1. Set Top upside-down on a non-marring surface. Place Base onto Top so that holes in Base Bridgeplate
align with holes in Top Bridgeplate.
2. Use provided Wrench to attach bridgeplates together with (4) Flat Washers, (4) Lock Washers, and (4)
5/16" x 2" Bolts. Tighten securely.
3. Return assembled table to its upright position.
For additional consumer assistance please contact your Lexington dealer or call our Consumer Services Department
at 1-336-474-5300, Monday-Friday, 8-5 Eastern
ASSEMBLY INSTRUCTIONS
621-870 ROUND DINING TABLE
BASE
Part
Qty
5
4
" x 2" Bolt
16
Lock Washer
4
Flat Washer
4
Wrench
1
TOP
BRIDGEPLATE
TOP
BRIDGEPLATE
BASE
Advertisement
Table of Contents
Related Manuals for LEXINGTON 621-870
Summary of Contents for LEXINGTON 621-870
- Page 1 2. Use provided Wrench to attach bridgeplates together with (4) Flat Washers, (4) Lock Washers, and (4) 5/16” x 2” Bolts. Tighten securely. 3. Return assembled table to its upright position. For additional consumer assistance please contact your Lexington dealer or call our Consumer Services Department at 1-336-474-5300, Monday-Friday, 8-5 Eastern...
- Page 2 Leaf Installation: 1. Pull out all leaf supports. 2. Lay (1) leaf panel on supports. Center leaf so that both supports are same distance from each end of leaf. 3. Each leaf has a number stamped on the bottom on the ends. The numbers should be matched as the leaves are assembled to ensure a correct fit.
