About This Manual Thank you for selecting Hernon's Ultracure 6 for your application. The Ultracure 6 was developed with your needs in mind. Your Ultracure 6 has been calibrated and tested to ensure optimal performance and long life. To ensure safe and trouble-free operation, please review the procedures and warnings contained in this manual before setting up or operating your Ultracure 6.
107-022 Ultracure 6 Unpacking and Inspection Upon receipt of the unit, carefully remove the contents from the boxes and check for damage. Hernon is not responsible for damage from shipping – all claims for shipping damage should be made with carrier.
Keep area around device/s clear of all debris, water, oil, etc. Use only genuine OEM Hernon replacement parts when servicing this machine tool. Ignoring this warning could cause unintended operation and possible injury. WARNING: DANGEROUS ULTRAVIOLET EMMISSION (Hernon Part Number: 107-005)
2.5 /W cm² (max) @ 365nm I/O Port 5 pin CPC Cooling Dimensions (approx.) 6” x 2” x 1.5” System Warranty 1 year from purchase NOTE: Power Supply not included. Figure 1- Ultracure 6 dimensions and mounting specifications. P a g e...
Mounting The Ultracure 6 has two mounting options. Four M3 x 0.5 on electrical connector end, and four M2 x 0.4 on the bottom of the device. Refer to Figure 1. When mounting the Ultracure 6, do not to mount directly onto any surface that may obstruct the fan.
Single Unit Wiring with Feedback Status I/O Reference Drawing on next page. The Ultracure 6 unit will turn on under the following conditions: when the Power Supply (PS1) is on, the Switch (SW1) is closed, and shutter relay contacts are open.
Page 9
LED then that units’ error relay will turn on and the error loop will open. The red LED will turn on when an error is active. The Ultracure 6 units will turn on/off quickly when the shutter relay contacts are opened/closed.
Page 10
Hernon Manufacturing 107-022 Ultracure 6 10 | P a g e...
55°c. UV Output Curve The Ultracure 6 has an optimal distance for ideal curing properties. The diagram below shows the UV Intensity vs Distance Curve. Figure 5- UV output curve.
Hernon Manufacturing 107-022 Ultracure 6 External I/O Signals The only output signal on the Ultracure 6 is an Error signal from port 2. Refer to Figure 4. LED Failure In the event that the unit has experienced LED failure: 1. Open the enclosure, via six Philips-head M2 screws.
(from 1 to 5) until the unit turns back on. The unit will operate properly with one or more inoperable LEDs. Q: How often should the Ultracure 6 be cleaned? A: The unit should be cleaned prior to every start up. This will ensure a long life of the fan, and the LEDs.
Nothing in this bulletin is to be interpreted as a representation of freedom from domination of patents owned by others or a license under a Hernon patent. We recommend that each prospective user test his proposed application before repetitive use, using the data as a guide.
