Gateway MX6440 Setup Manual

FRONT
Speaker
Battery Indicator
Power Indicator
S-video
LEFT
Ventilation fan
(optional)
Caution: Do not block
Kensington™ lock slot
1
INSTALL THE BATTERY.
With the label side down, slide the battery into the
battery compartment until it clicks. Then lock it in place.
3
CONNECT TO THE INTERNET. (optional)
Connect the phone cord (included) to the
modem jack ( ) if using dialup Internet access.
Or connect your Ethernet ( ) or USB ( ) cable
(not included) if using high-speed access.
LCD panel release latch
Speaker
Headphone jack
Microphone jack
Optical Drive
BACK
Power connector
RIGHT
USB ports
IEEE 1394 port
PC Card slot
Memory card reader
2
CONNECT TO AC POWER.
Leave the AC adapter plugged in for at least three
hours the first time, so the battery will fully charge.
4
START THE NOTEBOOK.
Press the power button, then follow the on-screen instructions to
complete Windows setup.
Monitor port
Modem jack
Ethernet jack
USB ports
