- Page 1 REPAIR MANUAL MZ14H MZ16H MZ18H 87045363 2/04...
- Page 2 SECTION 7 - ELECTRICAL SYSTEM The sections used through out all New Holland product Repair manuals may not be used for each product. Each Repair manual will be made up of one or several books. Each book will be labeled as to which sections are in the overall Repair manual and which sections are in the each book.
-
Page 3: Table Of Contents
SECTION 1 - GENERAL INFORMATION SECTION 1 - GENERAL INFORMATION CONTENTS Section Description Page General Information ....................1-2 Think Safety First....................... 1-2 General Specifications....................1-3 Hydrostatic Transaxles ....................1-8 Torque Specifications ....................1-10 Standard Torque For Dry, Zinc Plated, and Steel Fasteners (Inch Series)....1-11 Standard Torque For Dry, Zinc Plated, and Steel Fasteners (Metric Fasteners) .. -
Page 4: General Information
This manual is intended as a service and repair manual only. The safety instructions provided herein are for troubleshooting, service, and repair of the MZ14H, MZ16H, MZ18H zero radius tractor. The MZ14H, MZ16H, MZ18H zero radius tractor and attachment operator's manuals contain safety information and operating tips for safe operating practices. -
Page 5: General Specifications
SECTION 1 - GENERAL INFORMATION GENERAL SPECIFICATIONS MZ14H MZ16H MZ18H ENGINE Type........Briggs & Stratton Briggs & Stratton Briggs & Stratton Model........280H070 286H770 31H777 Horsepower ......10.8 kw (14.5)@3600 11.9 kw (16.0)@3600 13.4 kw (18.0)@3600 Cylinders......Single Single Single Displacement....... - Page 6 SECTION 1 - GENERAL INFORMATION MZ14H MZ16H MZ18H Transport Levers ....Allow unit to be moved Allow unit to be moved Allow unit to be moved without engine running without engine running without engine running ATTACHMENT DRIVE Clutch ........Electric Clutch...
- Page 7 SECTION 1 - GENERAL INFORMATION MZ14H MZ16H MZ18H Engine Throttle ....Rightside console Rightside console Rightside console mounted lever mounted lever mounted lever Ignition Switch ..... Rightside console Rightside console Rightside console mounted electric with mounted electric with mounted electric with Power Take Off ....
- Page 8 SECTION 1 - GENERAL INFORMATION MZ14H MZ16H MZ18H Track Width ......32.9 in. (83.6 cm) cen- 32.9 in. (83.6 cm) cen- 34.6 in. (87.9 cm) center ter to center of rear tires ter to center of rear to center of rear tires 31.6 in.
- Page 9 SECTION 1 - GENERAL INFORMATION MZ14H MZ16H MZ18H BLADES Two 19.32” x 2.5” x Two 21.60” x 2.25” x Three 15.5” x 2.5” x .187” heat treated steel .164” heat treated steel .187” heat treated steel blades. blades. blades. TIP SPEED...
-
Page 10: Hydrostatic Transaxles
SECTION 1 - GENERAL INFORMATION HYDROSTATIC TRANSAXLES GENERAL SPECIFICATIONS Lubrication SAE 20W-50 API Classification SH/CD Oil Capacity 1.6 to 1.7 qt. (1.5 to 1.6 liters) Oil Level The transaxle is a sealed system and does not requre periodic checking. Check oil at the oil fill plug location only. - Page 11 SECTION 1 - GENERAL INFORMATION NOTE: If you are replacing the transaxle, after you have installed the hydro rods, remove the nut and washer located on the cam plate. Also, check the oil prior to installation.
-
Page 12: Torque Specifications
SECTION 1 - GENERAL INFORMATION TORQUE SPECIFICATIONS Recommended fastener torque values are listed in the following tables. For critical applications, as determined Holland, either recommended torque or a torque that is unique to the application is clearly identified and specified in the service manual. -
Page 13: Standard Torque For Dry, Zinc Plated, And Steel Fasteners (Inch Series)
SECTION 1 - GENERAL INFORMATION STANDARD TORQUE FOR DRY, ZINC PLATED, AND STEEL FASTENERS (INCH SERIES) SAE GRADE 5 SAE GRADE 8 SAE GRADE 1 BOLTS, GRADE 1, BOLTS, SCREWS, BOLTS, SCREWS, SCREWS, STUDS, & 5, & 8 WITH STUDS, & SEMS WITH STUDS, &... -
Page 14: Standard Torque For Dry, Zinc Plated, And Steel Fasteners (Metric Fasteners)
SECTION 1 - GENERAL INFORMATION STANDARD TORQUE FOR DRY, ZINC PLATED, AND STEEL FASTENERS (METRIC FASTENERS) CLASS 8.8 BOLTS, SCREWS, AND CLASS 10.9 BOLTS, SCREWS, AND THREAD SIZE STUDS WITH REGULAR HEIGHT STUDS WITH REGULAR HEIGHT NUTS NUTS (CLASS 8 OR STRONG NUTS) (CLASS 10 OR STRONG NUTS) M5 x 0.8 57 ±... -
Page 15: Other Torque Specifications
SECTION 1 - GENERAL INFORMATION OTHER TORQUE SPECIFICATIONS WHEEL BOLTS AND LUG NUTS SAE GRADE 8 STEEL SET SCREWS THREAD RECOMMENDED TORQUE THREAD RECOMMENDED TORQUE** SIZE SIZE SQUARE HEAD HEX SOCKET 7/16 - 20 UNF 65 ± 10 ft-lb 88 ± 14 N-m 1/4 - 20 UNC 140 ±... -
Page 16: Equivalents And Conversions
SECTION 1 - GENERAL INFORMATION EQUIVALENTS AND CONVERSIONS DECIMAL AND MILLIMETER EQUIVALENTS FRACTIONS DECIMALS FRACTIONS DECIMALS 1/64 0.015625 0.397 33/64 0.515625 13.097 1/32 0.03125 0.794 16/32 0.53125 13.484 3/64 0.046875 1.191 35/64 0.546875 13.891 1/16 0.0625 1.588 9/16 0.5625 14.288 5/64 0.078125 1.984... - Page 17 SECTION 1 - GENERAL INFORMATION U.S. METRIC CONVERSIONS TO CONVERT INTO MULTIPLY BY Miles Kilometers 1.609 Yards Meters 0.9144 Feet Meters 0.3048 Linear Measurement Feet Centimeters 30.48 Inches Meters 0.0254 Inches Centimeters 2.54 Inches Millimeters 25.4 Square Miles Square Kilometers 2.59 Area Square Feet...
- Page 18 SECTION 1 - GENERAL INFORMATION 1-16...
- Page 19 SECTION 2 - MODEL/SERIAL NUMBER LOCATION SECTION 2 - MODEL/SERIAL NUMBER LOCATION CONTENTS Section Description Page Model/Serial Number Location .................. 2-2 Engine Model and Serial Number Identification............2-2...
- Page 20 SECTION 2 - MODEL/SERIAL NUMBER LOCATION MODEL AND SERIAL NUMBER LOCATION The unit model and serial number plate is located on the frame under the seat as shown in the illustration. ENGINE MODEL AND SERIAL NUMBER IDENTIFICATION Consult the appropriate engine manufacturer’s service literature for the location and translation of the engine model and serial number information.
