Installation, Operating and Servicing
Instructions
Seal Upright Heated Merchandisers
UM50, UM50D, UMS50, UMS50D, UMO50,
UMO50D, UMSO50, UMSO50D
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 287 ECN 4838
Page 1 of 10
Advertisement
Table of Contents
Related Manuals for Lincat UM50
Summary of Contents for Lincat UM50
- Page 1 Installation, Operating and Servicing Instructions Seal Upright Heated Merchandisers UM50, UM50D, UMS50, UMS50D, UMO50, UMO50D, UMSO50, UMSO50D Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 287 ECN 4838...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
TECHNICAL DATA Model Height (mm) Width (mm) Depth (mm) Weight (kg) UM50, UM50D 37.0 UMS50, UMS50D UMO50, UMO50D 55.0 UMS050, UMSO50D CHECK LIST OF ENCLOSURES Warranty card... -
Page 4: Installation And Commissioning
INSTALLATION AND COMMISSIONING This appliance must be earthed. An equipotential bonding terminal is provided to allow cross bonding with other equipment. If replacing the plug connect the terminals as follows: Green and Yellow wire Earth Blue wire Neutral N Brown wire Live Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57) -
Page 5: Operating Instructions
Power Ratings Model Amps UM50, UM50D, UMS50, UMS50D UMO50, UMO50D, UMSO50, UMSO50D 12.6 Fig 2 Assemble the door handle as shown in Fig 2, with the grommet (B) passing through the plate (A) to protect the glass from the bolts (C). - Page 6 Fig 3 Display models Connect the appliance to an electrical supply and switch on the light (B). Turn the thermostat (A) to 5 and wait until the amber neon (C) extinguishes before loading with pre-heated product. Display/Oven models Operate the display as detailed above. To operate the oven, press the switch (E) and turn the thermostat (D) to the required setting.
-
Page 7: Cleaning
Fig 4 CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. The racks, base plate and water tray may be removed for cleaning. To remove the rotary rack, push upwards against the spring loaded pin and carefully rotate outwards from the bottom. -
Page 8: Servicing, Maintenance And Component Replacement
Part Number Description Used on BU72 Door bush CA111 Door catch CM02 Corner moulding CP12 Rotary coupling UM50, UM50D, UMO50, UMO50D EL174 Element – oven & display FE10 Foot UMO50, UMO50D, UMSO50, UMSO50D GL203 Side glass GL510 Door glass HA50... - Page 9 TH106 Thermostat - display TH46 Thermostat - oven UMO50, UMO50D, UMSO50, UMSO50D TH80 Cut out thermostat UMO50, UMO50D, UMSO50, UMSO50D IS 287 ECN 4838 Page 9 of 10...
-
Page 10: Service Information And Guarantee
All available on serial plate • Serial number • Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
