E2S STExC1 Instruction Manual page 10

2
1
WIRING LINKING BEACON & SOUNDER
A
FACTORY FITTED
Three/Four Stages. Voltage Free 2nd, 3rd & 4th Stage Activation Configuration
Common Positive
Customer Set H1 & H2 to Negative Switching (See Below)
Stage 1: Apply Power to Common +ve & Stage 1 -ve
B
Stage 2: Apply Power to Common +ve & Stage 1 -ve & connect Stage 2 -ve to Stage 1 -ve
Stage 3: Apply Power to Common +ve & Stage 1 -ve & connect Stage 3 -ve to Stage 1 -ve
Stage 4: Apply Power to Common +ve & Stage 1 -ve
& connect Stage 2 -ve & Stage 3 -ve to Stage 1 -ve
C
D
E
Set H1 & H2 to -ve switching
H1
F H2
DRAWING TO BS8888:2000
DRAWN
GEOMETRIC TOLERANCES TO ISO1101:1983
LINEAR DIMENSIONAL TOLS
R.S.RAIT
ANGULAR DIMENSIONAL TOLS
CHECKED
G
B.ISARD
STANDARDS
APPROVED
ALERTALARM RANGE
R.N.POTTS
3 4
OPTIONAL LINE MONITORING RESISTOR, CUSTOMER SUPPLIED,
RECOMMENDED MINIMUM VALUES:
14V MAX SYSTEM = 120Ω MIN, 2W MIN OR 1KΩ MIN, 0.5W MIN
28V MAX SYSTEM = 470Ω MIN, 2W MIN OR 2.4KΩ MIN, 0.5W MIN
Linked Sounder & Beacon Activation (Default)
Common +ve IN
Common +ve OUT
Stage 1 -ve OUT
Stage 1 -ve IN
Stage 2 -ve
Stage 3 -ve
SURFACE FINISH WEIGHT (Kg)
DATE
19/01/2022
MATERIAL
DATE
19/01/2022
ALTERNATIVE MATERIAL
DATE
19/01/2022
5
6
SWITCHES FOR STAGE OPERATION
CUSTOMER SUPPLIED
Config.: 2 Two Stage Configuration
Independent Stage Input
Reverse Polarity Stage Monitoring
Stage 1: Apply Power to Stage 1 +ve & Stage 1 -ve
Stage 2: Apply Power to Stage 1 +ve & Stage 1 -ve & connect Stage 2 -ve to Stage 1 -ve
+
-
+
+
-
Set H1 & H2 to -ve switching
-
H1
H2
S2
S3
Cut Link W1
THIS DRAWING AND ANY INFORMATION OR DESCRIPTIVE
MATTER THEREIN IS COMMUNICATED IN CONFIDENCE AND
IS THE COPYRIGHT PROPERTY OF EUROPEAN SAFETY
SYSTEMS LTD. NEITHER THE WHOLE OR ANY EXTRACT MAY
BE DISCLOSED, LOANED, COPIED OR USED FOR
MANUFACTURING OR TENDERING PURPOSES WITHOUT THEIR
WRITTEN CONSENT.
EUROPEAN SAFETY SYSTEMS LTD.
C
AS PER LATEST DATE OF ISSUE SHOWN ABOVE
8 9
7
ISSUE MOD No. REASON - INITIAL - DATE
INTRODUCTION
1
RSR - 19/01/2021
Stage 1 +ve
Stage 1 -ve
Stage 2 -ve
Stage 2 +ve
ALL DIMENSIONS IN MM
2S
IF IN DOUBT, ASK -
DO NOT SCALE
warning signals
TITLE
D1xC1X / D1xC2X / STExC1X DC SOUNDER /
EUROPEAN SAFETY SYSTEMS LTD
XENON WIRING DIAGRAMS
IMPRESS HOUSE
MANSELL ROAD
ACTON
DRAWING NUMBER
LONDON W3 7QH SCALE SHEET
WWW.E2S.COM
NTS 2
6
OF
10
A
Config.: 3
B
C
D
+
-
E
+
+
-
-
F
S2
A3
G
D190-06-201
