Lincat BPSM7 Manual

Lincat BPSM7 Manual

Refigerated cabinets and work tables
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation, Operating and Servicing
Instructions
REFIGERATED CABINETS AND WORK TABLES
BPSM7, BPSM14, BPSB7, BPSB14
BPETM2, BPETM3
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS791 ECN 4879
Page 1 of 34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPSM7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lincat BPSM7

Summary of Contents for Lincat BPSM7

  • Page 1 Installation, Operating and Servicing Instructions REFIGERATED CABINETS AND WORK TABLES BPSM7, BPSM14, BPSB7, BPSB14 BPETM2, BPETM3 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS791 ECN 4879 Page 1 of 34...

  • Page 2: Table Of Contents

    CONTENTS IMPORTANT INFORMATION ............................3 WARNINGS AND PRECAUTIONS ..........................4 1.1 TESTING AND INTENDED USE ........................4 INTRODUCTION ............................4 1.3 PRODUCT DESCRIPTION..........................4 1.4 GENERAL SAFETY REGULATIONS ....................... 5 1.5 CUSTOMER’S RESPONSIBILITIES ........................ 6 1.6 CUSTOMER SERVICE REQUESTS ......................... 6 1.7 ORDERING OF SPARE PARTS ........................

  • Page 3: Important Information

    WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol isused whenever there is a risk of damaging your Lincat product. NOTE: This symbol isused to provide additional information, hints and tips. KEEP THIS MANUAL FOR FUTURE REFERENCE...

  • Page 4: Warnings And Precautions

    WARNINGS AND PRECAUTIONS 1.1 TESTING AND INTENDED USE This equipment is tested in compliance with established regulations and then shipped ready for use. “If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.” INTRODUCTION This manual provides all instructions required for the correct use of the equipment and to keep it in optimal condition.

  • Page 5: General Safety Regulations

    safety including radius interior corners, funnel-shaped base panel to convey condensate to exterior, no rough surfaces, fixed guards protecting moving or potentially dangerous parts. 1.4 GENERAL SAFETY REGULATIONS Read this manual carefully and follow the instructions contained herein. The user assumes full responsibility in case of operations carried out without observing the instructions in the manual.

  • Page 6: Customer's Responsibilities

     ARNING:   Do not damage the refrigerant circuit. Do not use FLAME to check for gas leak. Do not under any circumstances try to modify or repair valves, regulator, connectors, controls or any other appliance. Doing so creates the risk of a gas leak. 1.5 CUSTOMER’S RESPONSIBILITIES The customer is required to: ...
  • Page 7 Electrical Shock LABEL A Use of this equipment involves power supplies which convert line voltage to low voltage power. Do not modify or use power supplies other than OEM equipment. Connection of the power supply may require a properly grounded receptacle.
  • Page 8 Refrigerating Equipment intended for laboratory use. Packaging markings (Label attached upon the cartoon box) Service markings. (Label located near the cooling unit compartment) Service markings (Label located near the cooling unit compartment IS791 ECN 4879 Page 8 of 34...
  • Page 9 Disposal (Marking attached upon the exterior of the cabinet) Max high load IS791 ECN 4879 Page 9 of 34...

  • Page 10: Technical Data

    Adjustable temperature control range: lowest T = -2 °C (-28°F), highest T = 8 °C (46°F) Operating temperature: 0°C to 2°C (32°F to 36°F) Factory pre-set to: 2°C (36°F) Models:BPSM7, BPSM14 Under counterchillers Adjustable temperature control range: lowest T = -2 °C (-28°F), highest T = 8 °C (46°F) Operating temperature: 0°C to 2°C (32°F to 36°F)

  • Page 11: Installation And Commissioning

    BPETM3 177,5 230/1/50 Note: All relevant data referring to these products can be found on the data label visible either on the rear part of the cabinet or inside the cooled compartment . Here is an example of the label: How to read the Serial Number: XXXXXX Last two numbers of the production...

  • Page 12: Positioning

    The equipment is secured to a wooden pallet base, wrapped in a plastic film and packaged into a three waves carton box.. The equipment must be handled using a fork lift truck or a pallet truck with suitable forks (fork length at least equal to 2/3 length of unit). 2.2 POSITIONING Incorrect positioning can cause damage to the equipment and generate hazardous conditions for personnel.

  • Page 13: Set Up Operations

    If the SUPPLY CORD is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. 2.4SET UP OPERATIONS To avoid errors and accidents, perform a series of checks for possible damage sustained during transport, installation and hook-up operations before starting up the unit.

  • Page 14: Operating Instructions

     Electrical and electronic equipment (WEEE) The manufacturer shall not be chargeable for any disposal of the apparatus at the end of its working life. In line with EU Directive 2002/96/EC for waste electrical and electronic equipment (WEEE), this electrical product must not be disposed of as unsorted municipal waste.

  • Page 15: Regulation

    Connections: Fixed screws terminal blocks for wires up to 2,5 mm ; removable screw terminal blocks for wires up to 2,5 mm (by request); Micro-MaTch connectors. Maximum length allowed to the connection cables: 10 meters (32,8ft) for power supply cord; 10 meters (32,8ft) for Analogue inputs; 10 meters (32,8ft) for Digital inputs; 10 meters (32,8ft) for Digital outputs.

  • Page 16: Controller User Interface And Main Function

    3.1.2 CONTROLLER USER INTERFACE AND MAIN FUNCTION Use of LEDs Reduced Set/Economy Set Fan LED Permanently ON: Energy Saving ON Permanently ON: Fan active Blinking: Reduced set point active OFF: Otherwise Rapid blinking: access to level 2 password OFF: Otherwise Compressor LED Alarm LED Permanently ON: Compressor active...

  • Page 17: Switching The Device On/Off

    3.1.3 Switching the device ON/OFF The instrument can be switched off/on by pressing the key for longer than 5 seconds. Switching off the device, the adjustment algorithms and defrost cycles are disabled and the text “OFF” will appear on the display. Once the device is switched on the display will show the actual air temperature read by the air probe.

  • Page 18: 7Alarms

    - E2: In the event of defrost probe faulty (Pb2), the indication “E2” will appear on the display 3.1.7ALARMS Label Fault Cause Effects Remedy Probe1 faulty -measured values -Display label E1 -check probe type (cold room) outside operating range -Alarm icon permanently -check probe wiring -Probe faulty/short-...

  • Page 19: 8Controller's Input/Output

    -Recording of folder nPA on the D.I. (Automatic in folder AL, with the Reset) number pressure switch activations -Regulation locked (Compressor and Fans) General Activation pressure number -Switch the device off pressure alarm by general pressure switch and back on again switch alarm pressure switch.
  • Page 20 CAUTION!The modification of a level 2-parameter without authorization of the manufacturer causes the lost of guarantee. Parameter Description Range Unit of M. Compressor parameters (CP folder) 0,1 …. 30,0 Differential: Compressor relay activation differential. N.B.: °C/°F diF cannot be equal to 0. Maximum value that can be assigned to the Setpoint.
  • Page 21 Parameter Description Range Unit of M. Temperature threshold for start of defrost -67.0 .. 320 °C/°F Time for which the temperature of the evaporator must 0 .. 250 remain below dSE Fan regulator parameters (FAn folder) Characterizes the "FSt" parameter that can be expressed Flag or as an absolute temperature value or as a value related to Setpoint.
  • Page 22 Parameter Description Range Unit of M. absolute value based on Att) which, if exceeded in an upward direction, triggers the activation of the alarm signal.See "Max/Min Temperature Alarms". LAL (!) Minimum temperature alarm. Temperature value -67,0 to HAL °C/°F (intended as distance from the set point or as an absolute value based on Att) which, when exceeded downwards, triggers the activation of the alarm signal.See "Max/Min Temperature Alarms".
  • Page 23 Parameter Description Range Unit of M. ENERGY SAVING parameters (EnS folder) Energy Saving mode: 0 ... 6 -0= disabled; -1= Offset on setpoint; -2= Offset on differential; -3= Offset on setpoint and differential; -4= Bottle cooler open front' algorithm; -5= Bottle cooler glass door' algorithm; -6= Vertical display cabinet' algorithm AUX output status in energy saving mode: 0/1/2...
  • Page 24 Parameter Description Range Unit of M. read by Pb2. This sum is used both for the temperature displayed and for regulation. Calibration 3. -12,0...12,0 °C/°F Positive or negative temperature value added to the value read by Pb3. This sum is used both for the temperature displayed and for regulation.

  • Page 25: Maintenance And Cleaning

    Parameter Description Range Unit of M. present. Probe 3 present (Pb3). n= not present; y= present. Flag reLease firmware. Device version: read-only parameter tAble of parameters. Reserved: read-only parameter MAINTENANCE AND CLEANING Maintenance and repair must be carried out by qualified personnel authorized by the manufacturer.

  • Page 26: Troubleshooting

    Always switch off the unit and disconnect power cord before cleaning, it is dangerous to do it with power ON: fan may start suddenly at any time. Use a convenient ladder to reach the condenser. Use an air jet or vacuum with a soft dry brush if necessary and remove any dust or fluff from the heat exchanger fins.

  • Page 27: Spare Parts List

    ALUMINUM DOOR BOTTOM BRACKET DOOR SPRING HINGE KIT DOOR UPPER HINGE BUSH DOOR UPPER HINGE W/PIVOT NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 EO 230V LINCAT LOGO STICKER TOP FACADE DOOR SWITCH NET FILTER FAST FUSE FUSE HOLDER IS791 ECN 4879...
  • Page 28 DOOR SPRING HINGE KIT FUSE HOLDER FAST FUSE NET FILTER NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 EO 230V LINCAT LOGO STICKER DOOR UPPER HINGE BUSH DOOR UPPER HINGE W/PIVOT DOOR SWITCH TOP FACADE IS791 ECN 4879 Page 28 of 34...
  • Page 29 DOOR UPPER HINGE BUSH DOOR UPPER HINGE W/PIVOT DOOR FRAME HEATER MOD. 44W 230V L=4400mm NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 EO 230V LINCAT LOGO STICKER TOP FACADE MOD. 49cu.ft UP-RIGHT CABINET NET FILTER DOOR SWITCH FAST FUSE FUSE HOLDER...
  • Page 30 IS791 ECN 4879 Page 30 of 34...
  • Page 31 ALUMINUM DOOR BOTTOM BRACKET DOOR SPRING HINGE KIT FAST FUSE FUSE HOLDER NET FILTER NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 EO 230V LINCAT LOGO STICKER DOOR UPPER HINGE BUSH DOOR UPPER HINGE W/PIVOT DOOR SWITCH IS791 ECN 4879 Page 31 of 34...
  • Page 32 MOTOR COMPARTMENT FRONT PANEL FUSE HOLDER FAST FUSE NET FILTER NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 EO 230V FAN uR% SWITCH LINCAT LOGO STICKER UPPER HINGE BUSH UPPER HINGE PIVOT MOD. BRASS 24,5x7,9xM6 IS791 ECN 4879 Page 32 of 34...
  • Page 33 MOTOR COMPARTMENT FRONT PANEL FUSE HOLDER FAST FUSE NET FILTER MOD. 16S7D-A147410 16A NTC TEMPERATURE PROBE CONTROLLER MOD. EWP974 230V FAN uR% SWITCH LINCAT LOGO STICKER UPPER HINGE BUSH UPPER HINGE PIVOT MOD. BRASS 24,5x7,9xM6 IS791 ECN 4879 Page 33 of 34...

  • Page 34: Service Information

    All available on serial plate Type number  Serial number Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
