Installation Instructions TSTATCCPS101 Digital Thermostat TSTATBBPS101 P374-1000 NOTE: Read the entire instruciton manual before starting the installation. HEAT COOL 6:03 & AUTO HEAT PUMP MULTI-STAGE SINGLE DAY PROGRAMMABLE Form: IM-TSTAT-13 Cancels: Printed in U.S.A. Catalog No. 13TS-TA39...
Table Of Contents PREPARATION REMOVE OLD THERMOSTAT WIRE CONNECTIONS WIRING DIAGRAMS CALIBRATION TEST OPERATION TROUBLESHOOTING CAUTION Follow Installation Instructions carefully. DISCONNECT POWER TO THE HEATER - AIR CONDITIONER BEFORE REMOVING THE OLD THERMOSTAT AND INSTALLING WARNING THE NEW THERMOSTAT. Replacement Component Division Carrier Corporation 4/01 This device complies with Part 15 of the FCC rules.
STEP #1 PREPARATION Proper installation of the thermostat will be accomplished by following these step by step instructions. If you are unsure about any of these steps, call a qualified technician for assistance. Assemble tools Flat Blade Wire cutter Screwdriver &...
STEP #2 REMOVE & REPLACE OLD THERMOSTAT Remove the cover of the old thermostat. If it does not come off easily check for screws. Loosen the screws holding the thermostat base or subbase to the wall, and lift away. Disconnect the wires from the old thermostat.
STEP #3 WIRE CONNECTIONS If the terminal designations on your old thermostat do not match those on the new thermostat, refer to the chart below, or the wiring diagrams that follow. Install on the Wire from the old thermostat new thermostat Function connector marked terminal marked...
Sample Wiring Diagrams 5 Wire, 1 Stage Cooling, 1 Stage Gas Heat Residential Gas or Electric Heat *, Electric Cool, split systems & package units Thermostat 24 vac common fan relay compressor relay 1st stage heat circuit 24 vac return * If using electric heat this option must be selected on during advanced setup.
Page 7
Sample Wiring Diagrams 6 Wire, 1 Stage Cooling, 2 Stage Heat Residential & commercial 1 Stage Cooling, with 2 Stage Gas or Electric Heat* Thermostat 24 vac common fan relay compressor relay 1st stage heat circuit 24 vac return 2nd stage heat circuit 5 Wire, 1 Stage Cooling, 1 Stage Heat - Heat Pump* No auxiliary heat, residential Heat Pumps , split systems &...
STEP #4 TEST OPERATION Turn the power on to the Heating/Air Conditioning system. Press the MODE button repeatedly until the HEAT icon appears on the display. Press the Up or Down buttons until the set temperature is 10 degrees above room temperature.
TROUBLESHOOTING SYMPTOM: When using 4 wires (R, G, W, Y), the air conditioning equipment tries repeatedly to turn on, but cannot. At times the display dims or disappears. CAUSE: There is not enough power available to "power share". REMEDY: Connect a 270 ohm, 10 watt power resistor at the furnace as shown below.
Page 11
TROUBLESHOOTING SYMPTOM: The air conditioning does not attempt to turn on. CAUSE: The cooling setpoint is set too high. REMEDY: Consult the Owner's Manual in the Setup section to lower the cooling setpoint limit. SYMPTOM: The heating does not attempt to turn on.
Page 12
"conventional" (non heat pump) system. REMEDY: Consult the Owner's Manual in the Advanced Setup section to turn off the heat pump. Slimline TSTATCCPS101 TSTATBBPS101 P374-1000 Tested to Comply with FCC Standards FOR HOME OR OFFICE USE 4Z95...
