- Page 1 Thomson WhisperTrak™ Electric Linear Actuator Installation Manual Edition 2011-06 DW110685-NA-1126 www.thomsonlinear.com...
- Page 2 (12) months from date of delivery. The application of this product is the responsibility of the buyer and Thomson makes no representation or warranty as to the suitability of the product for any particular use or purpose. For a copy of the entire warranty for this product that is contained in our standard terms and conditions of sale, please go to http://www.thomsonlinear.com/website/com/...
-
Page 3: Table Of Contents
4.6 Wire cross section ....................9 5. Technical specifications ................ 10 5.1 Dimensions ......................10 5.2 Performance diagrams ..................10 5.3 Technical data ...................... 11 5.4 Type designation key ................... 11 Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 4: General
1.6 Disposal Where required by law, used packaging and actuators are taken back by Thomson for professional disposal if the transportation cost is taken over by the sender. Please contact Thomson for information on where to ship it. 1.7 Support In case you need technical support or any information related to this product, please contact the nearest Thomson Service Center. -
Page 5: Safety
Can be used when the machine or the system, which it shall be, a part of is in accordance with the demands in the EEC Machinery Directive and/or other relevant regulations. Kristianstad 2011-01-24 Date Håkan Persson Product Line Manager Name Title Signature Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 6: Installation
Please study the name plate to see what type of actuator you have before starting any installation or service on the actuator. If you need any assistance from Thomson, please tell us the manufacturing date and the deisgnation of the actuator(s) in question. -
Page 7: Mechanical Installation
If the anti-rotation option is not selected, for proper function, the application must provide a minimum restraining torque of 11 Nm between the mounting pins. Otherwise the extension tube will rotate. Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 8: Electrical Installation
• Make sure that the switch can handle the maximum motor current. Actuators with ELS option (E) • The actuator will automatically switch off when reaching the ends of stroke or if a mid-stroke overload occurs. Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 9: Wire Cross Section
Wire cross sections Lenght of cable (L) Min. allowed cross section (X) 00 - 10 m 1.0 mm (AWG 18) 10 - 20 m 1.5 mm (AWG 14) Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 10: Technical Specifications
438 (17.24) 589 (23.19) 689 (27.13) Weight [kg (lbs)] 1.20 (2.65) 1.35 (2.98) 1.5 (3.31) 1.65 (3.64) 1.80 (3.97) 5.2 Performance diagram Speed Current @ 12 VDC Current @ 24 VDC Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... -
Page 11: Technical Data
Definition of front and rear adapter hole positions. 50- = 500 mm 5. Limit switch and feedback options N = no option E = electronic limit switches / low level switching (ELS) Standard position Adapters turned 90° Thomson WhisperTrak™ Electric Linear Actuator - Installation Manual - 2011-06... - Page 12 E-mail: sales.scandinavia@thomsonlinear.com www.thomsonlinear.com DW110685-NA-1126 ENG Specifications are subject to change without notice. It is the responsibility of the product user to determine the suitability of this product for a specific application. All trademarks property of their respective owners. © Thomson 2011.
