INSTRUCTIONS–PARTS LIST
This manual contains IMPORTANT
WARNINGS AND INSTRUCTIONS
READ AND RETAIN FOR REFERENCE
AIR MOTOR MUFFLERS
FOR MONARK AND PRESIDENT AIR MOTORS
MODEL 215–354
Fits Monark Air Motors
Except Models 205–237, 205–471, and 207–546
IMPORTANT
You cannot order parts or request service and warranty infor-
mation for the complete pump without the information on the
serial plate.
LUFTMOTOR–AIR MOTOR
Model
Series
Record all the information from the air motor and serial plate
in these spaces. Keep this manual in a safe place as an extra
precaution.
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441
PUMP
MAX.GPM(l/MIN)
PART NO.
MAX AIR
PSI (bar)
RATIO
SERIES
SERIAL
COPYRIGHT 1979, GRACO INC.
307–361
MODEL 214–873, Series A
Fits President Air Motors
Rev C
Supersedes B
