- Page 1 User Guide...
- Page 2 • It is recommended that the installation of the device be carried out by professional personnel. Kopilot ChildCare is a device that alerts a vehicle's driver to inspect a vehicle for unintentionally le passengers or children. Once the driver inspects the vehicle and touches “verified for children”, the system acknowledges the inspection.
-
Page 3: Table Of Contents
So ware Settings Regional configurations and settings Advanced configuration and settings Operation and use Normal Use What to do if my inspection is delayed? What to do if the alarm is triggered? Care and maintenance of your Kopilot Childcare Troubleshooting Help... -
Page 4: What Is Kopilot Childcare
/ How does it work? Kopilot ChildCare comprises a device to be installed on the rear panel of a bus cabin or in the passenger’s door of van style vehicles. A er the driver completes the transportation, the driver must walk toward the rear of the vehicle inspecting for passengers who may still be on-board. -
Page 5: Benefits And Advantages
We care for people and specially the most vulnerable to escape of this situation. One device that fits all. We designed Kopilot ChildCare to work in most of the current vehicle’s series and models. You don’t need to buy di erent devices. -
Page 6: Parts And Accesories
/ Parts and accesories Module • Alarms the driver to inspect the vehicle • Only visible element in vehicle’s cabin • Must be installed in the rear side • Works on +12V or +24V vehicles. • Easy to setup. Just choose your Region •... -
Page 7: Specifications
/ Specifications Type of vehicles Vehicles with +12V or +24V Batteries. Type of alarm Audible 85dB in cabin. Inspection delay window 1 - 255 seconds. So ware configurable. Non-contact button Yes. 0.5 - 0.75 inch. Inputs Input 1: Engine Start or Alternator. Input 2: User configurable Input 3: User configurable Voltage: 0V to + Battery. -
Page 8: Installation
/ Installation Warning: Despite we designed Kopilot ChildCare to be easily install, it is highly recommended that this installation must only be pe ormed by professional or instructed personnel. An electrical vehicular technician or similar might be qualified to pe orm the task. -
Page 9: Installation Of Module
/ Installation of module Selection of installation place: It is recommended to install in a dry place protected of the rain, leakage or any other fluid. Install in the upper location where only a responsible person could access the device. Keel away of hot places as exhaust or any other. -
Page 10: Wire Harness Installation
Extend the cable through a safe route. As a guide the lights dome of the cabin has a route to the front of the vehicle that could be used. Kopilot Engine Childcare... - Page 11 Make the electrical connections: Black Battery Yellow Alternator Peel o around 3 feet of cable cover from the (3) wire harness end. Locate the red cable and use the electrical connector (4) to attach it to the fuse holder (5) cable. Use the other end of the fuse holder (5) and crimp the ring terminal (6).
-
Page 12: So Ware Settings
Please visit www.drivekopilot.com/childcare to download the newest version of the so ware. Open the Kopilot App. If prompted to update the so ware version, click Yes. The So ware will update to the latest version. Plug in a USB C cable to computer and the device. If prompted to update the firmware version, click Yes. -
Page 13: Regional Configurations And Settings
To download the electrical schematic to apply any Regional Configuration, please visit www.drivekopilot.com/childcare to download the recommended electrical connections required in your region. You can also choose a Country and a Region in the Kopilot App and press the button “See Connections” Kopilot Childcare... -
Page 14: Advanced Configuration And Settings
GPS system and the Kopilot ChildCare. / Operation and Use / Normal Use Kopilot ChildCare is simple and friendly to use. Turn on the engine Drive and / or transport the passengers Turn o the engine Inspect the vehicle for le passenger inside Wave your hand close to the module until you hear a beep. -
Page 15: What To Do If My Inspection Is Delayed
/ What to do if the alarm is triggered? An alarm is triggered when the inspection is not acknowledged in the Kopilot ChildCare. To deactivate the alarm, please wave your hand in Kopilot ChildCare or follow Normal Use in page 14. / Care and... -
Page 16: Troubleshooting
Contact Customer Care Center. My device cannot communicate with the Kopilot App Check the USB C cable for broken parts. Grant access to Kopilot App in your computer to the USB ports. Download the latest so ware www.drivekopilot.com/customercenter/ Check if the device is powered. The LED must be Green or Yellow. -
Page 17: Help
A connected light (or similar) to output 2 or output 3 does not turn on when triggered Use the Kopilot App to apply a Regional or Advanced settings. Please read Regional configurations and Settings and Advanced configurations and settings in pages 13 and 14. - Page 18 All rights reserved, DST 2021 Designed by: DST America LLC 5401 West Kennedy Boulevard Suite 100 33609-2457 For more information visit: Tampa, FL www.drivekopilot.com/childcare...
