MB2019_NTG6.0-D
- MODEL : MB-NTG-191002
- DATE : 2020.08.23

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB-NTG-191002 and is the answer not in the manual?

Questions and answers

Related Manuals for GU Electronic MB-NTG-191002

Summary of Contents for GU Electronic MB-NTG-191002

  • Page 1 MB2019_NTG6.0-D - MODEL : MB-NTG-191002 - DATE : 2020.08.23...
  • Page 2 1. Main Spec 2. Block Diagram 3. Dimension 4. External Appearance 5. Connector Pin Assignment 6. Product Composition 7. DIP S/W Setting 8. Mode Change 9. Touch Control 10. OSD(On Screen Display) Control 11. Install Manual 12. Q & A GU Electronic...
  • Page 3 - Input Power : 8VDC ~ 24VDC - Consumption Power : 12Watt, Max 4. Switch Input mode - Possible to select CAR model while switching mode by DIP S/W - By button on the Commander in the car via CAN GU Electronic...

  • Page 4: Block Diagram

    2. Block Diagram INTERFACE COMMAND EEPROM SYSTEM RECEIVER LVDS LVDS LVDS LVDS RELAY NAVIGATION LVDS Scaler SYSTEM (PIP) VIDEO COMPOSITE TFT-LCD LVDS GU Electronic...
  • Page 5 3. Dimension 151mm * 83mm * 24mm 151 mm 24mm 83mm * This can change under manufacturer’s circumstance GU Electronic...

  • Page 6: External Appearance

    4. External Appearance PROGRAM IMAGE DIP S/W LVDS POWER/CAN TOUCH VIDEO Digital Not use. LVDS GU Electronic...
  • Page 7 4. External Appearance DIP S/W IMAGE PROGRAM LVDS POWER/CAN TOUCH VIDEO Digital Not use. LVDS GU Electronic...

  • Page 8: Connector Pin Assignment

    ③ B DATA (Blue) ③ CAN-HIGH (Orange) ④ X+ ④ SYNC (White) ④ CAN-LOW (Green) ⑤ GND (Black) ⑤ CAN-HIGH (Purple) ⑥ DMB IR (Green) ⑥ CAN-LOW (White) ⑦ DVD IR (Orange) ⑦ REAR_DETECT (Brown) ⑧ GND (Black) GU Electronic...

  • Page 9: Product Composition

    6. Product Composition Interface 1 EA Power Cable 1 EA RGB NAVI Cable(7pin) 1 EA Touch convertor Cable(KD-900) 1 EA OSD Board 1 EA LVDS Cable 1 EA GU Electronic...
  • Page 10 6. Product Composition * CarPlay Set Sales(option) – KPLAY AUX Cable 1 EA Interface 1 EA Power Cable 1 EA HDMI Cable 1 EA Bluetooth / Wifi Antenna 2EA Microphone 1 EA GU Electronic...
  • Page 11 6. Product Composition * CarPlay(NV17) Set Sales(option) AUX Cable 1 EA CarPlay Main 1 EA Power Cable 1 EA HDMI Cable 1 EA Microphone 1 EA GU Electronic...
  • Page 12 6. Product Composition * VHQ(Video High Quality Set Sales(option) HDMI Cable 1 EA Interface 1 EA Power Cable 1 EA GU Electronic...
  • Page 13 6. Product Composition * HDMI-TO-DIGITAL Set Sales(option) HDMI Cable 1 EA Interface 1 EA Power Cable 1 EA GU Electronic...

  • Page 14: Dip S/W Setting

    ON : Not Used NAVI GLE 12.3” OFF : Used ON : Not Used DVB-T(AV1) OFF : Used ON : Not Used DVD(AV2) SPRINTER 8.0” OFF : Used Manual transmission SPRINTER 8.0” Automatic transmission CAR type SEL Right Picture A180 7.0” GU Electronic...

  • Page 15: Mode Change

    8. Mode Change A-CLASS 12.3” A-CLASS 8.0” SPRINTER 12.3”/ 8.0” mode change(1 second) GU Electronic...

  • Page 16: Touch Control

    Touch control - Calibration Press and hold for more than 11 seconds on NAVI, DVB-T, DVD screen. (Note that it only works the first time after switching screens) + Touch according to the shape coordinates. OSD menu -> Utility -> Calibration GU Electronic...
  • Page 17 9. Touch Control DVB-T/DVD Control DVB-T Press Icon GU Electronic...
  • Page 18 Press to display when there is no OSD screen. When OSD screen is on, press it to EXIT or OFF. Item Selection, Value Selection Item up Increase selected value DOWN Item down Decrease selected value Mode State First Menu Second Menu Third Menu GU Electronic...
  • Page 19 NAVI-RGB Setting the Connected NAVI Model ELT_DVBT20 DVB-T(DMB) Setting the Connected DVB-T Model ELT_980XU Slim Config Setting the Connected DVD Model AVM VIDEO RearCam Setting the Connected RearCam Model Reset Execute Reset to default value of Config menu GU Electronic...
  • Page 20 FrontCam-Type ExtDevice Equipped with external camera After RearCam shows FrontCam and returns to previous state FrontCam-RcvOpt Disable feature To use the Streeing button You must select the “ON" button in SteeringWheel Btn the menu Do not use features. GU Electronic...
  • Page 21 ScrChg_PS switched to original. Disable feature Mode change is executed when Short the button is pressed briefly. NAV Btn Mode change is executed when Long the button is pressed and held. Reset Execute Option Menu all Reset GU Electronic...
  • Page 22 10. OSD(On Screen Display) Control OSD Option -> FrontCam-RcvOpt Front Camera Auto Mode 0 second = FrontCam-RcvOpt menu OFF 1~30 second = FrontCam-RcvOpt menu ON & time control NAVI NAVI REAR FRONT AV1(DVB-T) AV1(DVB-T) AV2(DVD) AV2(DVD) Select time of display 1~30 second GU Electronic...
  • Page 23 Adjust the value of contrast Saturation Adjust the value of Saturation Image Adjust the value of Hue Sharpness Adjust the value of Sharpness Reset Excute Option Menu all Reset << Brightness >> << Contrast >> << Saturation >> GU Electronic...
  • Page 24 Output screen horizontal Horizontal movement Output screen vertical Vertical movement Scale X Up Reduce / increase output screen width Screen Scale X Down Scale Y Up Reduce / Increase Output Screen Height Scale Y Down Reset Screen menu all reset GU Electronic...
  • Page 25 Third Menu Description Horizontal value OSD Menu Horizontal Shift value Vertical OSD menu vertical Shift OSD Menu Display Time (in value Display Time seconds) value Transparency OSD menu transparency Language OSD menu display language Reset Execute Initialize OSD settings GU Electronic...
  • Page 26 3. Before using IR learning function, select All-Clear to delete existing stored data. 4. Press the remote control button to be used in each ICON once in New Code, press once again in Cfm Code to confirm it is the same and save it. GU Electronic...
  • Page 27 (Check for future upgrades) Last Source : FDSYOOKRX-180209 Software Version Software Month Software Year Special Version National : CN=CHINA, KR=KOREA, JP=JAPAN, US=United States Hardware Version PIP model : S3=Sync3, PP=PIP, LV=LVDS Motor model : FD=FORD, BM=BMW, BE=BENZ, MA=MASERATI, LX:LEXUS GU Electronic...
  • Page 28 11. Install Manual 1. Installation Navigation Connection *Digital navigation Roik, Qroi • Select the navigation you want to use from the above items. GU Electronic...
  • Page 29 11. Install Manual 2. Installation DVB-T Remote Control Connection ① or ② 선택1 DVD IR DVB-T IR SYNC BLUE GREEN 선택2 DVB-T-IR • Select the DVB-T you want to use from the above items. GU Electronic...
  • Page 30 11. Install Manual 3. Installation DVD Remote Control Connection` DVD IR DVB-T IR SYNC BLUE GREEN DHA-S690 DVD-IR • Select the DVD you want to use from the above items. GU Electronic...
  • Page 31 11. Install Manual 4. Installation Front Camera Connection • Refer to page. 10. OSD (On Screen Display) Control -> OSD option -> FrontCam-RcvOpt. • When AV mode is activated, the Front camera can be viewed using the Mode change button.. GU Electronic...
  • Page 32 REAR-POWER (Red) 8. GND (Black) 7. REAR-DETECT (Brown) 6. CAN-LOW (White) 5. CAN-HIGH (Purple) +12V 4. CAN-LOW (Green) 3. CAN-HIGH (Orange) 2. REAR_POWER (Red) 1. BATTERY (Yellow) • Select the RearCam you want to use from the above items. GU Electronic...
  • Page 33 6. Installation VHQ(Video High Quality) Module - Front Camera Connection • Refer to page. 10. OSD (On Screen Display) Control -> OSD option -> FrontCam-RcvOpt. • When AV mode is activated, the Front camera can be viewed using the Mode change button.. GU Electronic...
  • Page 34 REAR-POWER (Red) 8. GND (Black) 7. REAR-DETECT (Brown) 6. CAN-LOW (White) 5. CAN-HIGH (Purple) +12V 4. CAN-LOW (Green) 3. CAN-HIGH (Orange) 2. REAR_POWER (Red) 1. BATTERY (Yellow) • Select the RearCam you want to use from the above items. GU Electronic...
  • Page 35 11. Install Manual 8. Installation HDMI-TO-DIGITAL Connection • Select the navigation you want to use from the above items. GU Electronic...
  • Page 36 11. Install Manual 9. Installation LVDS connection A-Class HeadUnit Position - Driver door GLE HeadUnit Position Under the passenger seat GU Electronic...
  • Page 37 11. Install Manual 10. Jack-by-Jack power cable Structure change - Interface power BATTERY -> ACC change Cutting GU Electronic...
  • Page 38 11. Install Manual 11. Installation CarPlay - KPLAY * When installing CarPlay, set it to OSD MENU-OPTION-NAV COM-KPLAY. Only iPhone Wireless connection Iphone Smartphone (Android / iphone) Cable connection Microphone 3.5pie aux cable Screen GU Electronic...
  • Page 39 11. Install Manual 12. Installation CarPlay – NV17 * When installing CarPlay, set it to OSD MENU-OPTION-NAV COM-NV17. 3.5pie aux cable Iphone Screen Screen Microphone Screen GU Electronic...
  • Page 40 2. LVDS cable must be connected correctly according to the manual 3. Insulate the end of wire by using electrical tape 4. The installation should be done by expert 5. GU electronic does not take any responsibility for any problem caused by wrong installation GU Electronic...
