GGM GUS-U Series Quick Start Manual

SPEED CONTROL UNIT - GUS
60
30
2-Φ4.5
Confirmation when
the product is handed over
- Confirm that the delivered product is the product you ordered.
- If a different product is installed, it will create the risk of injury or fire.
- Contact a nearby retail store if you were delivered an insufficient
number of products or if a damaged product wasdelivered.
1) CONTROLLER
2) One Extension cable (0.5m)
3) External operation cable (0.5m)
4) User's manual (this manual)
5) Optional (extension cable)
Item name
KE-05
KE-10
KE-15
KE-20
Panel process drawing
H-4
10
------------------- one
one
-------------------
------------------- one
one
-------------------
length of extension cable
0.5m
1m
1.5m
2m
Attachment
104
86
3
Property &
Model name
Rated voltage and
power frequency
Operating
voltage range
Applied motor
output
Speed control
range
Speed regulation
Speed setting
Operating
temperature range
Storage
temperature range
Operating humidity
range
① Indicates the current rotation speed (r/min).
② The motor speed can be controlled simply by connecting the
motor and the control unit with the exclusive connector and
connecting the AC terminal to the power source.
③ You can increase the space between the motor and the control
unit by up to 2M and control the speed by using the optional
extension cable for the connector.
④ You can control the speed simply by using the front dial.
- Variable speed range 50Hz : 100 ~ 1430 r/min,
⑤ Various operation modes can be set through the parameter
setting.
GUS-U-□
Single-phase AC110V
Single-phase AC
50/60Hz
Single-phase AC115V
50/60Hz
±10%(in comparison to the rated voltage)
INDUCTION : 6 ~ 180W
REVERSIBLE : 6 ~ 180W
60Hz : 100~1730rpm
50Hz : 100~1430rpm
±5%(Standard value)
Set according tothe volume
-10~40℃
-20~60℃
less than 85% (in an environment with no
dew condensation)
60Hz : 100 ~ 1730 r/min
GUS-C-□
220~240V
50/60Hz
