3 Quick Start

The Spatial OEM development kit is ready to function straight out of the box using the USB
interface. It is recommended that users familiarise themselves with Spatial OEM through the
Spatial Manager software prior to starting their own integration.
1. If you are using Windows, install Java from http://www.java.com.
2. Download Spatial Manager from the Advanced Navigation website.
3. Open Spatial Manager by double clicking on it. If this does not work, right click and choose
open with → Java
4. Screw the GNSS antenna onto the board connector finger tight and place the antenna in an
area with a view of the sky.
5. Plug one end of the USB cable into the development board and the other end into your
computer.
6. Click connect in Spatial Manager. If the connection indicator does not turn green,
disconnect and try selecting another serial port.
3.1

Troubleshooting

If the serial port does not show up when the OEM development board is plugged in, the system
may require drivers. These are available from http://www.ftdichip.com/Drivers/VCP.htm.
