Page 1
I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Medium Flat Panel Steel Stud Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description JWDSK210...
JWDSK210 Installation Instructions DISCLAIMER WARNING: Failure to read, thoroughly understand, and CSAV, Inc., and its affiliated corporations and subsidiaries follow all instructions can result in serious personal injury, (collectively, "CSAV"), intend to make this manual accurate and damage to equipment, or voiding of factory warranty! It is the complete.
Page 3
Installation Instructions JWDSK210 TOOLS REQUIRED FOR INSTALLATION AND PARTS 1/2" (Ø13mm) (3/16") (5/32") A (1) B (2) T (4) F (4) E (6) C (4) D (4) M4 x 12mm M4 x 12mm M4 x 16mm M4 x 20mm M4 x 8mm U (4) (1/4")
JWDSK210 Installation Instructions Site Requirements WARNING: IMPROPER INSTALLATION CAN LEAD TO EQUIPMENT FALLING CAUSING SERIOUS PERSONAL INJURY OR DAMAGE TO EQUIPMENT! The figure below identifies the minimum reguirements for installation of display mounts onto a steel stud structure. If the structure or its components do not meet these requirements contact the mount manufacturer for specific instructions before attempting installation.
Page 5
Installation Instructions JWDSK210 Mount Installation After determining the site meets the installation requirements: Drywall 1. Identify desired mounting location on wall. 2. Using a stud finder or similar method locate studs. 3. Align mounting holes in mount with studs making sure Plastic Straps mounting holes are centered on studs.
JWDSK210 Installation Instructions Display Installation Steel Stud The mounting holes on the back of your display will either be Drywall flush with the back surface, or recessed into the back surface. Refer to the applicable installation procedure. Plastic Cap Flush Mount Display...
Page 7
Installation Instructions JWDSK210 Tighten all hardware. Back of Display (T) x 1 (K,O) x 4 (D, E, F, G, H, L, M, N) Figure 9 (D) x 2 Tighten all hardware. Start two Phillips pan head screws (C) into top mounting holes (100 x 100) in interface bracket (X).
JWDSK210 Installation Instructions ADJUSTMENTS Swing Arm PIVOT / SWING (X) x 1 Using 3/16" hex key, slightly loosen or tighten the adjustment screw(s) as necessary (See Figure 13). Adjustment Screws (C) x 2 Figure 11 Figure 13 Centris Head CABLE MANAGEMENT If previously attached, disconnect cables from display, then Attach all cables to display.
