S900 Alternate Remote Update Process. V2
The following instructions provide an alternate method of remote recovery of a PAX S900 using a Wi-Fi internet
connection, following issues preventing the device from functioning normally.
You should expect this process to take approximately 20 minutes, though the majority of that takes place during
the final download stage which does not require full attendance. An unlimited number of devices can be
completed in parallel.
Some of the early steps are time-sensitive, it is recommended to review the complete guidance before starting the
procedure.
NOTE: If your PAX S900 is connected only via GPRS (2G – Mobile/Cellular) then please prepare a Wi-Fi connection, this
cannot be performed via mobile connections.
Turn off the device (Hold the RED Button)
1
even if doing so requires the removal of a power supply or battery
Turn on the device (hold the RED button)
(!) Attention
During start-up press the "2" button repeatedly to enter the System Menu.
2
It is possible to press 2 accidentally once the menu has been displayed –
this is normal. Should this occur, please use the red key to "back up" until
the menu displayed looks like this, with the heading "Main Menu":
Enter "System Config" menu
4
Press "1" selecting "System Config"
1
Advertisement
Related Manuals for PAX S900
Summary of Contents for PAX S900
- Page 1 Some of the early steps are time-sensitive, it is recommended to review the complete guidance before starting the procedure. NOTE: If your PAX S900 is connected only via GPRS (2G – Mobile/Cellular) then please prepare a Wi-Fi connection, this cannot be performed via mobile connections.
- Page 2 Enter the Password When prompted to do so, enter the system password. It will be one of four 6-digit options. If one fails, please try another until successful. The options are: 123456 505640 525640 or 408625 Press “Remote Load” The menu will now display “System Config” in the blue heading bar at the top of the display.
- Page 3 Press “WIFI” (!) Attention Please make sure your WiFi point or a hotspot point are already available Enter the Remote IP address When prompted, key in the following “Remote IP” Address and confirm by pressing the green enter key. 101.68.92.243 (!) Attention There are some variances as to how the keyboard input works between devices.
- Page 4 Enter the Terminal ID You will now be prompted to specify a “Terminal ID”. Key in the following 8- Digit number and press the green enter key. 97979705 “WiFi Open Succ” Should be briefly displayed on screen Select the WIFI network The terminal will then scan for available Wi-Fi networks.
-
Page 5: Initial Download
Initial Download After a short delay, the terminal will connect to your network and immediately download a small file. If the terminal then displays the message “Download Succ!!” then this step has completed successfully. (!) Attention However, if an error code is displayed: A. - Page 6 Main download The terminal will again scan for available Wi-Fi networks. Find and select your Wi-Fi Network again by pressing the touchscreen or corresponding number. Your Wi-Fi Password should have been saved from the previous step, so just press the green enter key to continue. The device will again connect to the host and begin a second download.
