ASSEMBLY INSTRUCTIONS
7592-47 END TABLE PART LIST
PART
DRAWING
A
B
C
D
United Wood Products, Inc. Customer Service Contact Information:
Toll Free Phone Number: 1-800-458-7212
Email: consumercare@ufifurniture.com
Website: www.unitedfurnitureindustries.com
PLEASE NOTE: With use, screw may become loose & must be tightened periodically.
DESCRIPTION
QTY
TABLE TOP
MOUNTING PLATE
V-LEGS
STRETCHERS
COMPLETED END TABLE
ASSEMBLY
Page 1 of 3
PART
DRAWING
H1
1
H2
H3
1
H4
H5
H6
2
H7
NOTE: If needed, only part H1 - H7 are available for
2
replacement.
ITEM # 7592-47
END TABLE
DESCRIPTION
LONG BOLT (Ø1/4'' * 4'')
SHORT BOLT (Ø1/4'' * 1-1/8'')
SPRING WASHER (Ø1/4'')
FLAT WASHER (Ø1/4'')
ALLEN KEY (M4)
SPANNER
ADJUSTABLE LEVELER
MADE IN VIET NAM
7592-47 END TABLE
QTY
4
12
16
16
1
1
4
