Summary of Contents for Furniture of America CM7383Q
- Page 4 2. Align the headboard posts (#2) to the holes along the side of the headboard (#1). Insert a bolt assembly into each hole and secure using the Allen wrench (#F). Apply a wood button (#E) onto each. 1. Prepare 2 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#D) onto that same bolt (#A).
- Page 5 Hook each end of the side rails (#4) onto the slots along the headboard (#1) and footboard (#3). Insert the threaded ends of the support legs (#6) into the holes along the slats (#5). Turn right to tighten. Adjust according to the ground level.
- Page 6 Align each end of the slats (#5) to the holes along the side rails (#4), then insert a screw (#G) into each end. Secure. ASSEMBLY IS COMPLETED...
- Page 10 2. Align the headboard posts (#2) to the holes along the side of the headboard (#1). Insert a bolt assembly into each hole and secure using the Allen wrench (#F). Apply a wood button (#E) onto each. 1. Prepare 2 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#D) onto that same bolt (#A).
- Page 11 Hook each end of the side rails (#4) onto the slots along the headboard (#1) and footboard (#3). Insert the threaded ends of the support legs (#6) into the holes along the slats (#5). Turn right to tighten. Adjust according to the ground level.
- Page 12 Align each end of the slats (#5) to the holes along the side rails (#4), then insert a screw (#G) into each end. Secure. ASSEMBLY IS COMPLETED...
