  • Page 1: Table Of Contents

    CONTENTS Contents INTRODUCTION ................. SAFETY INFORMATION ..............INSTALLATION MATERIAL..............Kit supplied dishwasher (fully integrated)..........Kit supplied dishwasher (integrated)............ DIMENSIONS OF DISHWASHER............INSTALLATION AND HOOK-UP ............Levelling....................Connections ..................5.2.1 Connection to the water supply............. 5.2.1.1 Connection to the water tap............... 5.2.1.2 Connection to the drain hose.............
  • Page 3: Introduction

    INTRODUCTION 1  INTRODUCTION Thank you for choosing one of our products. To install this dishwasher correctly and safely, please read this manual carefully. The manual is divided into sections giving you a step-by-step guide to installation of the appliance. The texts are easy to understand and are complete with detailed illustrations.
  • Page 4: Safety Information

    WARNINGS 2 SAFETY INFORMATION THIS MANUAL FORMS AN INTEGRAL PART OF THE APPLIANCE: IT MUST ALWAYS BE KEPT INTACT TOGETHER WITH THE DISHWASHER. BEFORE USING THE APPLIANCE, CAREFULLY READ ALL THE INSTRUCTIONS CONTAINED IN THIS MANUAL. INSTALLATION MUST BE PERFORMED BY A QUALIFIED TECHNICIAN, IN COMPLIANCE WITH THE REGULATIONS IN FORCE.
  • Page 5 WARNINGS CHECK THAT THE VOLTAGE, FREQUENCY AND PROTECTION OF THE DOMESTIC MAINS POWER SUPPLY MATCH THE RATINGS ON THE NAME PLATE OF THE APPLIANCE. TWO PEOPLE WEARING SAFETY GLOVES ARE REQUIRED TO LIFT THE DISWASHER. DO NOT LEAVING DISCARDED PACKAGING MATERIALS UNSUPERVISED WITHIN THE HOME.
  • Page 6 WARNINGS DO NOT OPERATE THE DISHWASHER UNLESS ALL THE OUTER PANELS HAVE BEEN POSITIONED CORRECTLY. IMMEDIATELY AFTER INSTALLATION, BRIEFLY TEST THE APPLIANCE FOLLOWING THE INSTRUCTIONS INDICATED BELOW. IF THE DISHWASHER FAILS TO OPERATE CORRECTLY, DISCONNECT IT FROM THE ELECTRICAL POWER SUPPLY AND CALL THE NEAREST TECHNICAL SERVICE CENTRE.
  • Page 7: Installation Material

    INSTALLATION INSTRUCTION 3 INSTALLATION MATERIAL To install the dishwasher correctly, the following materials are required: phillips screwdriver ( rif. A Fig. 1); Ÿ spirit level (rif. B Fig. 1); Ÿ tape measure ( rif. C Fig. 1); Ÿ compass saw ( rif. D Fig. 1); Ÿ...
  • Page 8: Kit Supplied Dishwasher (Fully Integrated)

    INSTALLATION INSTRUCTION Kit supplied with dishwasher (fully integrated) The kit supplied with the dishwasher comprises: • 1 adhesive steam guard or 1 steel steam guard (ref. A or B fi g. 2)*; • 1 template for door panel (ref. C fi g. 2); •...
  • Page 9: Kit Supplied Dishwasher (Integrated)

    INSTALLATION INSTRUCTION Kit supplied with dishwasher (integrated) The kit supplied with the dishwasher comprises: • 1 adhesive steam guard or 1 steel steam guard (ref. A or B fi g. 2)*; • 1 template for door panel (ref. C fi g.3); •...
  • Page 10: Dimensions Of Dishwasher

    INSTALLATION INSTRUCTION DIMENSION OF DISHWASHER A height B width C depth Integrated 81.8 cm ÷ 88.8 cm 57 cm - 22-7/16" dishwasher Fig. 4 32-13/64"÷ 34-61/64" 59.7 cm ÷ 59.9 cm Integrated with steel 23-1/2"÷ 23-37/64" 60 cm - 23-5/8" 86 cm ÷...
  • Page 11: Installation And Hook-Up

    INSTALLATION INSTRUCTION INSTALLATION AND HOOK-UP DURING INSTALLATION, TAKE CARE NOT TO INJURE YOURSELF ON THE SHARP EDGES OF THE APPLIANCE. Remove the polystyrene rack blocks. Position the appliance in the chosen installation position. The sides and rear of the appliance can lie against kitchen units or walls.
  • Page 12: Levelling

    INSTALLATION INSTRUCTION 5.1 Leveling Level the appliance using the relative adjustable feet (e.g.: ref. A fig. 5); use an open-ended wrench to rotate the feet until the dishwasher is perfectly level. Some models are fitted with just one rear foot which can be adjusted with a screw located at the bottom front of the appliance (ref.
  • Page 13: Connections

    INSTALLATION INSTRUCTION 5.2 Connections Install the dishwasher so as to allow ease of access to the electrical and hydraulic connections through the adjacent unit. These connections must never be behind the dishwasher. The inlet and drain hoses can be pointed in all directions.
  • Page 14: Connection To The Water Supply

    INSTALLATION INSTRUCTION 5.2.1 Connecting to the water supply PREVENTING THE RISK OF CLOGGING OR DAMAGE: IF THE WATER PIPE IS NEW OR HAS NOT BEEN USED FOR A LONG TIME, BEFORE CONNECTING TO THE WATER SUPPLY CHECK THAT THE WATER IS CLEAR AND FREE OF IMPURITIES, TO PREVENT DAMAGE TO THE APPLIANCE.
  • Page 15 INSTALLATION INSTRUCTION Do not cut the inlet hose (see fig. 10). If the hose is cut, the dishwasher will not work, water will leak and you may be injured. If the hose is too long, wind it up tidily and place it behind the appliance. The cable harness and electrical components must not come into contact with the hydraulic system and the water inlet and drain hoses.
  • Page 16: Connection To The Drain Hose

    INSTALLATION INSTRUCTION 5.2.1.2 Connecting to a drain hose Insert the relative hose into a drain with a minimum diameter of 4 cm (1-37/64") (ref. A fig.12); alternatively, place the hose on the sink (ref. B fig. 11) using the supplied hose support (see fig.13), but taking care to avoid obstructions or excessive curving.
  • Page 17 INSTALLATION INSTRUCTION Do not cut the inlet hose (see Fig. 14) If the hose is cut, the dihwasher will not work, water will leak and you may be injured. If the hose is too long, wind it up tidily and place it behind the appliance.
  • Page 18 INSTALLATION INSTRUCTION Connecting to a «T» union of the drain circuit MAKE THE CONNECTION UPLINE FROM THE SIPHON OF THE DRAIN LINE AND AT LEAST 400 mm (15-3/4 ") ABOVE THE FLOOR ON WHICH THE DISHWASHER WILL BE INSTALLED. 1. Connect the dishwasher drain hose (ref. A Fig. 16) to the «T» union (ref. B Fig.16) of the drain circuit using a 38 mm to 50 mm (1-1/2"...
  • Page 19 INSTALLATION INSTRUCTION Connecting to a waste disposal unit with an air gap MAKE THE CONNECTION UPLINE FROM THE SIPHON OF THE DRAIN LINE AND AT LEAST 400 mm (15-3/4 ") ABOVE THE FLOOR ON WHICH THE DISHWASHER WILL BE INSTALLED. 1.
  • Page 20 INSTALLATION INSTRUCTION Connecting to the air gap (no waste disposal unit) IMAKE THE CONNECTION UPLINE FROM THE SIPHON OF THE DRAIN LINE AND AT LEAST 400 mm (15-3/4 ") ABOVE THE FLOOR ON WHICH THE DISHWASHER WILL BE INSTALLED. 1. Connect the dishwasher drain hose (ref. A Fig. 18) to the air gap (ref.
  • Page 21 INSTALLATION INSTRUCTION Connecting to a waste disposal unit (no air gap) IMAKE THE CONNECTION UPLINE FROM THE SIPHON OF THE DRAIN LINE AND AT LEAST 400 mm (15-3/4 ") ABOVE THE FLOOR ON WHICH THE DISHWASHER WILL BE INSTALLED. 1. Remove the cover of the waste disposal unit (ref. A Fig. 19 ). 2.
  • Page 22: Electrical Connections And Warnings

    INSTALLATION INSTRUCTION 5.2.2 Electrical connections and warnings CHECK THAT THE VOLTAGE AND THE FREQUENCY OF THE MAINS MATCH THE RATINGS ON THE NAMEPLATE OF THE APPLIANCE POSITIONED ON THE INNER EDGE OF THE DOOR. IN THE EVENT OF DAMAGE TO THE SUPPLY CORD, HAVE IT REPLACED BY THE MANUFACTURER OR AN AUTHORIZED TECHNICAL SERVICE CENTRE.
  • Page 23: Commissioning

    INSTALLATION INSTRUCTION DO NOT CHANCE THE PLUG ATTACHED TO THE APPLIANCE. IF THE PLUG IS NOT SUITABLE FOR THE SOCKET, CALL IN A QUALIFIED ELECTRICIAN TO FIT A SUITABLE PLUG. THE PLUG AT THE END OF THE POWER CORD AND THE CORRESPONDING SOCKET MUST BE OF THE SAME TYPE AND MUST CONFORM TO CURRENT REGULATIONS GOVERNING ELECTRICAL APPLIANCES.
  • Page 24 INSTALLATION INSTRUCTION Fig.21 Fig.22 Put the dishwasher into position, taking care not twist or crush the power cord or hoses (see Fig. 23). TWO PEOPLE WEARING SAFETY GLOVES ARE NEEDED TO PUSH THE DISHWASHER INTO PLACE. Fig.23...
  • Page 25: Door Panel Assembly Procedure (Fully Integrated)

    INSTALLATION INSTRUCTION 5.3.2 Door panel assembly procedure (fully integrated) Mount the door panel. Place the template on the inner surface of the panel, centering it along the upper side and matching up the reference locators (ref. A Fig. 24); mark the position of the door hooks with a pencil (see Fig.
  • Page 26 INSTALLATION INSTRUCTION Drill holes for the panel handle using a drill with a suitable bit. Use the screw-driver to secure the door handle before hooking the panel to the dishwasher (see Fig. 26). N.B.: the screws are not supplied. Fig. 26 Attach the door panel: fit the hooks into their slots on the dishwasher and allow the panel to slide downwards and slip into place (see Fig.
  • Page 27: Door Panel Assembly Procedure (Integrated)

    INSTALLATION INSTRUCTION 5.3.3 Door panel assembly procedure (integrated) Mount the door panel. Place the template on the inner surface of the panel, centering it along the upper side and matching up the reference locators (ref. A Fig. 28); mark the position of the door hooks with a pencil (see Fig. 28). Remove the template and use a drill with a suitable bit to make holes at the points marked on the panel.
  • Page 28 INSTALLATION INSTRUCTION If a gap is created between the control panel and the door panel (ref. A Fig.30), use the supplied strips (ref. B Fig.30) to fill it. The number of strips depends on the size of the gap. Fig.30 Position the strips between the control panel and the door panel of the dishwasher (ref.
  • Page 29: Door Screwing Procedure

    INSTALLATION INSTRUCTION Attach the door panel: fit the hooks into their slots on the dishwasher and allow the panel to slide upwards and slip into place (see Fig. 32). Fig.32 5.3.4 Door screwing Secure the door to the panel with the supplied screws. The panel must have a minimum tickness of 20mm (25/32") (see Fig.
  • Page 30: Completion Of Installation

    INSTALLATION INSTRUCTION 5.3.5 Completion of installation (if necessary, for all models) Make sure the dishwasher door, complete with panel, opens confortably and that the base plate (ref. A Fig. 34-35) does not prevent it from opening fully. If the base plate prevents the door from opening, mark out the section to remove (see Fig.
  • Page 31 INSTALLATION INSTRUCTION Finish the cut with a file (see Fig. 37), in order to remove any burrs and/or imperfections. Put back the base plate (see Fig. 38) and try to open the dishwasher door fully; if the base plate still obstructs the door, repeat the above operations.
  • Page 32: Apply The Gaskets - Type A

    INSTALLATION INSTRUCTION Apply the gaskets - Type A (the shape of the gaskets depends on the model) Before securing the dishwasher to the adjacent units, attach the gaskets to the sides. Remove the adhesive band on the gasket (see Fig. 39) Fig.39 Fix the gasket to the dishwasher, inserting it in the seat on the sides towards the front (see Fig.39), and making sure that the long side of the...
  • Page 33 INSTALLATION INSTRUCTION Fig.44 Fig.42 shows the state of the dishwasher after the above operations are performed. Fig.42...
  • Page 34: Apply The Gaskets - Type B

    INSTALLATION INSTRUCTION Apply the gaskets - Type B (the shape of the gaskets depends on the model) Before securing the dishwasher to the adjacent units, attach the gaskets to the sides. Remove the adhesive band on the gasket (see Fig. 43) Fig.43 Fix the gasket to the dishwasher, inserting it in the seat on the sides towards the front (see Fig.43), and making sure that the long side of the...
  • Page 35 INSTALLATION INSTRUCTION Fig.45 Fig.46 shows the state of the dishwasher after the above operations are performed. Fig.46...
  • Page 36: Testing

    INSTALLATION INSTRUCTION Tighten the supplied screws with a screwdriver; this operation definitively fixes the dishwasher to the adjacent units; cover the side holes using the supplied plugs ( rif. A Fig.47 ). Fig.47 5.6 Testing After installation, test the dishwasher by starting a work cycle. Check for leaks and make sure the appliance does not malfunction...
