DEMO MANUAL DC2050A
PARTS LIST
ITEM QTY REFERENCE
31 1 R16
32 1 R17
33 2 R18, R19
34 2 R20, R28
35 1 R23
36 1 R25
37 1 R26
38 1 R29
39 1 R32
40 1 R33
41 1 T1
42 1 U1
43 1 U2
44 1 U3
Additional Demo Board Circuit Components
1 0 CO2 (OPT)
2 0 C31 (OPT)
3 0 R10 (OPT)
Hardware-For Demo Board Only
1 2 E1, E2
2 4 E3, E4, E5, E6
3 4 J1-J4
4 4 MH1-MH4
5 1
6
PART DESCRIPTION
RES., Chip, 34.8k, 0.1W, 1% 0603
RES., Chip, 15Ω, 0.1W, 5% 0603
RES., Chip, 100k, 0.1W, 5% 0603
RES., Chip, 137k, 0.25W, 1% 0603
RES., Chip, 100Ω, 0.1W, 5% 0603
RES., Chip, 10k, 0.1W, 5% 0603
RES., Chip, 200Ω, 0.125W, 1% 0805
RES., Chip, 100Ω, 0.125W, 1% 0805
RES., Chip, 5.1Ω, 0.125W, 5% 1206
RES., Chip, 5.1Ω, 0.125W, 5% 0805
TRANSFORMER,
I.C., LT3753EFE#TRPBF, TSSOP-38(31)
I.C., PS2801C-1-P-A
I.C., LT1431CS8 SO8
CAP., 1210
CAP.,
RES., 0603
TESTPOINT, TURRET, 0.061" PBF
TESTPOINT, TURRET, 0.094" PBF
BANANA JACK
STAND-OFF, NYLON 0.25"
FAB, PRINTED CIRCUIT BOARD
MANUFACTURER/PART NUMBER
VISHAY, CRCW060334K8FKEA
VISHAY, CRCW060315R0JNEA
VISHAY, CRCW0603100KJNEA
VISHAY, CRCW0603137KFKEA
VISHAY, CRCW0603100RJNEA
VISHAY, CRCW060310K0JNEA
YAGEO, RC0805FR-07200R
VISHAY, CRCW0805100RFKEA
VISHAY, CRCW12065R10JNEA
VISHAY, CRCW08055R10JNEA
CHAMPS, G45R2-0209
LINEAR TECH., LT3753EFE#TRPBF
NEC, PS2801C-1-P-A
LINEAR TECH., LT1431CS8#TRPBF
MILL-MAX, 2308-2-00-80-00-00-07-0
MILL-MAX, 2501-2-00-80-00-00-07-0
KEYSTONE, 575-4
KEYSTONE, 8831(SNAP ON)
DEMO CIRCUIT 2050A
