LAKE 72''
DINING
x4
#8022
PARTS
& HARDWARE
x1
WWW.BLUDOT.COM
All manuals and user guides at all-guides.com
TABLE
ASSEMBLY NOTES
x4
#5005
x8
x6
#3001
#4011
x2
x2
Insert cylindrical
dowel nut into stretcher
rails and attach to leg
frames using allen bolts,
lock washers, and
washers. Insert magnetic
brass covers once
everything has been
tightened down.
x8
#3007
x8
#8023
x1
#9015
1
ASSEMBLE
UPSIDE DOWN
x8
x8
x8
3007
3001
1062
LAKE 72'' DINING TABLE rev02 - PAGE 1 OF 2
x1
x4
x8
9015
8022
8023
x4
5005
