Table of Contents

Advertisement

Quick Links

Download this manual
Challenger
2 0 1 1
O W N E R ' S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Challenger and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dodge Challenger

Summary of Contents for Dodge Challenger

  • Page 1 Challenger 2 0 1 1 O W N E R ’ S M A N U A L...
  • Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and features and equipment that are either standard or op- the name Chrysler Canada Inc.

  • Page 3: Introduction

    TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .

  • Page 5: Table Of Contents

    INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .

  • Page 6: Introduction

    4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
  • Page 7 INTRODUCTION 5...

  • Page 8: Vehicle Identification Number

    6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.

  • Page 9: Vehicle Modifications/Alterations

    INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death. NOTE: It is illegal to remove or alter the VIN.

  • Page 11: Things To Know Before Starting Your Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Vehicle Security Alarm ....18 Wireless Ignition Node (WIN) .
  • Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Open The Trunk ....25 Wind Buffeting ..... . . 40 Using The Panic Alarm .
  • Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 Seat Belts And Pregnant Women ..55 Safety Tips ......80 Seat Belt Extender .

  • Page 14: Things To Know Before Starting Your Vehicle 9

    12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN) Your vehicle uses a keyless ignition system. This system The Wireless Ignition Node (WIN) operates similar to an consists of a Key Fob with Remote Keyless Entry (RKE) ignition switch.

  • Page 15: Key Fob

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.

  • Page 16: Removing Key Fob From Ignition

    14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Removing Key Fob From Ignition at the top of the Key Fob sideways with your thumb and Place the shift lever in PARK. Turn the Key Fob to the then pull the key out with your other hand.

  • Page 17: Key-In-Ignition Reminder

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 WARNING! CAUTION! • Never leave children alone in a vehicle. Leaving An unlocked car is an invitation to thieves. Always unattended children in a vehicle is dangerous for a remove the Key Fob from vehicle, cycle the ignition number of reasons.

  • Page 18: Sentry Key

    16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE will cause the reminder chime to sound. Refer to “Start- seconds for a bulb check. If the light remains on after the ing Procedures” in “Starting And Operating” for further bulb check, it indicates that there is a problem with the information.

  • Page 19: Replacement Keys

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Replacement Keys Duplication of Key Fobs may be performed at an autho- rized dealer, this procedure consists of programming a NOTE: Only Key Fobs that are programmed to the blank Key Fob to the vehicle electronics. A blank Key Fob vehicle electronics can be used to start and operate the is one that has never been programmed.

  • Page 20: Vehicle Security Alarm

    18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • This device must accept any interference that may be Rearming Of The System received, including interference that may cause unde- If something triggers the alarm, and no action is taken to sired operation.

  • Page 21: To Disarm The System

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 2. Perform one of the following methods to lock the NOTE: • The driver’s door key cylinder and the trunk button on vehicle: the RKE transmitter cannot arm or disarm the Vehicle •...

  • Page 22: Illuminated Entry

    20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE vehicle and open a door, the alarm will sound. If this Tamper Alert occurs, disarm the Vehicle Security Alarm. If something has triggered the Vehicle Security Alarm in your absence, the horn will sound three times when you If the Vehicle Security Alarm is armed and the battery disarm the Vehicle Security Alarm.

  • Page 23: Remote Keyless Entry (Rke)

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 NOTE: NOTE: Inserting the Key Fob with RKE transmitter into • The front courtesy overhead console and door cour- the ignition switch disables the system from responding tesy lights do not turn on if the dimmer control is in to any button presses from that RKE transmitter.

  • Page 24: To Unlock The Doors

    22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When not using the EVIC, perform the following To Unlock The Doors Press and release the UNLOCK button on the RKE steps: transmitter once to unlock the driver’s door or twice 1.
  • Page 25 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 activated will cause the alarm to sound. Press the UN- 3. Test the feature while outside of the vehicle by press- LOCK button to deactivate the Security Alarm. ing the LOCK/UNLOCK buttons on the RKE transmitter with the ignition switch in the OFF position and the Key Flash Lights With Remote Key Lock Fob removed.

  • Page 26: To Lock The Doors

    24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When not using the EVIC, perform the following To Lock The Doors Press and release the LOCK button on the RKE transmit- steps: ter to lock both doors. The turn signal lights will flash 1.

  • Page 27: Remote Open Window Feature

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 Remote Open Window Feature The Panic Alarm will stay on for three minutes unless This feature allows you to remotely lower both door you turn it off by either pressing the PANIC button a windows at the same time.

  • Page 28: Transmitter Battery Replacement

    26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transmitter Battery Replacement 3. To reassemble the RKE transmitter case, snap the two The recommended replacement battery is CR2032. halves of the case together. Make sure there is an even “gap” between the two halves. If equipped, install and NOTE: Perchlorate Material –...

  • Page 29: Remote Starting System

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 If your RKE transmitter fails to operate from a normal How To Use Remote Start distance, check for these two conditions: All of the following conditions must be met before the engine will remote start: 1.
  • Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE programmed). Then, the engine will start and the vehicle WARNING! will remain in the Remote Start mode for a 15-minute • Do not start or run an engine in a closed garage or cycle.
  • Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 To Exit Remote Start Mode Without Driving The into the ignition switch and turn the switch to the Vehicle ON/RUN position. • Press and release the REMOTE START button one time NOTE: •...

  • Page 32: Door Locks

    30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Cancel Remote Start Remote Starting will also cancel if any of the following occur: • The engine stalls or engine speed exceeds 2500 rpm • Any engine warning lights come on • Fuel lamp turns on •...

  • Page 33: Power Door Locks

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the Key Fob from the ignition and lock your vehicle.
  • Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you press the power door lock switch while the Key 6. The doors were not previously locked using the power Fob is in the ignition, and either door is open, the power door lock switch or Remote Keyless Entry (RKE) locks will not operate.
  • Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 2. Within 15 seconds, cycle the ignition switch between Automatic Unlock Doors On Exit LOCK and ON/RUN and then back to LOCK four times The doors will unlock automatically if: ending up in the LOCK position (do not start the engine). 1.

  • Page 36: Keyless Enter-N-Go - If Equipped

    34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • When not using the EVIC, perform the following 6. Repeat these steps if you want to return this feature to steps: its previous setting. 1. Enter the vehicle and close all doors. NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws.
  • Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 • If a Passive Entry door handle has not been used for 72 hours, the Passive Entry feature for the handle may time out. Pulling the deactivated front door handle will reactivate the door handle’s Passive Entry feature. •...
  • Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlock From The Passenger Side: If one of the vehicle doors is open and the door panel With a valid Passive Entry RKE transmitter within 5 ft switch is used to lock the vehicle, once all open doors (1.5 m) of the passenger door handle, grab the front have been closed the vehicle checks the inside and passenger door handle to unlock both doors automati-...
  • Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 To Lock The Vehicle’s Doors With one of the vehicle’s Passive Entry RKE transmitters within 5 ft (1.5 m) of the driver or passenger front door handles, press the door handle LOCK button to lock both doors.

  • Page 40: Windows

    38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.
  • Page 41 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 NOTE: AUTO-Down Feature • The door window will lower slightly if it is closed The driver’s door power window switch and passenger completely when opening the door. The window will door power window switch have an AUTO-down fea- return to its fully closed position after closing the door.

  • Page 42: Wind Buffeting

    40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Wind Buffeting NOTE: The transmission must be in PARK before the Wind buffeting can be described as the perception of button will operate. If equipped with a manual transmis- pressure on the ears or a helicopter-type sound in the sion, the vehicle speed must be under 5 mph (8 km/h) ears.

  • Page 43: Trunk Safety Warning

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 With the ignition switch in the OFF position or the key Trunk Emergency Release removed from the ignition switch, the Trunk Open sym- bol will display until the trunk is closed. Refer to “Keyless Enter-N-Go” in “Things To Know Before Starting Your Vehicle”...

  • Page 44: Occupant Restraints

    42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Front seat belts incorporate pretensioners that may OCCUPANT RESTRAINTS Some of the most important safety features in your enhance occupant protection by managing occupant vehicle are the restraint systems: energy during an impact event •...
  • Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 NOTE: The Advanced Front Air Bags have a multistage secured in the rear seat in child restraints or belt- inflator design. This allows the air bag to have different positioning booster seats. Older children who do not use rates of inflation based on the severity and type of child restraints or belt-positioning booster seats should collision.
  • Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Do not lean against the door or window. If your WARNING! (Continued) vehicle has side air bags, and deployment occurs, the • Being too close to the steering wheel or instrument side air bags will inflate forcefully into the space panel during Advanced Front Air Bag deployment between you and the door.

  • Page 47: Lap/Shoulder Belts

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 Buckle up even though you are an excellent driver, even The belt webbing retractor is designed to lock during on short trips. Someone on the road may be a poor driver very sudden stops or impacts. This feature allows the and cause an accident that includes you.
  • Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lap/Shoulder Belt Operating Instructions WARNING! (Continued) 1. Enter the vehicle and close the door. Sit back and • Wearing a seat belt incorrectly is dangerous. Seat adjust the front seat. belts are designed to go around the large bones of your body.
  • Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Latch Plate Latch Plate To Buckle 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.”...
  • Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt that is buckled into the wrong buckle will Your body could strike the inside surfaces of the not protect you properly.
  • Page 51 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 4. Position the lap belt across your thighs, below your 5. Position the shoulder belt on your chest so that it is abdomen. To remove slack in the lap belt portion, pull up comfortable and not resting on your neck.

  • Page 52: Lap/Shoulder Belt Untwisting Procedure

    50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. 2. At about 6 to 12 in (15 to 30 cm) above the latch plate, The belt will automatically retract to its stowed position. grasp and twist the belt webbing 180 degrees to create a If necessary, slide the latch plate down the webbing to fold that begins immediately above the latch plate.

  • Page 53: Automatic Locking Retractor Mode (Alr) - If Equipped

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 Automatic Locking Retractor Mode (ALR) — Driver Center Passenger If Equipped First Row In this mode, the shoulder belt is automatically pre- Second Row locked. The belt will still retract to remove any slack in Third Row the shoulder belt.

  • Page 54: Energy Management Feature

    52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. Allow the belt to retract. As the belt retracts, you will Energy Management Feature hear a clicking sound. This indicates the safety belt is This vehicle has a safety belt system with an Energy now in the Automatic Locking Mode.

  • Page 55: Seat Belt Pretensioners

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 Seat Belt Pretensioners Enhanced Seat Belt Use Reminder System The seat belts for both front seating positions are (BeltAlert ) equipped with pretensioning devices that are designed to BeltAlert is a feature intended to remind the driver and remove slack from the seat belt in the event of an front passenger (if equipped with front passenger accident.
  • Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The front passenger seat BeltAlert is not active when the 2. Turn the ignition switch to the ON/RUN position, but front passenger seat is unoccupied. BeltAlert may be do not start the engine. Wait for the Seat Belt Reminder triggered when an animal or heavy object is on the front Light to turn off and then proceed to the next step.

  • Page 57: Seat Belts And Pregnant Women

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 The BeltAlert can be reactivated by repeating this pro- extender. This extender should be used only if the cedure. existing belt is not long enough. When it is not required, remove the extender and store it. NOTE: When the BeltAlert is deactivated, the Seat Belt Reminder Light will continue to illuminate as long as the WARNING!
  • Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE instrument panel, above the glove compartment. The The Advanced Front Air Bags have a multistage inflator words SRS AIRBAG are embossed on the air bag covers. design. This allows the air bag to have different rates of inflation based on the severity and type of collision.
  • Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 • Steering Wheel and Column This vehicle is equipped with Supplemental Side Air Bag Inflatable Curtains (SABIC) to protect the driver, front, • Instrument Panel and rear passengers sitting next to a window. The SABIC •...
  • Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Advanced Front Air Bag Features WARNING! The Advanced Front Air Bag system has multistage • No objects should be placed over or near the air driver and front passenger air bags. This system provides output appropriate to the severity and type of collision as bag on the instrument panel, because any such determined by the Occupant Restraint Controller (ORC),...
  • Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Supplemental Seat-Mounted Side Air Bags (SAB) When the air bag deploys, it opens the seam between the Supplemental Seat-Mounted Side Air Bags may provide front and side of the seat’s trim cover. Each air bag enhanced protection to help protect an occupant during a deploys independently;...
  • Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Side Air Bag Inflatable Curtain (SABIC) SABIC air bags may offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure. Each air bag features inflated chambers placed adjacent to the head of each outboard occupant that reduce the potential for side- impact head injuries.
  • Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 The system includes side impact sensors that are cali- WARNING! (Continued) brated to deploy the side air bags during impacts that • If your vehicle is equipped with SABIC air bags, require air bag occupant protection. do not have any accessory items installed which will alter the roof, including adding a sunroof to WARNING!

  • Page 64: Air Bag Deployment Sensors And Controls

    62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Along with seat belts and pretensioners, Advanced Front Advanced Front Air Bags are designed to provide addi- Air Bags work with the knee bolsters to provide im- tional protection by supplementing the seat belts in proved protection for the driver and front passenger.
  • Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Because air bag sensors measure vehicle deceleration Also, the ORC turns on the Air Bag Warning over time, vehicle speed and damage by themselves are Light in the instrument panel for approxi- not good indicators of whether or not an air bag should mately four to eight seconds for a self-check have deployed.
  • Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE are possible, based on the collision type and severity. The WARNING! steering wheel hub trim cover and the upper right side of the instrument panel separate and fold out of the way as Ignoring the Air Bag Warning Light in your instru- the air bags inflate to their full size.
  • Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 Based on the severity and type of collision, the side air A quantity of non-toxic gas is generated to inflate the side bag inflator on the crash side of the vehicle may be curtain air bag.
  • Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Enhanced Accident Response System NOTE: Front and/or side air bags will not deploy in all In the event of an impact causing air bag deployment, if collisions. This does not mean something is wrong with the communication network remains intact, and the the air bag system.
  • Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 bag inflation. These airborne particles may irritate the Maintaining Your Air Bag System skin, eyes, nose, or throat. If you have skin or eye WARNING! irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air.
  • Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light WARNING! (Continued) You will want to have the air bags ready to • Do not attempt to modify any part of your air bag inflate for your protection in a collision. The system.

  • Page 71: Event Data Recorder (Edr)

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 • Whether or not the driver and passenger safety belts NOTE: If the speedometer, tachometer, or any engine related gauges are not working, the Occupant Restraint were buckled/fastened; Controller (ORC) may also be disabled. The air bags may •...

  • Page 72: Child Restraints

    70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To read data recorded by an EDR, special equipment is WARNING! required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, In a collision, an unrestrained child, even a tiny baby, such as law enforcement, that have the special equip- can become a projectile inside the vehicle.
  • Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 Infants And Child Restraints WARNING! • Safety experts recommend that children ride Rearward-facing child seats must never be used in rearward-facing in the vehicle until they are at least the front seat of a vehicle with the front passenger air one year old and weigh at least 20 lbs (9 kg).
  • Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • If the shoulder belt contacts the face or neck, move the The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit child closer to the center of the vehicle.
  • Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 • Carefully follow the instructions that come with the WARNING! (Continued) restraint. If you install the restraint improperly, it may • A rearward-facing child restraint should only be not work when you need it. used in a rear seat.
  • Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE the child restraint using lower anchorages and upper child seats so that two seats share a common lower tether straps from the child restraint to the vehicle anchorage. If installing child seats in adjacent rear- structure.
  • Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Installing The LATCH-Compatible Child Restraint window. These tether strap anchorages are under a System plastic cover with this symbol on it. We urge you to follow the manufacturer’s directions Many, but not all, restraint systems will be equipped with carefully when installing your child restraint.
  • Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE provide the most direct path between the anchor and the restraint installation, instead of tucking the seat belt child restraint. Finally, tighten all three straps as you behind the child restraint, route the seat belt through push the child restraint rearward and downward into the the child restraint belt path and then buckle it.
  • Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 • N/A — Not Applicable Installing Child Restraints Using The Vehicle Seat Belt • ALR — Automatic Locking Retractor The seat belts in the passenger seating positions are equipped with either an Automatic Locking Retractor To install a child restraint, first, pull enough of the seat (ALR) or a cinching latch plate or both.
  • Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To attach a child restraint tether strap: 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint.

  • Page 81: Engine Break-In Recommendations

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 Transporting Pets While cruising, brief full-throttle acceleration within the Air Bags deploying in the front seat could harm your pet. limits of local traffic laws contributes to a good break-in. An unrestrained pet will be thrown about and possibly However, wide-open throttle acceleration in low gear can injured, or injure a passenger during panic braking or in be detrimental and should be avoided.

  • Page 82: Safety Tips

    80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE should be considered a normal part of the break-in and WARNING! (Continued) not interpreted as an indication of difficulty. • Do not allow people to ride in any area of your vehicle that is not equipped with seats and seat SAFETY TIPS belts.

  • Page 83: Safety Checks You Should Make Inside The Vehicle

    THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Do not run the engine in a closed garage or in confined damaged, have a competent mechanic inspect the com- areas any longer than needed to move your vehicle in or plete exhaust system and adjacent body areas for broken, out of the area.
  • Page 84 82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Air Bag Warning Light Floor Mat Safety Information The light should come on and remain on for four to eight Always use floor mats designed to fit the footwell of your seconds as a bulb check when the ignition switch is first vehicle.
  • Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 WARNING! (Continued) WARNING! (Continued) • Never place or install floor mats or other floor • Always make sure that objects cannot fall into the coverings in the vehicle that cannot be properly driver footwell while the vehicle is moving.

  • Page 86: Periodic Safety Checks You Should Make Outside The Vehicle

    84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside Lights The Vehicle Have someone observe the operation of exterior lights while you work the controls. Check turn signal and high Tires beam indicator lights on the instrument panel. Examine tires for excessive tread wear and uneven wear patterns.

  • Page 87: Understanding The Features Of Your Vehicle

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors ......89 “Slide-On-Rod” And Extender Features Of Sun Visor .
  • Page 88 86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Command — If Equipped ... 123 Lights ......139 Voice Command System Operation .
  • Page 89 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 Flash-To-Pass ..... . . 144 To Deactivate ..... . . 150 Map/Reading Lights .
  • Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Security ......158 Wind Buffeting ..... . 162 Troubleshooting Tips .

  • Page 91: Mirrors

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 MIRRORS Inside Day/Night Mirror — If Equipped A two-point pivot system allows for horizontal and vertical adjustment of the mirror. Adjust the mirror to center on the view through the rear window. Headlight glare can be reduced by moving the small control under the mirror to the night position (toward the rear of the vehicle).

  • Page 92: Automatic Dimming Mirror - If Equipped

    90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Automatic Dimming Mirror — If Equipped CAUTION! This mirror automatically adjusts for headlight glare from vehicles behind you. You can turn the feature on or To avoid damage to the mirror during cleaning, never off by pressing the button at the base of the mirror.

  • Page 93: Outside Mirrors Folding Feature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 WARNING! Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away than they really are. Relying too much on your passenger side convex mirror could cause you to collide with another vehicle or other object.

  • Page 94: Heated Mirrors - If Equipped

    92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE move. When you are finished adjusting the mirror, turn Heated Mirrors — If Equipped the control to the center position to prevent accidentally These mirrors are heated to melt frost or ice. This moving a mirror.

  • Page 95: Slide-On-Rod" And Extender Features Of Sun Visor

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 desired position. To use the extender feature of the sun visor, grab the extender which is located at the rear of the visor and pull rearward. Illuminated Vanity Mirror “Slide-On-Rod” And Extender Features Of Sun Visor To use the “Slide-On-Rod”...

  • Page 96: Uconnect™ Phone - If Equipped

    For Uconnect™ customer support, visit the following long as your phone is turned on and has been paired to websites: the vehicle’s Uconnect™ Phone. The Uconnect™ Phone • www.chrysler.com/uconnect allows up to seven mobile phones to be linked to the • www.dodge.com/uconnect...
  • Page 97 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 system. Only one linked (or paired) mobile phone can be Voice Command Button used with the system at a time. The system is available in Actual button location may vary with the ra- English, Spanish, or French languages.

  • Page 98: Operation

    96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Operation example, you can use the compound form voice Voice commands can be used to operate the Uconnect™ command “Phonebook New Entry”, or you can break Phone and to navigate through the Uconnect™ Phone the compound form command into two voice com- menu structure.
  • Page 99 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 • When prompted, after the beep, say “Pair a Device” Cancel Command At any prompt, after the beep, you can say “Cancel” and and follow the audible prompts. you will be returned to the main menu. However, in a •...
  • Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE phone to use if multiple mobile phones are in the Call By Saying A Name vehicle at the same time. For example, if priority three • Press the button to begin. and priority five phones are present in the vehicle, the •...
  • Page 101 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Add Names To Your Uconnect™ Phonebook After you are finished adding an entry into the phone- book, you will be given the opportunity to add more NOTE: Adding names to the Uconnect™ Phonebook is phone numbers to the current entry or to return to the recommended when the vehicle is not in motion.
  • Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • To call a name from the Uconnect™ Phonebook or • Only the mobile phone’s phonebook is downloaded. downloaded Phonebook, follow the procedure in SIM card phonebook is not part of the Mobile phone- “Call by Saying a Name”...
  • Page 103 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 • After the “Ready” prompt and the following beep, say mobile and a home number, but you can add “John “Phonebook Edit Entry”. Doe’s” work number later using the “Phonebook Edit Entry” feature. •...
  • Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone will ask you to verify that you from the list, press the button while the wish to delete all the entries from the phonebook. Uconnect™ Phone is playing the desired entry and say “Delete”.

  • Page 105: Phone Call Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 • To call one of the names in the list, press the Answer Or Reject An Incoming Call — No Call Currently In Progress button during the playing of the desired name, and When you receive a call on your mobile phone, the say “Call”.
  • Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE when another call is in progress. Therefore, the user can Toggling Between Calls only answer an incoming call or ignore it. If two calls are in progress (one active and one on hold), press the button until you hear a single beep, indicat- Making A Second Call While Current Call Is In...
  • Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Call Termination Call Continuation To end a call in progress, momentarily press the Call continuation is the progression of a phone call on the Uconnect™ Phone after the vehicle ignition key has been button.

  • Page 108: Uconnect™ Phone Features

    106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone Features Emergency Assistance If you are in an emergency and the mobile phone is Language Selection reachable: To change the language that the Uconnect™ Phone is • Pick up the phone and manually dial the emergency using: number for your area.
  • Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Canada and 060 for Mexico). The number dialed may Towing Assistance not be applicable with the available mobile service and If you need towing assistance: area. • Press the button to begin. • If supported, this number may be programmable on •...
  • Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Paging When calling a number with your Uconnect™ Phone that To learn how to page, refer to “Working with Automated normally requires you to enter in a touch-tone sequence Systems”. Paging works properly except for pagers of on your mobile phone keypad, you can press the certain companies, which time out a little too soon to button and say the sequence you wish to enter, followed...
  • Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 The Uconnect™ Phone will then send the corresponding Turning Confirmation Prompts ON/OFF phone number associated with the phonebook entry, as Turning confirmation prompts off will stop the system tones over the phone. from confirming your choices (e.g., the Uconnect™ Phone will not repeat a phone number before you dial it).

  • Page 112: Advanced Phone Connectivity

    110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dialing Using The Mobile Phone Keypad Mute/Un-Mute (Mute OFF) You can dial a phone number with your mobile phone When you mute the Uconnect™ Phone, you will still be keypad and still use the Uconnect™ Phone (while dialing able to hear the conversation coming from the other via the mobile phone keypad, the user must exercise party, but the other party will not be able to hear you.
  • Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 • When prompted, say “List Phones”. from your Uconnect™ Phone paired mobile phone to the Uconnect™ Phone or vice versa, press the button • The Uconnect™ Phone will play the phone names of and say “Transfer Call”.

  • Page 114: Things You Should Know About Your Uconnect™ Phone

    112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The selected phone will be used for the next phone Things You Should Know About Your Uconnect™ call. If the selected phone is not available, the Phone Uconnect™ Phone will return to using the highest Uconnect™...
  • Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 You can either press the Uconnect™ Phone button to Voice Command restore the factory setting or repeat the words and • For best performance, adjust the rearview mirror to phrases when prompted by the Uconnect™ Phone. For provide at least ⁄...
  • Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • fully closed windows, • Numbers must be spoken in single digits. “800” must be spoken “eight-zero-zero” not “eight hundred”. • dry weather condition. • You can say “O” (letter “O”) for “0” (zero). •...
  • Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 • fully closed windows, Uconnect™ Phone can read or send new messages on • dry weather conditions, and your phone. • operation from the driver’s seat. Read Messages: • Performance, such as audio clarity, echo, and loudness If you receive a new text message while your phone is to a large degree rely on the phone and network, and connected to Uconnect™...
  • Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Send Messages: 3. Where are you? You can send messages using Uconnect™ Phone. To send 4. I need more direction. a new message: 5. L O L • Press the button. 6. Why •...
  • Page 119 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 16. Can this wait? Bluetooth Communication Link Mobile phones have been found to lose connection to the 17. Bye for now Uconnect™ Phone. When this happens, the connection 18. When can we meet can generally be reestablished by switching the phone off/on.
  • Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 121 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119...
  • Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
  • Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) zero call cancel confirmation prompts three continue four delete five dial download seven edit eight emergency nine English star (*) erase all plus (+) Espanol pound (#) Francais add location...
  • Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Voice Commands Primary Alternate(s) Primary Alternate(s) language return to main menu return or main menu list names select phone select list phones send mobile set up phone settings or phone set up mute towing assistance mute off...

  • Page 125: General Information

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...

  • Page 126: Commands

    124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you ever wish to interrupt the system while it lists The system will best recognize your speech if the win- options, press the Voice Command button, listen dows are closed, and the heater/air conditioning fan is set to low.
  • Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 2. Say a command (e.g., “Help”). Radio AM To switch to the AM band, say “AM” or “Radio AM”. In 3. Use the ON/OFF VOLUME rotary knob to adjust the this mode, you may say the following commands: volume to a comfortable level while the Voice Command •...
  • Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • “Menu Radio” (to switch to the radio menu) Disc To switch to the disc mode, say “Disc”. In this mode, you • “Main Menu” (to switch to the main menu) may say the following commands: Satellite Radio •...
  • Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 • “Switch to system setup” − “Continue” (to continue recording) • “Change to setup” − “Delete” (to delete the recording) • “Play Memos” (to play previously recorded memos) • “Main menu setup” or —...

  • Page 130: Voice Training

    128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Training WARNING! For users experiencing difficulty with the system recog- • It is dangerous to ride in a cargo area, inside or nizing their voice commands or numbers the Uconnect™ Voice “Voice Training” feature may be used. outside of a vehicle.
  • Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Adjusting The Seat Up Or Down The height of the seats can be adjusted up or down. Pull upward or push downward on the seat switch, the seat will move in the direction of the switch. Release the switch when the desired position has been reached.
  • Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Push the switch rearward to decrease the lumbar sup- WARNING! port. Pushing upward or downward on the switch will • Adjusting a seat while driving may be dangerous. raise and lower the position of the support. Moving a seat while driving could result in loss of control which could cause a collision and serious injury or death.

  • Page 133: Heated Seats

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 You can choose from HIGH, LOW or OFF heat settings. CAUTION! Amber indicator lights in each switch indicate the level of heat in use. Two indicator lights will illuminate for Do not place any article under a power seat or HIGH, one for LOW and none for OFF.

  • Page 134: Manual Front Seatback Recline

    132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Front Seatback Recline WARNING! To adjust the seatback, lift the lever located on the • Persons who are unable to feel pain to the skin outboard side of the seat, lean back to the desired position and release the lever.

  • Page 135: Passenger Seat Easy Entry

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. Passenger Seat Easy Entry On the passenger seat, pull forward on the lever located on the side of the seatback in order to dump the seatback...
  • Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To raise the head restraint, pull upward on the head WARNING! restraint. To lower the head restraint, press the push The head restraints for all occupants must be prop- button, located at the base of the head restraint, and push erly adjusted prior to operating the vehicle or occu- downward on the head restraint.
  • Page 137 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 NOTE: The head restraints should only be removed by To raise the head restraint, pull upward on the head qualified technicians, for service purposes only. If either restraint. To lower the head restraint, press the push of the head restraints require removal, see your autho- button, located at the base of the head restraint, and push rized dealer.

  • Page 138: Folding Rear Seat

    136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The outboard head restraints are not adjustable. Refer to “Occupant Restraints” in “Things To Know Before Starting Your Vehicle” for tether routing. Folding Rear Seat The rear seatbacks can be folded forward to provide an additional storage area.
  • Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 WARNING! • Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers. An improperly latched seat could cause serious injury.

  • Page 140: To Open And Close The Hood

    138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TO OPEN AND CLOSE THE HOOD 2. Move to the outside of the vehicle and push the safety Two latches must be released to open the hood. catch to the left. The safety catch is located under the center front edge of the hood.

  • Page 141: Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 LIGHTS CAUTION! Headlights And Parking Lights To prevent possible damage, do not slam the hood to The headlight switch is located on the left side of the close it. Lower the hood until it is open approxi- instrument panel.

  • Page 142: Automatic Headlights - If Equipped

    140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rotate the headlight switch clockwise to the first detent Headlights On With Wipers for parking light and instrument panel light operation. (Available With Automatic Headlights Only) Turn it to the second detent for headlight, parking light When this feature is active, the headlights will turn on and instrument panel light operation.

  • Page 143: Daytime Running Lights - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 To activate the delay feature, place the ignition in the OFF The Headlight delay time is programmable. Refer to position while the headlights are still on. Then, turn off “Electronic Vehicle Information Center (EVIC)/ the headlights within 45 seconds.

  • Page 144: Lights-On Reminder

    142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder If the headlights or parking lights are on after the ignition is in the OFF position, a chime will sound to alert the driver when the driver’s door is opened. Fog Lights — If Equipped The front fog light switch is built into the head- light switch.

  • Page 145: Multifunction Lever

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Multifunction Lever Turn Signals The multifunction lever controls the operation of the turn Move the multifunction lever up or down and the arrows signals, headlight beam selection, and passing lights. The on each side of the instrument cluster flash to show multifunction lever is located on the left side of the proper operation of the front and rear turn signal lights.

  • Page 146: High/Low Beam Switch

    144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High/Low Beam Switch transmitter is pressed, or when the dimmer control is Push the multifunction lever away from you to switch turned fully upward, past the second detent. the headlights to high beam. Pull the multifunction lever toward you to switch the headlights back to low beam.

  • Page 147: Interior Lights

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Interior Lights Dome Light Position The interior lights come on when a door is opened. Rotate the dimmer control completely upward to the second detent to turn on the interior lights. The interior To protect the battery, the interior lights will turn off lights will remain on when the dimmer control is in this automatically 10 minutes after the ignition is placed in...

  • Page 148: Windshield Wipers And Washers

    146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Rotate the end of the multifunction lever to the first The multifunction lever operates the windshield detent past the intermittent settings for low-speed wiper wipers and washer when the ignition is placed in operation, or to the second detent past the intermittent the ON/RUN or ACC position.

  • Page 149: Mist Feature

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 to a maximum of approximately 18 seconds between If you activate the washer while the windshield wiper cycles. The delay intervals will double in duration when control is in the delay range, the wipers will operate for the vehicle speed is 10 mph (16 km/h) or less.

  • Page 150: Headlights On With Wipers (Available With Automatic Headlights Only)

    148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights On With Wipers (Available With handle is located below the steering wheel at the end of Automatic Headlights Only) the steering column. When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned on if the headlight switch is placed in the A (AUTO) position.

  • Page 151: Electronic Speed Control - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 wheel outward or push it inward as desired. To lock the The Electronic Speed Control buttons are located on the steering column in position, push the lever upward until right side of the steering wheel. fully engaged.

  • Page 152: To Activate

    150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the same time. If this occurs, the Electronic Speed Control To Set A Desired Speed System can be reactivated by pushing the Electronic Turn the Electronic Speed Control ON. When the vehicle Speed Control ON/OFF button and resetting the desired has reached the desired speed, press the SET (-) button vehicle set speed.

  • Page 153: To Vary The Speed Setting

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 To Vary The Speed Setting To Accelerate For Passing When the Electronic Speed Control is set, you can in- Press the accelerator as you would normally. When the crease speed by pushing the RES (+) button. If the button pedal is released, the vehicle will return to the set speed.

  • Page 154: Overhead Console

    152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your ve- hicle could go too fast for the conditions, and you could lose control and have an accident. Do not use Electronic Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.

  • Page 155: Sunglasses Storage

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 These lights also turn on when a door is opened, when The HomeLink buttons are located in the overhead the UNLOCK button on the Remote Keyless Entry (RKE) console designating the different HomeLink channels. transmitter is pressed, or when the dimmer control is turned fully upward, past the second detent.

  • Page 156: Programming Homelink

    154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Programming HomeLink WARNING! • Your motorized door or gate will open and close Before You Begin If you have not trained any of the HomeLink buttons, while you are training the Universal Transceiver. erase all channels before you begin training.
  • Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 2. Place the handheld transmitter 1 to 3 in (3 to 8 cm) NOTE: Some gate operators and garage door openers from the HomeLink buttons while keeping the EVIC may require you to replace Step 3 with procedures noted display in view.
  • Page 158 156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE This can usually be found where the hanging antenna 6. Firmly press and release the LEARN or TRAINING wire is attached to the garage door opener motor (it is button. The name and color of the button may vary by NOT the button normally used to open and close the manufacturer.

  • Page 159: Gate Operator/Canadian Programming

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Gate Operator/Canadian Programming If you unplugged the device for training, plug it back in Canadian radio-frequency laws require transmitter sig- at this time. nals to “time-out” (or quit) after several seconds of Then proceed with Step 4 under “Programming transmission –...

  • Page 160: Security

    158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Press and hold the desired HomeLink button for Troubleshooting Tips 20 seconds until the EVIC display states “CHANNEL # If you are having trouble programming HomeLink , here TRAINING.” Do not release the button. are some of the most common solutions: •...

  • Page 161: Power Sunroof - If Equipped

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 2. This device must accept any interference that may be POWER SUNROOF — IF EQUIPPED received including interference that may cause undesired The power sunroof switch is located between the sun operation. visors on the overhead console. NOTE: The transmitter has been tested and it complies with FCC and IC rules.

  • Page 162: Opening Sunroof - Express

    160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening Sunroof — Express WARNING! Press the switch rearward and release it within one-half • Never leave children in a vehicle with the key in second and the sunroof will open automatically from any the ignition switch (or with the ignition in the position.

  • Page 163: Closing Sunroof - Express

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Closing Sunroof — Express sunroof will automatically retract. Remove the obstruc- Press the switch forward and release it within one-half tion if this occurs. Next, press the switch forward and second and the sunroof will close automatically from any release to Express Close.

  • Page 164: Sunshade Operation

    162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE and will occur regardless of sunroof position. During with the sunroof open, adjust the sunroof opening to Express Vent operation, any movement of the switch will minimize the buffeting or open any window. stop the sunroof.
  • Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 converted by your authorized dealer to provide power when the ignition is placed in the OFF position. NOTE: To ensure proper operation a MOPAR knob and element must be used. CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts.
  • Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console power outlet is powered directly from Items plugged into this power outlet may discharge the the battery (power available at all times). battery and/or prevent the engine from starting. Center Console Power Outlet Power Outlet Fuse Locations 1 —...
  • Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery even when not in use (i.e., cellular phones, etc.).

  • Page 168: Cupholders

    166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not insert any other object in the power outlet as this will damage the outlet and blow the fuse. Improper use of the power outlet can cause damage not covered by your warranty.

  • Page 169: Rear Cupholders

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 Rear Cupholders CONSOLE FEATURES The rear seat cupholders are located in the center armrest Sliding Center Console Armrest between the rear seats. The cupholders are positioned The center console armrest slides forward with three forward in the armrest and side-by-side to provide con- detents to provide flexibility for comfort, cupholder use venient access to beverage cans or bottles while maintain-...

  • Page 170: Console Storage

    168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Console Storage The center console has a storage compartment located underneath the armrest, and also contains a 12 Volt power outlet, a molded-in coin holder (designed to hold various size coins). The center console may also be equipped with a Universal Consumer Interface (UCI).

  • Page 171: Rear Window Features

    UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 NOTE: To prevent excessive battery drain, use the rear WARNING! window defroster only when the engine is operating. Do not operate this vehicle with a console compart- CAUTION! ment lid in the open position. Cellular phones, music players, and other handheld electronic devices Failure to follow these cautions can cause damage to should be stowed while driving.
  • Page 173 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel Features ....174 Keyless Enter-N-Go Display — If Equipped ......196 Instrument Cluster .
  • Page 174 172 UNDERSTANDING YOUR INSTRUMENT PANEL Media Center 730N/430/430N (RHR/RER/ Media Center 130 With Satellite Radio RBZ/RHB) CD/DVD/HDD/NAV — (Sales Code RES+RSC)....212 If Equipped .
  • Page 175 UNDERSTANDING YOUR INSTRUMENT PANEL 173 Controlling The iPod Or External USB CD Player ......237 Device Using Radio Buttons ... . . 230 CD/DVD Disc Maintenance .

  • Page 176: Instrument Panel Features

    174 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT PANEL FEATURES 1 — Air Outlets 5 — Heated Seat Switch 9 — Ignition Switch 2 — Instrument Cluster 6 — ESP OFF Switch 10 — Trunk Release Button 3 — Glove Compartment 7 — Hazard Warning Switch 11 —...

  • Page 177: Instrument Cluster

    UNDERSTANDING YOUR INSTRUMENT PANEL 175 INSTRUMENT CLUSTER...

  • Page 178: Instrument Cluster Descriptions

    176 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DESCRIPTIONS 5. Tachometer The red segments indicate the maximum permissible 1. Fuel Gauge engine revolutions per minute (RPM x 1000) for each gear The pointer shows the level of fuel in the fuel tank when range.
  • Page 179 UNDERSTANDING YOUR INSTRUMENT PANEL 177 7. Electronic Throttle Control (ETC) Warning Light If the light is flashing when the engine is running, This light will turn on briefly as a bulb check immediate service is required. In this case, you may when the ignition switch is placed in the ON/ experience reduced performance, an elevated/rough idle RUN position.
  • Page 180 178 UNDERSTANDING YOUR INSTRUMENT PANEL 9. Turn Signal Indicators CAUTION! The arrow will flash with the exterior turn signal when the turn signal lever is operated. Driving with a hot engine cooling system could damage your vehicle. If the temperature gauge reads NOTE: “H,”...
  • Page 181 UNDERSTANDING YOUR INSTRUMENT PANEL 179 11. Engine Temperature Warning Light 13. Electronic Stability Program (ESP) Indicator Light / This light will turn on and a single chime will Brake Assist System (BAS) Warning Light sound to warn of an overheated engine condition. The malfunction light for the Electronic Stabil- When this light turns on, the engine temperature ity Program (ESP) is combined with Brake...
  • Page 182 180 UNDERSTANDING YOUR INSTRUMENT PANEL 15. High Beam Indicator WARNING! This indicator will turn on when the high beam headlights are on. Push the multifunction lever If the warning light remains on, the system may not away from the steering wheel to switch the headlights to be working and you will not have the benefit of ESP high beam.
  • Page 183 UNDERSTANDING YOUR INSTRUMENT PANEL 181 17. Shift Lever Indicator — Automatic Transmission the repair technician should leave the odometer reading Only the same as it was before the repair or service. If s/he The Shift Lever Indicator is self-contained within the cannot do so, then the odometer must be set at zero, and instrument cluster.
  • Page 184 182 UNDERSTANDING YOUR INSTRUMENT PANEL This display shows the Electronic Vehicle Information A loose, improperly installed, or damaged fuel filler cap Center (EVIC) messages when the appropriate conditions may also turn on the Malfunction Indicator Light (MIL). exist. Refer to Electronic Vehicle Information Center Lo tirE (EVIC) for further information.
  • Page 185 UNDERSTANDING YOUR INSTRUMENT PANEL 183 means the engine oil change interval may fluctuate 20. Brake Warning Light dependent upon your personal driving style. This light monitors various brake functions, including brake fluid level and parking brake Unless reset, this message will continue to display each application.
  • Page 186 184 UNDERSTANDING YOUR INSTRUMENT PANEL The light will remain on until the cause is corrected. Vehicles equipped with the Anti-Lock Brake System (ABS), are also equipped with Electronic Brake Force NOTE: The light may flash momentarily during sharp Distribution (EBD). In the event of an EBD failure, the cornering maneuvers which change fluid level condi- Brake Warning Light will turn on along with the ABS tions.
  • Page 187 UNDERSTANDING YOUR INSTRUMENT PANEL 185 21. Vehicle Security Light — If Equipped As an added safety feature, your vehicle has been This light will flash at a fast rate for approxi- equipped with a Tire Pressure Monitoring System mately 15 seconds, when the vehicle security (TPMS) that illuminates a low tire pressure telltale when alarm is arming, and then will flash slowly one or more of your tires is significantly under-inflated.
  • Page 188 186 UNDERSTANDING YOUR INSTRUMENT PANEL Your vehicle has also been equipped with a TPMS CAUTION! malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is The TPMS has been optimized for the original combined with the low tire pressure telltale. When the equipment tires and wheels.
  • Page 189 UNDERSTANDING YOUR INSTRUMENT PANEL 187 If the ABS light remains on or turns on while driving, the ignition is in the ON/RUN position before engine then the Anti-Lock portion of the brake system is not start. If the MIL does not come on when turning the key functioning and service is required.

  • Page 190: Electronic Vehicle Information Center (Evic)

    188 UNDERSTANDING YOUR INSTRUMENT PANEL WARNING! A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal operating conditions. This can cause a fire if you drive slowly or park over flammable substances such as dry plants, wood, cardboard, etc. This could result in death or serious injury to the driver, occupants or others.
  • Page 191 UNDERSTANDING YOUR INSTRUMENT PANEL 189 • Vehicle Information Warning Message Displays The system allows the driver to select information by pressing the following buttons mounted on the steering • Tire Pressure Monitor System wheel: • Personal Settings (Customer-Programmable Features) • Compass Display •...

  • Page 192: Electronic Vehicle Information Center (Evic) Displays

    190 UNDERSTANDING YOUR INSTRUMENT PANEL MENU Button SELECT Button Press and release the MENU button to access Press and release the SELECT button for access the main menu, or to return to the main menu to main menus, sub-menus or to select a per- from the sub-menus.
  • Page 193 UNDERSTANDING YOUR INSTRUMENT PANEL 191 • Right Rear Turn Signal Light Out (with a single chime) • Did Not Train • Personal Settings Not Available – Vehicle Not in PARK • Low Tire Pressure (with a single chime) • Left/Right Door Ajar •...

  • Page 194: Engine Oil Change Indicator System

    192 UNDERSTANDING YOUR INSTRUMENT PANEL • Press Brake & Push Button to Start Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN • Push Button or Insert Key/Turn To Run (refer to position or cycle the ignition to the ON/RUN position if “Remote Starting System”...

  • Page 195: Trip Functions

    UNDERSTANDING YOUR INSTRUMENT PANEL 193 • Trip B Vehicles Not Equipped With Keyless Enter-N-Go • Elapsed Time 1. Turn the ignition switch to the ON/RUN position (Do not start the engine.) • Display Units of Measure in 2. Fully depress the accelerator pedal, slowly, three times Press the UP or DOWN buttons to cycle through all the within 10 seconds.
  • Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL The FUEL SAVER MODE message will display above the This feature allows you to monitor when you are driving average fuel economy in the EVIC display. This message in a fuel efficient manner, and it can be used to modify will appear whenever the Multi-Displacement System driving habits in order to increase fuel economy.
  • Page 197 UNDERSTANDING YOUR INSTRUMENT PANEL 195 • Elapsed Time and average fuel economy, according to the current fuel tank level. DTE cannot be reset through the SELECT Shows the total elapsed time of travel since the last reset button. when the ignition switch is in the ACC position. Elapsed time will increment when the ignition switch is in the ON NOTE: Significant changes in driving style or vehicle or START position.

  • Page 198: Keyless Enter-N-Go Display - If Equipped

    196 UNDERSTANDING YOUR INSTRUMENT PANEL Keyless Enter-N-Go Display — If Equipped The round symbol in the middle rotates to point at the When the ENGINE START/STOP button is pressed to new ignition switch position. If desired, the ignition change ignition switch positions, the Keyless Enter-N-Go switch position graphic can be set to be constantly visible icon momentarily appears in the EVIC display showing by pressing the EVIC MENU button until the display...

  • Page 199: Compass Display

    UNDERSTANDING YOUR INSTRUMENT PANEL 197 • Video Surround displayed temperature; therefore, temperature readings are not updated when the vehicle is not moving. • Audio Surround Automatic Compass Calibration While in the Surround Sound menu, press the SELECT This compass is self-calibrating, which eliminates the button to change surround modes.
  • Page 200 198 UNDERSTANDING YOUR INSTRUMENT PANEL 2. Press and release the MENU button until Personal NOTE: Keep magnetic materials away from the top of Settings displays in the EVIC. the instrument panel, such as iPod’s, Mobile Phones, Laptops and Radar Detectors. This is where the compass 3.

  • Page 201: System Warnings (Customer Information Features)

    UNDERSTANDING YOUR INSTRUMENT PANEL 199 • Oil Pressure 2. Press and release the MENU button until Personal Settings displays in the EVIC. Shows the actual oil pressure. • Tire Pressure 3. Press the UP or DOWN button until “COMPASS VARIANCE” message and the last variance zone number Shows the actual tire pressure for each tire (EXCLUDING displays in the EVIC.
  • Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL SELECT button while in this display to select English, Remote Key Unlock Espanol, or Francais. Then, as you continue, the informa- When Driver Door 1st Press is selected, only the driver’s tion will display in the selected language. door will unlock on the first press of the Remote Keyless Entry (RKE) transmitter UNLOCK button.
  • Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 only result in the driver’s door opening. If driver door Headlamps On with Wipers first is selected, once the driver door is opened, the (Available with Auto Headlamps Only) interior door lock/unlock switch can be used to unlock When ON is selected, and the headlight switch is in the all doors (or use RKE transmitter).

  • Page 204: Understanding Your Instrument Panel

    202 UNDERSTANDING YOUR INSTRUMENT PANEL Hill Start Assist (HSA) — If Equipped ignition switch is turned OFF. Opening either front When on is selected, the HSA system is active. Refer to vehicle door will cancel this feature. To make your “Electronic Brake Control System”...

  • Page 205: Media Center 730N/430/430N

    UNDERSTANDING YOUR INSTRUMENT PANEL 203 Keyless Enter-N-Go (Passive Entry) MEDIA CENTER 730N/430/430N (RHR/RER/RBZ/ This feature allows you to lock and unlock the vehicle’s RHB) CD/DVD/HDD/NAV — IF EQUIPPED door(s) without having to press the RKE transmitter lock NOTE: The sales code is located on the lower right side or unlock buttons.

  • Page 206: Media Center 130 (Sales Code Res)

    204 UNDERSTANDING YOUR INSTRUMENT PANEL MEDIA CENTER 130 (SALES CODE RES) Operating Instructions — Radio Mode NOTE: The radio sales code is located on the lower right NOTE: The ignition switch must be in the ON or ACC side of the radio faceplate. position to operate the radio.
  • Page 207 UNDERSTANDING YOUR INSTRUMENT PANEL 205 SEEK Buttons 4. Adjust the minutes using the right side TUNE/ Press and release the SEEK buttons to search for the next SCROLL control knob. Press the TUNE/SCROLL control listenable station in AM/FM mode. Press the right switch knob to save time change.
  • Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob a second AM/FM Button time and MID will display. Turn the TUNE/SCROLL Press the buttons to select either AM or FM mode. control knob to the right or left to increase or decrease the SET/RND Button —...

  • Page 209: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    UNDERSTANDING YOUR INSTRUMENT PANEL 207 • This radio is capable of playing compact discs (CD), and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by recordable compact discs (CD-R), rewritable compact pressing the pushbutton twice.
  • Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL If you have ejected a disc and have not removed it within CAUTION! 10 seconds, it will be reloaded. If the CD is not removed, • This CD player will accept 4-3/4 in (12 cm) discs the radio will reinsert the CD but will not play it.

  • Page 211: Notes On Playing Mp3 Files

    UNDERSTANDING YOUR INSTRUMENT PANEL 209 RW/FF Notes on Playing MP3 Files Press and hold the FF (Fast Forward) button and the CD The radio can play MP3 files; however, acceptable MP3 player will begin to fast forward until FF is released, or file recording media and formats are limited.
  • Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL • Maximum number of files: 255 Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of • Maximum number of folders. (The radio display of file multisession for CD audio or MP3 playback may result in names and folder names is limited.
  • Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 Playback of MP3 Files MPEG Sampling Fre- Bit Rate (kbps) When a medium containing MP3 data is loaded, the Specification quency (kHz) radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128,...

  • Page 214: Operation Instructions - Auxiliary Mode

    212 UNDERSTANDING YOUR INSTRUMENT PANEL Operation Instructions - Auxiliary Mode MEDIA CENTER 130 WITH SATELLITE RADIO The auxiliary (AUX) jack is an audio input jack, which (SALES CODE RES+RSC) allows the user to plug in a portable device, such as an NOTE: The radio sales code is located on the lower right MP3 player, or cassette player, and utilize the vehicle’s side of the radio faceplate.

  • Page 215: Operating Instructions - Radio Mode

    UNDERSTANDING YOUR INSTRUMENT PANEL 213 Operating Instructions — Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
  • Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL Phone Button Uconnect™ Phone — If Equipped 4. Adjust the minutes using the right side TUNE/ Press this button to operate the Uconnect™ Phone feature SCROLL control knob. Press the TUNE/SCROLL control (if equipped). Refer to “Uconnect™ Phone” in “Under- knob to save time change.
  • Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
  • Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five Program Type 16-Digit Character Display seconds will allow the program format type to be se- News News lected. Many radio stations do not currently broadcast Nostalgia Nostalga Music Type information.
  • Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 By pressing the SEEK button when the Music Type icon is AM/FM Button displayed, the radio will be tuned to the next frequency Press the button to select either AM or FM mode. station with the same selected Music Type name. The SET/RND Button —...

  • Page 220: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play

    218 UNDERSTANDING YOUR INSTRUMENT PANEL • This radio is capable of playing compact discs (CD), and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by recordable compact discs (CD-R), rewritable compact pressing the pushbutton twice.
  • Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 If you have ejected a disc and have not removed it within CAUTION! 10 seconds, it will be reloaded. If the CD is not removed, • This CD player will accept 4–3/4 in (12 cm) discs the radio will reinsert the CD but will not play it.

  • Page 222: Notes On Playing Mp3 Files

    220 UNDERSTANDING YOUR INSTRUMENT PANEL RW/FF Notes On Playing MP3 Files Press and hold FF (Fast Forward) and the CD player will The radio can play MP3 files; however, acceptable MP3 begin to fast forward until FF is released or RW or file recording media and formats are limited.
  • Page 223 UNDERSTANDING YOUR INSTRUMENT PANEL 221 • Maximum number of files: 255 Discs created with an option such as keep disc open after writing are most likely multisession discs. The use of • Maximum number of folders. (The radio display of file multisession for CD audio or MP3 playback may result in names and folder names is limited.
  • Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files MPEG Sampling Fre- Bit Rate (kbps) When a medium containing MP3 data is loaded, the Specification quency (kHz) radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128,...

  • Page 225: List Button (Cd Mode For Mp3 Play)

    UNDERSTANDING YOUR INSTRUMENT PANEL 223 LIST Button (CD Mode for MP3 Play) Press and hold the INFO button again for three seconds Pressing the LIST button will bring up a list of all folders to return to elapsed time display. on the disc.

  • Page 226: Uconnect™ Multimedia (Satellite Radio) - If Equipped

    224 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) radio system in your vehicle. Sirius will supply a wel- Press this button to change the display to time of day. The come kit that contains general information, including time of day will display for five seconds (when the how to setup your on-line listening account.
  • Page 227 UNDERSTANDING YOUR INSTRUMENT PANEL 225 using the TUNE/SCROLL control knob until Sirius ID is Reception Quality selected. Press the TUNE/SCROLL control knob and the Satellite reception may be interrupted due to one of the Sirius ID number will display. The Sirius ID number following reasons: display will time out in two minutes.
  • Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons RW/FF Press and release the SEEK buttons to search for the next Pressing the RW (Rewind) or FF (Fast Forward) buttons channel in Satellite mode. Press the right switch to seek causes the tuner to search for the next channel in the up and the left switch to seek down.
  • Page 229 UNDERSTANDING YOUR INSTRUMENT PANEL 227 By pressing the SEEK button when the Music Type Select the button (1-6) you wish to lock onto this channel function is active, the radio will be tuned to the next and press and release that button. If a button is not channel with the same selected Music Type name.

  • Page 230: Ipod /Usb/Mp3 Control - If Equipped

    228 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions - Uconnect™ Phone iPod control supports Mini, 4G, Photo, Nano, 5G iPod (If Equipped) and iPhone devices. Some iPod software versions may Refer to “Uconnect™ Phone” in “Understanding The not fully support the iPod control features. Please visit Features If Your Vehicle”.

  • Page 231: Using This Feature

    UNDERSTANDING YOUR INSTRUMENT PANEL 229 NOTE: If the audio device battery is completely dis- charged, it may not communicate with the iPod /USB/ MP3 control system until a minimum charge is attained. Leaving the audio device connected to the iPod /USB/ MP3 control system may charge it to the required level.

  • Page 232: Controlling The Ipod Or External Usb Device Using Radio Buttons

    230 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it counterclockwise (backward) by one Controlling The iPod Or External USB Device Using Radio Buttons click, will jump to the previous track in the list or To get into the iPod /USB/MP3 control mode and access press the VR button and say Previous Track a connected audio device, either press the “AUX”...

  • Page 233: List Or Browse Mode

    UNDERSTANDING YOUR INSTRUMENT PANEL 231 • While a track is playing, press the INFO button to see • RND button (available on sales code RES radio only): the associated metadata (artist, track title, album, etc.) Pressing this button toggles between Shuffle ON and for that track.
  • Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL • Preset 6 – Podcasts press the TUNE control knob to select and start playing the track. Turning the TUNE control knob • Pressing a PRESET button will display the current fast will scroll through the list faster. During fast list on the top line and the first item in that list on scroll, a slight delay in updating the information on the second line.

  • Page 235: Bluetooth Streaming Audio (Btsa)

    UNDERSTANDING YOUR INSTRUMENT PANEL 233 Bluetooth Streaming Audio (BTSA) CAUTION! Music can be streamed from your cellular phone to the • Leaving the iPod or external USB device (or any Uconnect™ phone system. supported device) anywhere in the vehicle in Controlling BTSA Using Radio Buttons extreme heat or cold can alter the operation or To get into the BTSA mode, press either “AUX”...

  • Page 236: Kicker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped

    234 UNDERSTANDING YOUR INSTRUMENT PANEL 2. After the Ready prompt and the following beep, say KICKER HIGH PERFORMANCE SOUND SYSTEM Setup , then Select Audio Devices . WITH DRIVER-SELECTABLE SURROUND (DSS) – IF EQUIPPED 3. Say the name of the audio device or ask the Uconnect™...
  • Page 237 UNDERSTANDING YOUR INSTRUMENT PANEL 235 Your vehicle is equipped with a state of the art audio DSS modes for audio sources are “Stereo” and “Audio amplifier that provides 5.1-channel simulated surround Surround,” which is surround sound equalized for the sound from any stereo audio source. A new feature of the front seat occupants.

  • Page 238: Steering Wheel Audio Controls - If Equipped

    236 UNDERSTANDING YOUR INSTRUMENT PANEL STEERING WHEEL AUDIO CONTROLS — The right-hand control is a rocker-type switch with a IF EQUIPPED pushbutton in the center and controls the volume and The remote sound system controls are located on the rear mode of the sound system.

  • Page 239: Cd Player

    UNDERSTANDING YOUR INSTRUMENT PANEL 237 The button located in the center of the left-hand control CD/DVD DISC MAINTENANCE will tune to the next preset station that you have pro- To keep a CD/DVD in good condition, take the following grammed in the radio preset pushbutton. precautions: CD Player 1.

  • Page 240: Radio Operation And Mobile Phones

    238 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: If you experience difficulty in playing a particu- CLIMATE CONTROLS lar disc, it may be damaged (i.e., scratched, reflective Automatic Temperature Control (ATC) coating removed, a hair, moisture or dew on the disc) The Automatic Temperature Control system automati- oversized, or have protection encoding.

  • Page 241: Automatic Operation

    UNDERSTANDING YOUR INSTRUMENT PANEL 239 Automatic Operation You will experience the greatest efficiency by simply Operation of the system is quite simple. allowing the system to function automatically. Selecting the “O” (OFF) position on the blower control stops the 1. Turn the Mode Control knob (on the right) and the system completely and closes the outside air intake.

  • Page 242: Blower Control

    240 UNDERSTANDING YOUR INSTRUMENT PANEL • If your air conditioning performance seems lower than Manual Operation expected, check the front of the A/C condenser located This system offers a full complement of manual override in front of the radiator for an accumulation of dirt or features, which consist of Blower Preferred Automatic, insects.
  • Page 243 UNDERSTANDING YOUR INSTRUMENT PANEL 241...
  • Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL • Floor The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control Air is directed through the floor outlets with a knob (on the right) to one of the following positions. small amount flowing through the defrost and side window demist outlets.
  • Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 243 • Air Conditioner Control NOTE: • When the ignition switch is turned to the LOCK Press this button to turn on the air conditioning during manual operation position, the recirculation feature will be cancelled. only. When the air conditioning is •...

  • Page 246: Operating Tips

    244 UNDERSTANDING YOUR INSTRUMENT PANEL • Most of the time, when in Automatic Operation, you Summer Operation can temporarily put the system into Recirculation The engine cooling system in air-conditioned vehicles Mode by pressing the Recirculation button. However, must be protected with a high-quality antifreeze coolant under certain conditions, while in Automatic Mode, to provide proper corrosion protection and to protect the system is blowing air out the defrost vents.
  • Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
  • Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL Control Setting Suggestions for Various Weather Conditions...

  • Page 249: Starting And Operating

    STARTING AND OPERATING CONTENTS Starting Procedures ....252 Engine Block Heater — If Equipped ..259 Manual Transmission –...
  • Page 250 248 STARTING AND OPERATING AutoStick ......271 Brake System ......281 Operation .
  • Page 251 STARTING AND OPERATING 249 Tire Safety Information ....291 Tire Spinning ..... . . 306 Tire Markings .
  • Page 252 250 STARTING AND OPERATING Fuel Requirements ..... 321 Ethanol Fuel (E-85) ....327 3.6L And 5.7L Engine (With Automatic Fuel Requirements .
  • Page 253 STARTING AND OPERATING 251 Gross Vehicle Weight Rating (GVWR) ..333 Trailer And Tongue Weight ... . . 338 Gross Axle Weight Rating (GAWR) ..333 Towing Requirements .

  • Page 254: Starting Procedures

    252 STARTING AND OPERATING STARTING PROCEDURES Manual Transmission – If Equipped Before starting your vehicle, adjust your seat, adjust the Apply the parking brake, place the shift lever in NEU- inside and outside mirrors, fasten your seat belt, and if TRAL and press the clutch pedal before starting vehicle.

  • Page 255: Automatic Transmission - If Equipped

    STARTING AND OPERATING 253 WARNING! CAUTION! Do not attempt to push or tow your vehicle to get it Damage to the transmission may occur if the follow- started. Unburned fuel could enter the catalytic con- ing precautions are not observed: •...

  • Page 256: Keyless Enter-N-Go - If Equipped

    254 STARTING AND OPERATING Do not press the accelerator. Use the Fob with Integrated Installing And Removing The ENGINE Key to briefly turn the ignition switch to the START START/STOP Button position and release it as soon as the starter engages. The Installing The Button starter motor will continue to run, and it will disengage automatically when the engine is running.

  • Page 257: Normal Starting

    STARTING AND OPERATING 255 NOTE: The ENGINE START/STOP button should only Using The ENGINE START/STOP Button – be removed or inserted with the ignition in the OFF Manual Transmission Only position. NOTE: Normal starting of either a cold or a warm Normal Starting engine is obtained without pumping or pressing the accelerator pedal.
  • Page 258 256 STARTING AND OPERATING 2. The ignition switch will return to the OFF position. To Turn Off The Engine Using ENGINE START/STOP Button – Manual Transmission Only 3. If the shift lever is not in PARK, the ENGINE START/ STOP button must be held for two seconds and vehicle 1.

  • Page 259: Extreme Cold Weather (Below -20°F Or 29°C)

    STARTING AND OPERATING 257 • If the vehicle speed is above 5 mph (8 km/h), the • Press the ENGINE START/STOP button a second time ENGINE START/STOP button must be held for two to change the ignition switch to the ON/RUN position seconds before the engine will shut off.

  • Page 260: If Engine Fails To Start

    258 STARTING AND OPERATING If Engine Fails To Start Clearing A Flooded Engine (Using ENGINE START/STOP Button) – Automatic Transmission WARNING! Only If the engine fails to start after you have followed the • Never pour fuel or other flammable liquids into “Normal Starting”...

  • Page 261: After Starting

    STARTING AND OPERATING 259 the way to the floor and hold it, then press and hold the CAUTION! ENGINE START/STOP button for no more than 15 sec- onds. Release the accelerator pedal and the clutch pedal, To prevent damage to the starter, wait 10 to 15 sec- wait 10 to 15 seconds, then repeat the “Normal Starting”...

  • Page 262: Manual Transmission - If Equipped

    260 STARTING AND OPERATING The engine block heater must be plugged in at least one CAUTION! hour to have an adequate warming effect on the engine. • Never drive with your foot resting on the clutch WARNING! pedal, or try to hold the vehicle on a hill with the clutch pedal partially engaged, as this will cause Remember to disconnect the engine block heater abnormal wear on the clutch.
  • Page 263 STARTING AND OPERATING 261 NOTE: During cold weather, you may experience in- Shifting creased effort in shifting until the transmission fluid Fully press the clutch pedal and lift your foot off the warms up. This is normal. accelerator pedal before shifting gears. As you release the clutch pedal, lightly press the accelerator pedal.
  • Page 264 262 STARTING AND OPERATING MANUAL TRANSMISSION CAUTION! RECOMMENDED SHIFT SPEEDS Always make sure the vehicle comes to a complete Axle stop before shifting into REVERSE. Failure to do so Ratio may result in transmission damage. 3.73 You must always use first gear (or Reverse) when starting (km/h) (32) (40)
  • Page 265 STARTING AND OPERATING 263 NOTE: 1–4 Skip Shift • Your vehicle is equipped with a transmission reverse There are times when you must shift the transmission inhibitor system. When vehicle speed is greater than directly from first gear to fourth gear instead of from first 3 mph (5 km/h), the reverse inhibitor activates to help gear to second gear.

  • Page 266: Automatic Transmission - If Equipped

    264 STARTING AND OPERATING Downshifting AUTOMATIC TRANSMISSION — IF EQUIPPED To maintain a safe speed and prolong brake life, down- CAUTION! shift to maintain a safe speed when descending a steep grade. Damage to the automatic transmission may occur if the following precautions are not observed: WARNING! •...

  • Page 267: General Information

    STARTING AND OPERATING 265 • Shift lever position WARNING! • Accelerator position It is dangerous to move the shift lever out of PARK or • Vehicle speed NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, The gear shifting process is continuously adapted, de- the vehicle could accelerate quickly forward or in pendent on the driving style, the driving situation, and...
  • Page 268 266 STARTING AND OPERATING • The electronically-controlled transmission provides a WARNING! precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new Unintended movement of a vehicle could injure vehicle may be somewhat abrupt or soft until after the those in and near the vehicle.

  • Page 269: Key Ignition Park Interlock

    STARTING AND OPERATING 267 Over-Temperature Mode key fob can only be removed from the ignition when the The transmission electronics constantly monitor the ignition is in the LOCK position. Once the key fob is transmission oil temperature. If the transmission exceeds removed, the shift lever is locked in PARK.

  • Page 270: Five-Speed Automatic Transmission

    268 STARTING AND OPERATING Five-Speed Automatic Transmission Gear Ranges Shifting from DRIVE to PARK or REVERSE should be PARK done only after the accelerator pedal is released and the This range supplements the parking brake by locking the vehicle is stopped. Be sure to keep your foot on the brake transmission.
  • Page 271 STARTING AND OPERATING 269 WARNING! CAUTION! Never use the PARK position as a substitute for the Damage to the shifter could result if the shift lever is parking brake. Always apply the parking brake fully moved out of PARK before the ignition is turned when parked to guard against vehicle movement and from the LOCK (OFF position with Keyless Enter-N- possible injury or damage.
  • Page 272 270 STARTING AND OPERATING The transmission automatically upshifts through fifth CAUTION! gear. The DRIVE position provides optimum driving characteristics under all normal operating conditions. Coasting the vehicle or driving for any other reason with the shift lever in NEUTRAL can result in When frequent transmission shifting occurs when using transmission damage.

  • Page 273: Autostick

    STARTING AND OPERATING 271 damage, the transmission will engage Limp Home Mode. 5. Restart the engine. If vehicle acceleration worsens or the transmission no 6. Move the shift lever into the desired range. If the longer shifts, the transmission is most likely operating in problem is no longer detected, the transmission will the Limp Home Mode.

  • Page 274: Operation

    272 STARTING AND OPERATING braking, eliminate undesirable upshifts and downshifts, The transmission will automatically downshift as the and improve overall vehicle performance. This system vehicle slows to a stop (to prevent engine lugging) and can also provide you with more control during passing, will display the current gear.

  • Page 275: Driving On Slippery Surfaces

    STARTING AND OPERATING 273 • You can start out in first or second gear. The system DRIVING ON SLIPPERY SURFACES will ignore attempts to upshift at too low of a vehicle Acceleration speed. Rapid acceleration on snow covered, wet, or other slip- •...

  • Page 276: Traction

    274 STARTING AND OPERATING Traction 3. Replace tires when tread wear indicators first become When driving on wet or slushy roads, it is possible for a visible. wedge of water to build up between the tire and road 4. Keep tires properly inflated. surface.

  • Page 277: Flowing/Rising Water

    STARTING AND OPERATING 275 Flowing/Rising Water Shallow Standing Water Although your vehicle is capable of driving through WARNING! shallow standing water, consider the following Caution and Warning before doing so. Do not drive on, or cross, a road or a path where water is flowing and/or rising (as in storm run-off).
  • Page 278 276 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause dam- • Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.

  • Page 279: Power Steering

    STARTING AND OPERATING 277 POWER STEERING If the “SERVICE POWER STEERING SYSTEM” Your vehicle is equipped with an electro-hydraulic power message and a flashing icon are displayed on steering system that will give you good vehicle response the EVIC screen, it indicates that the vehicle and increased ease of maneuverability in tight spaces.

  • Page 280: Parking Brake

    278 STARTING AND OPERATING NOTE: NOTE: • Even if power steering assistance is no longer opera- • When the parking brake is applied and the transmis- tional, it is still possible to steer the vehicle. Under sion is placed in gear, the “Brake Warning Light” will these conditions there will be a substantial increase in flash.

  • Page 281: Manual Transmission - If Equipped

    STARTING AND OPERATING 279 Manual Transmission – If Equipped Automatic Transmission – If Equipped The foot operated parking brake is positioned below the The foot operated parking brake is located below the lower left corner of the instrument panel. To release the lower left corner of the instrument panel.
  • Page 282 280 STARTING AND OPERATING WARNING! WARNING! (Continued) • Always fully apply the parking brake when leav- • Never use the PARK position as a substitute for ing your vehicle, or it may roll and cause damage the parking brake. Always apply the parking or injury.

  • Page 283: Brake System

    STARTING AND OPERATING 281 BRAKE SYSTEM Anti-Lock Brake System (ABS) — If Equipped Your vehicle is equipped with dual hydraulic The Anti-Lock Brake System (ABS) provides increased brake systems. If either of the two hydraulic vehicle stability and brake performance under most systems loses normal capability, the remaining braking conditions.
  • Page 284 282 STARTING AND OPERATING ABS is activated during braking under certain road or WARNING! stopping conditions. ABS-inducing conditions can in- • The Anti-Lock Brake System (ABS) contains so- clude ice, snow, gravel, bumps, railroad tracks, loose debris, or panic stops. phisticated electronic equipment that may be sus- ceptible to interference caused by improperly in- You also may experience the following when the brake...
  • Page 285 STARTING AND OPERATING 283 Anti-Lock Brake Warning Light WARNING! (Continued) The “Anti-Lock Brake System (ABS) Warning • The Anti-Lock Brake System (ABS) cannot prevent Light” monitors the Anti-Lock Brake System. The the natural laws of physics from acting on the light will come on when the ignition switch is turned to vehicle, nor can it increase braking or steering the ON position and may stay on for as long as four...

  • Page 286: Electronic Brake Control System

    284 STARTING AND OPERATING If both the “Brake Warning Light” and the “ABS Warning Anti-Lock Brake System (ABS) Light” remain on, the ABS and EBD systems are not This system aids the driver in maintaining vehicle control functioning. Immediate repair to the ABS system is under adverse braking conditions by controlling hydrau- required.

  • Page 287: Traction Control System (Tcs)

    STARTING AND OPERATING 285 Traction Control System (TCS) Brake Assist System (BAS) This system monitors the amount of wheel spin of each This system complements the ABS by optimizing the driven wheel. If wheel spin is detected, brake pressure is vehicle braking capability during emergency braking applied to the slipping wheel(s) and engine power is maneuvers.

  • Page 288: Hill Start Assist (Hsa) - Manual Transmission Only

    286 STARTING AND OPERATING brake pedal. If the driver does not apply the throttle WARNING! during this short period of time, the system will release brake pressure and the vehicle will roll down the hill. The The BAS cannot prevent the natural laws of physics system will release brake pressure in proportion to from acting on the vehicle, nor can it increase the amount of throttle applied as the vehicle starts to move in...

  • Page 289: Electronic Stability Program (Esp)

    STARTING AND OPERATING 287 Electronic Stability Program (ESP) WARNING! This system enhances directional control and stability of the vehicle under various driving conditions. The ESP There may be situations on minor hills (i.e., less than corrects for oversteering and understeering the vehicle 8%), with a loaded vehicle, or while pulling a trailer, by applying the brake of the appropriate wheel.
  • Page 290 288 STARTING AND OPERATING The “ESP/TCS Indicator Light” located in the WARNING! instrument cluster, starts to flash as soon as the tires lose traction and the ESP system becomes The ESP cannot prevent the natural laws of physics active. The “ESP/TCS Indicator Light” also from acting on the vehicle, nor can it increase the flashes when TCS is active.
  • Page 291 STARTING AND OPERATING 289 Partial Off The “Partial Off” mode is intended for times when a more spirited driving experience is desired. It is also intended for driving in deep snow, sand, or gravel. This mode disables the TCS portion of the ESP and raises the threshold for ESP activation, which allows for more wheel spin than what ESP normally allows.

  • Page 292: Esp/Bas Malfunction Indicator Light And Esp/Tcs Indicator Light

    290 STARTING AND OPERATING mode is overcome, turn the ESP ON again by momen- and you have driven the vehicle several miles (kilome- tarily pressing the “ESP OFF” switch. This may be done ters) at speeds greater than 30 mph (48 km/h), and the while the vehicle is in motion.

  • Page 293: Tire Safety Information

    STARTING AND OPERATING 291 TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
  • Page 294 292 STARTING AND OPERATING Tire Sizing Chart TIRE SIZING TERMS Size Designation: P = Passenger Car tire size based on U.S. design standards ..blank..= Passenger Car tire based on European design standards LT = Light Truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm)
  • Page 295 STARTING AND OPERATING 293 TIRE SIZING TERMS Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
  • Page 296 294 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.

  • Page 297: Tire Terminology And Definitions

    STARTING AND OPERATING 295 Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof. Cold Tire Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.

  • Page 298: Tire Loading And Tire Pressure

    296 STARTING AND OPERATING Tire Loading And Tire Pressure This placard tells you important information about the: Tire Placard Location 1) number of people that can be carried in the vehicle NOTE: The proper cold tire inflation pressure is listed 2) total weight your vehicle can carry on the driver’s side B-Pillar.
  • Page 299 STARTING AND OPERATING 297 NOTE: Under a maximum loaded vehicle condition, Steps For Determining Correct Load Limit gross axle weight ratings (GAWRs) for the front and rear 1. Locate the statement “The combined weight of occu- axles must not be exceeded. For further information on pants and cargo should never exceed XXX kg or XXX lbs”...
  • Page 300 298 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: • The following table shows examples on how to calcu- cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five late total load, cargo/luggage, and towing capacities 150 lb (68 kg) passengers in your vehicle, the amount of of your vehicle with varying seating configurations...
  • Page 301 STARTING AND OPERATING 299...

  • Page 302: Tires - General Information

    300 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.

  • Page 303: Tire Inflation Pressures

    STARTING AND OPERATING 301 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to Some vehicles may have supplemental tire pressure the right or left.
  • Page 304 302 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the winter.

  • Page 305: Radial Ply Tires

    STARTING AND OPERATING 303 Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...

  • Page 306: Compact Spare Tire - If Equipped

    304 STARTING AND OPERATING vehicle has an option for a spare tire matching original CAUTION! equipment tire and wheel, refer to the recommended tire rotation pattern in “Tire Rotation Recommendations” in Because of the reduced ground clearance, do not take “Starting and Operating”...

  • Page 307: Full Size Spare - If Equipped

    STARTING AND OPERATING 305 Since this tire has limited tread life the original equip- Full Size Spare – If Equipped ment tire should be repaired (or replaced) and reinstalled The full size spare is for temporary emergency use only. on your vehicle at the first opportunity. This tire may look like the original equipped tire on the front or rear axle of your vehicle, but it is not.

  • Page 308: Tire Spinning

    306 STARTING AND OPERATING your original equipment tire, replace (or repair) the Tire Spinning original equipment tire and reinstall on the vehicle at the When stuck in mud, sand, snow, or ice conditions, do not first opportunity. spin your vehicle’s wheels above 30 mph (48 km/h). Refer to “Freeing A Stuck Vehicle”...

  • Page 309: Life Of Tire

    STARTING AND OPERATING 307 Life Of Tire The service life of a tire is dependent upon varying factors including, but not limited to: • Driving style • Tire pressure • Distance driven WARNING! Tires and the spare tire should be replaced after six years, regardless of the remaining tread.

  • Page 310: Replacement Tires

    308 STARTING AND OPERATING Replacement Tires WARNING! The tires on your new vehicle provide a balance of many • Do not use a tire, wheel size or rating other than characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- that specified for your vehicle.

  • Page 311: Tire Chains

    STARTING AND OPERATING 309 WARNING! (Continued) CAUTION! • Failure to equip your vehicle with tires having To avoid damage to your vehicle or tires, observe the following precautions: adequate speed capability can result in sudden tire • Because of restricted chain clearance between tires failure and loss of vehicle control.

  • Page 312: Snow Tires

    310 STARTING AND OPERATING SNOW TIRES CAUTION! (Continued) Some areas of the country require the use of snow tires • Do not drive for prolonged period on dry pave- during the winter. All season tires can be identified by the ment.

  • Page 313: Tire Rotation Recommendations

    STARTING AND OPERATING 311 poorer than that of non-studded tires. Some states pro- The suggested rotation method is the “forward-cross” hibit studded tires; therefore, local laws should be shown in the following diagram. checked before using these tire types. TIRE ROTATION RECOMMENDATIONS Tires on the front and rear axles of vehicles operate at different loads and perform different steering, handling, and braking functions.

  • Page 314: Tire Pressure Monitor System (Tpms)

    312 STARTING AND OPERATING TIRE PRESSURE MONITOR SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if The Tire Pressure Monitor System (TPMS) will warn the the tire pressure falls below the low-pressure warning driver of a low tire pressure based on the vehicle recom- limit for any reason, including low temperature effects mended cold placard pressure.
  • Page 315 STARTING AND OPERATING 313 For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) placard pressure • The TPMS has been optimized for the original of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), equipment tires and wheels.

  • Page 316: Base System

    314 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, NOTE: • The TPMS is not intended to replace normal tire care and the TPMS will monitor the actual tire pressure in and maintenance or to provide warning of a tire failure the tire.
  • Page 317 STARTING AND OPERATING 315 Tire Pressure Monitoring Low Pressure Warnings system fault still exists. The “TPM Telltale Light” will The “TPM Telltale Light” will illuminate in the turn off when the fault condition no longer exists. A instrument cluster, a “LOW TIRE” message will be system fault can occur due to any of the following: displayed and a chime will sound when tire pres- 1.

  • Page 318: Premium System - If Equipped

    316 STARTING AND OPERATING 2. If you install the compact spare tire in place of a road Telltale Light” and “LOW TIRE” message will turn OFF, tire that has a pressure below the low-pressure warning as long as no tire pressure is below the low-pressure limit, upon the next ignition switch cycle, a chime will warning limit in any of the four active road tires.
  • Page 319 STARTING AND OPERATING 317 The TPMS consists of the following components: • Receiver module, • Four TPM sensors, • Various TPMS messages, which display in the Elec- tronic Vehicle Information Center (EVIC), and • TPM Telltale Light Tire Pressure Monitoring Low Pressure Warnings The “TPM Telltale Light”...
  • Page 320 318 STARTING AND OPERATING will turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information. Service TPMS Warning If a system fault is detected, the “TPM Telltale Light” will flash on and off for 75 seconds and then remain on solid.
  • Page 321 STARTING AND OPERATING 319 If the ignition switch is cycled, this sequence will repeat, The EVIC will also display a SERVICE TPM SYSTEM providing the system fault still exists. If the system fault message for a minimum of five seconds when a system no longer exists, the “TPM Telltale Light”...

  • Page 322: General Information

    320 STARTING AND OPERATING 2. If you install the compact spare tire in place of a road 5. Once you repair or replace the original road tire and tire that has a pressure below the low-pressure warning reinstall it on the vehicle in place of the compact spare, limit, upon the next ignition switch cycle, the “TPM the TPMS will update automatically.

  • Page 323: Fuel Requirements

    STARTING AND OPERATING 321 The TPM sensors are regulated under one of the follow- Light spark knock at low engine speeds is not harmful to ing licenses: your engine. However, continued heavy spark knock at high speeds can cause damage and immediate service is required.

  • Page 324: L Engine (With Manual Transmission)

    322 STARTING AND OPERATING 5.7L Engine (with Manual Transmission) Gasoline/Oxygenate Blends The 5.7L engine (with manual transmis- Some fuel suppliers blend unleaded gasoline with oxy- sion) is designed to meet all emissions genates such as 10% ethanol, MTBE, and ETBE. Oxygen- regulations and provide excellent fuel ates are required in some areas of the country during the economy and performance when using...

  • Page 325: E-85 Usage In Non-Flex Fuel Vehicles

    STARTING AND OPERATING 323 • disconnect and reconnect the battery to reset the E-85 Usage In Non-Flex Fuel Vehicles Non-FFV vehicles are compatible with gasoline contain- engine controller memory ing 10% ethanol (E10). Gasoline with higher ethanol More extensive repairs will be required for prolonged content may void the vehicle’s warranty.

  • Page 326: Materials Added To Fuel

    324 STARTING AND OPERATING can be used at levels higher than those allowed in the Fuel System Cautions United States. MMT is prohibited in Federal and Califor- CAUTION! nia reformulated gasoline. Materials Added to Fuel Follow these guidelines to maintain your vehicle’s All gasoline sold in the United States is required to performance: contain effective detergent additives.

  • Page 327: Carbon Monoxide Warnings

    STARTING AND OPERATING 325 Carbon Monoxide Warnings CAUTION! (Continued) • The use of fuel additives, which are now being WARNING! sold as octane enhancers, is not recommended. Carbon monoxide (CO) in exhaust gases is deadly. Most of these products contain high concentra- Follow the precautions below to prevent carbon tions of methanol.

  • Page 328: Flexible Fuel (3.6L Engine Only) - If Equipped

    326 STARTING AND OPERATING the other sections of this manual for information on WARNING! (Continued) features that are common between Flexible Fuel and • Guard against carbon monoxide with proper gasoline-only powered vehicles. maintenance. Have the exhaust system inspected every time the vehicle is raised. Have any abnor- mal conditions repaired promptly.

  • Page 329: Ethanol Fuel (E-85)

    STARTING AND OPERATING 327 Ethanol Fuel (E-85) CAUTION! E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. Only vehicles with the E-85 fuel filler door label can operate on E-85. WARNING! Ethanol vapors are extremely flammable and could cause serious personal injury.

  • Page 330: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles

    328 STARTING AND OPERATING • Some additives used in regular gasoline are not fully For best results, a refueling pattern that avoids alternat- ing between E-85 and unleaded gasoline is recom- compatible with E-85 and may form deposits in your engine.

  • Page 331: Starting

    STARTING AND OPERATING 329 Starting Replacement Parts The characteristics of E-85 fuel make it unsuitable for use Many components in your Flexible Fuel Vehicle (FFV) are when ambient temperatures fall below 0°F (-18°C). In the designed to be compatible with ethanol. Always be sure range of 0°F (-18°C) to 32°F (0°C), you may experience an that your vehicle is serviced with correct ethanol com- increase in the time it takes for your engine to start, and...

  • Page 332: Adding Fuel

    330 STARTING AND OPERATING ADDING FUEL Fuel Filler Cap (Gas Cap) The gas cap is located behind the fuel filler door on the left side of the vehicle. Use a finger to pull open the door. If the gas cap is lost or damaged, be sure the replacement cap is for use with this vehicle.
  • Page 333 STARTING AND OPERATING 331 CAUTION! WARNING! • Damage to the fuel system or emissions control • Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the tank filler tube cap (gas cap).

  • Page 334: Loose Fuel Filler Cap Message

    332 STARTING AND OPERATING • When the fuel nozzle “clicks” or shuts off, the fuel VEHICLE LOADING tank is full. The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information Loose Fuel Filler Cap Message should be used for passenger and luggage loading as If the vehicle diagnostic system determines that the fuel indicated.

  • Page 335: Gross Vehicle Weight Rating (Gvwr)

    STARTING AND OPERATING 333 • Gross Axle Weight Rating (GAWR) rear WARNING! • Vehicle Identification Number (VIN) Because the front wheels steer the vehicle, it is • Type of Vehicle important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can •...

  • Page 336: Loading

    334 STARTING AND OPERATING Figure out the weight on the front and rear of the vehicle NOTE: Refer to the “Vehicle Certification Label” affixed separately. It is important that you distribute the load to the rear of the driver’s door for your vehicle’s GVWR evenly over the front and rear axles.

  • Page 337: Common Towing Definitions

    STARTING AND OPERATING 335 Common Towing Definitions Gross Combination Weight Rating (GCWR) The following trailer towing related definitions will assist The GCWR is the total permissible weight of your vehicle you in understanding the following information: and trailer when weighed in combination. Gross Vehicle Weight Rating (GVWR) NOTE: The GCWR rating includes a 150 lbs (68 kg) The GVWR is the total allowable weight of your vehicle.
  • Page 338 336 STARTING AND OPERATING Tongue Weight (TW) of hitches are the most popular on the market today and The TW is the downward force exerted on the hitch ball they are commonly used to tow small- and medium- by the trailer. In most cases, it should not be less than 10% sized trailers.

  • Page 339: Trailer Hitch Classification

    STARTING AND OPERATING 337 Trailer Hitch Classification Definitions WARNING! Class Max. Trailer Hitch Industry • An improperly adjusted weight distributing hitch Standards system may reduce handling, stability, braking Class I - Light Duty 2,000 lbs (907 kg) performance, and could result in a collision. Class II - Medium 3,500 lbs (1587 kg) •...

  • Page 340: Trailer Towing Weights (Maximum Trailer Weight Ratings)

    338 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area Max. GTW (Gross Trailer Wt.) Max. Tongue Wt. 3.6L Automatic 12 sq ft (1.11 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg) 5.7L Automatic...

  • Page 341: Towing Requirements

    STARTING AND OPERATING 339 Consider the following items when computing the Towing Requirements weight on the rear axle of the vehicle: To promote proper break-in of your new vehicle drive- train components the following guidelines are recom- • The tongue weight of the trailer. mended: •...
  • Page 342 340 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the frame or hook retainers of the vehicle hitch.
  • Page 343 STARTING AND OPERATING 341 − Check for signs of tire wear or visible tire damage WARNING! (Continued) before towing a trailer. Refer to “Tires – General 2. GTW Information” in “Starting and Operating” for the 3. GAWR proper inspection procedure. 4.
  • Page 344 342 STARTING AND OPERATING − An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.
  • Page 345 STARTING AND OPERATING 343 Towing Requirements – Trailer Lights And Wiring Whenever you pull a trailer, regardless of the trailer size, stoplights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package may include a four- and seven- pin wiring harness.

  • Page 346: Towing Tips

    344 STARTING AND OPERATING Towing Tips Before setting out on a trip, practice turning, stopping, and backing up the trailer in an area located away from heavy traffic. Automatic Transmission The DRIVE range can be selected when towing. How- ever, if frequent shifting occurs while in this range, use the AutoStick mode to select a lower gear range.
  • Page 347 STARTING AND OPERATING 345 specified for “police, taxi, fleet, or frequent trailer tow- adequate performance. For example, choose “4” if the ing.” Refer to “Maintenance Schedule” for the proper desired speed can be maintained. Choose “3” or “2” if maintenance intervals. needed to maintain the desired speed.

  • Page 348: Recreational Towing (Behind Motorhome, Etc.)

    346 STARTING AND OPERATING − Air Conditioning Towing This Vehicle Behind Another Vehicle — Turn off temporarily. Manual Transmission Flat towing of vehicles equipped with a manual trans- RECREATIONAL TOWING mission is permitted within the following limitations: (BEHIND MOTORHOME, ETC.) Your vehicle may be towed under the following condi- Towing This Vehicle Behind Another Vehicle —...

  • Page 349: What To Do In Emergencies

    WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....349 Jacking And Tire Changing ....360 If Your Engine Overheats .
  • Page 350 348 WHAT TO DO IN EMERGENCIES Freeing A Stuck Vehicle ....374 Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Shift Lever Override .

  • Page 351: Hazard Warning Flashers

    WHAT TO DO IN EMERGENCIES 349 HAZARD WARNING FLASHERS NOTE: With extended use the Hazard Warning flashers The Hazard Warning flasher switch is located in the may wear down your battery. switch bank near the bottom center of the instrument IF YOUR ENGINE OVERHEATS panel.

  • Page 352: Tirefit Kit - If Equipped

    350 WHAT TO DO IN EMERGENCIES • You can also turn the temperature control to maximum WARNING! heat, the mode control to floor and the blower control to high. This allows the heater core to act as a You or others can be badly burned by hot engine supplement to the radiator and aids in removing heat coolant (antifreeze) or steam from your radiator.

  • Page 353: Tirefit Storage

    WHAT TO DO IN EMERGENCIES 351 TIREFIT Storage TIREFIT Kit Components And Operation The TIREFIT kit is located in the trunk. 1. Sealant Bottle TIREFIT Location 2. Deflation Button 3. Pressure Gauge 4. Power Button...
  • Page 354 352 WHAT TO DO IN EMERGENCIES 5. Mode Select Knob Selecting Sealant Mode Turn the Mode Select Knob (5) to this 6. Sealant Hose (Clear) position to inject the TIREFIT Sealant 7. Air Pump Hose (Black) and to inflate the tire. Use the Sealant Hose (clear hose) (6) when selecting 8.

  • Page 355: Tirefit Usage Precautions

    WHAT TO DO IN EMERGENCIES 353 • You can use the TIREFIT air pump to inflate bicycle TIREFIT Usage Precautions tires. The kit also comes with two needles, located in • Replace the TIREFIT Sealant Bottle (1) and Sealant the Accessory Storage Compartment (on the bottom of Hose (6) prior to the expiration date (printed on the the air pump) for inflating sport balls, rafts, or similar bottle label) to assure optimum operation of the sys-...
  • Page 356 354 WHAT TO DO IN EMERGENCIES WARNING! (Continued) WARNING! (Continued) • Do not use TIREFIT or drive the vehicle under the • A loose TIREFIT kit thrown forward in a collision following circumstances: or hard stop could endanger the occupants of the vehicle.

  • Page 357: Sealing A Tire With Tirefit

    WHAT TO DO IN EMERGENCIES 355 This will provide the best positioning of the kit when WARNING! (Continued) injecting the sealant into the deflated tire and running the • TIREFIT Sealant solution contains latex. In case of air pump. Move the vehicle as necessary to place the an allergic reaction or rash, consult a physician valve stem in this position before proceeding.
  • Page 358 356 WHAT TO DO IN EMERGENCIES 4. Remove the cap from the valve stem and then screw NOTE: Sealant may leak out through the puncture in the fitting at the end of the Sealant Hose (6) onto the the tire. valve stem.
  • Page 359 WHAT TO DO IN EMERGENCIES 357 NOTE: If the Mode Select Knob (5) is on Air Mode and If the tire does not inflate to at least 26 psi (1.8 Bar) the pump is operating, air will dispense from the Air pressure within 15 minutes: Pump Hose (7) only, not the Sealant Hose (6).
  • Page 360 358 WHAT TO DO IN EMERGENCIES hose, and place the TIREFIT kit in the vehicle storage WARNING! location. Quickly proceed to (D) “Drive Vehicle”. TIREFIT is not a permanent flat tire repair. Have the CAUTION! tire inspected and repaired or replaced after using TIREFIT.
  • Page 361 WHAT TO DO IN EMERGENCIES 359 3. Uncoil the Air Pump Hose (7) (black in color) and 2. Disconnect the TIREFIT kit from the valve stem, screw the fitting at the end of hose (7) onto the valve reinstall the cap on the valve stem and unplug from 12 stem.

  • Page 362: Jacking And Tire Changing

    360 WHAT TO DO IN EMERGENCIES 2. Locate the round Sealant Bottle release button in the JACKING AND TIRE CHANGING recessed area under the sealant bottle. WARNING! 3. Press the Sealant Bottle release button. The Sealant • Do not attempt to change a tire on the side of the Bottle (1) will pop up.

  • Page 363: Jack Location/Spare Tire Stowage

    WHAT TO DO IN EMERGENCIES 361 2. Lift the access cover using the pull strap. WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only.
  • Page 364 362 WHAT TO DO IN EMERGENCIES 3. Remove the fastener securing the spare tire. 5. Remove the fastener securing the jack. Spare Tire Fastener Jack Fastener 4. Remove the spare tire.

  • Page 365: Preparations For Jacking

    WHAT TO DO IN EMERGENCIES 363 6. Remove the scissors jack and lug wrench from the Preparations For Jacking spare wheel as an assembly. Turn the jack screw to the left 1. Park the vehicle on a firm, level surface as far from the to loosen the lug wrench, and remove the wrench from edge of the roadway as possible.

  • Page 366: Jacking And Changing A Tire

    364 WHAT TO DO IN EMERGENCIES 6. Block the front and rear of the WARNING! (Continued) wheel diagonally opposite of the jack- • Always park on a firm, level surface as far from ing position. For example, if changing the edge of the roadway as possible before raising the right front tire, block the left rear the vehicle.
  • Page 367 WHAT TO DO IN EMERGENCIES 365 2. If equipped with aluminum wheels where the center WARNING! (Continued) cap covers the lug nuts, use the lug wrench to pry the • If working on or near a roadway, be extremely center cap off carefully before raising the vehicle. careful of motor traffic.
  • Page 368 366 WHAT TO DO IN EMERGENCIES 3. Before raising the vehicle, use the lug wrench to 4. Place the jack underneath the lift area that is closest to loosen, but not remove, the lug nuts on the wheel with the flat tire. Turn the jack screw clockwise to firmly the flat tire.
  • Page 369 WHAT TO DO IN EMERGENCIES 367 WARNING! Raising the vehicle higher than necessary can make the vehicle less stable. It could slip off the jack and hurt someone near it. Raise the vehicle only enough to remove the tire. 6. Remove the lug nuts and tire. 7.

  • Page 370: Compact Spare Tire

    368 WHAT TO DO IN EMERGENCIES 8. Install the lug nuts with the cone shaped end of the lug in doubt about the correct tightness, have them checked nut toward the wheel. Lightly tighten the lug nuts. To with a torque wrench by your authorized dealer or at a avoid the risk of forcing the vehicle off the jack, do not service station.

  • Page 371: Center Cap Installation - If Equipped

    WHAT TO DO IN EMERGENCIES 369 vehicle only. Since this tire has limited tread life, the Center Cap Installation — If Equipped original tire should be repaired (or replaced) and rein- 1. Mount the road tire on the axle. For vehicles equipped stalled at the first opportunity.

  • Page 372: Jump-Starting Procedures

    370 WHAT TO DO IN EMERGENCIES 5. Finish tightening the lug nuts. Push down on the WARNING! wrench while tightening for increased leverage. Alternate lug nuts until each nut has been tightened twice. The A loose tire or jack thrown forward in a collision or correct tightness of each lug nut is 110 ft/lb.

  • Page 373: Preparations For Jump-Start

    WHAT TO DO IN EMERGENCIES 371 CAUTION! Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. WARNING! Do not attempt jump-starting if the battery is frozen.

  • Page 374: Jump-Starting Procedure

    372 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
  • Page 375 WHAT TO DO IN EMERGENCIES 373 CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.

  • Page 376: Freeing A Stuck Vehicle

    374 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper FREEING A STUCK VEHICLE cable from the positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion.

  • Page 377: Shift Lever Override

    WHAT TO DO IN EMERGENCIES 375 NOTE: Turn off the Electronic Stability Program (ESP) WARNING! before rocking the vehicle. Refer to “Electronic Stability Program,” or “Traction Control” in “Starting And Oper- Fast spinning tires can be dangerous. Forces gener- ating” for further information. ated by excessive wheel speeds may cause damage, or even failure, of the axle and tires.

  • Page 378: With Keyless Enter-N-Go - If Equipped

    376 WHAT TO DO IN EMERGENCIES 3. Turn the ignition switch to the ON/RUN position. 6. Move the shift lever into the NEUTRAL position. 4. Press and maintain firm pressure on the brake pedal. 7. The vehicle may then be started in NEUTRAL. 5.

  • Page 379: Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) - Automatic Transmissions

    WHAT TO DO IN EMERGENCIES 377 Towing This Vehicle Behind Another Vehicle (Flat CAUTION! Towing With All Four Wheels On The Ground) — • If the transmission is not operative or if the Automatic Transmissions Flat towing of vehicles equipped with an automatic vehicle is to be towed more than 15 mi (24 km) or transmission is permitted within the following limita- faster than 30 mph (48 km/h), then the only ap-...

  • Page 380: Towing This Vehicle Behind Another Vehicle (Flat Towing With All Four Wheels On The Ground) - Manual Transmissions

    378 WHAT TO DO IN EMERGENCIES Towing This Vehicle Behind Another Vehicle (Flat CAUTION! Towing With All Four Wheels On The Ground) — • Do not attempt to tow this vehicle from the front Manual Transmissions Flat towing of vehicles equipped with a manual trans- with sling-type towing equipment.

  • Page 381: Towing This Vehicle Behind Another Vehicle With A Tow Dolly

    WHAT TO DO IN EMERGENCIES 379 CAUTION! CAUTION! • If the transmission is not operative then the only • Do not attempt to tow this vehicle from the front approved method of towing is with a flatbed with sling-type towing equipment. Damage to the truck.
  • Page 383 MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.6L ... . . 384 Maintenance Procedures ....389 Engine Compartment —...
  • Page 384 382 MAINTAINING YOUR VEHICLE Exhaust System ..... 399 Vehicle Storage ..... . . 426 Cooling System .
  • Page 385 MAINTAINING YOUR VEHICLE 383 Center High-Mounted Stop Lamp Fluids, Lubricants, And Genuine Parts ..434 (CHMSL) ......431 Engine .

  • Page 386: Engine Compartment - 3.6L

    384 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.6L 1 — Integrated Power Module (Fuses) 5 — Air Cleaner Filter 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir Access Cover 7 — Remote Jump Start (Positive Battery Post) 4 —...

  • Page 387: Engine Compartment - 5.7L

    MAINTAINING YOUR VEHICLE 385 ENGINE COMPARTMENT — 5.7L 1 — Integrated Power Module (Fuses) 5 — Engine Oil Fill 2 — Brake Fluid Reservoir Access Cover 6 — Engine Oil Dipstick 3 — Engine Coolant Reservoir 7 — Remote Jump Start (Positive Battery Post) 4 —...

  • Page 388: Onboard Diagnostic System - Obd Ii

    386 MAINTAINING YOUR VEHICLE ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.

  • Page 389: Emissions Inspection And Maintenance Programs

    MAINTAINING YOUR VEHICLE 387 Trip Odometer button to turn off the message. If the Normally, the OBD II system will be ready. The OBD II problem continues, the message will appear the next time system may not be ready if your vehicle was recently the vehicle is started.

  • Page 390: Replacement Parts

    388 MAINTAINING YOUR VEHICLE 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.

  • Page 391: Maintenance Procedures

    MAINTAINING YOUR VEHICLE 389 your vehicle. Refer to these Service Manuals before MAINTENANCE PROCEDURES attempting any procedure yourself. The pages that follow contain the required maintenance services determined by the engineers who designed your NOTE: Intentional tampering with emissions control vehicle.

  • Page 392: Engine Oil

    390 MAINTAINING YOUR VEHICLE regular intervals, such as every fuel stop. The best time to CAUTION! (Continued) check the engine oil level is about five minutes after a • Your vehicle has been built with improved fluids fully warmed engine is shut off. that protect the performance and durability of Checking the oil while the vehicle is on level ground will your vehicle and also allow extended maintenance...
  • Page 393 MAINTAINING YOUR VEHICLE 391 regular intervals, such as every fuel stop. The best time to NOTE: Under no circumstances should oil change check the engine oil level is about five minutes after a intervals exceed 8,000 miles (13 000 km) or six months, fully warmed engine is shut off.
  • Page 394 392 MAINTAINING YOUR VEHICLE Engine Oil Viscosity (SAE Grade) – 5.7L Engine CAUTION! SAE 5W-20 engine oil is recommended for all operating temperatures. This engine oil improves low temperature Do not use chemical flushes in your engine oil as the starting and vehicle fuel economy.

  • Page 395: Engine Oil Filter

    MAINTAINING YOUR VEHICLE 393 Synthetic Engine Oils Engine Oil Filter You may use synthetic engine oils provided the recom- The engine oil filter should be replaced with a new filter mended oil quality requirements are met, and the recom- at every engine oil change. mended maintenance intervals for oil and filter changes Engine Oil Filter Selection are followed.

  • Page 396: Maintenance-Free Battery

    394 MAINTAINING YOUR VEHICLE Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- The air induction system (air cleaner, hoses, etc.) can tenance required. provide a measure of protection in the case of engine backfire.
  • Page 397 MAINTAINING YOUR VEHICLE 395 WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Do not allow battery fluid to contact your eyes, skin, or clothing. Do not lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.

  • Page 398: Air Conditioner Maintenance

    396 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! (Continued) For best possible performance, your air conditioner • The battery in this vehicle has a vent hose that should be checked and serviced by an authorized dealer should not be disconnected and should only be at the start of each warm season.

  • Page 399: Body Lubrication

    MAINTAINING YOUR VEHICLE 397 Protection Agency and is an ozone-saving product. How- WARNING! ever, the manufacturer recommends that air conditioning • Use only refrigerants and compressor lubricants service be performed by authorized dealers or other service facilities using recovery and recycling equipment. approved by the manufacturer for your air condi- tioning system.

  • Page 400: Windshield Wiper Blades

    398 MAINTAINING YOUR VEHICLE hood latching components to ensure proper function. Avoid using the wiper blades to remove frost or ice from When performing other underhood services, the hood the windshield. Keep the blade rubber out of contact with latch, release mechanism and safety catch should be petroleum products such as engine oil, gasoline, etc.

  • Page 401: Exhaust System

    MAINTAINING YOUR VEHICLE 399 When refilling the washer fluid reservoir, apply some WARNING! washer fluid to a cloth or towel and wipe the wiper blades clean. This will help blade performance. Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care To prevent freeze-up of your windshield washer system must be exercised when filling or working around in cold weather, select a solution or mixture that meets or...
  • Page 402 400 MAINTAINING YOUR VEHICLE into the passenger compartment. In addition, inspect the CAUTION! exhaust system each time the vehicle is raised for lubri- • The catalytic converter requires the use of un- cation or oil change. Replace as required. leaded fuel only. Leaded gasoline will destroy the WARNING! effectiveness of the catalyst as an emissions con- trol device and may seriously reduce engine per-...
  • Page 403 MAINTAINING YOUR VEHICLE 401 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.

  • Page 404: Cooling System

    402 MAINTAINING YOUR VEHICLE Cooling System Coolant Checks Check engine coolant (antifreeze) protection every WARNING! 12 months (before the onset of freezing weather, where applicable). If coolant is dirty or rusty in appearance, the • When working near the radiator cooling fan, dis- system should be drained, flushed, and refilled with connect the fan motor lead or turn the ignition fresh coolant.
  • Page 405 MAINTAINING YOUR VEHICLE 403 drain from the coolant recovery bottle. DO NOT RE- CAUTION! MOVE THE COOLANT PRESSURE CAP WHEN THE • Mixing of engine coolant (antifreeze) other than COOLING SYSTEM IS HOT. specified HOAT engine coolant (antifreeze), may Cooling System – Drain, Flush, And Refill result in engine damage and may decrease corro- If the engine coolant (antifreeze) is dirty or contains a sion protection.
  • Page 406 404 MAINTAINING YOUR VEHICLE • Mix a minimum solution of 50% HOAT engine coolant Adding Coolant Your vehicle has been built with an improved engine and distilled water. Use higher concentrations (not to coolant (antifreeze) that allows extended maintenance exceed 70%) if temperatures below 34°F ( 37°C) are intervals.
  • Page 407 MAINTAINING YOUR VEHICLE 405 Cooling System Pressure Cap WARNING! (Continued) The cap must be fully tightened to prevent loss of engine • Do not use a pressure cap other than the one coolant (antifreeze), and to ensure that engine coolant specified for your vehicle.
  • Page 408 406 MAINTAINING YOUR VEHICLE adequate. With the engine OFF and cold, the level of the from the front of the engine compartment. This is nor- engine coolant (antifreeze) in the bottle should be be- mally a result of moisture from rain, snow, or high tween the ranges indicated on the bottle.

  • Page 409: Brake System

    MAINTAINING YOUR VEHICLE 407 does not drop when the engine cools, the cooling Brake System system should be pressure tested for leaks. In order to assure brake system performance, all brake system components should be inspected periodically. • Maintain engine coolant (antifreeze) concentration at Refer to the “Maintenance Schedule”...
  • Page 410 408 MAINTAINING YOUR VEHICLE Master Cylinder – Brake Fluid Level Check Use only manufacturer’s recommended brake fluid. Re- Check the fluid level in the master cylinder immediately fer to “Fluids, Lubricants, and Genuine Parts” in “Main- if the brake system warning light indicates system fail- taining Your Vehicle”...

  • Page 411: Clutch Hydraulic System - Manual Transmission (If Equipped)

    MAINTAINING YOUR VEHICLE 409 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.

  • Page 412: Manual Transmission - If Equipped

    410 MAINTAINING YOUR VEHICLE Manual Transmission – If Equipped Change Transmission Fluid If contaminated with water, change the fluid immedi- Fluid Level Check ately. See your authorized dealer for service. Check the fluid level by removing the fill plug on the left side of the transmission.
  • Page 413 MAINTAINING YOUR VEHICLE 411 Special Additives Fluid Level Check Automatic Transmission Fluid (ATF) is an engineered Regular automatic transmission fluid level checks are not product and its performance may be impaired by supple- required. For this reason, the dipstick is omitted. mental additives.

  • Page 414: Rear Axle

    412 MAINTAINING YOUR VEHICLE Rear Axle CAUTION! (Continued) Fluid Level Check • The fluid level is preset at the factory and it does Checking the fluid level while the vehicle is on level ground not require adjustment under normal operating will improve the accuracy of the fluid level reading.
  • Page 415 MAINTAINING YOUR VEHICLE 413 • Salt in the air near seacoast localities. on trees and road surfaces during other seasons, are highly corrosive to the metal in your vehicle. Outside • Atmospheric fallout/industrial pollutants. parking, which exposes your vehicle to airborne contami- nants, road surfaces on which the vehicle is operated, Washing extreme hot or cold weather and other extreme condi-...
  • Page 416 414 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, CAUTION! touch them up immediately. The cost of such repairs is • Do not use abrasive or strong cleaning materials considered the responsibility of the owner. such as steel wool or scouring powder that will •...
  • Page 417 MAINTAINING YOUR VEHICLE 415 • Blot any remaining stain with a clean, damp towel. Wheel And Wheel Trim Care All wheels and wheel trim, especially aluminum and • For tough stains, apply MOPAR Total Clean or chrome-plated wheels should be cleaned regularly with a equivalent, or a mild soap solution to a clean, damp mild soap and water to prevent corrosion.
  • Page 418 416 MAINTAINING YOUR VEHICLE Interior Trim should be cleaned starting with a damp WARNING! cloth, or MOPAR Satin Select or equivalent. Do not use harsh cleaners or Armor All . Use MOPAR Total Clean Do not use volatile solvents for cleaning purposes. or equivalent to clean vinyl upholstery.
  • Page 419 MAINTAINING YOUR VEHICLE 417 Glass Surfaces 1. Clean with a wet soft rag or micro-fiber towel. A mild All glass surfaces should be cleaned on a regular basis soap solution may be used, but do not use high alcohol with MOPAR Glass Cleaner or equivalent, or any com- content or abrasive cleaners.

  • Page 420: Fuses

    418 MAINTAINING YOUR VEHICLE Cleaning The Center Console Cupholders Clean with a damp cloth or towel using a mild detergent with the cupholder in the center console. NOTE: The cupholder cannot be removed. FUSES Integrated Power Module The Integrated Power Module is located in the engine compartment.
  • Page 421 MAINTAINING YOUR VEHICLE 419 Cavity Cartridge Mini- Description CAUTION! Fuse Fuse • When installing the integrated power module — 15 Amp Washer Motor cover, it is important to ensure the cover is prop- Blue erly positioned and fully latched. Failure to do so —...
  • Page 422 420 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse — — — 50 Amp — Radiator Fan 30 Amp — Windshield Wiper Pink — — — 30 Amp — Anti-Lock Brake Sys- — —...

  • Page 423: Rear Power Distribution Center

    MAINTAINING YOUR VEHICLE 421 Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Access Panel...
  • Page 424 422 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description CAUTION! Fuse Fuse • When installing the power distribution center 60 Amp — Ignition Off Draw cover, it is important to ensure the cover is prop- Yellow (IOD) Cavity 1 of the erly positioned and fully latched.
  • Page 425 MAINTAINING YOUR VEHICLE 423 Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse 30 Amp — Heated Seats – If 12 * — — — Pink Equipped 13 * — — — — 20 Amp Fuel Pump —...
  • Page 426 424 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse — — — — 5 Amp Cluster/Electronic Orange Stability Program — — — (ESP)/Powertrain — — — Control Module — — — (PCM)/STOP LIGHT —...
  • Page 427 MAINTAINING YOUR VEHICLE 425 Cavity Cartridge Mini- Description Cavity Cartridge Mini- Description Fuse Fuse Fuse Fuse — 25 Amp Hands-Free Phone – 30 Amp — Rear Window De- Natural If Equipped/Radio/ Pink froster Amplifier Feed 20 Amp — Amplifier/Sunroof – —...

  • Page 428: Vehicle Storage

    426 MAINTAINING YOUR VEHICLE VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 days, you may want to take these steps to protect your LIGHT BULBS – Interior Bulb Number battery. Rear Courtesy/Reading Lamps ... . . W5W Rear Compartment (Trunk) Lamp .

  • Page 429: Bulb Replacement

    MAINTAINING YOUR VEHICLE 427 BULB REPLACEMENT LIGHT BULBS – Exterior Bulb Number Headlamp – High Intensity Discharge (HID) ..D1S Low Beam Headlamp, High Beam Headlamp, (Serviced at Authorized Dealer) Park/Turn Lamp — Models with Halogen Halogen Headlamp.

  • Page 430: Front/Rear Side Marker Lamp

    428 MAINTAINING YOUR VEHICLE Front/Rear Side Marker Lamp WARNING! 1. Remove the front/rear side marker. Use a fiber stick or A transient high tension occurs at the bulb sockets of similar tool to gently pry the lamp on the outboard side HID headlamps when the headlamp switch is turned to disengage the clip.

  • Page 431: Tail/Turn And Stop Lamp

    MAINTAINING YOUR VEHICLE 429 Tail/Turn and Stop Lamp 1. Open the trunk. 2. Using a screwdriver, remove the tail lamp retainer. 4. Pull back the trunk liner. 5. Remove the remaining fasteners from the back of the tail lamp assembly. 3.
  • Page 432 430 MAINTAINING YOUR VEHICLE 6. Pull the tail lamp assembly clear from the vehicle to 7. Push the electrical connector locking tab to the side. access the bulbs. 8. Disconnect the electrical connector. 9. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the tail lamp assembly.

  • Page 433: Center Tail/Backup Lamp

    MAINTAINING YOUR VEHICLE 431 Center Tail/Backup Lamp See your authorized dealer for bulb replacement. Center High-Mounted Stop Lamp (CHMSL) The CHMSL uses LED lamps that are not serviceable separately. The CHMSL must be replaced as an assembly, see your authorized dealer. 14.

  • Page 434: License Lamp

    432 MAINTAINING YOUR VEHICLE License Lamp 1. Remove the screws securing the lamp to the rear fascia. 2. Remove the bulb and socket assembly. 3. Disconnect the bulb from the socket assembly and install the replacement bulb. 1 — License Lamp Bulb 2 —...

  • Page 435: Fluid Capacities

    MAINTAINING YOUR VEHICLE 433 FLUID CAPACITIES U.S. Metric Fuel (Approximate) All Engines 19 Gallons 72 Liters Engine Oil with Filter 3.6 Liter Engine (SAE 5W-30, API Certified) 6 Quarts 5.6 Liters 5.7 Liter Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System * 3.6 Liter Engine (MOPAR Antifreeze/Coolant 5 Year/100,000 Mile...

  • Page 436: Fluids, Lubricants, And Genuine Parts

    434 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hy- brid Organic Additive Technology) or equivalent. Engine Oil – 3.6L Engine Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.

  • Page 437: Chassis

    MAINTAINING YOUR VEHICLE 435 Chassis Component Fluid, Lubricant, or Genuine Part Manual Transmission – If Equipped MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Automatic Transmission – If MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed Equipped ATF+4 product. Brake Master Cylinder MOPAR DOT 3, SAE J1703 or equivalent should be used.
  • Page 439 MAINTENANCE SCHEDULES CONTENTS Maintenance Schedule ....438 Required Maintenance Intervals ..440...
  • Page 440 438 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE On Non-EVIC equipped vehicles, “Change Oil” will flash The Scheduled Maintenance services listed in this in the instrument cluster odometer and a single chime manual must be done at the times or mileages specified will sound, indicating that an oil change is necessary. to protect your vehicle warranty and ensure the best Based on engine operation conditions, the oil change vehicle performance and reliability.
  • Page 441 MAINTENANCE SCHEDULES 439 • Change your engine oil more often if you drive your “Understanding Your Instrument Panel” or under “In- vehicle off-road for an extended period of time. strument Cluster Description/Odometer/Trip Odom- eter” in “Understanding Your Instrument Panel” for •...
  • Page 442 440 MAINTENANCE SCHEDULES Once A Month At Each Oil Change • Check tire pressure and look for unusual wear or • Change the engine oil filter. damage. • Inspect the brake hoses and lines. • Inspect the battery, and clean and tighten the terminals CAUTION! as required.
  • Page 443 MAINTENANCE SCHEDULES 441 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...

  • Page 444: Service Schedule

    442 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 445 MAINTENANCE SCHEDULES 443 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 446 444 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). Odometer Reading Date Repair Order #...
  • Page 447 MAINTENANCE SCHEDULES 445 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
  • Page 448 446 MAINTENANCE SCHEDULES 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 449 MAINTENANCE SCHEDULES 447 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). Odometer Reading Date Repair Order #...
  • Page 450 448 MAINTENANCE SCHEDULES 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
  • Page 451 MAINTENANCE SCHEDULES 449 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 452 450 MAINTENANCE SCHEDULES 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
  • Page 453 MAINTENANCE SCHEDULES 451 128,000 Miles (208,000 km) or 96 Months Maintenance Service 136,000 Miles (221,000 km) or Schedule 102 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 454 452 MAINTENANCE SCHEDULES 144,000 Miles (234,000 km) or 108 Months Maintenance Service 152,000 Miles (247,000 km) or Schedule 114 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
  • Page 455 MAINTENANCE SCHEDULES 453 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.

  • Page 457: If You Need Consumer Assistance

    IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Customer Assistance For The Hearing Or Vehicle......457 Speech Impaired (TDD/TTY) .
  • Page 458 456 IF YOU NEED CONSUMER ASSISTANCE Department Of Transportation Uniform Tire Traction Grades ..... 463 Quality Grades ......463 Temperature Grades .

  • Page 459: Suggestions For Obtaining Service For Your Vehicle

    IF YOU NEED CONSUMER ASSISTANCE 457 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...

  • Page 460: Chrysler Group Llc Customer Center

    458 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (800) 423–6343 •...

  • Page 461: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)

    IF YOU NEED CONSUMER ASSISTANCE 459 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.

  • Page 462: Warranty Information

    460 IF YOU NEED CONSUMER ASSISTANCE We appreciate that you have made a major investment WARRANTY INFORMATION when you purchased the vehicle. An authorized dealer See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.

  • Page 463: In Canada

    IF YOU NEED CONSUMER ASSISTANCE 461 If NHTSA receives similar complaints, it may open an In Canada investigation, and if it finds that a safety defect exists in If you believe that your vehicle has a safety defect, you a group of vehicles, it may order a recall and remedy should contact the Customer Service Department imme- campaign.
  • Page 464 462 IF YOU NEED CONSUMER ASSISTANCE • Service Manuals • Owner’s Manuals These comprehensive Service Manuals provide the These Owner’s Manuals have been prepared with the information that students and professional technicians assistance of service and engineering specialists to need in diagnosing/troubleshooting, problem solving, acquaint you with specific Chrysler Group LLC ve- maintaining, servicing, and repairing Chrysler Group hicles.
  • Page 465 IF YOU NEED CONSUMER ASSISTANCE 463 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
  • Page 466 464 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
  • Page 467 INDEX...
  • Page 468 466 INDEX About Your Brakes ....278,281 Airbag, Side ..... . 59,62,64,65 ABS (Anti-Lock Brake System) .
  • Page 469 INDEX 467 Automatic Door Locks ....32,33 B-Pillar Location ......296 Automatic Headlights .
  • Page 470 468 INDEX Brightness, Interior Lights ....145 Check Engine Light Bulb Replacement ..... 426,427 (Malfunction Indicator Light) .
  • Page 471 INDEX 469 Connector Radiator Cap ..... . . 405 UCI ......228 Selection of Coolant (Antifreeze) .
  • Page 472 470 INDEX Dipsticks Electronic Power Distribution Center (Fuses) ..421 Oil (Engine) ......390 Electronic Speed Control (Cruise Control) .
  • Page 473 INDEX 471 Checking Oil Level ....390 Temperature Gauge ....177 Compartment .
  • Page 474 472 INDEX Flash-To-Pass ......144 Engine Oil ......390 Flashers Fluid, Brake .
  • Page 475 INDEX 473 Requirements ..... . . 321 Gauges Saver Mode ......193 Coolant Temperature .
  • Page 476 474 INDEX Head Restraints ......133 Hitches Headlights ......427 Trailer Towing .
  • Page 477 INDEX 475 Intermittent Wipers (Delay Wipers) ... 146 Lane Change and Turn Signals ....143 Introduction ......4 Lap/Shoulder Belts .
  • Page 478 476 INDEX Courtesy/Reading ....144,152 Intensity Control ..... 145 Cruise .
  • Page 479 INDEX 477 Turn Signal ....84,143,178 Maintenance Schedule ....438 Vanity Mirror .
  • Page 480 478 INDEX Mode Oil, Engine ......390,434 Fuel Saver ......193 Capacity .
  • Page 481 INDEX 479 Overheating, Engine ....178,349 Seats ......128 Owner’s Manual (Operator Manual) .
  • Page 482 480 INDEX Rear Window Defroster ....169 Reporting Safety Defects ....460 Rear Window Features .
  • Page 483 INDEX 481 Seat Belts ......42,45,81 Tilting ......128 And Pregnant Women .
  • Page 484 482 INDEX Side Airbag ......64 Remote ......27 Side Window Demisters (Defrosters) .
  • Page 485 INDEX 483 Supplemental Restraint System - Airbag ..55 TIREFIT ......350 Sway Control, Trailer .
  • Page 486 484 INDEX Rotation ......311 Trailer Towing ......334 Safety .
  • Page 487 INDEX 485 Transmitter Programming Vanity Mirrors ......92 (Remote Keyless Entry) ....21 Variance, Compass .
  • Page 488 486 INDEX Washing Vehicle ......413 Windshield Defroster ....82,242 Water Windshield Washers .
  • Page 489 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
  • Page 490 Chrysler Group LLC 11D491-126-AE Fifth Edition Printed in U.S.A.

This manual is also suitable for:

2011 challenger

Table of Contents
