Replacing the Gateway 200ARC
Keyboard
This package includes a replacement keyboard for your Gateway 200ARC
notebook and these printed instructions.

Tools you need

You need a small Phillips and a small flat-blade screwdriver to replace the
keyboard.

Preventing static electricity discharge

The components inside your notebook are extremely sensitive to static
electricity, also known as electrostatic discharge (ESD).
Warning
Warning
Before replacing the keyboard, follow these guidelines:
Turn off your notebook.
Wear a grounding wrist strap (available at most electronics stores) and
attach it to a bare metal part of your workbench or other grounded
connection.
Warning
Touch a bare metal surface on your workbench or other grounded object.
ESD can permanently damage electrostatic
discharge-sensitive components in your notebook.
Prevent ESD damage by following ESD guidelines every
time you replace the keyboard.
To avoid exposure to dangerous electrical voltages and
moving parts, turn off your notebook and unplug the power
cord and modem and network cables and remove the
battery before opening the case.
To prevent risk of electric shock, do not insert any object
into the vent holes of the notebook.
www.gateway.com
Replacing the Gateway 200ARC Keyboard
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 200ARC and is the answer not in the manual?

Questions and answers

Summary of Contents for Gateway 200ARC

  • Page 1: Preventing Static Electricity Discharge

    Replacing the Gateway 200ARC Keyboard This package includes a replacement keyboard for your Gateway 200ARC notebook and these printed instructions. Tools you need You need a small Phillips and a small flat-blade screwdriver to replace the keyboard. Preventing static electricity discharge The components inside your notebook are extremely sensitive to static electricity, also known as electrostatic discharge (ESD).
  • Page 2: Removing The Keyboard

    Follow the instructions under “Preventing static electricity discharge” on page 1. Turn off your notebook. Remove any PC Cards. Disconnect the AC adapter and modem and network cables. Disconnect the optional port replicator. Turn your notebook over so the bottom is facing up. Remove the battery. www.gateway.com...
  • Page 3 With a small Phillips screwdriver, remove the two keyboard screws and put them in a safe place. Turn your notebook over so the top is facing up. Open the LCD panel to the normal viewing position. Replacing the Gateway 200ARC Keyboard Screws www.gateway.com...
  • Page 4 The keyboard will spring up slightly. While lifting the front of the keyboard, slide the keyboard toward you to release the five tabs at the back of the keyboard. Tabs www.gateway.com...
  • Page 5 Replacing the Gateway 200ARC Keyboard Lift the back edge of the keyboard, then slowly rotate it toward you so it lies keys-down on top of your notebook. Be careful not to damage the LCD panel. www.gateway.com...
  • Page 6: Installing The Keyboard

    Slide the end of the keyboard cable into the keyboard connector. Using two fingers, press backward on the keyboard connector clamp. This locks the keyboard cable into the keyboard connector. Rotate the keyboard toward the LCD panel until the keyboard is almost face-up. www.gateway.com...
  • Page 7 Gently press the front of the keyboard down until the spring loaded tabs click into place and the keyboard is flat all the way across. The keyboard should easily fall into place. Be careful not to damage the LCD panel. Close the LCD panel. www.gateway.com Replacing the Gateway 200ARC Keyboard...
  • Page 8: Technical Support

    See your user’s guide for important safety, regulatory, and legal information. © 2003 Gateway, Inc. All rights reserved. Gateway, Gateway Country, the Gateway stylized logo, and the black-and-white spot design are trademarks or registered trademarks of Gateway, Inc. in the United States and other countries.
