Summary of Contents for Grundig GD-CT-BP2247P
- Page 1 User Guide GD-CT-BP2247P grundig-security.com...
- Page 2 Abetechs GmbH (Grundig Security) reserves the right to change the contents of this document without prior notice. Design and specifications are subject to change without prior notice.
- Page 3 If the product uses batteries, please use a battery type that is recommended by the manufacturer. Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way.
-
Page 4: Table Of Contents
Table of Contents 1 Installation ......................1 1.1 Connecting the Cables ......................1 1.2 DIP Switch Settings ........................2 1.3 Wiring and Installation ......................4 1.3.1 Wiring ..........................4 1.3.2 Installing the Mount ......................5 1.3.3 Setting the DIP Switch ....................... 6 1.3.4 Installing the Speed Dome .................... -
Page 5: Installation
1 Installation Before you start: Check the package contents and make sure that the device in the package is in good condition and all the assembly parts are included. There are several ways to install the analog speed dome. The wall mounting is taken as an example below. -
Page 6: Dip Switch Settings
1.2 DIP Switch Settings 1.2.1 IR Speed Dome Settings The DIP switch is used for setting the speed dome address, baud rate, protocol, video output mode, and terminal resistor, with value OFF=0. DIP switch of mini IR speed dome is shown in figure 1-7, and the DIP switch of 5-inch IR speed dome is shown in figure 1-8. - Page 7 Address Settings The No.1 to No.5 DIP switches are for setting the address of speed dome, with value ON=1, 2, 3, 4, 5 standing respectively for 1, 2, 4, 8, 16, and OFF=0. You can refer to Table 1-14 for setting the address.
-
Page 8: Wiring And Installation
The speed dome is self-adaptive to private protocol when the No.7 switch is OFF. Video Output Settings The No.8 and No.9 DIP switches are for setting the video output mode of the speed dome. You can refer to Table 1-17 for setting the video output. Table 1-6 Set Video Output Switch No. -
Page 9: Installing The Mount
1.3.2 Installing the Mount Before you start: Wall mounting is applicable for the indoor/outdoor solid wall. The followings are the mandatory precondition for wall mounting: The wall must be thick enough to install the expansion screws. Make sure that the wall is strong enough to withstand more than 8 times the weight of the dome and the mount. -
Page 10: Setting The Dip Switch
Note: Follow the same instructions described above for the short-arm wall mount. For outdoor applications, adopt the water-proof measures. The short-arm wall mount is not recommended for outdoor applications. 1.3.3 Setting the DIP Switch Set the address and baud rate for the speed dome. The default value of DIP switch is shown below: ... -
Page 11: Application And Operations
2 Application and Operations 2.1 System Application The device can be controlled through the back-end device or control software. The back-end device includes control keyboard, DVR (Digital Video Recorder), etc., and the control software includes client software. Here we take the connection of DVR as an example. Figure 2-1 System Application Note: ... -
Page 12: Configuring Patrol
MAIN MENUS <SYS INFO> <SYS SETTINGS> <RESTORE SETTINGS> <RESTORE CAMERA> <REBOOT SYS> <LANGUAGE> ENGLISH EXIT Figure 2-2 Main Menu Note: Refer to the user manual for details to set the speed dome. 2.2.1 Configuring Patrol You can set the patrol function by operating the DVR and OSD menu, as well as the one-touch patrol can be realized. - Page 13 Figure 2-4 Key point Configuration 4. Configure key point parameters, such as the key point No., duration of staying for one key point and speed of patrol. The key point is corresponding to the preset. The Key Point No. determines the order at which the PTZ will follow while cycling through the patrol. The Duration refers to the time span to stay at the corresponding key point.
- Page 14 There are two choices for the dwell time set section. If you select GRADE, the actual implement by the dome will be different from the instruction sent by the DVR. For example, you set the DVR to 15s, corresponding to the dome it would be 140s. Refer to the interface for more details.
-
Page 15: Configuring Park Actions
2.2.2 Configuring Park Actions Purpose: For some certain model of the speed dome, it can be configured to start a predefined park action (scan, preset, patrol and etc.) automatically after a period of inactivity (park time). Configuring Park Actions by DVR Steps: 1. - Page 16 MOTION AUTO FLIP PROPORTIONAL PAN PARK TIME PARK ACT NONE SCAN SPEED IMAGE FREEZE MOVE SPEED BACK EXIT Figure 2-8 PTZ Configuration 2. Select the PARK TIME, and set the value according to your needs. 3. Select the PARK ACT, and the action can be set to NONE, PAN SCAN, TILT SCAN, PANORAMA, FRAME SCAN, RANDOM SCAN, PATROL-D, PATROL 1-10, PATTERN 1-5, PRESET 1-8, DAY, and NIGHT.
-
Page 17: Troubleshooting
3 Troubleshooting 3.1 Device Exceptions Question Why does the speed dome fail to start or repeatedly reboot? Why does the speed dome restart intermittently when controlling PTZ, calling presets or turning on the infrared lights of the IR dome at night? Answer ... - Page 18 Answer Please check whether the protective film of the bubble has been removed. Please check whether there are foreign objects on the bubble or the lens. Please check where there are obstructions such as spider web nearby. ...
- Page 19 UG-GD-CT-BP2247P-2020-05-29-V4-EN ©ABETECHS GMBH, DÜSSELDORF, GERMANY grundig-security.com...
