Summary of Contents for Lincat Seal SSG5
- Page 1 INSTALLATION AND USER INSTRUCTIONS REFRIGERATED FOOD DISPLAY BAR ACCESSORIES IS278 ECN2970...
- Page 2 Used for the purposes for which it is intended, and with careful maintenance as outlined in this User Guide, your Lincat product will give years of trouble free use. IMPORTANT INFORMATION Please read all of the safety and operating instructions carefully before using this product.
-
Page 3: Product Specification
CONTENTS Contents Page Product specification………………………………………………….. 3 Back and Self-service Glass…………………………………….……. 4 Wall Brackets……………………………………………………………. 5 Stainless steel lid.………………………………………………………. 6 PRODUCT SPECIFICATION Food Display Bar Self-Service Glass – SSG4, SSG5, SSG6, SSG8, SSG10 Food Display Bar Back Service Glass – BSG4, BSG5, BSG6, BSG8, BSG10 Display Bar Wall Bracket –... -
Page 4: Back And Self-Service Glass
BACK & SELF SERVICE GLASS Pack Contents:- 2 x Perspex Blocks 4 x Plastic Washers 4 x Chromed Screws 2 x Side Glass Panels 4 x Tube Spacers 1 x Main Glass Panel Back Service Glass GL479: Back Service Glass for FDB4 PB68 GL480: Back Service Glass for FDB5 Chromed Screw... -
Page 5: Wall Brackets
WALL BRACKETS (DBWB) This accessory is suitable for both Food Display Bar and Food Preparation Bar. SPACING BETWEEN DBWB HOLE CENTRES: FDB4 - 955mm FDB5 - 1132mm FDB6 - 1309mm FDB8 - 1663mm FDB10 - 2017mm FPB5 - 1160mm FPB7 - 1514mm Hole centres for FDB feet or wall mounting for FPB Hole centres for FPB feet... -
Page 6: Stainless Steel Lid
STAINLESS STEEL LID Pack contents:- 1 x Stainless Steel Lid 1 x Left Hand Hinge 1 x Right Hand Hinge 4 x M5 x 20 Countersunk Head Screws 2 x M4 x 6 Dome head screws Right hand hinge screwed in place HI122 M5 x 20 C/sunk Head Screw Left Hand Hinge...
