- Page 1 SERIES ETSV SUBMITTAL DOCUMENT MODELS: ETSV40, ETSV80 Series ETSV - Models 40, 80 Page 1 September 14, 2020...
-
Page 2: Table Of Contents
SERIES ETSV SUBMITTAL DOCUMENT MODEL: ETSV40, ETSV80 TABLE OF CONTENTS SUBMITTAL FORM ....... . . 3 PRODUCT DETAILS . -
Page 3: Submittal Form
NOW AVAILABLE NOW AVAILABLE IN BLACK SUBMITTAL FORM PROJECT: __________________________________________________________________________________________________________________________ ADDRESS: _________________________________________________________________________________________________________________________ CITY: ____________________________ STATE/PROV: ________________________ POSTAL CODE/ZIP: _____________ COUNTRY: __________________ ENGINEER: _____________________________________________________ ENGINEER FIRM: ________________________________________________ CONTRACTOR: ____________________________ MODEL#: ___________________________________ DATE: ______________________________________ SUBMITTED BY: ________________________________________________ APPROVED BY: __________________________________________________ Page 3 September 14, 2020 Series ETSV - Models 40, 80... -
Page 4: Product Details
PRODUCT DETAILS MODEL EXTERIOR FINISH LENGTH GAS TYPE RATED BTU/HR INPUTS Marine Grade High 38,500 ETSV40 145�25” Aluminum Low 23,000 High-Temp Black Powder High 38,500 ETSV40BL Coated on Marine Grade 145�25” Low 23,000 Aluminum Marine Grade 316 High 38,500 ETSV40MS 145�25”... - Page 5 Combustible Wall Mounting Bracket kits SRP has developed combustible wall mounting bracket kits for the model ETSV� The current wall mount bracket kit, in 304 S/S or black finish is made with a shorter bracket (CR139), which is only suitable for non-combustible installations� The new wall mount bracket kit in 304 S/S or black finish is made with a larger bracket (CR225) which meets the clearance requirements for mounting on a combustible surface�...
-
Page 6: Etsv Features
ETSV FEATURES MADE IN CANADA 0% TUBE IMPINGEMENT Reliable • High Quality • Durable • Excellent Warranty Absolutely no infrared is absorbed by the tube EASY TO INSTALL MINIMIZED CLEARANCES Maintenance free heat solution Clearance to combustibles as low as 2” ENCLOSED &... -
Page 7: Performance Charts
PERFORMANCE CHARTS Input Updates Power & Gas Specifications MODEL ETSV40 ETSV80 Rated Input High Fire Rate 38,500 BTU/HR 80,000 BTU/HR Low Fire Rate 23,000 BTU/HR 50,000 BTU/HR Inlet Pressure Natural Gas Maximum 14.0” W.C. Minimum 5.0” W.C. Inlet Pressure Propane Maximum 14.0”... -
Page 8: Technical Specifications
TECHNICAL SPECIFICATIONS Pre-Install Dimensions Note: All dimensions are in inches Model ETSV40 Model ETSV80 Series ETSV - Models 40, 80 Page 8 September 14, 2020... -
Page 9: Heater Mounting & Bracket Specifications
Heater Mounting & Bracket Specifications Standard ceiling/wall mounting kits ETSV All Models The heater can be mounted in a variety of ways, using a combination of chains or mounting brackets� It is critical that the heater is prevented from swaying and putting stress on the gas connection� Also, be sure to check local codes for seismic bracing requirements for outdoor heating equipment�... - Page 10 Ceiling and wall mount brackets are available for all ETSV models Standard Ceiling Mounting All Models 30° Ceiling Angle Mounting All Models 30° Wall Angle Mounting All Models Combustible Wall 30° Angle Mounting Bracket kits All Models CR225 Surface area = 140�69 square inches For further information and assistance please contact us at info@irenergy�ca or 1 855 295 3922 Series ETSV - Models 40, 80 Page 10...
-
Page 11: Electrical Wiring
Electrical Wiring General Requirements Heaters are normally controlled by line voltage (120V) or low voltage (24V) thermostats� Line voltage thermostats are wired directly while low voltage thermostats use a relay� In all cases, heaters must be grounded in accordance with the National Electric Code, ANSI/NFPA 70 in the US, and the Canadian Electric Code, CSA C22�1 in Canada, and must comply with all local requirements�... -
Page 12: Multiple Heaters Wiring (Thermostat)
Multiple Heaters Wiring (Thermostat) Series ETSV - Models 40, 80 Page 12 September 14, 2020... -
Page 13: Timer Specifications
Timer Specifications Timer Mode (Optional Feature) Application of input voltage to the timer energizes the load and starts the time delay� At the end of the time delay, the load is de-energized� Removal and re-application of input voltage resets the timer� Has the capability to be installed in the burner or externally�... -
Page 14: Venting
Venting General Requirements • Refer to the National Fuel Gas Code, ANSI Z223�1 (NFPA 54) in the USA and CSA B149�1 Installation Codes in Canada, as well as all local requirements for general venting guidance� • Series ETSV Heaters may be installed vented or unvented� •... - Page 15 Vented Operation Horizontal Venting • Requirements for combustion air supply and dilution air vary by jurisdiction, building type and specific installation details� See local codes for guidance� In general, fresh air ventilation must be provided to the building space at 3 cfm per 1000 BTU/Hr in Canada and 4 cfm per 1000 BTU/h in USA�...
- Page 16 Note: Horizontally vented heaters must be individually vented and cannot use a common vent� Combustion Air Supply (Optional) • An outside combustion air supply is strongly recommended if the building space encloses a negative pressure due to ex- haust etc� or if the building contains materials which would expose the heater to halogenated hydrocarbon atmospheres� •...
-
Page 17: Install
Install External Wiring Options (Outdoor Installation Only) NEMA RATINGS NEMA ratings are specific enclosure ‘types’, their applications, and the environmental conditions they are designed to protect against, when completely and properly installed� NEMA4 – Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against incidental contact with the enclosed equipment;... -
Page 18: Multiple Heater Wiring (Switch P/N Ee020)
Multiple Heater Wiring (Switch P/N EE020) Series ETSV - Models 40, 80 Page 18 September 14, 2020... -
Page 19: Connections
Connections Connections for all ETSV Models Installation must comply with local building codes and/or, for the USA/National Fuel Gas Code, ANZI Z 223.1 (NFPA 54) and for Canada, CSA B149.1 National Gas and Propane Installation Code (latest editions). Appliance must be electrically grounded in accordance with local codes or, in their absence; the National Electrical Code, ANSI/NFPA 70 in the USA, CSA C22.1 Canadian Electrical Code in Canada. -
Page 20: Clearance To Combustibles
Clearance to Combustibles General Recommendations A general clearance of 18” (0�5 m) in every direction is recommended for servicing around each Burner� This ensures adequate air flow in and around the Heating System� In addition to this it is very important to observe the minimum clearance to combustibles at all times to avoid any possibility of property damage or personal injury. -
Page 21: Post-Install
Post-Install Durability Some of our customers live around the coast, so we make sure our units are upgraded to a standard component and hardware list� • Epoxy coated ignition module - Smart LED • Hi–temp wires equipped with a rubber boot for the main ignition wire •... - Page 22 SERIES ETSV SUBMITTAL DOCUMENT MODELS: ETSV40, ETSV80 CANADA 563 Barton St�, Stoney Creek, ON L8E 5S1 315 N Madison St�, Fortville, IN 46040 T� 905 664 9082 | TF� 855 295 3922 T� 905 664 9082 | TF� 855 295 3922 info@irenergy�ca info@irenergy�ca www�irenergy�ca...
