About This Manual Thank you for selecting Hernon's Ultracure 7 for your application. The Ultracure 7 was developed with your needs in mind. Your Ultracure 7 has been calibrated and tested to ensure optimal performance and long life. To ensure safe and trouble-free operation, please review the procedures and warnings contained in this manual before setting up or operating your Ultracure 7.
Hernon Manufacturing ® 107-028 Ultracure 7 Table of Contents Ultracure 7 ..............................1 About This Manual ............................2 Table of Contents ............................3 Unpacking and Inspection ..........................4 Safety ................................5 Features/Specifications .................. Error! Bookmark not defined. Power Requirements ..........................6 Status Indicator ............................
107-028 Ultracure 7 Unpacking and Inspection Upon receipt of the unit, carefully remove the contents from the boxes and check for damage. Hernon is not responsible for damage from shipping – all claims for shipping damage should be made with carrier.
Keep area around device/s clear of all debris, water, oil, etc. Use only genuine OEM Hernon replacement parts when servicing this machine tool. Ignoring this warning could cause unintended operation and possible injury. WARNING: DANGEROUS ULTRAVIOLET EMMISSION Recommended #5 Green shade goggles for eye protection This equipment is designed to be used properly, set up with components correctly connected, and operated in accordance with relevant instructions.
107-028 Ultracure 7 General The Ultracure 7 carries the same functionality as the Ultracure 6, but is more optimized for tight spaces with its two-piece design. A 90° cable connector is available upon request. Figure 1- The Ultracure 7 shown as both straight and 90°.
Mounting The Ultracure 7 has three mounting options on the LED unit: Four M4 x 0.8 on electrical connector end, two M4 x 0.8 on the bottom face of the device, and two M4 x 0.8 on both sides of the LED. Refer to Figure 2.
Single Unit Wiring with Feedback Status I/O Reference Drawing on next page. The Ultracure 7 unit will turn on under the following conditions: when the Power Supply (PS1) is on, the Switch (SW1) is closed, and shutter relay contacts are open.
Page 9
LED then that units’ error relay will turn on and the error loop will open. The red LED will turn on when an error is active. The Ultracure 7 units will turn on/off quickly when the shutter relay contacts are opened/closed.
Page 10
Hernon Manufacturing ® 107-028 Ultracure 7 Figure 7- Multi-Unit Wiring. 10 | P a g e...
Page 11
55°c. UV Output Curve The Ultracure 7 has an optimal distance for ideal curing properties. The diagram below shows the UV Intensity vs Distance Curve. Figure 8- UV output curve.
Hernon Manufacturing ® 107-028 Ultracure 7 External I/O Signals The only output signal on the Ultracure 7 is an Error signal from port 2. Refer to Figure 5 LED Failure The unit has experienced an LED failure; this is fixed by opening the driver enclosure and flipping the corresponding dipswitches one at a time (from 1 to 5) until the unit turns back on.
Page 13
Hernon Manufacturing ® 107-028 Ultracure 7 Q: How often should the Ultracure 7 be cleaned? A: The unit should be cleaned prior to every start up. This will ensure a long life of the LEDs. Use a razorblade to clean glass of any cured sealant...
