- Page 1 Instruction Manual Audi 4G HDMI for AUDI, PORCSHE, Volkswagen...
-
Page 2: Table Of Contents
INDEX Specifications Main Spec. ------------------------------------ Diagram --------------------------------------- Components ---------------------------------- Exterior ---------------------------------------- Settings Dip Switch ------------------------------------- Touch Control --------------------------------- Original button ------------------------------- Key board ------------------------------------- OSD Menu ------------------------------------ Installation Diagram --------------------------------------- CAN Connection ------------------------------ Caution ---------------------------------------- GU Electronic... -
Page 3: Specifications
- Possible to select CAR model while switching mode by DIP S/W - By button on the Commander in the car via CAN 2. Features - Easy installation - Possible to use the OEM touch screen to control the external devices (PCM4.0) - OEM type’s guide line GU Electronic... -
Page 4: Diagram
Specification 3. Diagram INTERFACE Capacitive EEPROM Touch NAVIGATION SYSTEM Scaler CVBS1 CVBS2 COMPOSITE LVDS RELAY FRONT CAMERA REAR CAMERA COMMAND SYSTEM LVDS TFT-LCD GU Electronic... -
Page 5: Components
Specification 4. Components GU Electronic... -
Page 6: Exterior
Specification 5. Exterior Touch Connect ① ② ③ ④ ① ② ③ ④ ⑤ ⑥ ⑦ 1. Y- 2. X- 3. Y+ 4. X+ GU Electronic... -
Page 7: Settings
Audi A3 5.8” Audi A3 7” Audi A3 7” Audi A6 8” (OPS Function ON) (OPS Function OFF) (OPS Function ON) (OPS Function OFF) Audi A4 /Q7 Audi Q2 Audi A4 /Q7 (OPS Function ON) (OPS Function OFF) GU Electronic... -
Page 8: Touch Control
Touch OEM screen in any mode more than Touch the “+” correctly 7sec. For calibration (This function can be activated only one time after switching mode) - DVB-T/DVD Control Press Touch (Anywhere) Press Icon ※ Refer Icon : P. 13 GU Electronic... -
Page 9: Original Button
Settings 3. Original button (VOLKSWAGEN Gof7, Polo) 5.8” MONITOR 8.0” MONITOR Steering wheel - 1 Steering wheel - 2 (Mode change) (Mode change) ※ You can choose the Steering wheel type from the OSD Menu (P.16) GU Electronic... - Page 10 Steering wheel - 1 Steering wheel - 2 (Mode change) (Mode change) ※ It is necessary to connect MMI wire / CAN wire to use the original button ※ You can choose the Steering wheel type from the OSD Menu (P.16) GU Electronic...
- Page 11 Steering wheel - 1 Steering wheel - 2 (Mode change) (Mode change) ※ It is necessary to connect CAN wire to use the original button ※ You can choose the Steering wheel type from the OSD Menu (p, 16) GU Electronic...
- Page 12 ※ Macan Steering wheel ‘Mode’ button : Switching mode ※ You can setting for Steering wheel button (switching mode) from OSD MENU (p, 16) ※ You can setting for Steering wheel button (DVB-T Channel up/down) from OSD MENU (p, 16) GU Electronic...
- Page 13 [Play/Pause] [DISC UP] [stop] [DISC DOWN] [Audio] [Play next [FR] chapter] [Play previous [FF] chapter] ※ To use this function, It is necessary to offer the remote IR code to manufacturer or setting OSD IR – Ctrl（P. 22） GU Electronic...
-
Page 14: Key Board
Config - NAVI-RGB : Setup for the type of RGB Config - DVB-T(DMB) : Setup for the type of DVB-T(DMB) Config - DVD : Setup for the type of DVD Config - HDMI : Setup for the type of HDMI Reset : Reset all value GU Electronic... - Page 15 ExtDevice - External rear camera OEM - Original camera FrontCam-Power : Setup for Front VCC wire in power cable • ON - +12V out always (current consumption : 200mA) AUTO - +12V out in rear mode only (200mA) OFF - Power OFF GU Electronic...
- Page 16 AUDI: ON- MODE or NAV OFF- OFF VOLKSWAGEN: ON - MUTE or DOWN OFF - OFF PORSCHE: ON - MODE OFF- OFF SteeringChannel : Setting for Steering wheel button (DVB-T Channel Up/Down) • PORSCHE: ON - Roller OFF- OFF GU Electronic...
- Page 17 Settings 5. OSD Menu ※ Press “MENU” button on Key board Option Camera : AV3 • On – Display AV3 Off – Off Reset: Initialization • GU Electronic...
- Page 18 MENU Screen NAVI Config Horizontal Vertical Option Scale X Up Image Scale X Down Screen Scale X Up Parking - DVD, DVBT, NAVI-AV, REAR, FRONT Image MENU IMAGE Rear Config Brightness Option Contrast Image Saturation Screen Parking Sharpness GU Electronic...
- Page 19 AUDI (OPS Function OFF) GOLF 7 , POLO PORSCHE ※ The position of PDC will be changed according to the parking guide line (PORSCHE) ※ PDC (OPS) for Audi car is set by Dip sw - Refer to P. 7 GU Electronic...
- Page 20 - Adjust the position of Parking guide line Possible to adjust the position of line by Keypad in Horizontal / Vertical menu ※ Pressing this Horizontal / Vertical menu, The OSD screen automatically disappears. Please adjust from the parking line Screen. Left Right Down GU Electronic...
- Page 21 • OSD – Transparency • OSD – Language : Setting language of ODS menu • - IR – Ctrl (p.22) - Utility MENU Utility Factory Reset Execute Cancel IR-Ctrl Version AD4P52KRX - 160509 Utility Utilityy– INTERFACE SOFTWARE • GU Electronic...
- Page 22 ③ Press a button on the remote control separately of DVD/DTV then the IR code will be appeared on “New code” menu. Press the same button one more time to confirm the IR code. (Cfm code = confirm code) GU Electronic...
-
Page 23: Installation Diagram
Installation 1. Installation Diagram Wireless Mirroring [Rear Camera] GU Electronic... - Page 24 Installation 2. CAN connect ① Please remove the indicated grey connector from the OEM plug & plug connector ② Please connect in the direction of the protruding portion GU Electronic...
-
Page 25: Can Connection
LVDS cable must be connected correctly according to the manual • Insulate the end of wire by using electrical tape • The installation should be done by expert • GU electronic does not take any responsibility for any problem • caused by wrong installation... - Page 26 GU Electronic For your better driving...
