PART
HARDWARE LIST
5
Bolt Ø
" x 4"
16
A
(Ø8mm x 100mm)
Lock Washer
B
Flat Washer
C
Wrench
D
For additional consumer assistance please contact your Lexington dealer or call our
Consumer Services Department at 1-336-474-5300, Monday-Friday, 8-5 Eastern
ASSEMBLY INSTRUCTIONS
415-877 Vernon Hills Rectangular Dining Table
QTY
C
8 PCS
B
8 PCS
A
8 PCS
D
1 PC
LEG (4)
Top View of
Corner Block & Leg
*Metal T-Nuts in leg
should face the outside
of the table when leg
is properly oriented*
TABLE TOP (1)
TABLE LOCK
Closed Position
TABLE LOCK
Open Position
07/11/2019
