GU Electronic MB-PAS-190502 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
BENZ_W204(2010)-PAS-DC3
- MODEL : MB-PAS-190502
- DATE : 2021.08.17

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB-PAS-190502 and is the answer not in the manual?

Questions and answers

Related Manuals for GU Electronic MB-PAS-190502

Summary of Contents for GU Electronic MB-PAS-190502

  • Page 1 BENZ_W204(2010)-PAS-DC3 - MODEL : MB-PAS-190502 - DATE : 2021.08.17...
  • Page 2 Index 1. Main Spec 2. Block Diagram 3. Dimension 4. External Appearance 5. Connector Pin Assignment 6. Product Composition 7. DIP S/W Setting 8. I-DRIVE Control 9. OSD(On Screen Display) Control 10. Install Manual 11. Q & A GU Electronic...
  • Page 3 - Input Power : 8VDC ~ 24VDC - Consumption Power : 12Watt, Max 4. Switch Input mode - Possible to select CAR model while switching mode by DIP S/W - By button on the Commander in the car via CAN GU Electronic...

  • Page 4: Block Diagram

    2. Block Diagram INTERFACE COMMAND EEPROM SYSTEM RECEIVER LVDS LVDS Scaler LVDS DIGITAL RGB LVDS RELAY (PIP) LVDS RGB+Sync FRONT CAMERA COMPOSITE REAR CAMERA REAR CAMERA POWER TFT-LCD LVDS GU Electronic...
  • Page 5 3. Dimension 151mm * 83mm * 22mm 151mm 22mm 83mm * This can change under manufacturer’s circumstance GU Electronic...

  • Page 6: External Appearance

    4. External Appearance PROGRAM IMAGE DIP S/W POWER/CAN NAVI REAR LVDS-IN LVDS-OUT Digital FRONT GU Electronic...
  • Page 7 4. External Appearance PROGRAM DIP S/W IMAGE POWER/CAN NAVI REAR LVDS-IN LVDS-OUT Digital FRONT GU Electronic...

  • Page 8: Connector Pin Assignment

    11. N.C ④ SYNC (White) 4. N.C 12. Rear-VCC (Red) ⑤ GND (Black) 5. CAN1-L (Green) 13. N.C ⑥ DVB-T-IR 6. CAN1-H (Orange) 14. N.C ⑦ DVD-IR 7. CAN2-L (Blue) 15. GND (Black) 8. CAN2-H (Red) 16. GND (Black) GU Electronic...

  • Page 9: Product Composition

    6. Product Composition LVDS Cable 1 EA Interface 1 EA RGB NAVI Cable 1 EA Power Cable 1 EA GU Electronic...
  • Page 10 6. Product Composition * CarPlay Set Sales(option) – KPLAY AUX Cable 1 EA Interface 1 EA Power Cable 1 EA HDMI Cable 1 EA Bluetooth / Wifi Antenna 2EA Microphone 1 EA GU Electronic...
  • Page 11 6. Product Composition * CarPlay(NV17) Set Sales(option) AUX Cable 1 EA CarPlay Main 1 EA Power Cable 1 EA HDMI Cable 1 EA Microphone 1 EA GU Electronic...

  • Page 12: Dip S/W Setting

    ON : Not Used DVD(AV2) OFF : Used 5.8”Model ON : Used CAN IN/OUT OFF : Not Used CAR type SEL Right Picture 2015year SL63 AMG 7.0”SplitView * To use CarPlay, be sure to turn down Dip-sw 5. GU Electronic...
  • Page 13 8. I-DRIVE Control Mode Change Long press to mode change NAVI GU Electronic...
  • Page 14 ⑤ Move UI Right ⑤ ① ④ ③ - DVB-T UI off operation status ② Short press to channel Up ③ Short press to channel Down ② Long press to SCAN DVB-T UI -> on/off selection to OSD MENU GU Electronic...
  • Page 15 - DVB-T UI on operation status ① Long press to DVB-T UI on ⑤ ① Short press to Selection ① ④ ④ Move UI Left ⑤ Move UI Right ③ DVD UI -> on/off selection to OSD MENU GU Electronic...
  • Page 16 ⑤ if Carplay, Track up if Android auto, Moving right ⑥ Moving up ⑦ Moving down ⑧ Long Press : Mode Change Short Press : Back ⑨ Long Press : OSD menu on Short Press : Siri call GU Electronic...
  • Page 17 Increase selected value RIGHT First->Second->Third Menu move Third Menu에서 Item down Increase selected value DOWN Item down Decrease selected value LEFT Third->Second->First Menu move Third Menu에서 Item up Decrease selected value Mode State First Menu Second Menu Third Menu GU Electronic...
  • Page 18 First Menu Second Menu Third Menu Description DIGTAL-INAVI NAVI-RGB Setting the Connected NAVI Model ELT_DVBT20 DVB-T(DMB) Setting the Connected DVB-T Model Config ELT_980XU Slim Setting the Connected DVD Model Reset Execute Reset to default value of Config menu GU Electronic...
  • Page 19 “ON" button in SteeringWheel Btn the menu Do not use features. DVB-T device control UI output function UI DVB-T (DMB) Disable feature DVD device control UI output function UI DVD Disable feature Reset Execute Option Menu all Reset GU Electronic...
  • Page 20 9. OSD(On Screen Display) Control OSD Option -> FrontCam-RcvOpt Front Camera Auto Mode 0 second = FrontCam-RcvOpt menu OFF 1~30 second = FrontCam-RcvOpt menu ON & time control NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) AV2(DVD) AV2(DVD) Select time of display 1~30 second GU Electronic...
  • Page 21 Adjust the value of contrast Saturation Adjust the value of Saturation Image Adjust the value of Hue Sharpness Adjust the value of Sharpness Reset Excute Option Menu all Reset << Brightness >> << Contrast >> << Saturation >> GU Electronic...
  • Page 22 Output screen horizontal Horizontal movement Output screen vertical Vertical movement Scale X Up Reduce / increase output screen width Screen Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset GU Electronic...
  • Page 23 Show parking line Line Display Do not show parking lines Warnings Lang Set warning text language Parking Moving a parking line Horizontal horizontally Vertical Moving a parking line vertically Transparency Parking line transparency Reset Parking menu all reset GU Electronic...
  • Page 24 9. OSD(On Screen Display) Control OSD Parking – OPS Display On / Off OPS ON Screen OPS OFF Screen OSD Parking – Guide line On / Off Parking Line ON Screen Parking Line OFF Screen GU Electronic...
  • Page 25 9. OSD(On Screen Display) Control OSD Parking – Change warning language GU Electronic...
  • Page 26 Keypad in Horizontal / Vertical menu ※ Pressing this Horizontal / Vertical menu, The OSD screen automatically disappears. Please adjust from the parking line Screen. MENU DOWN Press “UP” button Press “MENU” button Press “SEL” button Press “DOWN” button GU Electronic...
  • Page 27 Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift OSD Menu Display Time (in value Display Time seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute Initialize OSD settings GU Electronic...
  • Page 28 (Check for future upgrades) Last Source : FDSYOOKRX-180209 Software Version Software Month Software Year Special Version National : CN=CHINA, KR=KOREA, JP=JAPAN, US=United States Hardware Version PIP model : S3=Sync3, PP=PIP, LV=LVDS Motor model : FD=FORD, BM=BMW, BE=BENZ, MA=MASERATI, LX:LEXUS GU Electronic...
  • Page 29 10. Install Manual 1. Installation Navigation Connection DVD-IR DVBT-IR *Analog navigation SYNC Analog RGB BLUE GREEN KD-900 *Digital navigation Roik, Qroi Analog Navigation and Digital Navigation cannot be used together. GU Electronic...
  • Page 30 10. Install Manual 2. Installation DVB-T Remote Control Connection ① or ② 선택1 DVD IR DVB-T IR SYNC BLUE GREEN 선택2 DVB-T-IR GU Electronic...
  • Page 31 10. Install Manual 3. Installation DVD Remote Control Connection DVD IR DVB-T IR SYNC BLUE GREEN DHA-S690 DVD-IR GU Electronic...
  • Page 32 REAR-POWER (Red) 13. N.C Rear-Power (Red) 11. N.C 10. CAN3-H (Violet) 9. CAN3-L (White) 8. CAN2-H (Red) 7. CAN2-L (Blue) 6. CAN1-H (Orange) 5. CAN1-L (Green) 4. N.C +12V Rear-Camera Detect (Brown) 2. ACC (Red) 1. ACC (Red) GU Electronic...
  • Page 33 10. Install Manual 5. Installation LVDS connection Head Unit SCREEN GU Electronic...
  • Page 34 Push the lock to Remove genuine White disconnect the connector connector Attach the connector with care in the direction of the Attach the connector arrow with care in the direction of the arrow ※ Be sure to note the arrows ！ GU Electronic...
  • Page 35 14. N.C 13. N.C 12. Rear-Power (Red) 11. N.C 10. CAN3-H (Violet) 9. CAN3-L (White) 8. CAN2-H (Red) 7. CAN2-L (Blue) 6. CAN1-H (Orange) 5. CAN1-L (Green) 4. N.C 3. Rear-Camera Detect (Brown) 2. ACC (Red) 1. ACC (Red) GU Electronic...
  • Page 36 10. Install Manual 8. Installation CarPlay - KPLAY * When installing CarPlay, set it to OSD MENU-OPTION-NAV COM-KPLAY. Only iPhone Wireless connection Iphone Smartphone (Android / iphone) Cable connection Microphone 3.5pie aux cable Screen GU Electronic...
  • Page 37 10. Install Manual 9. Installation CarPlay – NV17 3.5pie aux cable * When installing CarPlay, set it to OSD MENU-OPTION-NAV COM-NV17. Iphone Screen Screen Microphone Screen GU Electronic...
  • Page 38 A : LVDS cable itself is bad or bad contact. 3. If you find any symptoms with these symptoms, please contact your distributor. How to distinguish NTG4.5 / NTG5.0 BENZ_W204(2010) PAS DC3 product supports only NTG4.5 model NTG4.5 NTG5.0 GU Electronic...
