Operating- and servicemanual
Gram Standard Plus / Baker Standard 139


765042420


Rev.000










1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Standard Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Gram Standard Plus

Summary of Contents for Gram Standard Plus

  • Page 1                   Operating- and servicemanual Gram Standard Plus / Baker Standard 139           765042420 Rev.000...

  • Page 2: Table Of Contents

      Table of contents Application ..............................3   Safety information ............................4   Location ................................. 5   Optimizing the energy consumption ......................7   General description ............................8   Refrigerant / GWP value ..........................9   Climate / temperature class ........................... 9  ...

  • Page 3: Application

    Gram Commercial representatives and dealers placed all over the world are ready to help you. Please refer to your dealer for information about the warranty coverage of your new Gram product. Any warranty is subject to correct use according to specifications in this user manual, where e.g.

  • Page 4: Safety Information

    If these instructions are not observed, the product might be damaged or destroyed. Be aware that Gram Commercial has taken precautions to ensure that the safety of the product is in order. Please read carefully the following information regarding safety.

  • Page 5: Location

        Location     When receiving the product, check the packaging material for damage. If any damage occurs at the packaging material, it should be considered if the product might have been damaged too. If the damage is substantial, please contact your dealer. The transport pallet can be removed by loosening the screws that fasten the pallet to the product.
  • Page 6       If the cabinet has been transported in horizontal position it must stand upright at least 2 hours before it is started to allow the oil from the compressor to run back. Because of the heavy weight of the product, the floor might be damaged or scratched when moving the product.

  • Page 7: Optimizing The Energy Consumption

        Optimizing the energy consumption      Correct set up gives the most effective operation.  The product should be located in a dry and adequately ventilated room.  To ensure efficient operation, it may not be placed in direct sunlight or against heat-emitting surfaces.

  • Page 8: General Description

        General description     Compressor Condenser with air filter Front panel Display Gasket Door Air intake Air distribution plate Shelves for storage Fig. 4     765042420 Rev.000...

  • Page 9: Refrigerant / Gwp Value

      Refrigerant / GWP value     Refrigerator Regrigerant Charge kg equivalent STANDARD PLUS K 139 G R290 0,146 STANDARD PLUS M 139 G R290 0,146 Freezer STANDARD PLUS F 139 G R290 0,143   Climate / temperature class  ...
  • Page 10   Fig. 5 Always disconnect the power if interruptions in power supply occur, and when electrical parts are removed/put on, and before cleaning and maintenance of the product. Repairing of electrical/technical parts may only be performed by authorized technicians with proper knowledge of the product.

  • Page 11: General Use

        General use     Do not damage the refrigeration system parts. During normal operation, some parts of the refrigeration system in the compressor compartment might reach high temperatures, and could therefore cause burns if touching these components. Do not use electrical devices inside the product. To ensure correct and efficient air flow in the cabinet, the upper and lower areas must be kept free of items as shown on the next page.
  • Page 12         Do not place foodstuff Below the bottom shelf support   Fig. 6                            765042420 Rev.000...

  • Page 13: Operating The Product

        Operating the product       Display The display contains the elements that are shown to the left of this text. Not all the symbols shown are used in this product. The symbols that are used are described below. The temperature is shown in the 4 alphanumeric positions.

  • Page 14: Keyboard Lock

      This symbol indicates that the temperature in the display is measured in °C When this symbol is lit, the cabinet is in standby mode. Operating On/off button. Used to switch the cabinet on or buttons   off and to exit a menu. Press the P button to set the desired  ...

  • Page 15: Changing The Temperature

        Changing the temperature      To set the desired set point, do the following:  Briefly press the button . Once this has been done, the current set point of the product is shown in the display. Furthermore, the symbol will flash as an indication that the set point is about to be changed.

  • Page 16: Display Of The Evaporator Sensor Reading

      ALARMS Display Explanation Defrosting alarm. This code is shown in the display if the defrosting has been interrupted at the maximum time allowed for a defrosting. The product will in all probability continue to function normally. This is just an indication that the product is being or has been subjected to a greater load than the defrosting parameter settings are able to accommodate.

  • Page 17: Haccp Alarms

          HACCP Alarms     The controls can store up to three HACCP alarms. The information saved for these alarms  The critical value(s)  Duration of the alarm The controls can display the following alarms: Display Explanation Low temperature alarm.

  • Page 18: Deletion Of Haccp Alarms

      If one or more alarms are active for the cabinet, then the symbol will be lit. Active alarms cannot be deleted. If “HACCP” is either continuously lit or flashing in the display, it is possible to read out the alarm(s) contained in the log.

  • Page 19: Cleaning Of Condenser Filter

        Cleaning of condenser filter       Reminder about cleaning the condenser's air filter: To ensure the proper operation of the cabinet, it will be periodically indicated that the filter in front of the condenser has to be cleaned. This is indicated by the warning light being lit.

  • Page 20: Defrost Water

      Defrost water The product generates defrost water during defrosting, which is conducted out into a re- evaporation tray at the back of the product (see Fig. 7). A re-evaporation tube from the cooling system on freezers or an electric heating element placed on the tray for refrigerators (K and M models) will enable the water to be re-evaporated.

  • Page 21: Door Closing Mechanism

      Door closing mechanism The door is equipped with a self-closing system. If the door is opened less than 90, it will close by itself. If the door is opened more than 90, it will stay open. The door can be opened by using the foot pedal. This leaves both hands free when placing foodstuffs the cabinet.

  • Page 22: Door Gaskets

      Door gaskets This chapter deals with the importance of a well-functioning door gasket. Gaskets are an important part of a refrigerator/freezer. Gaskets with reduced functionality, reduces the tightness of the cabinet. Reduced tightness might cause increased humidity, internal icing, an iced up evaporator (leading to reduced refrigeration capacity), and in worst case reduced lifecycle of the cabinet.

  • Page 23: Service

    When contacting us please tell us the name and serial number (S/N) / (WWYY) of the cabinet. This information is stated on the name plate, see Fig. 8. Location of the name plate: Gram Commercial A/S, Denmark Made in DK. CVR nr. 12 00 66 32 Input: 230 V 50 Hz 231 W 1,29 A...

  • Page 24: Disposal

    Disposal of an old cabinet is only available when we are delivering a new one at the same time. Cabinets must be fully defrosted and emptied prior to collection. Gram recognises that our products for the catering market are considered as WEEE when they become obsolete. To ensure that Gram’s responsibilities are handled correctly and environmentally friendly, we are signed up the largest Business to Business compliance scheme in the UK –...

  • Page 25: Ec-Declaration Of Conformity

    Adress: Aage Grams Vej 1, 6500 Vojens Tel.: 73 20 12 00 Product Model: Standard Plus 139, Baker Standard 139 Refrigerant: R290 Year: 2020 Directives The product is in compliance with all the essential health- and safety requirements and provisons in:...

  • Page 26: Default Factory Settings

        Default factory settings     The controller can be reset to default factory settings. Please be aware that default factory settings of the controller can differ from the settings implemented when the cabinet was delivered. Therefore some parameters might have to be modified after resetting to controller factory setting.

  • Page 27: Parameter Overview

    Parameter overview     Freezer Refrigera Refriger Cabinet type ator extended -22 /-10 -5/+12 +2/+12 Temperature area 45-358- 45-358- 45-358- GRAM sparepart item number 0133 0134 0132 Para- Maxi- Mini- Value Factory setting meter  °C/°F Temperature setpoint  -25.0 25.0...
  • Page 28     COMPRESSOR PROTECTION SYSTEM Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Value Factory setting meter C0  Delay in switching on compressor after turning on cabinet C1  Minimum time between two consecutive compressor start-ups;...
  • Page 29   DEFROSTING Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Value Factory setting meter d0  defrosting interval (only if d8 = 0, 1 or 2) 0= never activated Defrost type d1  0 = Electric 1 = Hotgas 2 = Compressor stop...
  • Page 30   Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Factory setting Value meter d6  Temperature displayed during defrosting - - - - 0= Room temperature 1= N/A d7  Dripping duration Defrosting activation criterias d8 ...
  • Page 31   average - d19”) (only if d8 = 3 and for condition 2); also look at d17 d20  minimum consecutive time the compressor must be switched on such as to provoke the defrost activation 0 = the defrost will never be activated because the compressor has been switched minimum consecutive time the compressor must be d21 ...
  • Page 32   ALARM PARAMETERS Freezer Refrige- Refrige- Cabinet type  rator rator extended -22 /-10 -5/+12 +2/+12  Temperature area Para- Maxi- Mini- Value Factory setting meter Sensor for low temperature alarm (code “AL”)  - - - - 0 = Room temperature 1 = Evaporator temperature temperature below that at which the minimum ...
  • Page 33   EVAPORATOR FAN PARAMETERS Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Value Factory setting meter Evaporator fan activity during normal operation 0 = Switched off 1 = Switched on; F13, F14 and ∟...
  • Page 34   Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Factory setting Value meter Effect caused by door switch activation; see also ∟ 0 = deactivated  - - - - 1 = compressor and evaporator fan will be switched ∟...
  • Page 35     DIGITAL OUTPUTS Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Value Factory setting meter operation controlled by the fourth relay output 0 = CELL LIGHT - in this case the AUXILIARY key and parameters i0 and u2 will be activated u1 ...
  • Page 36     SERIAL NETWORK (MODBUS) Freezer Refrige- Refrige- Cabinet type rator rator extended -22 /-10 -5/+12 +2/+12 Temperature area Para- Maxi- Mini- Value Factory setting meter - - - - LA  instrument address Lb  - - - - baud rate 0 = 2,400 baud 1 = 4,800 baud 2 = 9,600 baud...

  • Page 37: Wiring Diagram K/M 139

        Wiring diagram K/M 139       765042420 Rev.000...

  • Page 38: Wiring Diagram F 139

      Wiring diagram F 139       765042420 Rev.000...

  • Page 39: Piping Diagram

      Piping diagram     765042420 Rev.000...
