Read safety Instructions carefully and understand them before using.
Retain this Instruction Manual for future reference.
为了安全地使用，请您在使用之前仔细阅读本使用说明书。
另外，请您注意保管本使用说明书，以便随时查阅。
CSA-1371CTLD
直驱式高速筒型绷缝机
Direct Drive,High Speed,
Interlock Machine
使用说明书
INSTRUCTION MANUAL
INSTRUCTION MANUAL
Cylinder-Bed,
No:A1371CTLD00
No:A1371CTLD00
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Golden wheel CSA-1371CTLD
Summary of Contents for Golden wheel CSA-1371CTLD
- Page 1 CSA-1371CTLD 直驱式高速筒型绷缝机 Direct Drive,High Speed, Cylinder-Bed, Interlock Machine 使用说明书 INSTRUCTION MANUAL INSTRUCTION MANUAL No:A1371CTLD00 No:A1371CTLD00 Read safety Instructions carefully and understand them before using. Retain this Instruction Manual for future reference. 为了安全地使用，请您在使用之前仔细阅读本使用说明书。 另外，请您注意保管本使用说明书，以便随时查阅。...
- Page 2 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 直驱式高速筒型绷缝机 直驱式高速筒型绷缝机...
-
Page 3: Specification
CSA-1371CTLD 说明书 / INSTRUCTION MANUAL Manual Instruction 1.Specification: Model....... CSA-1371CTLD Name........ Direct Drive,High Speed,Cylinder-Bed,Interlock Machine Size........475mm(length)*220mm(width)*405mm(height) Cylinder length....280mm Weight......39Kg Interlock sewing type..ISO 406,407,602,605 Sewing speed....6000 needle/minute( back puller type 4500needle/minute) Stitch length..... 1.4mm~3.6mm Needle quantity:7-18needle/inch 8-21needle/30mm Needle type...... - Page 4 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 2. Installation of machine head on table: 2-1.Table open hole drawing *Install machine head on table directly(A:standard installation)
- Page 5 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL *Install machine head on table directly(B)
- Page 6 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL *semi-submerged...
- Page 7 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 机架 坐凳 机台板 2-2. Installation of machine head Installing the machine correctly according to the picture, fix the thread rod and nut on the table, then put rubber blanket on the thread rod, and fix the machine head on the machine table 机器台板...
- Page 8 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 4. Motor and belt Using three phases, two poles, 400w (1/2HP) clutch motor and M belt, installing of motor should adjust- ment with the rotation and hand wheel when pedal is moving. M型皮带 *Because the motor on the market with a 5mm sewing distance, the data above is the approaching figure.
- Page 9 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 5-3. Oil meter and muzzle Before using the machine every day, please check the oil meter, if the direction of oil is not between the two lines, and it should add more oil, making sure that oil can eject form the muzzle before start operating.
- Page 10 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 5-6. The clean of head-machine Please clean the ash and thread after use everyday.open front-cap and side-cap,take off the rear side rubber stopper of head-machine every 1~2 week,use air-gun or tweezers to wipe off the surround of ash or sundries of oil filter core.
- Page 11 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 6-2. Threading Please threading as pictures indicate,incorrect threading will lead to skipped needle/break line or unstable sewing. A.B.C---------needle thread D-------up-thread E-------------crochet thread The threading method of three-thread seaming like the picture indicate,the same as two-thread,and the difference is the up-needle-thread only have 2 threads.press (F)when threading,rise support panel,press(G)again after threading to recovery.
- Page 12 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 6-3. Adjust the pressure of the press foot Fitst loose the nut (A) ，twist the screw in the clock- wise direction to increase the pressure , twist the screw in the anti-clockwise direction to reduce the pressure,in the normal situation ,please keep the pressure of the press foot be least.
- Page 13 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 6-6. Adjust the the differential Turn around the (C) to adjust the positive differential or negative differential ,since the main transmission and the the differential are separated ,the differential needs to adjust when the main transmission has been changed for example , when you need to set the stitch length 2,if the（C）...
- Page 14 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 6-7. HR&SP DEVICE Under high speed bind stitch ,it perhaps make a lot of heat causing thread damage 、skip needle、hole of needle too big , especially working with synthetic fibre cloth or Chemical fibre line,in case these situations ,HR(the point of needle cool down) &SP(thread touch-...
- Page 15 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 7-2. Adjust the stitch ◆For some stitch thread,if the thread not easy to control and hard to hook the thread,cause jump stitch,make it through the A. ◆When using the elastic thread,thread ring is not stable,should use the guide bar,when seting the criterion,let the needle bar st the lowest position,align the thread hole B and guide bar C.
- Page 16 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL (2) Install the guide plate Set the distance form guide plate D to upper looper is 0.5mm,and tight the screw E,MAKE SURE WHEN THE UPPER looper swing to the right ,can hook the thread. (3) Install the thread guard Put the needle bar in the lowest position,upper guide plate D to thred guard is 1.0mm...
- Page 17 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 7-4. Adjustment of roller feed amount (Attached is roller model ) The adjustment of roller feed are as follows: (1)Take the plug between up and down cover (2)Turn hand -wheel until screw B show up,and then loosen screw B.
- Page 18 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL 针 * For convenience of adjustment looper, please use timing guage,this specification can get from company or agency! * Timing Gauge There is A,B,C,D mark on it,locate right needle to V groove,and move looper to the most right end,after reading the mark, move the looper to the setting position,and tighten the setting screw (A).
- Page 19 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL (3) Adjust the gap between the needle and the looper * 3 needles: when the top of the low looper (A) meet the left needle (B), the gap is 0.2mm~0.3mm When adjusting, loose the screw (D) of the low looper needle clamp, then adjust.
- Page 20 CSA-1371CTLD 说明书 / INSTRUCTION MANUAL (5) The position of the front needle holder When lower looper reach the center of the left needle, the front needle holder should be 1.5mm- 2.0mm above the needle top point. When adjust, loose the screw (E) (F), adjust the gap between needle and holder be 0-0.3mm, and low looper...
- Page 21 启 翔 股 份 有 限 公 司 CHEE SIANG INDUSTRIAL CO., LTD. No.32, Wu Chuan 7th Road, Wu Ku, Wu Ku District 24890, New Taipei City, Taiwan.
