B. Outdoor Temperature Sensor
An outdoor temperature sensor may be provided to read the
outside temperature. The thermostat will not control to the
outside temperature sensor. Outside temperature can be viewed
by pressing and holding the Mode button for 2 seconds.
C. Duct Temperature Sensor
A duct temperature sensor may be provided to read the duct
temperature. The thermostat will not control to the duct tem-
perature sensor. Duct temperature can be viewed by press-
ing and holding the Mode button for 2 seconds.
D. Add-A-Wire™ Accessory
The Add-A-Wire accessory is used to repair a broken wire on
a thermostat or to add an extra terminal for cooling or heat
pump operation.
VI. SENSOR CALIBRATION
Every thermostat is factory calibrated. Under normal circum-
stances there will never be a need to re-calibrate the ther-
mostat. If re-calibration must be done, perform the following
procedure:
1. Hold down the Mode and Fan buttons for 5 seconds. All
of the icons on the display screen will appear. Release
the buttons. Press the UP and DOWN ARROW buttons
simultaneously.
2. Press the UP and DOWN ARROW buttons simulta-
neously again. The current temperature will be
displayed.
3. Use an accurate thermometer to measure room tem-
perature. Press the UP or DOWN ARROW buttons un-
til the number equals room temperature.
4. Press the Mode button to return to normal operation.
Table 2 — Advanced Set Up Configuration
DESCRIPTION
Unoccupied Cooling Set Point
Unoccupied Heating Set Point
Heat Pump
Reversing Valve Polarity
Electric Heat
Deadband
Forced Minimum Temperature Difference
Cycles per Hour
Dry Contact Switch
Reset Service Filter Icon
Service Filter Run Time
Soft Start
Temperature Units
Sensor Type
Security Level
Maximum Allowable Heat Set Point
Minimum Allowable Cooling Set Point
RANGE
35 - 99 F / OF
35 - 75 F / OF
Off/On
O / B
Off/On
1 - 6 degrees
0 - 6 degrees
d, d1, 2 - 6
Normally Open /
Normally Closed
—
0-1950 hrs
0 - 99
F / C
Yes / No
0 - 3
35 - 99 F (1- 37 C)
35 - 99 F (1 - 37 C)
VII. CHECK THERMOSTAT OPERATION
To check thermostat operation, perform the following
procedure:
1. Press the Mode button repeatedly until the Heat icon
appears on the display. The thermostat is now in Heat-
ing mode.
2. Press the UP ARROW button until the heating set point
is 10 F (6 C) higher than the current room temperature.
Heating and fan should be energized. The red indicator
light should be lit.
3. Press the Mode button repeatedly until the Cool icon ap-
pears on the display. The thermostat is now in Cooling
mode.
4. Press the DOWN ARROW button until the cooling set
point is 10 F lower than the current room temperature.
Cooling and fan should be energized. The green indica-
tor light should be lit.
5. Press the Mode button repeatedly until the Off icon
appears. Press the Fan button until the display reads
Fan On. The fan should energize.
6. If heating, cooling, or fan do not work, check wiring and
consult Troubleshooting section.
VIII. FINAL CHECKLIST
1. Put away tools and instruments. Clean up debris and
packaging.
2. Review Owner's Guide with occupant or owner.
3. Leave the manuals with owner.
—5—
DEFAULT
85 F
55 F
Off
O
Off
2
2
6
Normally
Open
—
500 hrs
0
F
No
0
80 F (27 C)
65 F (18 C)
