FDDI DAS M
®
Q
Connections and LEDs
2 x Sets of Port Status LEDs Show data flow, connection to
1
the ring and power status.
2 x DAS Ports Connect a device using multimode fiber–optic
2
cable.
1 x Optical Bypass Switch Connects an Optical Bypass
3
Switch using a 6–pin Mini–DIN connector.
S
UPER
TACK
R
UICK
EFERENCE
II E
NTERPRISE
(3C81665)
ODULE
G
UIDE
Checking Status Using the LEDs
.
Off indicates data flowing normally through that port.
WRAP
Green indicates that the port has become isolated.
Green when the probe has negotiated a connection to
LINK
the ring.
Green indicates optical power detected in the fiber
SIGNAL
connected to that port.
M
ONITOR
