- sions regulations and provide excellent fuel economy and performance when us- ing high quality unleaded “regular” gaso- line having an octane rating of 87. The use of premium gasoline is not recommended, as it will not provide any benefit over regular gasoline in these engines.
Page 348: Reformulated Gasoline
Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as reformulated gasoline. Reformulated gasolines contain oxygenates and are spe- cifically blended to reduce vehicle emissions and im- prove air quality. The manufacturer supports the use of reformulated gaso- lines.
Page 349: Mmt In Gasoline
348 STARTING AND OPERATING If a Non-FFV vehicle is inadvertently fueled with E-85 fuel, the engine will have some or all of these symptoms: • operate in a lean mode • OBD II “Malfunction Indicator Light” on • poor engine performance •...
Page 350: Materials Added To Fuel
Materials Added To Fuel All gasoline sold in the United States is required to contain effective detergent additives. Use of additional detergents or other additives is not needed under normal conditions and would result in additional cost. Therefore you should not have to add anything to the fuel. Fuel System Cautions CAUTION! Follow these guidelines to maintain your vehicle’s...
Page 351: Carbon Monoxide Warnings
350 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! Carbon monoxide (CO) in exhaust gases is deadly. Follow the precautions below to prevent carbon monoxide poisoning: • Do not inhale exhaust gases. They contain carbon monoxide, a colorless and odorless gas which can kill.
Page 352 Fuel Filler Cap STARTING AND OPERATING 351 CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel cap (gas cap). A poorly fitting cap could let impu- rities into the fuel system. Also, a poorly fitting aftermarket cap can cause the “Malfunction Indi- cator Light (MIL)”...
Page 353: Loose Fuel Filler Cap Message
352 STARTING AND OPERATING WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank is being filled. • Never add fuel when the engine is running. This is in violation of most state and federal fire regula- tions and may cause the MIL to turn on.
Page 354: Vehicle Loading
VEHICLE LOADING Certification Label As required by National Highway Traffic Safety Admin- istration regulations, your vehicle has a certification label affixed to the driver’s side door or B-Pillar. This label contains the month and year of manufacture, Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Number (VIN).
Page 355 354 STARTING AND OPERATING Each axle’s GAWR is determined by the components in the system with the lowest load carrying capacity (axle, springs, tires, or wheels). Heavier axles or suspension components, sometimes specified by purchasers for in- creased durability, does not necessarily increase the ve- hicle’s GVWR.
Page 356: Trailer Towing
the front or rear axles has been exceeded, but the total load is within the specified GVWR. If so, weight must be shifted from front to rear, or rear to front, as appropriate until the specified weight limitations are met. Store the heavier items down low and be sure that the weight is distributed equally.
Page 357 356 STARTING AND OPERATING exceed the GVWR. Refer to “Vehicle Loading/Vehicle Certification Label” in Starting and Operating” for fur- ther information. Gross Trailer Weight (GTW) The GTW is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or tem- porary) loaded in or on the trailer in its loaded and ready for operation condition.
Page 358 Tongue Weight The tongue weight is the downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle. Frontal Area The frontal area is the maximum height multiplied by the maximum width of the front of a trailer.
Page 359 358 STARTING AND OPERATING WARNING! • An improperly adjusted weight distributing hitch system may reduce handling, stability, and brak- ing performance and could result in a collision. • Weight distributing systems may not be compat- ible with surge brake couplers. Consult with your hitch and trailer manufacturer or a reputable rec- reational vehicle...
Page 360 STARTING AND OPERATING 359 With Weight-Distributing Hitch (Correct) Improper Adjustment of Weight-Distributing Hitch (Incorrect)
Page 361: Trailer Hitch Classification
360 STARTING AND OPERATING Trailer Hitch Classification Your vehicle is capable of towing trailers up to 2,000 lbs (907 kg) without added equipment or alterations to the standard equipment. Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional trailer tow prep package.
Page 362: Trailer Towing Weights (Maximum Trailer Weight Ratings)
Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/ Model Transmission 3.7L/Automatic 3.7L/Automatic 4.0L/Automatic 4.0L/Automatic Refer to local laws for maximum trailer towing speeds. NOTE: The trailer tongue weight must be considered as part of the combined weight of occupants and cargo (ie.
Page 363 362 STARTING AND OPERATING When Towing Trailers with Gross Trailer Weight (GTW) between 3,500 Lbs (1 588 kg) and 5,000 Lbs (2 268 kg) The following chart provides maximum trailer weight ratings towable for the following engine/transmission combinations, ONLY if using a weight distributing hitch. Engine/Transmission 3.7L/Automatic w/Trailer Tow Package...
Page 364: Trailer And Tongue Weight
STARTING AND OPERATING 363 Trailer and Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 365: Towing Requirements
364 STARTING AND OPERATING Consider the following items when computing the weight on the rear axle of the vehicle: • The tongue weight of the trailer. • The weight of any other type of cargo or equipment put in or on your vehicle. •...
Page 366 WARNING! Improper towing can lead to a collision. Follow these guidelines to make your trailer towing as safe as possible: • Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control.
Page 367 366 STARTING AND OPERATING WARNING! (Continued) 3. GAWR 4. Tongue weight rating for the trailer hitch utilized. (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight). Towing Requirements –...
Page 368 − An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required. − Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
Page 369 368 STARTING AND OPERATING Towing Requirements – Trailer Lights and Wiring Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for motoring safety. The trailer tow package may include a four-pin and seven-pin wiring harness.
Page 370: Towing Tips
Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 — Left Stop/Turn 3 — Right Stop/Turn 7 — Running Lamps 4 — Electric Brakes STARTING AND OPERATING 369 Towing Tips Before setting out on a trip, practice turning, stopping and backing up the trailer in an area away from heavy traffic.
Page 371 370 STARTING AND OPERATING 45 minutes of continuous operation. Refer to “Mainte- nance Schedule” for the proper maintenance intervals. TOW/HAUL – If Equipped To reduce potential for automatic transmission overheat- ing, press the “TOW/HAUL” button when driving in hilly areas or shift the transmission to DRIVE position 2 on more severe grades.
Page 372: Recreational Towing (Behind Motorhome, Etc.)
RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheel OFF the Ground Flat Tow NONE Front Dolly Tow On Trailer Two-Wheel Drive Models NOT ALLOWED NOT ALLOWED Rear STARTING AND OPERATING 371 Four-Wheel Drive Models NOT ALLOWED NOT ALLOWED NOT ALLOWED...
Page 373: Recreational Towing - Two-Wheel Drive Models
372 STARTING AND OPERATING Recreational Towing — Two-Wheel Drive Models Recreational towing is allowed if the rear wheels are OFF the ground. This may be accomplished using a tow dolly or vehicle trailer. If using a tow dolly, follow this proce- dure: 1.
Page 374: Recreational Towing - Four-Wheel Drive Models
The parking brake must be firmly engaged and the wheels chocked during driveshaft removal and installa- tion. The parking brake must remain engaged unless the vehicle is securely and properly connected to the tow vehicle, or the driveshaft is completely reinstalled. See your authorized dealer for proper driveshaft removal reinstallation procedures,...
Page 376: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....376 If Your Engine Overheats ....376 Jacking And Tire Changing .
Page 377: Hazard Warning Flasher
376 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The Hazard Warning Flasher switch is located on the lower switch bank below the climate controls. Press the switch to turn on the Hazard Warning flasher. When the switch is activated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 378: Jacking And Tire Changing
NOTE: There are steps that you can take to slow down an impending overheat condition: • If your air conditioner (A/C) is on, turn it off. The A/C system adds heat to the engine cooling system and turning the A/C off can help remove this heat. •...
Page 379: Jack Location
378 WHAT TO DO IN EMERGENCIES Jack Location The scissor-type jack and tire changing tools are located in the left rear trim panel behind the second row seat. Jack Storage Location Spare Tire Stowage The spare tire is stowed underneath the rear of the vehicle and is held in place by a cable winch mechanism.
Page 380: Preparations For Jacking
CAUTION! The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and they can damage the winch. When the spare is clear, tilt the retainer at the end of the cable and pull it through the center of the wheel.
Page 381: Jacking Instructions
380 WHAT TO DO IN EMERGENCIES Jacking Instructions WARNING! Carefully follow these tire changing warnings to help prevent personal injury or damage to your vehicle: • Always park on a firm, level surface as far from the edge of the roadway as possible before raising the vehicle.
Page 382 WHAT TO DO IN EMERGENCIES 381 1. Remove spare tire. 2. Remove jack and tools from mounting bracket. As- semble the tools by connecting the driver to the exten- sion, and then to the lug wrench. 3. Loosen (but do not remove) the wheel lug nuts by turning them to the left one turn while the wheel is still on the ground.
Page 383 382 WHAT TO DO IN EMERGENCIES Rear Jacking Location 5. Raise the vehicle by turning the jack screw to the right. Raise the vehicle only until the tire just clears the surface and enough clearance is obtained to install the spare tire. Minimum tire lift provides maximum stability.
Page 384: Jump-Starting Procedures
wheel nut tightness is 95 ft lbs (130 N·m). If in doubt about the correct tightness, have them checked with a torque wrench by your authorized dealer or at a service station. 10. Lower the jack to its fully closed position. WARNING! A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the ve-...
Page 385: Preparations For Jump-Start
384 WHAT TO DO IN EMERGENCIES Preparations for Jump-Start The battery in your vehicle is located in the front of the engine compartment, behind the left headlight assembly. NOTE: The positive battery post is covered with a protective cap. Lift up on the cap to gain access to the positive battery post.
Page 386: Jump-Starting Procedure
3. If using another vehicle to jump-start the battery, park the vehicle within the jumper cables reach, set the parking brake and make sure the ignition is OFF. WARNING! Do not allow vehicles to touch each other as this could establish a ground connection and personal injury could result.
Page 387 386 WHAT TO DO IN EMERGENCIES WARNING! Do not connect the cable to the negative post (-) of the discharged battery. The resulting electrical spark could cause the battery to explode and could result in personal injury. 5. Start the engine in the vehicle that has the booster battery, let the engine idle a few minutes, and then start the engine in the vehicle with the discharged battery.
Page 388: Towing A Disabled Vehicle
TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial wrecker service. If the trans- mission and drivetrain are operable, disabled vehicles Towing Condition Wheels OFF the Ground Flat Tow NONE Front Wheel Lift or Dolly Rear Flatbed Proper towing or lifting equipment is required to prevent...
Page 389: Towing Without The Ignition Key Fob
388 WHAT TO DO IN EMERGENCIES If you must use the accessories (wipers, defrosters, etc.) while being towed, the ignition must be in the ON/RUN position, not the ACC position. If the vehicle’s battery is discharged, see “Brake/ Transmission Interlock Manual Override” under “Auto- matic Transmission”...
Page 390 CAUTION! Towing faster than 30 mph (48 km/h) or farther than 15 miles (24 km) with rear wheels on the ground can cause severe damage to the transmission. Such dam- age is not covered by the New Vehicle Limited Warranty. If the transmission is not operable, or the vehicle must be towed faster than 30 mph (48 km/h) or farther than 15 miles (24 km), tow with the rear wheels OFF the...
Page 391: Four-Wheel Drive Vehicles
390 WHAT TO DO IN EMERGENCIES Four-Wheel Drive Vehicles The manufacturer requires towing with all wheels OFF the ground. Acceptable methods are to tow the vehicle on a flatbed or with one end of vehicle raised and the opposite end on a towing dolly. CAUTION! •...
Page 392: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.7L ... . . 393 Engine Compartment — 4.0L ... . . 394 Onboard Diagnostic System —...
Page 393 392 MAINTAINING YOUR VEHICLE Exhaust System ..... 407 Cooling System ..... 409 Brake System .
Page 394: Engine Compartment - 3.7L
ENGINE COMPARTMENT — 3.7L 1 — Air Cleaner Filter 2 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 4 — Integrated Power Module 5 — Battery MAINTAINING YOUR VEHICLE 393 6 — Washer Fluid Reservoir 7 — Engine Coolant Reservoir 8 —...
Page 395: Engine Compartment - 4.0L
394 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 4.0L 1 — Air Cleaner Filter 2 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 4 — Integrated Power Module 5 — Battery 6 — Engine Oil Fill 7 — Washer Fluid Reservoir 8 —...
Page 396: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 397: Emissions Inspection And Maintenance Programs
396 MAINTAINING YOUR VEHICLE “Electronic Vehicle Information Center (EVIC)” in “Un- derstanding Your Instrument Panel” for further informa- tion. Tighten the gas cap until a clicking sound is heard. This is an indication that the gas cap is properly tight- ened.
Page 398 2. If you crank or start the engine, you will have to start this test over. 3. As soon as you turn the ignition switch to the ON position, you will see the MIL symbol come on as part of a normal bulb check.
Page 399: Replacement Parts
398 MAINTAINING YOUR VEHICLE REPLACEMENT PARTS Use of genuine MOPAR parts for normal/scheduled maintenance and repairs is highly recommended to en- sure the designed performance. Damage or failures caused by the use of non-MOPAR parts for maintenance and repairs will not be covered by the manufacturer’s warranty.
Page 400: Engine Oil
CAUTION! • Failure to properly maintain your vehicle or per- form repairs and service when necessary could result in more costly repairs, damage to other components or negatively impact vehicle perfor- mance. Immediately have potential malfunctions examined by an authorized Chrysler Group LLC dealership or qualified repair center.
Page 401 400 MAINTAINING YOUR VEHICLE CAUTION! Overfilling or underfilling the crankcase will cause aeration or loss of oil pressure. This could damage your engine. Change Engine Oil The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance. Refer to “Maintenance Schedule”...
Page 402 Engine Oil Viscosity – 3.7L Engine SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature starting and vehicle fuel economy. Your engine oil filler cap shows the recommended engine oil viscosity for your vehicle.
Page 403: Engine Oil Filter
402 MAINTAINING YOUR VEHICLE Engine Oil Filter The engine oil filter should be replaced with a new filter at every engine oil change. NOTE: For best access to the oil filter, a drive on hoist should be used instead of a chassis hoist (3.7L Only). Engine Oil Filter Selection All of the manufacturer’s engines have a full-flow type disposable oil filter.
Page 404: Maintenance-Free Battery
Engine Air Cleaner Filter Selection The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be used to assure most efficient service. MOPAR engine air cleaner filters are a high quality filter and are recommended. Maintenance-Free Battery Your vehicle is equipped with a maintenance-free battery.
Page 405: Air Conditioner Maintenance
404 MAINTAINING YOUR VEHICLE CAUTION! • It is essential when replacing the cables on the battery that the positive cable is attached to the positive post and the negative cable is attached to the negative post. Battery posts are marked posi- tive (+) and negative (-) and are identified on the battery case.
Page 406: Body Lubrication
WARNING! • Use only refrigerants and compressor lubricants approved by the manufacturer for your air condi- tioning system. Some unapproved refrigerants are flammable and can explode, injuring you. Other unapproved refrigerants or lubricants can cause the system to fail, requiring costly repairs. Refer to Warranty Information Book, located on the DVD, for further warranty information.
Page 407: Windshield Wiper Blades
406 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. When performing other underhood services, the hood latch, release mechanism and safety catch should be cleaned and lubricated. The external lock cylinders should be lubricated twice a year, preferably in the Fall and Spring. Apply a small amount of a high quality lubricant, such as MOPAR Lock Cylinder Lubricant or equivalent, directly into the lock cylinder.
Page 408: Exhaust System
WARNING! Commercial windshield washer solvents are flam- mable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. Exhaust System The best protection against carbon monoxide entry into the vehicle body is a properly maintained engine exhaust system.
Page 409 408 MAINTAINING YOUR VEHICLE CAUTION! • The catalytic converter requires the use of un- leaded fuel only. Leaded gasoline will destroy the effectiveness of the catalyst as an emissions con- trol device and may seriously reduce engine per- formance and cause serious damage to the engine. •...
Page 410: Cooling System
To minimize the possibility of catalytic converter dam- age: • Do not shut off the engine or interrupt the ignition, when the transmission is in gear and the vehicle is in motion. • Do not try to start the engine by pushing or towing the vehicle.
Page 411 410 MAINTAINING YOUR VEHICLE garden hose vertically down the face of the A/C con- denser (if equipped) or the back of the radiator core. Check the engine cooling system hoses for brittle rubber, cracking, tears, cuts, and tightness of the connection at the coolant recovery bottle and radiator.
Page 412 CAUTION! • Mixing of engine coolant (antifreeze) other than the specified HOAT engine coolant (antifreeze) may result in decreased corrosion protection and engine damage. If a non-HOAT engine coolant (antifreeze) is introduced into the cooling system in an emergency, it should be replaced with the specified engine coolant (antifreeze) as soon as possible.
Page 413 412 MAINTAINING YOUR VEHICLE • Mix a minimum solution of 50% HOAT engine coolant and distilled water. Use higher concentrations (not to exceed 70%) if temperatures below anticipated. • Use only high purity water such as distilled or deion- ized water when mixing the water/engine coolant (antifreeze) solution.
Page 414 WARNING! (Continued) • Do not use a pressure cap other than the one specified for your vehicle. Personal injury or en- gine damage may result. Disposal of Used Engine Coolant Used ethylene glycol based engine coolant (antifreeze) is a regulated substance requiring proper disposal. Check with your local authorities to determine the disposal rules for your community.
Page 415 414 MAINTAINING YOUR VEHICLE Points to Remember NOTE: When the vehicle is stopped after a few miles/ kilometers of operation, you may observe vapor coming from the front of the engine compartment. This is nor- mally a result of moisture from rain, snow, or high humidity accumulating on the radiator and being vapor- ized when the thermostat opens, allowing hot engine coolant (antifreeze) to enter the radiator.
Page 416: Brake System
Brake System In order to assure brake system performance, all brake system components should be inspected periodically. Refer to “Maintenance Schedule” for further information. WARNING! Riding the brakes can lead to brake failure and possibly a collision. Driving with your foot resting or riding on the brake pedal can result in abnormally high brake temperatures, excessive lining wear, and possible brake damage.
Page 417 416 MAINTAINING YOUR VEHICLE WARNING! • Use only manufacturer’s recommended brake fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. Using the wrong type of brake fluid can severely damage your brake system and/or impair its performance.
Page 418: Automatic Transmission
WARNING! (Continued) • Do not allow petroleum based fluid to contami- nate the brake fluid. Brake seal components could be damaged, causing partial or complete brake failure. This could result in a collision. Automatic Transmission Fluid Level Check Your vehicle is equipped with a capped transmission oil fill tube.
Page 419: Transfer Case
418 MAINTAINING YOUR VEHICLE detecting fluid leaks. The use of transmission sealers should be avoided as they may adversely affect seals. CAUTION! Do not use chemical flushes in your transmission as the chemicals can damage your transmission compo- nents. Such damage is not covered by the New Vehicle Limited Warranty.
Page 420: Front/Rear Axle Fluid
Draining Fluid First remove the fill plug (1), then the drain plug (2). Recommended tightening torque for the drain and fill plugs is 15–25 ft lbs (20–34 N·m). CAUTION! Do not over-tighten the plugs. You could damage them and cause a leak. Lubricant Selection Use only manufacturer’s recommended fluid.
Page 421: Appearance Care And Protection From Corrosion
420 MAINTAINING YOUR VEHICLE Adding Fluid Add lubricant only at the fill hole and only to the level specified above. Selection of Lubricant Use only manufacturer’s recommended fluid. Refer to “Fluids, Lubricants, and Genuine Parts” in “Maintaining Your Vehicle” for further information. Appearance Care and Protection from Corrosion Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo-...
Page 422 Washing • Wash your vehicle regularly. Always wash your ve- hicle in the shade using MOPAR Car Wash or equiva- lent, or a mild car wash soap, and rinse the panels completely with clear water. • If insects, tar, or other similar deposits have accumu- lated on your vehicle, use MOPAR Super Kleen Bug and Tar Remover or equivalent to remove.
Page 423 422 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, touch them up immediately. The cost of such repairs is considered the responsibility of the owner. • If your vehicle is damaged due to a collision or similar cause which destroys the paint and protective coating, have your vehicle repaired as soon as possible.
Page 424 • For tough stains, apply MOPAR equivalent, or a mild soap solution to a clean, damp cloth and remove the stain. Use a fresh, damp towel to remove soap residue. • For grease stains, apply MOPAR Cleaner or equivalent to a clean, damp cloth and remove the stain.
Page 425: Fuses
424 MAINTAINING YOUR VEHICLE When cleaning the rear view mirror, spray cleaner on the towel or rag that you are using. Do not spray cleaner directly on the mirror. Cleaning Plastic Instrument Cluster Lenses The lenses in front of the instruments in this vehicle are molded in clear plastic.
Page 426 Totally Integrated Power Module (TIPM) Cav- Cartridge Mini- Fuse Fuse — — 30 Amp Transfer Case, Pwr Lift- Pink gate Module — — Cav- Cartridge Fuse 25 Amp Natural 25 Amp Natural 40 Amp Green 30 Amp Pink 40 Amp Green Description —...
Page 427 426 MAINTAINING YOUR VEHICLE Cav- Cartridge Mini- Fuse Fuse — — 60 Amp Ignition Off Draw – Yellow Main 40 Amp Rear Defroster Green 40 Amp Front Blower Green 40 Amp Starter Solenoid Green 20 Amp Powertrain Control Blue Module 60 Amp Radiator Fan Yellow...
Page 428 Cav- Cartridge Mini- Fuse Fuse 20 Amp Cigar Lighter Yellow 20 Amp Front Heated Seat – If Yellow Equipped — — 15 Amp Ignition Off Draw – Blue Video System, Satellite Radio, DVD, Hands- Free Module, Antenna, Universal Garage Door Opener, Vanity Lamp 10 Amp Ignition Off Draw –...
Page 429 428 MAINTAINING YOUR VEHICLE Cav- Cartridge Mini- Fuse Fuse 15 Amp Left Front Park & Side Blue Marker/Left Tail/ License/Park Lamp 15 Amp Right Front Park & Blue Side Marker/Right Tail/Park/Run Lamp 25 Amp Automatic Shutdown Natural #1 and #2 15 Amp Instrument Cluster In- Blue...
Page 430 Cav- Cartridge Mini- Fuse Fuse 15 Amp Rear Wiper Module, Blue Power Folding Mirror – If Equipped, Diagnostic Link 20 Amp Back-Up Lamps Yellow 10 Amp Airbag Module 10 Amp Powertrain Control Module Description Cav- Cartridge Fuse MAINTAINING YOUR VEHICLE 429 Mini- Description Fuse...
Page 431: Replacement Bulbs
430 MAINTAINING YOUR VEHICLE CAUTION! • When installing the integrated power module cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the integrated power module, and possibly result in a electrical system failure.
Page 432: Bulb Replacement
BULB REPLACEMENT Headlamp 1. Open the hood. 2. Reach behind the headlamp unit in the engine com- partment to access the headlamp bulb lock ring. 3. Firmly grasp the lock ring on the back of the headlamp unit housing. 4. Rotate the lock ring on the back of the headlamp housing counterclockwise to unlock it.
Page 433: Right Front Turn Signal
432 MAINTAINING YOUR VEHICLE 2. Remove the door in the left wheel liner by twisting counter clockwise. Access to the bulb can be gained through the wheel liner hole. Access Door 3. Disconnect the electrical connector. 4. Twist the bulb counter clockwise to remove. Right Front Turn Signal 1.
Page 434: Front Fog Lamp (Front Fascia Mounted)
e. Pull the grille assembly toward you to disconnect the grille clips to the fender and the headlamp ball- studs to the front end module. 3. Disconnect electrical connector. 4. Turn the bulb counterclockwise to remove. Front Fog Lamp (Front Fascia Mounted) 1.
Page 435: Rear Tail, Stop, Turn Signal, And Backup Lamp
434 MAINTAINING YOUR VEHICLE Rear Tail, Stop, Turn Signal, and Backup Lamp 1. Open the lift gate. 2. Remove the two push pins. Push Pins 3. Pull lamp straight back and disconnect electrical con- nection. 4. Remove the two screws attaching the backplate to the lamp assembly.
Page 436: Center High Mounted Stop Lamp (Chmsl)
Center High Mounted Stop Lamp (CHMSL) 1. Remove the two screws securing the CHMSL. Screw Locations MAINTAINING YOUR VEHICLE 435 2. Disconnect the electrical connector and washer hose (if equipped) from the CHMSL. 3. Replace the CHMSL.
Page 437: Fluid Capacities
436 MAINTAINING YOUR VEHICLE FLUID CAPACITIES Fuel (Approximate) Engine Oil with Filter 3.7 Liter Engine (SAE 5W-20, API Certified) 4.0 Liter Engine (SAE 10W-30, API Certified) Cooling System * 3.7 Liter Engine (MOPAR Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula or equivalent) 4.0 Liter Engine (MOPAR Antifreeze/Engine Coolant 5 Year/100,000 Mile Formula or equivalent) * Includes heater and coolant recovery bottle filled to MAX level.
Page 438: Fluids, Lubricants And Genuine Parts
FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Engine Coolant Engine Oil – 3.7L Engine Engine Oil – 4.0L Engine Engine Oil Filter Spark Plugs – 3.7L Engine Spark Plugs – 4.0L Engine Fuel Selection – 3.7L Engine Fuel Selection – 4.0L Engine Fluid, Lubricant, or Genuine Part MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent.
Page 439: Chassis
438 MAINTAINING YOUR VEHICLE Chassis Component Automatic Transmission Transfer Case Front Axle Rear Axle Brake Master Cylinder Power Steering Reservoir Fluid, Lubricant, or Genuine Part MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product.
Page 440 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..440 Maintenance Schedule ....440 Required Maintenance Intervals ..442...
Page 441 440 MAINTENANCE SCHEDULES EMISSIONS CONTROL SYSTEM MAINTENANCE The Scheduled Maintenance services listed in bold type must be done at the times or mileages specified to ensure the continued proper functioning of the emissions control system. These and all other maintenance services in- cluded in this manual, should be done to provide best vehicle performance and reliability.
Page 442 NOTE: • The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been six months since your last oil change even if the oil change indicator message is NOT illumi- nated.
Page 443 442 MAINTENANCE SCHEDULES Once a Month • Check tire pressure and look for unusual wear or damage. • Inspect the battery and clean and tighten the terminals as required. • Check the fluid levels of the coolant reservoir and the brake master cylinder, add as needed.
Page 444 8,000 Miles (13,000 km) or 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 8,000 miles (13 000 km). Odometer Reading Date Repair Order #...
Page 445: Service Schedule
444 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 18 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 24,000 miles (39 000 km). ❏...
Page 446 40,000 Miles (65,000 km) or 30 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 40,000 miles (65 000 km). Odometer Reading Date Repair Order #...
Page 447 446 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). Odometer Reading Repair Order # Dealer Code...
Page 448 72,000 Miles (117,000 km) or 54 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 72,000 miles (117 000 km). ❏...
Page 449 448 MAINTENANCE SCHEDULES 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). Odometer Reading Repair Order # Dealer Code...
Page 450 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 451 450 MAINTENANCE SCHEDULES 104,000 Miles (169,000 km) or 78 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 104,000 miles (169 000 km). ❏...
Page 452 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 453 452 MAINTENANCE SCHEDULES 128,000 Miles (208,000 km) or 96 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 128,000 miles (208 000 km). ❏...
Page 454 144,000 Miles (234,000 km) or 108 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 144,000 miles (234 000 km). ❏...
Page 455 454 MAINTENANCE SCHEDULES † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 456: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......457 Prepare For The Appointment .
Page 457 456 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Quality Grades ......463 Treadwear ......463 Traction Grades .
Page 458: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 459: Chrysler Group Llc Customer Center
458 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- solved with this process. • If for some reason you are still not satisfied, talk to the general manager or owner of the authorized dealer- ship.
Page 460: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
Customer Assistance For The Hearing Or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommuni- cation Devices for the Deaf) equipment at its customer center. Any hearing or speech impaired customer, who has access to a TDD or a conventional teletypewriter (TTY) in the United States, can communicate with the manufacturer by dialing 1–800–380–CHRY.
Page 461: Warranty Information
460 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment when you purchased the vehicle. An authorized dealer has also made a major investment in facilities, tools, and training to assure that you are absolutely delighted with the ownership experience.
Page 462: In Canada
If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your authorized dealer, and the manufacturer.
Page 463 462 IF YOU NEED CONSUMER ASSISTANCE • Service Manuals These comprehensive Service Manuals provide the information that students and professional technicians need in diagnosing/troubleshooting, problem solving, maintaining, servicing, and repairing Chrysler Group LLC vehicles. A complete working knowledge of the vehicle, system, and/or components is written in straightforward language with illustrations, diagrams, and charts.
Page 464 DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 465 464 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat, when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 466 INDEX...
Page 467 466 INDEX About Your Brakes ..... . . 304 ABS (Anti-Lock Brake System) ....306 Adding Engine Coolant (Antifreeze) .
Page 468 Fluid Type ......417,438 Special Additives ..... . 417 Torque Converter .
Page 469 468 INDEX Cargo Load Floor ......182 Cargo Tie-Downs ......180 Cargo (Vehicle Loading) .
Page 470 Cupholders ......177 Customer Assistance ..... 457 Data Recorder, Event .
Page 471 470 INDEX Overheating ......376 Emission Control System Maintenance ..396,440 Engine .
Page 472 Finish Care ......421 Flashers Hazard Warning ..... . . 376 Turn Signal .
Page 473 472 INDEX Garage Door Opener (HomeLink ) ... 165 Gas Cap (Fuel Filler Cap) ... . 350,352,395 Gas Gauge (Fuel Gauge) ....192 Gasoline (Fuel) .
Page 474 Ignition Key Removal ..... 12 Illuminated Entry ......19 Immobilizer (Sentry Key) .
Page 475 474 INDEX Alarm ......194 Anti-Lock ......199 Back-Up .
Page 476 Traction Control ..... . . 314 Turn Signal ....88,150,431,432,434 Voltage .
Page 477 476 INDEX MTBE/ETBE ......347 Multi-Function Control Lever ....148 New Vehicle Break-In Period .
Page 478 Phone, Cellular ......96 Phone, Hands-Free (Uconnect™) ....96 Placard, Tire and Loading Information .
Page 479 478 INDEX Restraints, Child ......74 Restraints, Occupant ..... . 38 Roll Over Warning .
Page 480 Service Engine Soon Light (Malfunction Indicator) ....204 Service Manuals ......461 Setting the Clock .
Page 481 480 INDEX Synthetic Engine Oil ..... . 401 System, Remote Starting ....25 Tachometer .
Page 482 Torque Converter Clutch ....295,299 Towing ......355,387 24-Hour Towing Assistance .
Page 483 482 INDEX Uconnect™ (Hands-Free Phone) ....96 Uniform Tire Quality Grades ....463 Universal Transmitter .
Page 484 Chrysler Group LLC 11KA74-126-AB Second Edition Printed in U.S.A.

Dodge 2011 Nitro Owner's Manual

Nitro
